Biamp RED-1 User Manual

®

Audia® & Nexia

RED-1 & RED-1F

Operation/Installation

Manual

Biamp Systems, 9300 SW Gemini Drive, Beaverton, OR 97008 U.S.A. [phone] www.biamp.com

TABLE OF CONTENTS

REMOTE ETHERNET DEVICE 1 (RED-1) FEATURES .......................................3

Setup and Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

FRONT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Capacitive-touch Scroll Wheel ........................................................................4

BACK PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Connectors ........................................................................................5

SET UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8

Device Setup Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Edit Network Conguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Edit Lock Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Edit Display Brightness .............................................................................8

Edit Timeouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

View Device Information .............................................................................8

Exit ..............................................................................................8

INSTALLATION ................................................................................ 9-12

SPECIFICATIONS ................................................................................13

WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

2

REMOTE ETHERNET DEVICE 1 (RED-1)

RED-1 Remote Ethernet Device is a remote control for Audia® and Nexia® systems. It offers a simple, intuitive interface for end users and

can be installed and congured to t the unique needs of a particular application. The device connects via standard Ethernet cabling and is
powered over Ethernet, eliminating the need for custom cabling and local power sources. Multiple remote control panels can be connected
over large distances using standard network technology.

Features

Adjustment and/or initiation of up to 32 selectable system volumes and actions•
Volumes are any individual or grouped system levels, including inputs, outputs, matrix cross-points, etc.•
Actions are any individual or grouped system operations, including presets, source selection, mutes, ducking, combining, etc.•
Control functions are programmed in the Audia and Nexia system design software •
High contrast OLED (Organic Light-Emitting Diode) display with a wide viewing angle•
The display brightness can be adjusted to t the ambient light present in the application and can automatically dim when not in use•
Capacitive touch technology eliminates protruding and moving parts to increase product reliability and longevity while •
simplifying cleaning
RED-1 surface mounts or ush mounts to most walls with a wide variety of mounting holes to accommodate standard US and •
international back boxes. RED-1F ush-mounts to any wall; mounts using the retrot plate (included) or installs in a Raco® 254

box for North American installation (not included).
330' (100m) Ethernet cable length can be extended with standard PoE network technology (routers, switches, hubs, •
media converters)
Connects with standard RJ45 or insulation displacement connector (IDC)•
Covered by • Biamp Systems’ ve-year warranty

RED-1F RED-1

3

RED-1 FRONT PANEL

Select

Scroll

Latch

Setup and Use

The Audia and Nexia software provides an intuitive interface for setup and programming of the RED-1. The information supplied by this
manual relates to physical connections and device setup. For more details on software setup, please consult the Audia or Nexia Help File.

Display

A graphic OLED (Organic Light-Emitting Diode) display with white characters on a black background shows a list of all control items avail­able from that panel, as well as the last selected item. If a control item includes a volume control assignment, the bottom of the display will
show a graphical representation of a volume bar with the current level indicated to the right (percentage of maximum level).

Capacitive-touch Scroll Wheel

The capacitive-touch sensor provides a sleek interface for menu navigation and selection. The glossy-nish nger groove allows for scrolling
through and selecting available control items, as well as adjusting volume.

4

RED-1 BACK PANEL

RED-1

Ethernet switch
with PoE

RED-1

Ethernet switch
without PoE

AC Power

PoE

injector

Connectors

Two Ethernet connectors—one rear-facing RJ45 and one top-facing insulation displacement connector (IDC)—are provided for
connecting to the network. Only one connector may be used. The RJ45 and IDC utilize unshielded twisted pair (UTP) wiring to connect
to an Audia or Nexia system. This connection is made to the Ethernet port of an Audia or Nexia unit, either directly (single station)
or via a network switch, and carries control data over Ethernet.

The RED-1 is powered using IEEE 802.3-2008 Power over Ethernet protocol as Class 1 devices. Either a PoE-capable network switch
or a PoE injector is required to power the device; there are no other provisions for power inlet.

5

RED-1 SET UP

Device Setup Mode

The RED-1 can be congured without connecting to a functional Audia or Nexia network. To enter setup mode, connect the RED-1 to a
PoE source and place the jumper or any metal object across the locksmith pins. When conguration is complete, remove the jumper and
attach it to only one pin to resume normal operation. Please note: many of the conguration settings can be accessed via the Audia or

Nexia software.

Locksmith: Bridge jumper

pins to enter setup mode

The cursor has two modes: select and modify. In select mode, the cursor appears as a gray box. When scrolling through the available
items in the list, the gray box will highlight the current selection.

“Select” mode in device
setup menu

On elds that can be modied, use the Select button to transition to and from modify mode. In modify mode, the cursor appears as an
outline box. Use the scroll wheel to adjust the setting up or down.

“Modify” mode in device

setup menu

Some screens have additional buttons that are used to accept (OK), reset, or cancel changed settings. Use the scroll wheel to navigate
the cursor to these buttons and press the Select button. The OK button saves the setting and exits the screen. The Reset button clears
the setting and does not save it. The Cancel button exits the screen without saving the setting.

6

RED-1 SET UP

Edit Device ID

To name the unit, scroll to the ID Tag icon and press the Select button. Use the scroll wheel and Select button to choose the desired
characters. The Device ID must match that of a corresponding block in the Audia or Nexia design. More than one unit may be identied
with the same design block (same ID). Device IDs may also be assigned via Device Maintenance in the Audia or Nexia software.

Edit Network Conguration

To edit the network conguration, scroll to the Network icon and press the Select button. The default setting (Static) initializes the
IP address to 192.168.1.201, network mask to 255.255.255.0, and gateway to 0.0.0.0. These default settings allow RED-1 to be discovered
by an Audia or Nexia device that also has default settings. Network settings may also be assigned via Device Maintenance in the Audia

or Nexia software.

Edit Lock Code

To set password protection, scroll to the Key icon and press the Select button. Use the scroll wheel and Select button to choose the desired
characters. During normal operation, holding down the Select button for two seconds will lock the unit, and the user will be prompted for
the Lock Code before obtaining access. Lock Codes may also be assigned via Device Maintenance in the Audia or Nexia software.

7

RED-1 SET UP

Edit Display Brightness

To change the brightness of the OLED panel, scroll to the Display Brightness icon and press the Select button. Use the scroll wheel
and Select button to make adjustments. The rst setting represents the normal operational display brightness, and the second setting
represents the dim display brightness. Display brightness cannot be assigned via Device Maintenance in the Audia or Nexia software.

Edit Timeouts

To change the lock, dim, and sleep timeouts, scroll to the Timeout icon and press the Select button. Use the scroll wheel and Select
button to make changes. For lock and dim, the timeout can be none or range from 5 seconds to 30 minutes; for sleep, the timeout cannot
be none. Timeouts may also be assigned via Device Maintenance in the Audia or Nexia software.

View Device Information

To view information about the unit, scroll to the Information icon and press the Select button. The Serial Number, MAC Address,
Firmware Version, and System ID are displayed. This is read-only information. The Serial Number is helpful in identifying physical units/
locations when naming them via Device Maintenance in the Audia or Nexia software. Press the Select button again to exit this screen.

Exit

To exit the setup screen, scroll to the Exit Door icon and press the Select button.

8

RED-1 INSTALLATION

Surface Mount Installation

The RED-1 surface mounts to most walls and has a wide variety of mounting holes that accommodate standard US and International
back boxes.

84mm 3.3"

USA, Japan, Australia EUR

including Germany, Sweden,

Use a screw driver or other suitable tool to engage the latch at the bottom of the RED-1 to detach the back enclosure. When installing
the RED-1 using the RJ45 connector, guide the Ethernet cable through the rear opening before attaching the RED-1 to the wall. Connect the
RJ45 and snap the front enclosure into the retention holes. When installing the RED-1 using the IDC, use a drill bit to create a hole
in the top, side, or rear of the back enclosure along the indentations. Remove the Ethernet cable jacket and shielding.

Indentations

Wire here for use with IDC

60mm

2.36"

UK, Netherland

84mm

3.3"

Italy

9

RED-1 INSTALLATION

Flush Mount Installation

The RED-1F may be ush mounted using the retro-t plate (provided with the product) or a Raco™ 254 box (purchased from an electrical
distributor). To install the RED-1F, a hole must be cut in the wall to accommodate the Raco™ 254 back-box or to use the retro-t plate. See
the gures below.

11.75cm

4 5/8″

4 3/4″

12.07cm

Wall cut out dimensions

Mounting using a Raco™ 254 back box Mounting using the retro-t plate

10

Retro-Fit Plate

RED-1 INSTALLATION

Raco™ 254

Trim Ring

Front Plate

Exploded view showing pieces required for mounting to the retro-t plate

or the Raco™ 254 back-box

When installing the RED-1F using the retro-t plate or the back-box, fasten the trim ring using the four screws provided to either the retro­t plate or the back-box. Once the trim ring has been fastened to the retro-t plate or the back-box, guide the RED-1F front plate at an
angle into the top of the trim ring to seat the tabs on the top of the front plate. Once this has been done rotate the bottom of the front plate
towards the bottom of the trim ring until it is seated in the trim ring via the bottom clip.

If the front plate needs to be removed use a screw driver or other suitable tool to engage the latch at the bottom of the RED-1F to detach
from the trim ring.

Refer to page 12 for instructions regarding the use of the insulation displacement connector.

11

RED-1 INSTALLATION

Connect the wire according to the color code silkscreened as text next to the IDC or as shown on the label on the back enclosure
(see gure below). The color code uses the T568A standard for wiring. When using the T568B wiring scheme, please note that the orange
wire pair (OR and WH/OR) and green wire pair (GR and WH/GR) need to be swapped. After inserting the wires, press the tabs until the
insulation is punctured with an audible click. No wire stripping is necessary.

Insulation Displacement Connector (IDC)

Note the appropriate bend radius requirements for category cables as shown in the gure below.

Figure X: IDC wiring scheme

Software support in Audia conguration software Version 5.1 and Nexia Version 3.1 or later provides user programming of all remote
functions, network setup, device naming, and device maintenance.

Visit www.biamp.com/support.php to obtain rmware and software updates related to this product. To speak with a Product Applications
Engineer, please call 1-800-826-1457 or email [e-mail].

585.0268.90B

12

SPECIFICATIONS (RED-1)

Dimensions
(Length x Width x Depth):

5.1 inches x 4.7 inches x 1.25 inches (130mm x 120mm x 32mm)

RED-1 SPECIFICATIONS

Weight:

Power consumption:

Material:

Control cable requirements:

Control cable length:

Devices per system:

Remote Ethernet Devices
(including NPS-1) per system:

Remote Ethernet Devices
per Audia or Nexia unit:

Control wiring topology:

Control programming:

Compliance:

0.5 lb

PoE Class 1 (3.2W max)

PC/ABS

Unshielded twisted pair (UTP) wiring, 100BaseT interface using either RJ45 or Insulation Displacement Connector (IDC)

330 ft. (100m) Ethernet cable length can be extended with standard PoE network technology

128

24

Standard Ethernet network wiring

Each control configured for specific operation by the system design software

EU Directive 2002/95/EC, RoHS Directive
CE marked
FCC

SPECIFICATIONS (RED-1F)

Dimensions

Power consumption

Control cable requirements

Control cable length

Control wiring topology

Control programming

Compliance

6.22"H x 5.82"W x 0.5"D (158mm x 148mm x 12.7mm)

PoE Class 1 (3.2W @ full display utilization)

CAT-5/6/7 Ethernet cable using either RJ-45 or IDC connector

330' (100m) Ethernet cable length can be extended with standard PoE network technology

Standard Ethernet network wiring

Each control configured for specific operation by the system design software

EU RoHS Directive 2002/95/EC; CE; FCC

13

RED-1 WARRANTY

BIAMP SYSTEMS IS PLEASED TO EXTEND THE FOLLOWING 5-YEAR LIMITED WARRANTY TO THE ORIGINAL PURCHASER OF
THE PROFESSIONAL SOUND EQUIPMENT DESCRIBED IN THIS MANUAL

1. BIAMP Systems warrants to the original purchaser of new products that the product will be free from defects in material and
workmanship for a period of 5 YEARS from the date of purchase from an authorized BIAMP Systems dealer, subject to the

terms and conditions set forth below.

2 If you notify BIAMP during the warranty period that a BIAMP Systems product fails to comply with the warranty, BIAMP Systems

will repair or replace, at BIAMP Systems’ option, the nonconforming product. As a condition to receiving the benets of this warranty,
you must provide BIAMP Systems with documentation that establishes that you were the original purchaser of the products. Such
evidence may consist of your sales receipt from an authorized BIAMP Systems dealer. Transportation and insurance charges to
and from the BIAMP Systems factory for warranty service shall be your responsibility.

3. This warranty will be VOID if the serial number has been removed or defaced; or if the product has been altered, subjected to
damage, abuse or rental usage, repaired by any person not authorized by BIAMP Systems to make repairs; or installed in any
manner that does not comply with BIAMP Systems’ recommendations.

4. Electro-mechanical fans, electrolytic capacitors, gooseneck microphones, cords connecting handheld microphones, hard-drives,
displays, and normal wear and tear of items such as paint, knobs, handles, keypads and covers are not covered under this war-

ranty. All server-based devices are warranted for 3 years only.

5. This warranty is in lieu of all other warranties, expressed or implied. BIAMP Systems disclaims all other warranties, expressed or
implied, including, but not limited to, implied warranties of merchantability and tness for a particular purpose.

6. The remedies set forth herein shall be the purchaser’s sole and exclusive remedies with respect to any defective product.

7. No agent, employee, distributor or dealer of BIAMP Systems is authorized to modify this warranty or to make additional warranties on

behalf of BIAMP Systems. Statements, representations or warranties made by any dealer do not constitute warranties by BIAMP
Systems. BIAMP Systems shall not be responsible or liable for any statement, representation or warranty made by any dealer or
other person.

8. No action for breach of this warranty may be commenced more than one year after the expiration of this warranty.

9. BIAMP Systems shall not be liable for special, indirect, incidental, or consequential damages, including lost prots or loss of use

arising out of the purchase, sale, or use of the products, even if BIAMP Systems was advised of the possibility of such damages.

14

EC DECLARATION OF CONFORMITY

 DoC RED201007



EC Declaration of Conformity

Biamp Systems Corporation, as manufacturer having sole responsibility, hereby
declares that the following described product complies with the applicable provisions of
the DIRECTIVES below except as noted herein. Any alterations to the product not
agreed upon and directed by Biamp Systems Corporation will invalidate this declaration.

Product Models

: RED-1, RED-1F

Product Description

: Control Accessories for use with audio DSPs.

Applicable EC Directives: Applicable Harmonized Standards:

LVD Directive (2006/95/EC) Safety EN 60065:2002

EMC Directive (2004/108/EC) Emissions EN 55103-1:1996, Environment E2
Immunity EN 55103-2:1996

Special Considerations for Product Environment or Compliance:

Shielded cabling must be used for system connections.

Use only CE marked Power over Ethernet (PoE) device.

Technical Construction File, Location and Contact:

Biamp Systems, Inc. phone: [phone]
9300 S.W. Gemini Drive fax: [phone]
Beaverton, OR USA 97008 e-mail: [e-mail]

Authorized Representative: Larry Copley, Compliance Engineer

Authorized Signature:

Issued: July, 2010

15

COMPLIANCE

(This information is presented to comply with the requirements of Chinese law SJ/T11363-2006)”

有害物质表

Biamp Systems Corporation

远程控制设备 (Remote Control Device)

RED-1, RED-1F

部件名称

󰥎󰱆󰥎󰈣󰾼质或元󱘼

Pb 铅Hg汞Cd 镉Cr+6

六价铬

PBB PBDE

设备机箱(EquipmentChassis)

X O X O O O

手册和其他书面文档 (Manual and Paper Documents)

O O O O O O

包装箱和所有包装材料 (Box and Packing Materials)

O O O O O O

0：表示该部件所有均质材料中的这种有毒有害物质低于 SJ/T11363-2006 的限制要求.

X：表示该部件中至少有一种均质材料所含的这种有毒有害物质高于 SJ/T11363-2006 的限制要求.

在电触头和（或）镀镉所含的均质材料中，镉及其化合物的含量可以超过 0.01%，但欧盟指令 91/338/EEC（根据欧盟指令
76/769/EEC）限制销售和使用某些危险物质和制剂部分中所禁止的用途除外

在以下一种或多种物质所含的均质材料中，铅及其化合物的含量可以超过 0.1%:

1) 电子元器件中玻璃内所含的铅

2) 铅在钢材中是作为一种合金元素，含量可达 0.35%

3) 铅在铝材中是作为一种合金元素，含量可达 0.4%

4) 铅在铜材中是作为一种合金元素，含量可达 4%

5) 高熔点类焊料中的铅（即铅料合金，铅含量超过 85%）

6) 电子陶瓷部件内的铅

7) 由两种以上元素组成的焊料中所含的铅，用于连接针脚和微处理器包装，其中
铅的含量超过 80% 但低于 85%

8) 顺应针连接系统内的铅

9) 󱳾󱥭󰾣󰉞󱳾导󱥭󰾣载体之间形成󲓸连󰜳󰙓󱅋焊料中󱈼



在正常使用情况下，中国环保使用期限为 10 年，条件是：

• 环境温度为 0-40C (32-104°F)

• 湿度为 0-95%，无凝结

• 海拔高度为 0-10,000 英尺

• 气流不受阻碍

• 没有水或其他液体进入任何部件

• 电源为 IEEE 802.3af PoE

• 部件没有损坏（损坏部件应立即修理）

• 󱅒󰍠󰜝󱅋󰙶󱈼󰥻󰡒󱲶󰙓󰥎



EU RoHS COMPLIANT

This Biamp product, including all attendant cables and
accessories supplied by Biamp, meets all requirements of EU
Directives 2002/95/EC of January 27, 2003, and 2005/618/EC
of August 18, 2005, the EU RoHS Directives. An EU RoHS
Materials Content Declaration document may be obtained at
www.biamp.com



16
