Binatone HB-733 User Manual [en, ru, fr]
Instruction Manual
Hand Blender
A
12
2
3
4
1
5
Hand Blender HB733
10 A
11 A
7
6
8
10 B
11 B
13
9
14
ENGLISH.........................................4
FRANÇAIS .................................... 10
РУССКИЙ .....................................16
ENGLISH
FRANÇAISРУССКИЙ
УКРАЇНСЬКА ............................... 22
3
УКРАЇНСЬКА
Hand Blender HB733
Please read the safety instructions carefully before using this
appliance. Please retain the instructions for future refer-
ence.
SAFETY MEASURES
When using your appliance, the following basic
safety precautions should always be followed:
X Before using for the first time, check that the
appliance voltage is the same as your local supply.
X Only use the appliance for the purposes stipulated by the instructions.
X Only use attachments supplied with the equip-
X To avoid electric shocks, do not immerse the appliance,
plug or power cord in water or any other liquids. Do
not place the appliance where it could come into contact with
water or other liquids. If the appliance comes in contact with
water, immediately disconnect it from the mains. Do not use
the machine again until it has been serviced by an autho-
rized service center.
X Do not let children use the appliance without supervision.
X If the power cord plug does not fit to your wall socket,
consult a qualified electrician.
X Use of various adapters may result in damage to the
appliance and termination of warranty.
X Always supervise the appliance while in use.
X To avoid a circuit overload, do not operate any other high
voltage equipment on the same circuit.
X Always unplug before moving the appliance from one
place to another, cleaning and storing.
X Never pull the cord to disconnect the appliance, instead grasp
the plug and pull it to disconnect.
X Do not allow the cord or the machine itself to come in contact
with hot surfaces.
X Position the appliance and the cord so that nobody can acci-
dentally overturn it.
X Do not use the appliance if it has been dropped, or it has a
damaged power cord or plug. Do not modify or repair the
machine yourself.
X Do not dismantle the appliance as improper assembly might
result in an electric shock during the subsequent use of the
equipment. Repairs should only be done by authorized
service centers.
X Do not use the device in areas where combustible gas mixtures
or inflammable liquid vapors could present in the air, or in
areas with inflammable air-borne dust or fibers.
X This equipment is intended for household use only, not for
commercial or industrial use.
X Please follow all the requirements of this guide.
X Do not use the appliance if it has mechanical defects (dents,
cracks etc.), get it checked by the nearest authorized service
center.
ment.
4
SPECIAL SAFETY
PRECAUTIONS
X Before turning the appliance on for the first
time, make sure that all components of the blender
have been properly installed.
X Do not apply too much force when installing the
blender attachment, as it may result in the breakage of the appliance and in the termination of the
warranty.
X If a smell of burning, foreign sounds or power reduction occur
during the blending process, immediately unplug the appliance from the outlet and clean the blender. If the blender still
malfunctions after cleaning, contact an authorized service center.
X It is recommended that original factory packaging should be
used for the transportation of the blender in order to prevent
its parts from breaking.
X If the ingredients are hot, allow them to cool before blending
(maximum temperature: 800C). Never blend hot fat or oil with
the blender.
X Never use the blender to blend paints or solvents.
X Do not attempt to remove any ingredients when the blender is
in operation.
X Always turn the appliance off before removing the attach-
ment.
X Maximum allowed time of blender continuous operation – 1
minute with compulsory pause of not less 1 minute. Operating
time for solid products processing should not exceed 15 seconds.
X The blades of the blender are very sharp. Never touch the
blades of the blender.
X Turn the blender on only after it has been fully assembled.
Always check whether the appliance has been properly assembled before each use.
ENGLISH
DESCRIPTION OF THE
APPLIANCE PARTS
Figure A:
1. Body
2. Speed selector
3. Button to set normal speed mode
4. Button to set turbo speed mode
5. Buttons to release blender or whisks
6. Blender
7. Whisk
8. Mincer gear
9. Non-slippery bases / covers
10 a. Mincer blade for bowl A
10 b. Mincer blade for bowl B
11 A. Mincer bowl A - capacity 1250 ml
5
11 B. Mincer bowl B- capacity 500 ml
12.Power cord
13.Blending glass
14.Wall bracket
BEFORE THE FIRST USE
Unpack the appliance and wash blender,
mincer and whisks (6, 7, 8), blades (10a, 10b)
and bowls (11A, 11B), wipe appliance body
(1) and power cord (12) of the appliance with
moisturized fabric and then wipe them dry.
OPERATING MANUAL
Use of blender and whisk:
1. Insert selected whisk or blender (6, 7) in the
relevant opening of the appliance body (1 )
until you hear a click. Press release buttons (5)
in order to release whisk or blender.
whisk or blender (6,7) is inserted correctly!
3. Plug the appliance into mains.
4. Lower whisk or blender into the bowl with the product to be
processed or into blending glass (13).
Note:
blades of blender should be completely plunged
into the processed product in order to prevent
sputtering.
5. To switch on the appliance, select desired speed using speed
selector (2), then push the button to set normal speed mode
(3) or the button to set turbo speed mode (4). Keep the
button pressed while the appliance is operating.
6. If turbo mode is used the appliance operates at maximum
speed. It is impossible in this case to change speeds using
speed selector (2).
7. Unplug the appliance from mains after use.
8. The appliance can be used with any bowls or containers.
Use of mincer:
1. Both mincer bowls are suitable for mincing meat, cheese, onions, herbs, garlic, carrots, nuts etc. Before mincing, cut the
product into smaller parts, remove shell, bones, tendons and
cartilage. Use mincer bowl A (11 A) for larger volume of the
product, and use mincer bowl B (11 B) for smaller volumes.
Additionally, mincer bowl A can be used to prepare fruit,
vegetable and alcoholic beverages, mash, liquid dough etc
2. Choose one of two bowls A (11 A) or B (11 B).
3. Install appropriate mincer blade (10a, 10b) into the bowl
(11A, 11B).
4. Place products into the mincer bowl (11A, 11B).
5. Install the mincer gear (8) on the bowl (11A, 11B).
2. Before turning on, please, make sure that
6
6. Place the body of appliance (1) on mincer gear (8). Align
appropriate openings in the body (1) and in the mincer gear
(8).
7. Prior to switching on the appliance, make sure that the gear
(8) is properly installed!
8. Plug the appliance into mains.
9. Set desired speed using speed selector (2) and push switch
button (3,4) to turn on the appliance. Keep the button pressed
while the appliance is operating.
10.Unplug the appliance from mains after use.
MAINTENANCE AND
CLEANING
1. Always unplug the appliance from mains
before cleaning.
2. Remove blender, mincer or whisk (6,7,8)
from the body (1), by pressing release buttons
(5). Wash blender, mincer or whisk (6,7,8),
blade (10a,10b), blending glass (13) and
mincer bowl (11 A, 11B) in warm water and
get them completely dried.
3. Wipe the body (1) and power cord (12) with moisturized
fabric and then wipe them dry.
4. Never plunge the body (1) and power cord (12) in water.
5. Do not use abrasive cleansers to clean parts of the appliance.
6. Get the appliance completely dried before use.
7. Blender and whisk (6,7) can be stored using wall bracket
(14).
ENGLISH
USEFUL TIPS
X To produce a homogeneous mixture, move the
attachment in a circle inside the container. If you
need to scrape off the remainder of the unblended
ingredients from the walls of the container used for
blending, stop the appliance and scrape off the
remainder of the ingredients from the walls, using
a spoon. Then proceed with the blending process
X You can change the blender speed during the blending pro-
cess.
in the selected mode.
DISPOSAL
The appliance should be disposed of in accor
dance with waste disposal regulations in your coun
try and with the least damage to the environment.
Only ecologically safe materials are used in
the packaging of our products and the cardboard
and paper can be disposed of with normal paper
waste.
7
AFTER-SALES SERVICE
If your appliance does not operate at all
or operates poorly, call an authorized service
center for help or repairs.
The warranty does not cover the
following:
X Non-observance of the above safety mea-
X Commercial use (use outside the scope of personal household
needs).
X Plugging into a mains socket with a voltage different from the
voltage on the appliance rating plate.
X Improper care (ingress of liquid, dust, insects, and other for-
eign items and substances inside the appliance).
X Use of excessive force during appliance operation or other
damages (mechanical damages resulting from incorrect use,
shocks or dropping of the appliance).
X Unauthorized repairs or replacement of the appliance parts
performed by an unauthorized person or service center.
X Scale deposit on the appliance regardless of the use of water.
X Accidents, such as lightning strike, flood, fire and other acts of
God.
sures and operation instructions.
8
ENGLISH
Features may be changed by Binatone without any notice.
Warranty details are set out in the warranty card provided
with the product.
Exploitation period: 3 years after the day of purchase.
Manufacture: Binatone Industries Ltd, Great Britain, Vitabiotics
House,1 Apsley Way, Staples Corner, London, NW2 7HF, UK.
