User’s Guide
5" Digital Video Baby Monitor With Wi-Fi® Internet Viewing
Models: MBP855CONNECT, MBP855CONNECT-2,
MBP855CONNECT-3, MBP855CONNECT-4
The features described in this User’s Guide are subject to modifications without prior notice.
Welcome...
to your new Motorola Digital Video Baby Monitor!
Thank you for purchasing the Digital Video Baby Monitor. Now you can see
and hear your baby sleeping in another room or you can monitor your older
children in their play room.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola product, you will need to provide a copy
of your dated sales receipt to confirm warranty status. Registration is not
required for warranty coverage.
For product-related questions, please call:
US and Canada 1-888-331-3383
Email: support@motorolahome.com
On the Web: www.motorolahome.com/support
This User's Guide provides you with all the information you need to get the
most from your product.
Before you use the Digital Video Baby Monitor, we recommend that you
fully charge the battery that is pre-installed in the Parent Unit, so that it
continues to work if you disconnect it from the power supply. Please read
the Safety Instructions on pages 8 - 10 before you install the Units.
Got everything?
• 1 x Parent Unit
• 1 x Baby Unit (Camera)
• 1 x Power adapter for Parent Unit
• 1 x Power adapter for Baby Unit
• 1 x Stargrip
In multi-camera packs, you will find one or more additional Camera Units
with power adapters.
Overview of the Parent Unit
1
2
3
4
RESET
5
6
12 131415
16
1
1. Display (LCD screen)
2. VIDEO ON/OFF button V
ess to turn the LCD screen
Pr
ON/ OFF (Note: audio is maintained.)
3. TAL K b ut ton T
Press and hold to speak to your baby
4. RESET button (recessed - use
small pin)
5. UP button +
Normal Mode: Tilt camera Up
Menu Mode: Move Up menu
options
6. DOWN button -
Normal Mode: Tilt camera Down
Menu Mode: Move Down menu
options
7. MENU button M
Press to open / close the Menu
options
8. OK button O
9. Micro USB power adapter outlet
10. LEFT button <
No
rmal Mode: Pan camera Left
Menu Mode: Move Left along menu
options
7
7
8
9
DC 5V
10
11
11. RIGHT button >
Normal Mode: Pan camera Right
Menu Mode: Move Right along
menu options
12. Charging LED:
BLUE when mains power
connected.
13. Parent Unit ON/OFF LED (Green)
14. Audio Level LEDs (Green, Amber,
Red, Red)
15. Volume buttons
Press -/+ to decrease/increase
Volume level on Parent Unit
16. Power b utton 0
Press and Hold to turn the Parent
Unit ON/OFF
17. Microphone
18. Stand
19. Speaker
18
19
Parent Unit menu icons
V
Signal Level Indication (5 Levels)
Night Vision Mode (Video also changes to Black/White)
T
Talk Mo de On
Volume Level Indication (4 Levels)
Panning Camera Left
Panning Camera Right
Tilting Camera Up
Tilting Camera Down
Zoom Level Control (1X, 2X)
Brightness Level Control (8 Levels)
Lullaby Control (5 Sound Selections)
Alarm Setting (6h, 4h, 2h, OFF)
On status bar, indicates alarm set, and when flashing, that alarm time has
been reached or missed.
Temperature scale select (oC / oF)
Readings display in BLUE, but turn RED if > 29ºC / 84ºF, or < 14ºC / 57ºF
Displays HH
Displays LL
Camera Control (scan , view , add , delete )
Set Screen Off Timer (Off , 5 min, 30 min, 60 min)
Indicates the screen off timer is set
Volume Level Control (8 Levels + Off)
Indicates volume is off
No Baby Unit detected
View multiple cameras on screen. Available when you have more than 1
Baby Unit (Camera).
o
C / oF if >36oC / 97oF.
o
C / oF if < 1oC / 34oF.
Overview of Your Baby Unit (Camera)
1. Photo Sensor (Night Vision Mode)
2. Camera Lens
3. Infrared LEDs (x 8, for night vision)
4. Power LED (Blue when on)
On when linked to Parent Unit
Flashes when searching for Parent
Unit
5.
Microphone
6. Camera Battery LED
7. POWER ON/OFF switch
8. Temperature Sensor
9. Micro-USB Power Socket
10. PAIR Button
11. Speaker
12. Star Grip or Tripod Mount
13. Antenna
On when AC power is connected to
camera.
Flashes when the battery level of the
camera is low.
Important guidelines for installing your Baby Monitor
• To use your Video Monitor Baby and Parent Units together, you must be able to
establish a radio link between them, and the range will be affected by environmental
conditions.
• Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic doors or
reinforced concrete between the Baby and Parent Unit may block the radio signal.
• The signal strength may also be reduced by other solid structures, like walls, or by
radio or electrical equipment, such as TVs, computers, cordless or mobile phones,
fluorescent lights or dimmer switches.
• Use of other 2.4 GHz products, such as wireless networks (Wi-Fi
Bluetooth™ systems, or microwave ovens, may cause interference with this product,
so keep the Baby Monitor at least 5 feet away from these types of products, or turn
them off if they appear to be causing interference
• If the signal is weak, try moving the Parent and/or the Baby Unit to different positions
in the room(s).
®
routers),
Table of contents
1. Safety Instructions.................................................................................... 8
2. Getting Started....................................................................................... 11
2.1 Baby Unit Power Supply ........................................................................... 11
2.2 Parent Unit Power Supply........................................................................ 12
2.3 Registration (Pairing) ................................................................................ 14
3. Using the Baby Monitor.......................................................................... 15
3.1 Setting Up ................................................................................................. 15
3.2 Pan and Tilt ...............................................................................................15
3.3 Night Vision Mode .................................................................................... 15
3.4 Talk Mode................................................................................................. 15
3.5 Video ON/OFF ........................................................................................ 15
3.6 Temperature Display (HH °C / °F or LL °C / °F) ..................................... 16
4. Parent Unit Menu Options ......................................................................17
4.1 Volume .....................................................................................................17
4.2 Brightness .................................................................................................17
4.3 Lullaby ...................................................................................................... 17
4.4 Zoom ........................................................................................................17
4.5 Alarm ......................................................................................................... 17
4.6 Camera Control .......................................................................................18
4.6.1 Add (pair) a camera .................................................................. 18
4.6.2 View a camera ...........................................................................18
4.6.3 Delete a camera ........................................................................ 19
4.6.4 Scan camera ............................................................................. 19
4.7 Temperature ............................................................................................ 19
4.8 Power Saving Mode ................................................................................. 20
4.9 View multiple cameras on screen ........................................................... 20
5. Wi-Fi® Internet Viewing ......................................................................... 21
5.1 Minimum System Requirements............................................................. 21
5.2 Getting Started - Connecting Devices ....................................................22
5.2.1 Setup ......................................................................................... 22
5.3 User Account and Camera Setup on Android™ Devices...................... 23
5.3.1 Power ON and Connect the Camera...................................... 23
5.3.2 Download Hubble for Motorola Monitors App........................ 23
5.3.3 Run Hubble for Motorola Monitors App on Android™
device ........................................................................................ 23
5.3.4 Add the Camera to your account ............................................. 24
5.4 User Account and Camera Setup on iPhone®/iPad® ............................27
5.4.1 Power ON and Connect the Camera ...................................... 27
6 Table of contents
5.4.2 Download Hubble for Motorola Monitors App ........................27
5.4.3 Run Hubble for Motorola Monitors App on iPhone
5.4.4 Add the Camera to your account............................................. 28
5.5 Camera Functions: ...................................................................................33
5.5.1 Connecting the Camera Unit to power ...................................33
5.5.2 Overview of the Features on Hubble App............................... 33
5.6 Working with PC/Notebook ....................................................................36
5.7 Procedure for Resetting the Camera...................................................... 36
®
/iPad® ...27
6. Disposal of the Device (Environment) ................................................... 37
7. Cleaning ..................................................................................................38
8. Help .........................................................................................................39
9. General Information ............................................................................... 47
10. Technical Specifications .........................................................................52
ENGLISH
Table of contents 7
1. Safety Instructions
WARNING
:
Strangulation Hazard: Children have STRANGLED in cords. Keep this cord out of the reach of children (more than 3ft away). Never use extension cords with AC Adapters. Only use the AC Adapters provided.
8 Safety Instructions
CAMERA SET UP & USE:
• Choose a location for the Baby Unit that will provide the best view of
your baby in their crib.
• Place the Baby Unit on a flat surface, such as a dresser, desk, or shelf
or mount the Unit on a suitable Tripod or Stargrip using the screw
mount on the underside of the stand.
• NEVER place the Baby Unit or cords in the crib or within reach of the
baby (the unit and cords should be more than 3 feet away).
WARNING
This digital video Baby Monitor is compliant with all relevant standards
regarding electromagnetic fields and is, when handled as described in the
User's Guide, safe to use. Therefore, always read the instructions in this User's
Guide carefully before using the device.
• Adult assembly is required. Keep small parts away from children when
assembling.
• This product is not a toy. Do not allow children to play with it.
• This Baby Monitor is not a substitute for responsible adult supervision.
• Keep this User’s Guide for future reference.
• Do not place the Baby Unit or cords in the crib or within reach of the baby
(the unit and cords should be more than 3 feet away)
• Keep the cords out of reach of children.
• Do not cover the Baby Monitor with a towel or blanket.
• Never use extension cords with power adapters. Only use the power
adapters provided.
• Test this monitor and all its functions so that you are familiar with it prior to
actual use.
• Do not use the Baby Monitor near water.
• Do not place the Baby Monitor near a heat source.
• Only use the chargers and power adapters provided. Do not use other
chargers or power adapters as this may damage the device and battery
pack.
ENGLISH
Safety Instructions 9
• Do not touch the plug contacts with sharp or metal objects.
CAUTION
The Parent Unit includes a built-in, lithium-ion rechargeable battery pack, which
is not a user-accessible item. If you think the battery needs replacing, please
contact the helpline. Do not try to replace it yourself.
Risk of explosion if battery is replaced by an unapproved battery type.
Dispose of used batteries according to their instructions.
FCC/IC RF Radiation Exposure Statement Caution: This Transmitter must be
installed to provide a separation distance of at least 20 cm from all persons.
IC Radiation Déclaration d'exposition Attention: Cet émetteur doit être
installé pour fournir une distance de séparation d'au moins 20 cm de toute
personne.
10 Safety Instructions
2. Getting Started
2.1 Baby Unit Power Supply
1. Connect the micro USB plug of the power adapter to the Baby Unit
(camera) and the other end to a suitable electrical outlet.
NOTE
Only use the enclosed Power Adapter (5V DC / 1500mA).
2. Slide the POWER ON/OFF switch to the ON position to turn the Baby Unit
on.
3. Slide the POWER ON/OFF switch to the OFF position to turn the Baby
Unit off.
IMPORTANT
The Baby Unit is able
support of the built-in rechargeable battery (Ni-MH battery
Please charge the unit for at least 16 hours before first time use. The battery is
not a user-accessible item. Please contact the helpline if you think it needs
replacing.
to operate without AC power for up to 3 hours with the
3.6
V, 900mAh).
ENGLISH
Getting Started 11
2.2 Parent Unit Power Supply
IMPORTANT
The Parent Unit is
ion battery 2000mAh, to give up to 5 hours monitor operation), please charge it
for 16 hours before initial use. The battery is not a user-accessible item. Please
contact the helpline if you think it needs replacing.
1.
Connect the micro USB plug of the power adapter to the Parent Unit and
the other end to a suitable electrical outlet. Only use the enclosed
power adapter (5V
2. Press and hold the 0 POWER ON/OFF button for 3 seconds to switch ON
the Parent Unit, if it has not turned on automatically.
3. Once the Baby and Parent Units are switched on, the display on the Parent
Unit will show the color video captured by the Baby Unit. If the baby's room
is dark, the video will display in black and white, with a icon showing,
due to the infra-red illumination by the Baby Unit.
4. If there is no connection or you are out of range, the video display will go
off, a symbol will appear on the screen, and the Parent Unit will beep
repeatedly. Move the Parent Unit closer to the Baby Unit until the link is reestablished.
5. Press and hold the 0 POWER ON/OFF button, until the progress bar
finishes scrolling, to turn OFF the Parent Unit.
NOTE
The battery icon turns RED to indicate the battery is low and the parent
unit will beep every 15 seconds. This alert user that the battery needs to be
charged. The parent unit will take 16 hours to charge fully.
assembled with a built-in rechargeable battery pack (Lithium
DC / 1000mA) with the DC plug.
12 Getting Started
When charging
1. If the Parent Unit is turned OFF with the adapter plugged in, a 2-pin plug
logo will appear on-screen for about 5 seconds, and then a flashing battery
logo will display for 15 seconds. The Blue LED at the top left will light up;
indicating that the adapter is plugged in and charging is continuing.
2. While the power is ON and the adapter is plugged in, the battery icon at
the top right corner of the screen will show that the battery is charging. The
Charging LED at the top left of the Parent Unit will light up blue to indicate
that the adapter is plugged in.
ENGLISH
Getting Started 13
2.3 Registration (Pairing)
___
The Baby Monitor is pre-registered to your Parent Unit. You do not need to
register it again unless the Baby Unit loses its link with the Parent Unit.
To re-register your Baby Unit, or register a new Baby Unit, follow the procedures
below:
1. Press the M button of the Parent Unit and the menu bar will pop up.
2. Press the < LEFT button or > RIGHT button until is highlighted, and
del/ add/ view/ scan
the
3. Press the + UP button or - DOWN button to select
O button to confirm.
4. Camera will pop up, press the + UP button or - DOWN
button to select the desired Camera, and press the O button to start
searching for a camera unit, with "press PAIR on cam" shown.
Note: If a camera is currently paired with the Parent Unit, its camera
location (with a * against it) cannot be selected for a new registration.
5. Press and hold the PAI R button on the underside of the Baby Unit until the
Parent Unit finds the camera, beeps and PAIR OK appears on the screen.
The video from the camera will then appear.
NOTE
If a particular Baby Unit was registered previously, registering this current Baby
Unit again will cancel its old registration.
menu will pop up.
add
, and press the
14 Getting Started
3. Using the Baby Monitor
3.1 Setting Up
• Place the Baby Unit in a convenient location (e.g. on a table) and point the
camera lens towards the area you want to monitor.
• Adjust the angle of the Baby Unit's camera by using the pan and tilt function
(the arrows on the right and left side of the Parent Unit) to move up, down,
left, and right until you are satisfied with the image shown on the Parent Unit
NOTE
Do not place the Baby Unit within the baby's reach! If there is interference with
the picture or sound, try moving the units to different locations, and ensure they
are not close to other electrical equipment.
3.2 Pan and Tilt
The camera can be remotely controlled from the Parent Unit when in a camera
viewing mode.
1. Press the + UP button or - DOWN button on the left side of the Parent
Unit to tilt the camera up or down.
2. Press the < LEFT button or > RIGHT button on the right side of the Parent
Unit to pan the camera left or right.
3.3 Night Vision Mode
The Baby Unit has 8 high-intensity infrared LEDs for picking up clear images in
the dark. When the built-in photo sensor on the top of t he Unit detects a low level
of ambient light, the LEDs will automatically activate and the screen on the
Parent Unit will display in black and white. The icon will be displayed at the
top of the Parent Unit screen.
3.4 Talk Mode
Press and hold the TALK button T on the Par ent Uni t to tal k to you r ba by t hro ugh
the Baby Unit’s loudspeaker. The
Parent Unit screen.
T will be displayed at the top center of the
ENGLISH
Using the Baby Mon itor 15
3.5 Video ON/OFF
V
Press VIDEO On/Off button to turn the LCD screen on or off, while still
leaving the audio monitor on.
3.6 Temperature Display (HH °C / °F or LL °C / °F)
The temperature reading from the temperature sensor at the back of the Baby
Unit will be displayed at the top left of the LCD screen in °C or °F (see 4.7
“Temperature scale” for how to change). The readings will turn RED if the
temperature goes above 29°C / 84°F or below 14°C / 57°F. The reading will
change to HH °C / °F if the temperature goes above 36°C / 97°F. The reading
will change to LL °C / °F if the temperature goes below 1°C / 34°F.
The temperature reading updates about every minute.
16 Using the Baby Monitor
4. Parent Unit Menu Options
4.1 Volume
1. Press the Volume button - or + to adjust the volume level. The icon will
pop up and you can select the desired volume from level 0 - 8. (The default
volume level setting is level 5, and level 0 is OFF .)
4.2 Brightness
1. Press the M button and the menu bar will pop up.
2. Press the < LEFT button or > RIGHT button until is highlighted.
3. Press the + UP button or - DOWN button to select the desired brightness
from level 1 - 8. (The default brightness is level 4.)
4. Press the M button to close the menu bar.
4.3 Lullaby
1. Press the M button and the menu bar will pop up.
2. Press the < LEFT button or > RIGHT button until is highlighted.
3. Press the + UP button or - DOWN button to select from the 5 sounds
available. If a sound is selected, it will repeat continuously until it is
deselected or the TALK button is pressed. (The default setting is lullaby
OFF.)
4. Press the M button to close the menu bar.
4.4 Zoom
1. Press the M button and the menu bar will pop up with highlighted.
1X
OFF
.)
or 2X zoom. (The
6h, 4h
2. Press the + UP button or - DOWN button to select
1X
default setting is
.)
4.5 Alarm
1. Press the M button and the menu bar will pop up.
2. Press the < LEFT button or > RIGHT button until is highlighted.
3. Press the + UP button or - DOWN button to select the alarm time (
2h
). The icon will appear on the upper right of the Parent Unit screen
when alarm is on. (The default setting is Alarm
ENGLISH
,
Parent Unit Menu Options 17
Loading...
