USER’S GUIDE
MBP35BL, MBP35BW
BABY MONITOR
USER’S GUIDE
The features described in this user’s guide are subject to
modifications without prior notice.
Welcome...
to your new Motorola Baby Monitor!
Thank you for purchasing the MBP35BL, MBP35BW. Now you can
see and hear your baby sleeping in the other room or you can
monitor your older children in their playroom.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola product, you will need to provide
a copy of your dated sales receipt to confirm warranty status.
Registration is not required for warranty coverage.
For product related questions, please call:
1-888-331-3383 in US and Canada
On the Web: www.motorola.com
This User’s Guide provides you with all the information you need
to get the most from your product.
Before you can use the baby monitor, you’ll need to insert and
fully charge the battery on the parent unit. Please read the Safety
Instructions on page 6 before you install the units.
Got everything?
• 1 x Parent unit
• 1 x Baby unit
• 1 x Rechargeable Ni-MH battery pack for the Parent unit
• 1 x Power adapter for the Parent unit
• 1 x Power adapter for the Baby unit
IMPORTANT
The non-rechargeable batteries for the Baby unit are not supplied
with your product. We recommend the batteries to be installed
before use, so that the unit continues to work in the event of a
power supply failure.
Overview of your Parent unit
1
5
2
3 4
1. Display (LCD screen)
2. Up
< / Down key >
Normal mode: Adjust
speaker volume
Menu mode: Adjust settings
3. Power and low battery LED
4. Voice Activation LED
5. Lullaby On/Off key
i
Press to play lullaby.
Press again to turn off.
6. Lullaby selection key
j
Press to select a lullaby
during playback
Parent unit display symbols
Indicates that the baby unit is out of range or not linked to the
parent unit
Language
High
Low
Night Light
Talk
Appears when setting the language
Appears when displaying the Temperature reading
Appears when the temperature goes above 40°C (102°F)
Appears when the temperature goes below 0°C (32°F)
Appears when setting the Night Light function
Indicates that the Talk function is activated
Appears when playing lullabies
Appears when adjusting the Volume of parent unit
Appears when adjusting the Brightness of the LCD
11
6
7
7. Microphone
8. Menu key
Press to open the Menu
options
9. Talk k ey
Press and hold to speak to
your baby
10. Power key
Press to turn on the unit
Press and hold to turn it off
11. Antenna
12. Battery cover
13. Speaker
12
10 9 8
m
t
p
13
MENU
TALK
Parent unit display symbols (cont’d)
Appears when setting camera channel
Registration
Voice Activation
Appears when pairing parent to camera
Appears when setting the voice activation on/off
Overview of your Baby unit
1
2
3
4
5
1. Photo sensor
2. Camera lens
3. Infrared LEDs
4. Power LED
5. Night lights
Important guidelines for installing your Baby Monitor
• To use your video monitor baby and parent unit together, you must
be able to establish a radio link between them, and the range will be
affected by environmental conditions.
• Any large metal object, like a refrigerator, a mirror, a filing cabinet,
metallic doors or reinforced concrete, between the baby and parent
unit may block the radio signal.
• The signal strength may also be reduced by other solid structures, like
walls, or by radio or electrical equipment, such as TV's, computers,
cordless or mobile phones, fluorescent lights or dimmer switches.
• Use of other 2.4GHz products, such as wireless networks,
Bluetooth
with this product, so keep the baby monitor away from these types
of products, or turn them off if they appear to be causing
interference.
• If the signal is poor, try moving the parent and/or the baby unit to
different positions in the rooms.
®
systems or microwave ovens may cause interference
7
8
9
6. On/Off switch
7. Speaker
8. Antenna
9. Temperature sensor
6
Table of contents
1. Safety Instructions ......................................................................... 6
2. Getting started................................................................................ 7
2.1 Baby unit battery installation...........................................................7
2.2 Baby unit power supply ..................................................................8
2.3 Parent unit battery installation ........................................................8
2.4 Parent unit power supply................................................................9
2.5 Registration ..................................................................................10
3. Using the Baby Monitor MBP35BL, MBP35BW .........................11
3.1 Setting Up.....................................................................................11
3.2 Night Vision ..................................................................................11
3.3 Talk Function................................................................................11
3.4 Adjusting the volume of the parent unit ........................................11
3.5 Playing a lullaby for your baby......................................................12
4. MBP35BL, MBP35BW Parent Unit Menu Options ..................... 13
4.1 Setting Display Language.............................................................13
4.2 Brightness.....................................................................................13
4.3 Temperature Display (ºC or ºF)....................................................13
4.4 Night Light ....................................................................................13
4.5 Voice Activation............................................................................14
5. Disposal of the device (environment) ........................................ 15
6. Cleaning ........................................................................................ 16
7. Help................................................................................................ 17
8. General Information ..................................................................... 19
ENGLISH
Table of contents 5
1. Safety Instructions
WARNING
This baby monitor is compliant with all relevant standards regarding
electromagnetic fields and is, when handled as described in the User’s
Guide, safe to use. Therefore, always read the instructions in this User’s
Guide carefully before using the device.
• Adult assembly is required. Keep small parts away from children when
assembling.
• This product is not a toy. Do not allow children to play with it.
• This baby monitor is not a substitute for responsible adult supervision.
• Keep this User’s Guide for future reference.
• Do not place the baby unit or cables in the crib or within arm's reach of
the baby (the unit should be at least 3 feet away).
• Keep the cords out of reach of children.
• Do not cover the baby monitor with a towel or blanket.
• Never use extension cords with power adapters. Only use the power
adapters provided.
• Test this monitor and all its functions so that you are familiar with it
prior to actual use.
• Do not use the baby monitor near water.
• Do not install the baby monitor near a heat source.
• Only use the chargers and power adapters provided. Do not use other
chargers or power adapters as this may damage the device and
batteries.
• For the parent unit, only insert a rechargeable battery pack of the
same type. For the baby unit, use non-rechargeable batteries and
insert with the correct polarity, as indicated in the battery compartment
and in “2.1 Baby unit battery installation”.
• Do not touch the charger or plug contacts with sharp or metal objects.
CAUTION
Risk of explosion if battery is replaced by an incorrect type. Dispose of
used batteries according to the instructions.
6 Safety Instructions
2. Getting started
2.1 Baby unit battery installation
The camera uses either 3 AA size batteries (non-rechargeable batteries
recommended) or the household mains electricity. The Baby unit has no
charging function!
IMPORTANT
The non-rechargeable batteries for the Baby unit are not supplied with
your product. We recommend that batteries be installed before use, so
that the unit continues to work in the event of a power supply failure.
1. Loosen the screw in a counterclockwise direction using a small
screwdriver. Remove the battery cover.
2. Install 3 AA non-rechargeable batteries following the polarity as
shown in the compartment. Close the battery compartment and
tighten the screw in a clockwise direction.
3. Slide the power switch to the
in green.
To switch off the baby unit, slide the power switch to the
NOTE
When the battery level is low, the power LED will turn orange and will flash.
WARNING
Do not mix old batteries with new ones.
Keep batteries away from small children.
Do not short-circuit batteries or dispose of in fire.
Remove the batteries if this device is not going to be used for a long
period of time.
Getting started 7
ON
position. The power LED will light up
OFF
position.
ENGLISH
2.2 Baby unit power supply
1. Connect the small plug of the power adapter to the baby unit and the
other end to the electrical outlet (110V/60Hz).
NOTE
Only use the enclosed power adapter (6V DC / 800mA).
ON
2. Slide the power switch to the
in green.
3. To turn off the baby unit, return the switch to the
position. The power LED will light up
OFF
position.
2.3 Parent unit battery installation
Black
8 Getting started
Red
1. Loosen the screw in a counterclockwise direction using a small
screwdriver. Remove the battery cover.
2. Insert the wire tab of the rechargeable battery pack into the contact
slot as shown above and fit the battery pack into the compartment.
3. Close the battery compartment and tighten the screw in a clockwise
direction.
4. Press and hold
5. Press and hold
NOTE
When the battery level is low, the power LED will turn green and flash.
Charge the battery pack for at least 15 hours before using on battery
power only.
NOTE
When the unit is powered up with either the power adapter or the
rechargeable battery pack, the LED will light up in green. When the
rechargeable battery is in charging mode, the LED will light up in red.
p to turn ON the parent unit.
p to turn OFF the parent unit.
2.4 Parent unit power supply
1. Connect the small plug of the power adapter to the parent unit and
the other end to the electrical outlet (110V/60Hz).
NOTE
Only use the enclosed power adapter (6V DC / 800mA).
2. Press and hold
light up in green.
3. Press and hold
Getting started 9
p to turn ON the parent unit. The power LED will
p to turn OFF the parent unit.
ENGLISH
NOTE
Once the baby and parent units are switched on, the display on the parent
unit will show the video captured by the baby unit. When the Voice Activation
mode is on, the screen will turn off after a few seconds if the sound near the
baby unit drops below the Voice Activation threshold.
When there is no connection or the units are out of range, the icon on
the LCD display will flash and the parent unit will beep continuously. Move
the parent unit closer to the baby unit until the link is re-established.
2.5 Registration
The Baby monitor is pre-registered to your Parent unit. You do not need
to register it again unless the Baby unit loses its link with the Parent unit.
To re-register your Baby unit, or register a new Baby unit, follow the
procedure below:
1. Switch off the Baby unit
2. Press
3. Press
4. Switch the Baby unit ON to enter the registration mode. The power
The registration is completed when
captures the video from the baby unit’s camera on display screen of the
parent unit.
If the registration fails then
seconds then both parent and baby units return to normal mode.
NOTE
If a particular Baby unit had been registered already, register this current
Baby unit again will over-write the old registration.
m button on the Parent unit until
display screen.
m button to confirm the selection and
registration mode and appears on display screen for 15 seconds.
LED on the baby unit flashes quickly for approximately 3 seconds.
1… X
appears on display screen for 3
Registration
1… OK
appears for 3 seconds and
appears on
1
will enter the
10 Getting started
3. Using the Baby Monitor MBP35BL,
MBP35BW
3.1 Setting Up
• Place the camera in a convenient location and point the lens of the
camera towards the area you want to monitor.
• Tilt the head of the baby unit up or down to your desired position until
the parent unit gets a good reception of the baby.
NOTE
Do not place the camera within baby’s reach! If there is interference on
the picture or sound, try moving the units to different locations, and
ensure they are not close to other electrical equipment.
3.2 Night Vision
The camera has high-intensity infrared LEDs for picking up clear images
in the dark. When the built-in photo sensor detects a low level of ambient
light, the LEDs will automatically activate and the screen on the parent
unit will display in black and white.
NOTE
If the ambient light near the baby unit is marginal, the screen may appear
to flicker between colour and black and white.
3.3 Talk Function
Press and hold t on the Parent unit to talk to your baby through the
Baby unit loudspeaker. The symbol
the display screen.
3.4 Adjusting the volume of the parent unit
1. Press < and > to adjust the volume (5 levels) of the parent unit
during normal operations and (5 volume levels) appears on
the display screen.
NOTE
Volume adjustment does not work if the baby monitor selection is in
mode.
Using the Baby Monitor MBP35BL, MBP35BW 11
Talk
will be displayed in the middle of
AUTO
ENGLISH
3.5 Playing a lullaby for your baby
You can remotely activate a lullaby to be played on the baby unit.
1. Press the
2. To select another lullaby, press
lullabies available for selection, indicated by
or
3. To play all lullabies, press
4. Press
TIPS
• During the first 10 seconds of lullaby playback, pressing
adjust the lullaby volume of the baby unit. appears on the
display screen.
• Pressing
volume of the parent unit. appears on the display screen.
i button on the parent unit to play the last set lullaby.
j during playback. There are 5
1, 2, 3, 4
5
.
j until is displayed on the display screen.
j again to stop playback.
< or > will
< or > after 10 seconds of lullaby playback will adjust the
12 Using the Baby Monitor MBP35BL, MBP35BW
4. MBP35BL, MBP35BW Parent Unit
Menu Options
4.1 Setting Display Language
1. Press m repeatedly until
parent unit.
2. Press
3. Press
< or > to select the language you want
m button to confirm the selection.
4.2 Brightness
1. Press m repeatedly until appears on the display screen.
2. Press
3. Press
< and > to adjust the LCD brightness level to
3
default setting is
). The LCD brightness will be adjusted accordingly.
m repeatedly to exit.
4.3 Temperature Display (ºC or ºF)
1. Press m repeatedly until appears on the display screen.
2. Press
3. Press
NOTE
If the temperature goes above 40ºC (102ºF),
screen.
If the temperature goes below 0ºC (32ºF),
screen.
< and > to change the temperature display to
(the default setting is
changed accordingly.
m repeatedly to exit.
4.4 Night Light
1. Press m repeatedly until
2. Press
< to turn the Baby unit Night Light
OFF
Night Light
and off accordingly.
. The night light on the baby unit will be switched on
Language
appears on the display screen of
1, 2, 3, 4
, or 5 (the
ºC, ºF
or
ºC
). The temperature unit and reading will be
High
appears on the LCD
Low
appears on the LCD
Night Light
appears on the display screen.
ON
or press > to turn the
OFF
ENGLISH
MBP35BL, MBP35BW Parent Unit Menu Options 13
3. Press m repeatedly to exit.
4.5 Voice Activation
If you do not want the parent unit screen to be on continually, you can set
the Voice Activation mode ON so that the screen only turns on if there is
a sound near the baby unit.
The default setting, however, is Voice Activation OFF, which allows for
constant audio and video monitoring. It is best to use the power supplies
with both units when selecting Voice Activation OFF mode.
1. Press
2. Press
3. Press
NOTES
• When the Voice Activation function is on, the Voice Activation LED will
• The display screen will be switched back on when the sound level of
• When the Voice Activation function is off, the Voice Activation LED will
m repeatedly until
screen.
Voice Activation
appears on the display
< and > to adjust the voice activation to ON or OFF.
• Choose
• Choose
Voice Activation OFF
on, transmitting both video and audio. Please use the unit’s power
supplies with this setting.
Voice Activation ON
with video only when the sound is above the threshold. This saves
power and/or battery life.
if you wish to keep the monitor steadily
which allows the transmission of sound
m button repeatedly to exit.
be turned on (red) and the display screen will switch off after a few
seconds.
the baby reaches the Voice Activation threshold or when any button
on the parent unit is pressed.
be turned off and the display screen will always switch on.
14 MBP35BL, MBP35BW Parent Unit Menu Options
5. Disposal of the device
(environment)
At the end of the product lifecycle, you should not dispose
of this product with normal household waste. Take this
product to a collection point for the recycling of electrical
and electronic equipment. The symbol on the product,
user’s guide and/or box indicates this.
Some of the product materials can be re-used if you take
them to a recycling point. By reusing some parts or raw materials from
used products you make an important contribution to the protection of the
environment.
Please contact your local authorities in case you need more information on
the collection points in your area.
Dispose of the batteries in an environmentally-friendly manner according
to your local regulations.
ENGLISH
Disposal of the device (environment) 15
6. Cleaning
Clean the MBP35BL, MBP35BW with a slightly damp cloth or with an antistatic cloth. Never use cleaning agents or abrasive solvents.
Cleaning and care
• Do not clean any part of the product with thinners or other solvents
and chemicals –- this may cause permanent damage to the product
which is not covered by the warranty. When necessary, clean it with a
damp cloth.
• Keep your MBP35BL, MBP35BW away from hot, humid areas, or
strong sunlight, and don’t let it get wet.
• Every effort has been made to ensure high standards of reliability for
your MBP35BL, MBP35BW. However, if something does go wrong,
please do not try to repair it yourself –- contact Customer Service for
assistance.
16 Cleaning
7. Help
Display
No display
• Try recharging or replacing the batteries.
• Reset the units. Unplug the units’ electrical power, including the
batteries and both mains adapters, then plug them back in.
• Is the unit turned on?
Press and release
p on the parent unit to turn it on.
Is the Voice Activation mode on?
• Turn the Voice Activation off (see “4.5 Voice Activation”) to keep the
screen on continually.
Registration
If the baby unit has lost its link with the parent unit
• Try recharging or replacing the batteries.
• If the baby unit is too far away it may be going out of range, so move
the baby unit closer to the parent unit.
• Reset the units by disconnecting them from the battery and electrical
power. Wait about 15 seconds before reconnecting. Allow up to one
minute for the baby unit and the parent unit to synchronize.
• See “2.5 Registration” if there is a need to re-register the units.
Interference
Noise interference on your parent unit
• Your baby and parent units may be too close. Move them farther away
from each other.
• Make sure there is at least 1 metre between the 2 units to avoid audio
feedback.
ENGLISH
Help 17
• If the baby unit is too far away it may be going out of range, so move
the baby unit closer to the parent unit.
• Make sure the baby and parent units are not near other electrical
equipment, such as a television, computer or cordless/mobile
telephone.
18 Help
8. General Information
If your product is not working properly....
1. Read this User’s Guide or the Quick Start Guide.
2. Visit our website:
www.motorola.com
3. Contact Customer Service at 1-888-331-3383 in US and Canada.
To order a replacement battery, contact customer service or visit our
website.
Consumer Products and Accessories purchased in
the United States or Canada
What Does this Warranty Cover?
Subject to the exclusions and limitations contained below, Binatone
Electronics International LTD. warrants the Motorola branded consumer
products that it manufactures (“Products”) and the Motorola branded or
certified accessories sold for use with these Products that it manufactures
(“Accessories”) to be free from defects in materials and workmanship
under normal consumer usage for the period(s) outlined below. This
limited warranty is a consumer’s exclusive remedy, and only applies as
follows to new Motorola branded Products and Accessories
manufactured by Binatone Electronics International LTD., and purchased
by consumers in the United States or Canada, which are accompanied by
this written warranty:
Who is covered?
This warranty covers only the first consumer purchaser, and is not
transferable.
ENGLISH
General Information 19
What will BINATONE ELECTRONICS INTERNATIONAL LTD.
do?
BINATONE ELECTRONICS INTERNATIONAL LTD., at its sole option,
will at no charge repair, replace or refund the purchase price of any
Products or Accessories that does not conform to this warranty. Binatone
Electronics International LTD. may use functionally equivalent
reconditioned/ refurbished/ pre-owned or new Products, Accessories or
parts in such repair or replacement and any Products, Accessories or
parts removed or being replaced under this warranty become the
property of Binatone Electronics International LTD.
What Other Limitations Are There?
ANY IMPLIED WARRANTIES OR CONDITIONS IRRESPECTIVE OF
WHETHER THEY ARE IMPOSED BY LAW OR OTHERWISE,
INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED TO THE DURATION OF THIS LIMITED
WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR
REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY
IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS
PROVIDED IN LIEU OF ALL WARRANTIES AND MOTOROLA AND
BINATONE ELECTRONICS INTERNATIONAL LTD. MAKES NO OTHER
WARRANTIES OR CONDITIONS, EXPRESS OF IMPLIED. IN NO
EVENT SHALL MOTOROLA OR BINATONE ELECTRONICS
INTERNATIONAL LTD. BE LIABLE, WHETHER UNDER THIS LIMITED
WARRANTY OR IN CONTRACT OR TORT (INCLUDING NEGLIGENCE
OR STRICT PRODUCT LIABILITY) OR OTHERWISE FOR DAMAGES
OR CLAIMS IN EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT OR ACCESSORY, OR FOR ANY INDIRECT, INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS
OF REVENUE, SAVINGS OR PROFITS, LOSS OF BUSINESS, LOSS OF
PROGRAMS DATA INFORMATION (WHETHER CONFIDENTIAL
PROPRIETARY OR PERSONAL IN NATURE OR OTHERWISE) OR
OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION
WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS OR
20 General Information
ACCESSORIES AND BINATONE ELECTRONICS INTERNATIONAL
LTD. SHALL UNDER NO CIRCUMSTANCES BE LIABLE FOR ANY
CLAIMS OR DEMANDS MADE BY ANY THIRD PARTY OR MADE BY
YOU ON BEHALF OF ANY THIRD PARTY TO THE FULL EXTENT
THESE DAMAGES OR CLAIMS MAY BE DISCLAIMED BY LAW.
Some states, countries or jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or limitation on the
length of an implied warranty, so the above limitations or exclusions may
not apply to you in such states, countries or jurisdictions. This warranty
gives you specific legal rights, and you may also have other rights that
vary from state to state or from one country/jurisdiction to another.
Products or Accessories
Length of Coverage
Covered
Consumer Products One (1) year from the date of
purchase by the first consumer
purchaser of the product.
Consumer Accessories Ninety (90) days from the date of
purchase by the first consumer
purchaser of the accessory.
Consumer Products and
Accessories that are Repaired
or Replaced
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Exclusions
Normal Wear and Tear. Periodic maintenance, repair and replacement
of parts due to normal wear and tear are excluded from coverage.
Batteries. Only batteries whose fully charged capacity falls below 80% of
their rated capacity and batteries that leak are covered by this limited
warranty. Battery life and the changes in battery capacity with time or use
are excluded from this warranty.
ENGLISH
General Information 21
Abuse & Misuse. Defects or damage that result from: (a) improper or
unreasonable use, operation, storage, misuse or abuse, accident or
neglect or other external cause, such as physical damage (cracks,
scratches, etc.) to the surface of the product resulting from misuse; (b)
your failure to follow or operate outside the usage parameters stated in
the user instructions that came with the Products or Accessories; (c)
contact with liquid, water, rain, extreme humidity or heavy perspiration,
sand, dirt or the like, extreme heat, or food; (d) use of the Products or
Accessories for commercial purposes or subjecting the Product or
Accessory to abnormal usage or conditions; or (e) other acts or omissions
which are not the fault or neglect of Motorola or Binatone Electronics
International LTD., are excluded from coverage.
Use of Non-Motorola branded Products and Accessories. Defects or
damage that result from the use of Non-Motorola branded or certified
Products or Accessories or other peripheral equipment are excluded from
coverage.
Unauthorized Service or Modification. Defects or damages resulting
from service, testing, adjustment, installation, maintenance, alteration, or
modification in any way by someone other than Motorola, Binatone
Electronics International LTD. or its authorized service centers, are
excluded from coverage.
Altered Products. Products or Accessories with (a) serial numbers or
date tags that have been removed, altered or obliterated; (b) broken seals
or that show evidence of tampering; (c) mismatched board serial
numbers; or (d) nonconforming or non-Motorola branded housings, or
parts, are excluded from coverage.
Communication Services. Defects, damages, or the failure of Products
or Accessories due to any communication service or signal you may
subscribe to or use with the Products or Accessories is excluded from
coverage.
22 General Information
How to Obtain Warranty Service or Other Information?
To obtain service or information, please call:
1-888-331-3383 in US and Canada
You will receive instructions on how to ship the Products or Accessories,
the shipment of which shall be at your own risk and expense, to a
BINATONE ELECTRONICS INTERNATIONAL LTD. Authorized Repair
Center. To obtain service, you must include: (a) a copy of your receipt, bill
of sale or other comparable proof of purchase of the Products or
Accessories showing the date of purchase; (b) a written description of the
problem; and, most importantly; (c) your address and telephone number.
These terms and conditions constitute the complete warranty agreement
between you and BINATONE ELECTRONICS INTERNATIONAL LTD.
regarding the Products or Accessories purchased by you, and supersede
any prior agreement or representations, including representations made
in any literature publications or promotional materials issued by
BINATONE ELECTRONICS INTERNATIONAL LTD. or representations
made by any agent employee or staff of BINATONE ELECTRONICS
INTERNATIONAL LTD., that may have been made in connection with the
said purchase.
FCC and IC regulations
FCC Part 15
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the Federal
Communications Commission (FCC) rules. These limits are designed to
provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
General Information 23
ENGLISH
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by
the party responsible for compliance could void the user's authority to
operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Privacy of
communications may not be ensured when using this device.
To ensure safety of users, the FCC has established criteria for the
amount of radio frequency energy that can be safely absorbed by a user
or bystander according to the intended usage of the product. This product
has been tested and found to comply with the FCC criteria. The Baby unit
shall be installed and used such that parts of the user's body other than
the hands are maintained at a distance of approximately 20 cm (8 inches)
or more.
This Class B digital apparatus complies with Canadian ICES-003.
WARNING
Changes or modifications to this equipment not expressively approved by
the party responsible for compliance could void the user’s authority to
operate the equipment.
Industry Canada
Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any
interference, including interference that may cause undesired operation
of the device.
The term "IC: " before the certification/registration number only signifies
that the Industry Canada technical specifications were met.
This product meets the applicable Industry Canada technical
specifications.
24 General Information
RENSEIGNEMENTS RELATIFS AUX RÈGLEMENTS DE
LA COMMISSION FÉDÉRALE DES COMMUNICATIONS
'FCC' ET D'INDUSTRIE Canada 'IC'
Article 15 des règlements du FCC
AVIS: Cet équipement a été testé et s'est révelé conforme aux limites
d'un appareil numérique de classe B, conformément à la Section 15 du
réglement de la Federal Communications Commission (FCC). Ces
limites sont conçues pour offrir une protection raisonnable contre toute
interférence nuisible sur une installation résidentielle. Cet appareil
génère, utilise et peut émettre des fréquences radio et s'il n'est pas
installé selon les instructions, peut nuire aux radiocommunications.
Toutefois, rien ne garantit que des parasites ne surviendront pas dans
une installation particulière. Si cet appareil cause des interférences
nuisibles à la réception du téléviseur ou de la radio, ce que vous pouvez
déterminer en mettant votre appareil en et hors fonction, nous vous
invitons à essayer l'une des mesures correctives suivantes :
• Réorientez l'antenne de réception.
• Éloignez l'appareil du composant qui reçoit les ondes.
• Branchez l'appareil dans une prise de courant CA différente de celle
du composant qui reçoit les ondes.
• Au besoin, consultez votre marchand électronique ou un technicien
spécialisé dans le service des radios/téléviseurs pour des
suggestions supplémentaires.
Toute modification ou changement effectué à cet appareil sans l'accord
des parties responsables de l'homologation peut retirer à l'utilisateur son
droit d'utiliser l'appareil.
Cet appareil est conforme à l'article 15 de la FCC. Le fonctionnement est
soumis aux deux conditions suivantes: (1) Cet appareil ne doit pas
causer d'interférences nuisibles et; (2) Il doit pouvoir supporter les
parasites qu'il reçoit, incluant les parasites pouvant nuire à son
fonctionnement. La confidentialité des communications peut ne pas être
assurée avec cet appareil.
Afin de garantir la sécurité des utilisateurs, la FCC a établi les critères
relatifs à l'énergie générée par les fréquences radio pouvant être
General Information 25
ENGLISH
absorbée en toute sécurité par un utilisateur ou par quelqu'un se trouvant
à proximité, dépendamment de l'utilisation prévue du produit. Ce produit
a été testé et s'avère conforme aux normes de la FCC. L'unité du bébé
devra être installée et utilisée de manière à ce que le corps de l'utilisateur,
à l'exception des mains, soit toujours à une distance d'environ 20 cm (8
po.) ou plus.
Cet appareil numérique de la classe B est conforme à la norme NMB-003
du Canada.
AVERTISSEMENT
Tout changement ou modification à cet équipement, non expressement
autorisé par la partie responsable de la conformité, pourrait annuler
l'autorisation donnée à l'utilisateur d'utiliser cet équipement.
Industrie Canada
Le fonctionnement est soumis aux deux conditions suivantes : (1) Cet
appareil ne doit pas causer d'interférences nuisibles et; (2) Cet appareil
accepte toute les interférences dont celles qui pourraient provoquer le
fonctionnement involontaire de l'appareil.
L'abréviation 'IC' se trouvant avant cette homologation signifie que la
certification fut effectuée selon une déclaration de conformité spécifiant
que les normes d'Industrie Canada ont été rencontrées.
Cet appareil est conforme aux spécifications techniques d'Industrie
Canada.
26 General Information
Technical Specifications
Baby unit
Frequency 2.4GHz to 2.4835GHz
Maximum range Extended range up to 450 feet*
*Based on unobstructed line of sight. Actual range will
vary depending on surroundings.
Image sensor Color CMOS
Lens f 2.5mm, F 2.8
IR LED 4 pcs
Power Adapter:
Parent unit
Frequency 2.4GHz to 2.4835GHz
Display 3.5" TFT LCD
Display colors 16.7M color LCD
Brightness control 5 steps
Power Adapter:
Input — 100-240VAC, 50/60Hz (USA plug);
Output — 6VDC, 800 mA
(Supplier: Sure-power, Model: SW-060080A)
OR
Battery: 3xAA non-rechargeable batteries
(Note: Batteries are not included)
Input — 100-240VAC, 50/60Hz (USA plug);
Output — 6VDC, 800 mA
(Supplier: Sure-power, Model: SW-060080A)
OR
Battery: Ni-MH rechargeable battery pack
(Supplier: Desay, Model: AA2000)
WARNING
Do not use non-rechargeable batteries for the
Parent Unit. Risk of explosion if battery is
replaced by an incorrect type. Dispose of used
batteries according to the instructions.
ENGLISH
General Information 27
Manufactured, distributed or sold by
Binatone Electronics International LTD.,
official licensee for this product.
MOTOROLA and the Stylized M Logo,
and other Motorola trademarks and trade
dress are owned by Motorola, Inc. and
are used under license from Motorola,
Inc. MOTOROLA and the Stylized M
Logo are registered in the US Patent &
Trademark Office. All other product or
service names are the property of their
respective owners.
© Motorola, Inc. 2010. All rights reserved.
Version 1.0
Printed in China
Loading...
