DS-4 / DS-10
OPERATION MANUAL
May 2019
585.0252.90C
DS-4 / DS-10 Product Description
The DS-10 is a desktop networked paging station featuring embedded DSP and on-board memory,
supporting both standard and advanced public address functionality. All device-specific configuration
information is stored locally, which means the DS-10 does not rely on a centralized controller for
processing and page routing.
The DS-4 is a desktop networked paging station featuring embedded DSP and on-board memory,
supporting both standard and advanced public address functionality. All device-specific configuration
information is stored locally, which means the DS-4 does not rely on a centralized controller for
processing and page routing.
DS-4 / DS-10 Setup and Installation
Setup and Use
The Vocia software provides an intuitive interface for configuration, DSP equalization and programming of
the DS-4 and DS-10 components. The information supplied by this manual relates to physical
connections and assignment. For more details on software setup, please consult the Vocia Help File.
Installation
Install the unit away from heat sources, such as vents and radiators, and in rooms with adequate
ventilation. Ensure that air can circulate freely behind, beside, and above the unit. Do not exceed the
maximum ambient operating temperature of 32°-113° F (0° -42°C). Be aware of conditions in an enclosed
rack that may cause the temperature to exceed ambient room conditions.
