User’s Guide
Digital Video Baby Monitor
Models: MBP621, MBP621-2, MBP621-3, MBP621-4
The features described in this User’s Guide are subject to modifications without prior notice.
Welcome...
to your new Motorola Digital Video Baby Monitor!
Thank you for purchasing the Digital Video Baby Monitor. Now you can view and hear your baby sleeping in another room or you can monitor your older children in their play room.
Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage.
For product-related questions, please call:
US and Canada 1-888-331-3383
Email: support@motorolamonintors.com
This User's Guide provides you with all the information you need to get the most from your product.
Before you use the digital video baby monitor, we recommend that you insert and fully charge the battery in the parent unit, so that it continues to work if you disconnect it from the electrical outlet to carry it to another location. Please read the Safety Instructions on page 7 before you install the units.
Got everything?
•1 x Parent unit
•1 x Baby unit (camera)
•1 x Rechargeable Ni-MH battery pack for the Parent unit
•1 x Battery door for Parent unit
•1 x Belt clip/stand for Parent unit
•1 x Power adapter for Parent unit
•1 x Power adapter for Baby unit
In packs with multi baby units, you will find one or more additional baby units with power adapters.
Overview of the Parent Unit
1
2 |
|
|
|
3 |
|
|
4
5
1.LCD display
2.Battery level indicator
On when the parent unit battery is being charged.
Flashes when the parent unit battery is low and needs charging.
Off when the parent unit battery is fully charged, or when the battery is not installed.
3.Power/Link indicator
On when the parent unit is powered on. Off when the parent unit battery is fully charged.
Flashes when pairing, or when searching for a baby unit.
4.Microphone
5.Control key panel
UP / VOLUME +
Press to increase speaker volume. While in a menu, press to scroll up. While viewing a zoomed image, press and hold to move the image upward. DOWN / VOLUME -
Press to decrease speaker volume. While in a menu, press to scroll down. While viewing a zoomed image, press and hold to move the image downward.
6
7
9
8
LEFT/- <
While in a menu, press to choose the option on the left.
While viewing a zoomed image, press to zoom out; or press and hold to move the image leftward.
RIGHT/+ >
While in a menu, press to choose the option on the right.
While viewing a zoomed image, press to zoom in; or press and hold to move the image rightward.
Power ON/OFF button
Press and hold to power on or off. Press to turn the screen on or off. MENU/SELECT
Press to enter the menu.
While in a menu, press to choose an option, or save a setting.
TALK T
Press and hold to talk to the baby unit.
6.Speaker
7.Belt clip/stand
8.Battery compartment cover
9.Power jack
Parent Unit display icons
|
Connection status |
|||
|
- |
displays when strong signal strength is detected between the baby |
||
|
|
unit and the parent unit. |
||
|
- |
, |
or |
displays when moderate signal strength is detected |
|
|
between the baby unit and the parent unit. |
||
|
- |
displays when the link between the baby unit and the parent unit is |
||
|
|
lost. |
|
|
|
- |
displays when the parent unit is searching for a baby unit. |
||
|
|
|
|
|
|
Current view status |
|||
|
- Displays the number of the baby unit that is being viewed. |
|||
|
Zoom |
|
|
|
|
- Displays when the camera on the baby unit is zoomed in. |
|||
|
|
|
|
|
|
Volume off |
|||
|
- Displays when the volume is turned off. |
|||
|
|
|
|
|
|
Sound activation |
|||
|
- You can turn Sound activation function ON or OFF. |
|||
|
|
To check on your baby whenever there is sound in the baby’s room, |
||
|
|
please turn it ON. |
||
|
- Displays when sound activation is ON. |
|||
|
|
When the baby unit detects a sound in the baby's room, the video |
||
|
|
image of the baby will be displayed on the parent unit. |
||
|
|
|
|
|
61oF |
Current temperature |
|||
|
- Displays the current room temperature of the selected baby unit. |
|||
|
Battery status |
|||
|
- |
|
|
scrolls when the battery is charging. |
|
- |
displays when the battery is fully charged. |
||
|
- |
displays when the battery is low and needs charging. |
||
|
- |
displays when you do not have a battery installed but operates using |
||
|
|
AC power, or the battery has been installed incorrectly. |
||
|
Camera selection |
|||
|
- You can select the baby unit you want to view, or view all baby units in |
|||
|
|
Scan Mode. |
||
|
Brightness |
|||
|
- You can change the brightness of the screen. |
|||
|
|
|
|
|
|
Sensitivity |
|||
|
- You can change the sound sensitivity level of the baby unit. The higher |
|||
|
|
the sound sensitivity level, the more sensitive the baby unit is in |
||
|
|
detecting sounds and transmitting them to the parent unit. |
||
|
Pairing |
|
|
|
|
- The system comes with baby unit(s) already paired with the parent unit. |
|||
|
|
You can add or replace baby units. |
Overview of the Baby Unit
9
10
1
2
3
4 |
|
7 |
|
5
6
8
1.Camera lens
2.Infrared lights
4 x infra-red LEDs for night vision illumination.
3.Power/Link indicator
On steadily when the baby unit is powered on and linked to the parent unit.
Flashes when the baby unit is not linked to a parent unit; or the pairing process is in progress; or the parent unit is not viewing this baby unit.
4.Microphone
5.Control key panel PAIR
Press and hold to pair with the parent
unit.
Power ON/OFF button
Press and hold to power the baby unit on or off.
6.Stand
Tilt to adjust camera angle.
7.Power jack
8.Base
9.Speaker
10.Temperature sensor
Important guidelines for installing your digital video baby monitor
•To use your baby unit and parent unit together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions.
•Any large metal object, like a refrigerator, a mirror, a filing cabinet, a metallic door or reinforced concrete, between the baby unit and parent unit may block the radio signal.
•The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches.
•If the signal is poor, try moving the parent unit and/or the baby unit to different positions in the rooms.
Table of contents
1. |
Safety Instructions..................................................................................... |
7 |
|
2. |
Getting Started........................................................................................ |
10 |
|
|
2.1 |
Baby unit power supply............................................................................. |
10 |
|
2.2 |
Parent unit battery installation and power supply.................................... |
11 |
|
2.3 |
Belt clip/stand on parent unit.................................................................... |
12 |
3. |
Using Your Digital Video Baby Monitor.................................................. |
13 |
|
|
3.1 |
Power on or off the baby unit ................................................................... |
13 |
|
3.2 |
Power on or off the parent unit ................................................................. |
13 |
|
3.3 |
Turn on or off the parent unit screen ........................................................ |
13 |
|
3.4 |
Adjust speaker volume of the parent unit ................................................ |
13 |
|
3.5 |
Adjust LCD brightness of the parent unit................................................. |
14 |
|
3.6 |
Adjust sound sensitivity of the baby unit .................................................. |
14 |
|
3.7 |
Turn sound activation on or off ................................................................. |
14 |
|
3.8 |
Set temperature unit ................................................................................. |
14 |
|
3.9 |
Select camera............................................................................................ |
15 |
|
3.10 |
Zoom ......................................................................................................... |
15 |
|
3.11 |
Pairing and replacing baby unit(s)............................................................ |
15 |
|
3.12 |
Talk to the baby unit.................................................................................. |
16 |
|
3.13 |
Reset settings to default............................................................................ |
16 |
4. |
Disposal of the Device (Environment).................................................... |
17 |
|
5. |
Cleaning .................................................................................................. |
18 |
|
6. |
Troubleshooting ...................................................................................... |
19 |
|
7. |
General Information ................................................................................ |
21 |
|
8. |
Technical Specifications ......................................................................... |
26 |
6 |
Table of contents |
|
|
WARNING:
Strangulation Hazard. Children have STRANGLED in cords. Keep this cord out of the reach of children (more than 3ft (1m) away). Never use extension cords with AC Adapters. Only use the AC Adapters provided.
ENGLISH
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Safety Instructions |
7 |
|||
|
|
|
|
|
CAMERA SET UP & USE:
•Determine a location for the Baby Unit that will provide the best view of your baby in his/her crib.
•Place the Baby Unit on a flat surface, such as a dresser, bureau or shelf, or mount the Unit on a wall securely using the keyhole slots under the stand.
•NEVER place the Baby Unit or cords within the crib.
WARNING
This Digital Video Baby Monitor is compliant with all relevant standards regarding electromagnetic fields and is, when handled as described in the User's Guide, safe to use. Therefore, always read the instructions in this User's Guide carefully before using the device.
•Adult assembly is required. Keep small parts away from children when assembling.
•This product is not a toy. Do not allow children to play with it.
•This Digital Video Baby Monitor is not a substitute for responsible adult supervision.
•Keep this user's guide for future reference.
•Keep the cords out of reach of children.
•Do not cover the Digital Video Baby Monitor with a towel or blanket.
•Test this monitor and all its functions so that you are familiar with it prior to actual use.
•Do not use the Digital Video Baby Monitor in damp areas or close to water.
•Do not install the Digital Video Baby Monitor in extreme cold or heat, direct sunlight, or close to a heat source.
•Only use the chargers and power adapters provided. Do not use other chargers or power adapters as this may damage the device and battery pack.
•Only insert a battery pack of the same type.
•Do not touch the plug contacts with sharp or metal objects.
•Connect the power adapters to easily accessible electrical outlets.
8 |
Safety Instructions |
|
|
CAUTION
There is a risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.
Use only rechargeable battery pack with rating: 2.4V 750mAh
ENGLISH
Safety Instructions |
9 |
|
|
