BINATONE HAS-1060 User Manual

Instruction Manual

HAS1060

Hair Styler Dryer

HAS1060 Hair StylerDryer

ENGLISH ........................................ 4

FRANÇAIS .....................................10

РУССКИЙ .....................................16

ENGLISHFRANÇAISРУССКИЙ

УКРА¯НСЬКА ................................22

3

УКРА¯НСЬКА

Hot Air Styler HAS-1060

Please read the safety instructions carefully before using this ap-

pliance. Please retain the instructions for future reference.

SAFETY MEASURES

When using your appliance, the following basic

safety precautions should always be followed:
 Before using for the first time, check that the appli­ance voltage is the same as your local supply.
 Only use the appliance for the purposes stipulated
by the instructions.

 To avoid electric shocks, do not immerse the appliance, plug

or power cord in water or any other liquids. Do not place

the appliance where it could come into contact with water or other
liquids. If the appliance comes in contact with water, immediately
disconnect it from the mains. Do not use the machine again until it
has been serviced by an authorized service center.

 Do not let children use the appliance without supervision.
 If the plug of the appliance’s power cord does not fit your

wall outlet, contact an authorized service center.

 Use of various adapters may result in damage to the

appliance and termination of warranty.

 Always supervise the equipment while in use.
 To avoid a circuit overload, do not operate any other high voltage

equipment on the same circuit.

 Always unplug the appliance after use, before moving

and before cleaning it.

 Never pull the cord to disconnect the appliance, instead grasp the

plug and pull it to disconnect.

 Do not allow the cord or the machine itself to come in contact with

hot surfaces.

 Position the equipment and the cord so that nobody can acciden-

tally overturn the equipment.

 Do not use the appliance if it has been dropped, or it has a dam-

aged power cord or plug. Do not modify or repair the machine
yourself.

 Do not dismantle the appliance as improper assembly might result

in an electric shock during the subsequent use of the equipment.

Repairs should only be done by authorized service cen­ters.

 Do not use the appliance where the air may contain volatile flam-

mable substances.

 This equipment is intended for household use only, not for com-

mercial or industrial use.

 Please follow all the requirements of this guide.
 Do not use the appliance if it has mechanical defects (dents, cracks

etc.), get it checked by the nearest authorized service center.

 Only use attachments supplied with the equipment.

4

SPECIAL SAFETY MEASURES

 Care should be taken to prevent foreign objects
from entering the appliance as they may cause motor
failure and premature breakdown of the appliance
as well as electric shock.
 Never cover the appliance during use. When us­ing the hairdryer, make sure the air filter is clean and
not blocked.

 Switch the appliance off when not in use even if it is for a short

period of time.

 Do not use the appliance near a bathtub, washbasin, pool or other

sources of water.

 Avoid direct contact between attachments and your skin.
 For extra safety we recommend the installation of a residual cur-

rent device (RCD) with a tripping current of no more than 30 mA
in the mains circuit of the bathroom. Consult a qualified electrician
for help.

 This appliance is equipped with an automatic overheat protection.

When overheated, the appliance will switch itself off. In cases of
overheating unplug the appliance from the wall outlet. Let the ap­pliance cool down for several minutes and then plug it in again.

DESCRIPTION OF THE

APPLIANCE

1. Hair dryer housing

2. Hair dryer operating mode switch
O – the appliance is switched off;
I – warm airflow for light curling and mild hair
drying;
II – hot airflow for strong and intensive hair
curling and drying;
– cold airflow to fix the styling and preserving hair elastic­ity.

3. Attachment release button

4. Concentrator

5. Straightener

6. Massage brush to dry the hair

7. Small diameter round styling brush

8. Large diameter thermal brush with retractable bristle
a) Head

9. Large diameter curling-irons with velvety surface
b) Lever
c) Clamp
d) Working area

10.Rotating power cord

11.Pouch

ENGLISH

5

BEFORE USE

Remove all packing materials from the appli-

ance.

INSTRUCTIONS FOR USE

1. Insert the appropriate detachable dryer attach­ment (4,5 6, 7, 8 or 9) into the housing (1) until a
click is heard. Make sure the attachment is firmly
fixed.

2. Select the desired operation mode by setting the
switch (2) into the appropriate position (I, II or ).

4. For convenient use of the appliance the power cord (10) can be

rotated 360°, which prevents it from getting twisted.

5. In order to remove the attachments from the housing (1), push the

button (3) and pull the attachment and the housing (1) in opposite
directions.

 Concentrator (4) may be used to dry or style hair with a comb.

Separate a strand of hair and stretch it with a comb, while drying
the hair with the dryer with attached thickener (4).

 Hair straightener (5) helps you to make even very curly hair

straight. Dampen your hair, separate a strand, fix it between metal
working areas at the hair roots and pull towards the hair ends. For
perfect results use some styling gel on the hair prior to straighten­ing.

 Massage brush to dry the hair (6) helps you to dry the hair

while preserving the natural hairdo. At the same time it massages
the head skin and stimulates blood circulation and hair growth.

 Small diameter round styling brush (7) helps you to add

volume to the hair and curling at the hair ends. Switch the appli­ance on and one by one comb damp hair strands from their roots
to the very ends while slightly curling them.

 Large-diameter thermal brush (8) helps you to create loose

waves in medium length hair. Put a damp thin strand of hair on the
brush (8) and dry it using mode II. Then switch on the cold airflow
mode for several seconds to fix the curl. Carefully release the
strand by rotating the head (a) counterclockwise: the bristle will
retract inside the thermal brush (8) and the locks will easily be
released. After that turn the head (a) clockwise and the bristle will
return into the initial position. Similarly curl the rest of the hair.
Also with the help of the thermal brush (8) you can easily curl the
end of the hair: styling is made quick and easy because of the heat
in the metal working area of the thermal brush (8) and is assisted
by the hot air.

 Large diameter curling-irons (9) with velvet surface gently

3. Start drying and styling your hair.

Use of attachments

6

but firmly holds the hair and allows the styling of long hair. Push
the lever (b) to slightly raise the hair clamp (c). Insert hair strands
between the working area (d) and the clamp (c). Rotate the
appliance’s housing (1) so that the strands of hair are wound onto
the working area of the curling–irons (d). Keep the strand on the
curling –irons for 15-30 seconds, then switch the
5-10 seconds to fix the style and make the hair glossy. Carefully
release the strand by slightly raising the lever (b).

mode on for

CLEANING AND CARE

1. Always unplug the appliance and let it cool
down before cleaning.

2. Clean the dryer housing with a soft damp cloth.
Prevent water or other liquids from getting inside
the appliance.

3. After each use of the dryer remove any hairs
from the attachments and then wash them with

warm soapy water, if necessary.

4. Assemble the dryer only when all components are dry.

5. For easy use and storage the dryer is equipped with a pouch (11).

USEFUL TIPS

Hair care

 To keep your hair healthy, we recommend you to
make and use weekly, the following nutritional mask:
mix two eggs and 2 tablespoons of burdock oil and
apply to dry hair from the roots to the ends. Wrap the
hair with a towel, wait for 30 minutes and then thor­oughly shampoo the hair (repeat twice, if necessary).

 Use the following mixture as a hair rinse to make the hair shine:

mix strong infusion of medicinal herbs with the yolk of an egg, if
your hair is dry, or with the white of an egg if you have normal or
oily hair (chamomile is great for light hair, sage – for dark hair).
Apply the mixture to the hair and thoroughly massage the head;
then thoroughly wash the hair. This recipe is has a double thera­peutic action: the mixture stimulates the growth of the hair, which
then becomes glossy and manageable.

ENGLISH

DISPOSAL

This appliance should be disposed of in accor­dance with waste disposal regulations in your coun­try and with the least damage to the environment.

Only ecologically safe materials are used in the
packaging of our products and the cardboard and
paper can be disposed of with normal paper waste.

7

AFTER-SALES SERVICE

If your appliance does not operate at all or
operates poorly, call an authorized service cen­ter for help or repairs.

The warranty does not cover the fol­lowing:

 Non-observance of the above safety mea-

 Commercial use (use outside the scope of personal household

needs).

 Plugging into a mains socket with a voltage different from the volt-

age on the appliance rating plate.

 Improper care; ingress of liquid, dust, insects, and other foreign

items and substances inside the appliance).

 Use of excessive force during appliance operation or other dam-

ages (mechanical damages resulting from incorrect use, shocks or
dropping of the appliance).

 Unauthorized repairs or replacement of the appliance parts per-

formed by an unauthorized person or service center.

 Accidents, such as lightning strike, flood, fire and other acts of God.

sures and operation instructions.

8

ENGLISH

Features may be changed by Binatone without any notice.
Warranty details are set out in the warranty card provided with

the product.

Exploitation period: 3 years after the day of purchase.
Manufacture: Binatone Industries Ltd, Great Britain, Vitabiotics

House,1 Apsley Way, Staples Corner, London, NW2 7HF, UK.
