User’s Guide
Digital Video Baby Monitor
Models: MBP49, MBP49-2, MBP49-3, MBP49-4
The features described in this User’s Guide are subject to modifications without prior notice.
Welcome...
to your new Motorola Digital Video Baby Monitor!
Thank you for purchasing your new Motorola Digital Video Baby Monitor. Now you can see and hear your baby sleeping in another room or you can monitor your older children in their playroom.
Please retain your original dated sales receipt for your records.
For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage.
For product related questions, please call:
US and Canada 1-888-331-3383
E-mail: support@motorolahome.com
This User's Guide provides you with all the information you need to get the most from your product.
Before you can use the Baby Monitor, we recommend you fully charge the battery in the Parent Unit, so that it continues to work if you disconnect it from the power supply to carry it to another location. Please read the Safety Instructions on page 8 before you install the units.
Got everything?
•1 x Parent Unit
•1 x Baby Unit (Camera)
•1 x Power adapter for the Parent Unit
•1 x Power adapter for the Baby Unit
In multi-camera packs, you will find one or more additional camera and power adapter units.
Overview of the Parent Unit
1 |
12 13 |
14 |
15 |
16 |
17 |
2 |
|
|
|
|
7 |
3 |
|
|
|
|
8 |
4 |
|
|
|
|
9 |
5 |
|
|
|
|
10 |
6 |
|
|
|
|
11 |
18 |
19 |
1. |
Display (LCD screen) |
13. |
Unit ON/OFF LEDs (Green) |
2. |
VIDEO ON/OFF button V |
14. |
Audio Level LEDs (Green, Amber, |
|
Press to turn the LCD screen |
|
Red, Red) |
|
ON/OFF |
15. |
Volume button |
3. |
TALK button T |
|
Press -/+ to decrease/increase |
|
Press and hold to speak to your baby |
|
Volume level on Parent Unit |
4. |
RESET button (recessed - use |
16. |
Power button 0 |
|
small pin) |
|
Press and Hold to turn the unit |
5. |
UP button + |
|
ON/OFF |
|
Normal Mode: Tilt Up |
17. |
Microphone |
|
Menu Mode: Up |
18. |
Stand |
6. |
DOWN button - |
19. |
Speaker |
Normal Mode: Tilt Down
Menu Mode: Down
7.MENU button M
Press to open the Menu options
8.OK button O
9.Micro USB power adapter socket
10.LEFT button < Normal Mode: Pan Left Menu Mode: Left
11.RIGHT button > Normal Mode: Pan Right Menu Mode: Right
12.Charging LED:
BLUE when mains power connected.
Parent Unit menu icons
Signal Level (5 Levels)
Night Vision Mode (Screen changes to Black/White)
Talk Mode
Battery Level Indication (4 Levels)
Pan Left
Pan Right
Tilt Up
Tilt Down
Zoom Level Control (1X, 2X)
Brightness Level Control (8 Levels)
Lullaby Control (5 Sound Selections)
Alarm Setting (6h, 4h, 2h, Off)
|
|
|
|
Temperature scale select (oC / oF) |
||
|
|
|
|
Readings display in BLUE, but turn RED > 29ºC / 84ºF, or < 14ºC / 57ºF |
||
|
|
|
|
Displays HH oC / oF if >36oC / 97oF. |
||
|
|
|
|
|||
|
|
|
|
Displays LL oC / oF if < 1oC / 34oF. |
||
|
|
|
|
Camera Control (scan, view, add, delete) |
||
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
V |
Set Screen Off Timer (Off |
|
, 5 min, 30 min, 60 min) |
|||
|
||||||
|
|
|
|
|
|
|
|
|
|
|
Indicates the screen off timer is set |
||
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
Volume Level Control (8 Levels) |
||
|
|
|
|
|
|
|
|
|
|
|
No Baby Unit detected |
||
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
View multiple cameras on screen. Available when you have more than 1 |
||
|
|
|
|
|||
|
|
|
|
Baby Unit (Camera). |
||
|
|
|
|
Overview of Your Baby Unit
1 |
|
|
2 |
|
|
3 |
7 |
|
4 |
8 |
|
|
||
|
9 |
|
6 |
10 |
|
11 |
||
5 |
||
|
1. |
Photo Sensor (Night Vision Mode) |
7. |
Antenna |
2. |
Camera Lens |
8. |
Speaker |
3. |
Infrared LEDs (x 8, for night vision) |
9. |
PAIR button |
4. |
Power LED |
10. Power Adapter Socket |
|
5. |
Microphone |
11. Temperature Sensor |
|
6. |
POWER ON/OFF switch |
|
|
Important guidelines for installing your Baby Monitor
•To use your Video Monitor Baby and Parent Units together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions.
•Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic doors or reinforced concrete between the Baby and Parent Unit may block the radio signal.
•The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches.
•Use of other 2.4 GHz products, such as wireless networks (Wi-Fi® routers), Bluetooth™ systems, or microwave ovens, may cause interference with this product, so keep the Baby Monitor away at least 1 metre from these types of products, or turn them off if they appear to be causing interference.
•If the signal is weak, try raising the Parent Unit's Antenna, or moving the Parent and/or the Baby Unit to different positions in the room(s).
Table of contents
1. |
Safety Instructions..................................................................................... |
7 |
||
2. |
Getting Started........................................................................................ |
10 |
||
|
2.1 |
Baby Unit Power Supply ............................................................................ |
10 |
|
|
2.2 |
Parent Unit Power Supply ......................................................................... |
10 |
|
|
2.3 |
Registration (Pairing) ................................................................................ |
12 |
|
3. |
Using the Baby Monitor........................................................................... |
13 |
||
|
3.1 |
Setting up .................................................................................................. |
13 |
|
|
3.2 |
Pan and Tilt ................................................................................................ |
13 |
|
|
3.3 |
Night Vision Mode .................................................................................... |
13 |
|
|
3.4 |
Talk Mode .................................................................................................. |
13 |
|
|
3.5 |
Video ON/OFF ......................................................................................... |
13 |
|
|
3.6 |
Temperature Display (HH °C / °F or LL °C / °F) ...................................... |
14 |
|
4. |
Parent Unit Menu Options ...................................................................... |
15 |
||
|
4.1 |
Volume |
...................................................................................................... |
15 |
|
4.2 |
Brightness .................................................................................................. |
15 |
|
|
4.3 |
Lullaby ....................................................................................................... |
|
15 |
|
4.4 |
Zoom ......................................................................................................... |
|
15 |
|
4.5 |
Alarm ......................................................................................................... |
|
15 |
|
4.6 |
Camera ........................................................................................Control |
16 |
|
|
|
4.6.1 .................................................................. |
Add (pair) a camera |
16 |
|
|
4.6.2 ........................................................................... |
View a camera |
16 |
|
|
4.6.3 ........................................................................ |
Delete a camera |
17 |
|
|
4.6.4 .............................................................................. |
Scan camera |
17 |
|
4.7 |
Temperature ............................................................................................. |
17 |
|
|
4.8 |
Power Saving ..................................................................................mode |
18 |
|
|
4.9 |
View multiple ............................................................cameras on screen |
18 |
|
5. |
Disposal of The ...................................................Device (environment) |
19 |
||
6. |
Cleaning .................................................................................................. |
|
20 |
|
7. |
Help |
.......................................................................................................... |
|
21 |
8. |
General ................................................................................Information |
23 |
6 |
Table of contents |
|
|
1. Safety Instructions
WARNING:
Strangulation Hazard: Children have STRANGLED in cords. Keep this cord out of the reach of children (more than 1m (3ft) away). Never use extension cords with AC Adapters. Only use the AC Adapters provided.
ENGLISH
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Safety Instructions |
7 |
|||
|
|
|
|
|
Baby Unit SET UP & USE:
●Choose a location for the Baby Unit that will provide the best view of your baby in their cot.
●Place the Baby Unit on a flat surface, such as a dresser, desk, or shelf or mount the Unit to a wall securely using the keyhole slot on the underside of the stand.
●NEVER place the Baby Unit or cords inside your child's cot.
●Do not place the Baby Unit or cords in the cot or within reach of the baby (the unit and cords should be more than 1 metre away).
WARNING
This digital video Baby Monitor is compliant with all relevant standards regarding electromagnetic fields and is, when handled as described in the User's Guide, safe to use. Therefore, always read the instructions in this User's Guide carefully before using the device.
•Adult assembly is required. Keep small parts away from children when assembling.
•This product is not a toy. Do not allow children to play with it.
•This Baby Monitor is not a substitute for responsible adult supervision.
•Keep this User’s Guide for future reference.
•Do not place the Baby Unit or cords in the cot or within reach of the baby (the unit and cords should be more than 1 metre away)
•Keep the cords out of reach of children.
•Do not cover the Baby Monitor with a towel or blanket.
•Never use extension cords with power adapters. Only use the power adapters provided.
•Test this monitor and all its functions so that you are familiar with it prior to actual use.
•Do not use the Baby Monitor near water.
8 |
Safety Instructions |
|
|
• Do not place the Baby Monitor near a heat source. |
ENGLISH |
|
|
pack. |
|
• |
Only use the chargers and power adapters provided. Do not use other |
|
|
chargers or power adapters as this may damage the device and battery |
|
• |
Do not touch the plug contacts with sharp or metal objects. |
|
|
|
|
CAUTION
The Parent Unit includes a built-in, lithium-ion rechargeable battery pack, which is not a user-accessible item. If you think the battery needs replacing, please contact the helpline. Do not try to replace it yourself.
Risk of explosion if battery is replaced by an unapproved battery type. Dispose of used batteries according to their instructions.
The Unit should be set up and used so that parts of the user's body other than the hands are maintained at a distance of approximately 8 inches (20 cm) or more.
Safety Instructions |
9 |
|
|
2. Getting Started
2.1Baby Unit Power Supply
1.Connect the small plug of the power adapter to the Baby Unit (camera) and the other end to a suitable mains power socket.
NOTE
Only use the enclosed power adapter (5V DC / 1000mA).
2.Slide the POWER ON/OFF switch to the ON position. The power LED will light up in red.
3.Slide the POWER ON/OFF switch to the OFF position to turn the Baby Unit off.
2.2Parent Unit Power Supply
IMPORTANT
The Parent Unit is assembled with a built-in rechargeable battery pack (Lithiumion battery 1880mAh), please charge it for 16 hours before initial use. The battery is not a user-accessible item. Please contact the helpline if you think it needs replacing.
10 |
Getting Started |
|
|
