BiPAC GS08
8-Port Gigabit Green Ethernet Switch
User Manual
FCC Certifications
This Equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct
the interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received; including interference that may cause undesired operation.
CE Mark Warning
This equipment complies with the requirements relating to
electromagnetic compatibility, EN 55022 class A for ITE, the essential
protection requirement of Council Directive 89/336/EEC on the
approximation of the laws of the Member States relating to
electromagnetic compatibility.
Company has an on-going policy of upgrading its products and it may
be possible that information in this document is not up-to-date. Please
check with your local distributors for the latest information. No part of
this document can be copied or reproduced in any form without written
consent from the company.
Trademarks:
All trade names and trademarks are the properties of their respective
companies.
Copyright © 2008, All Rights Reserved.
1
The device is a powerful, high-performance Gigabit Ethernet switch,
with all ports capable of 10, 100 or 1000Mbps auto-negotiation
operation (NWay), which means the switch could automatically
negotiate with the connected partners on the network speed and
duplex mode. It is ideal for micro-segmenting large networks into
smaller, connected subnets for improved performance, enabling the
bandwidth demanding multimedia and imaging applications. Moreover,
the 10/100/1000Mbps auto-sensing ability provides an easy way to
migrate 10/100Mbps to 1000Mbps network with no pain. Compared to
the shared 10Mbps or 100Mbps networks, the switch delivers a
dedicated 10/100/1000Mbps connection to every attached client with
no bandwidth congestion issue. This switch also supports auto MDI /
MDI-X function. Each port could be used to connect to another switch
or hub with no crossover RJ-45 cable.
Store-and-forward switching mode promises the low latency plus
eliminates all the network errors, including runt and CRC error packe ts.
To work under full-duplex mode, transmission and reception of the
frames can occur simultaneously without causing collisions as well as
double the network bandwidth.
The switch provides 9K bytes jumbo frames, which means the frames
size is larger than normal 1.5K. With the Jumbo frame function, you can
get better network performance, because the switch can send more
data at the same time.
The switch is plug-n-play without any software to configure and also
fully compliant with all kinds of network protocols.
Before you start to install the switch, check the following contents in this
package：
z One Gigabit Ethernet switch
z One power adapter
z User’s manual
2
Please refer to the following table for LED definition:
8-Port Gigabi t Switch
1 2 3 4 5 6 7 8
POWER ▬ ▬ ▬ ▬ ▬ ▬ ▬ ▬ ▬ LINK/ACT
LED Status Operation
Power Steady Green Power is on
Off Power is off
Link/ACT Steady Green Port Connected
Blinking Green The port is transmitting/receiving data
3
Connect each station to the switch by twisted-pair cable. Plug one
RJ-45 connector into a RJ-45 port of the switch, and plug the other
RJ-45 connector into the station’s network adapter. Power on the
switch and then system is ready.
For cable selection, refer to the following table.
In making a switch interconnection, you could use any port to connect
another switch with straight or crossover cable. As all the ports support
auto MDI / MDI-X function, using a straight cable to make a
switch-to-switch connection is allowed.
For cable selection, refer to the following table:
Network Speed Cable Type Max. Length
10Mbps CAT. 3, 4, 5 UTP/STP 100 meters
100Mbps CAT. 5 UTP/STP 100 meters
1000Mbps CAT. 5e, 6 UTP/STP 100 meters
4
Standard IEEE 802.3 10BASE-T
Interface 8* 10/100/1000Mbps RJ-45 Gigabit Ethernet
Uplink
Network
Speed
MAC Addr.
Table
Buffer
Memory
Jumbo
Frame
Power
Supply
EMI CE, FCC, and VCCI class A
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3x full duplex operation and flow
control
ports
Auto MDI/MDI-X（Auto crossover）
10/100/1000Mbps & Full/Half duplex mode auto
detection (1000Mbps for Full duplex only)
4K MAC entries
1M bits
9K bytes
External Power Supply
12V 1A
