Bluetooth Car kit (GCKBTBO)
Quick Start Guide
2346 5
Product Parts
1
1. Talk button
2. Stop button
3. Volume up button
4. Volume down button
5. OLED Display
6. Power ON/OFF
Man Machine Interface
1. Switch Power Function
Switch Power Action Function
Power ON Switch Up System Power ON
Power OFF Switch Down System Power OFF
2. Button Function
Button Action Function
Volume UP Short Click To increase the volume
Volume Down Short Click To decrease the volume
Press and hold for
MIC Mute function
longer than 2
seconds
Talk
Short Click Answer an incoming call
Short Click Voice recognition dial
Short Click To establish an RFCOMM with a paired AG if the
Car kit is in standby mode.
Short Click Audio Transfer from AG to Car kit or from Car kit
to AG
Press and hold for
longer than 2
To send “Last Number Redial” request to AG if
RFCOMM is established.
seconds
Stop
Short Click Enter pairing mode if the Car kit is in standby mode.
Short Click Hang up an active call
Short Click To Reject the incoming call if the Car kit is an
incoming call
2
