I SERIES
BalancePoint™ Flyware Guide
Refer to the I SERIES BalancePoint™ Flyware Accessory Guide for an
inclusive installation guide for all of the kits. Clicking on each of the blue
model numbers will bring up the individual kit assembly instructions.
BalancePoint™ Fly Rails
BFR22H: BalancePoint™
Horizontal Fly Rails
- fly a single enclosure
(landscape orientation)
BFR22V: BalancePoint™
Vertical Fly Rails
- fly a single enclosure
(portrait orientation)
Horizontal Array Kits
IAF40 (1122/1152), IAF55 (1153):
Isometric Array Frames - for two to
three loudspeakers in portrait or
landscape orientation
(Requires U-Brackets or Vertical yokes)
SBR54: Subwoofer behind
BalancePoint™ Fly Rails (54")
- adds one or two subwoofers
behind any array configuration
HAB-BFR38 (1122/1152), HAB3-BFR38 (1153):
Horizontal Array Brackets with
BalancePoint™ Fly Rails Kit - to array two
full-range cabinets with a subwoofer in
between
Array Accessory Kits
DFS: Downfill Splay Bracket - to add a
downfill loudspeaker to any array
HVS (1122/1152), HVS3 (1153):
Horizontal/Vertical Splay Brackets
- to add one additional loudspeaker
to an array
HSB-BFR22 (1122/1152), HSB3-BFR22
(1153): Dual Horizontal Splay Kits
- horizontally array two full-range
models
Vertical Array Kits
VSB-BFR22 (1122/1152), VSB3-BFR22
(1153): Vertical Splay Kits - to
vertically array two full-range models
VAB-BFR38 (1122/1152/1153): Vertical
Array Brackets with BalancePoint™ Fly
Rails Kit - mount and aim a full-range
cabinet under a subwoofer
HSB-SBR54 (1122/1152), HSB3-SBR54 (1153):
Horizontal Splay Brackets with BalancePoint™
Fly Rails Kit - to array two full-range
loudspeakers with subwoofer(s) behind
VSB-SBR54 (1122/1152), VSB3-SBR54 (1153):
Vertical Splay Brackets with BalancePoint™ Fly
Rails - to array two full-range loudspeakers
with subwoofer behind
DVS-BFR22: Dual Vertical Splay with
BalancePoint™ Fly Rails
- to vertically array and aim two
loudspeakers or loudspeaker/
subwoofer combination (Can also be
used with one or two U-Brackets)
biamp.com
14DEC2020
U-Brackets and Vertical Yokes IV6 Rigging
IUB1122 (IP6/IP8-1122)
IUB1152 (IP6/8-1152)
IUB1153 (IP8-1153): Indoor
U-Brackets - mount and aim
single full-range loudspeakers
IVY1122 (IP6/8-1122)
IVY1152 (IP6/8-1152)
IVY1153 (IP8-1153): Vertical yokes
- vertically mount and aim
single full-range loudspeakers
(model specific)
IUB1122WRG (IP6/8-1122WR, IS6/8-212WR)
IUB1152WRG (IP6/IP8-1152WR)
IUB1153WRG (IP8-1153WR, IS6/8-215WR, IS6/8-
218WR)
IUB0002WRG (IP8-115WR, IP8-0002WR, IS6/8-
1152WR, IS6/8-118WR)
IUB112SWRG (IS6/8-112WR): Stainless steel
U-Brackets or weather-resistant versions of
loudspeakers and subwoofers
Note: Weather-resistant (WRG) U-Brackets are
wider than indoor brackets. They can be used with
their respective indoor loudspeakers,
but will need spacers to make up the
dierence when installed.
IV6-GP-AF: Glidepoint™ Array Frame -
supports up to 16 1122 cabs or 9 subs
IV6-LAF-PBB: Light Array Frame/
Pullback Bar - supports up to 10
cabs
IV6-LAU: Light Array Frame
U-Bracket Adapter - used with
the IV6-LAF-PBB supports up
to 3 cabs
IUB1062 (IC6-1062)
IUB1082 (IC6-1082)
IUB2082 (IC6-2082): Indoor
U-Brackets - mount and aim IC6
compact loudspeakers
IUB1062WR (IC6-1062WR)
IUB1082WR (IC6-1082WR)
IUB2082WR (IC6-2082WR):
U-Brackets - mount and aim IC6
weather-resistant compact
loudspeakers
IVY1082 (IC6-1082)
IVY2082 (IC6-2082): Vertical yokes
- vertically mount and aim IC6
compact loudspeakers
IV6-SB-AF: Sub Behind
Array Frame - supports up
to 8 subs
PY1-EN750-1550: Lift Point
for Array Frame - provides
a lift point for IV6-GP-AF
biamp.com
14DEC2020
