RS-232 Control
of the
Advantage DRI
________________________________________________________________________________________
Biamp Systems, 14130 N.W. Science Park, Portland, Oregon 97229 U.S.A. (503) 641-7287
an affiliate of Rauland-Borg Corp.
Introduction
This document contains technical information relating to computer control of the Biamp
Advantage DRI Digital Remote Interface. This information is intended for advanced users
- in particular for those who wish to develop their own computer programs to control the
Advantage DRI. It is assumed that the reader is an experienced programmer and has
some familiarity with standard programming practices, binary and hexadecimal numbers,
the ASCII character set, asynchronous serial data communications, and RS-232 interfaces.
Hexadecimal, ASCII-Hex, and "Pseudo-Hex" Numbers
Throughout this document, hexadecimal numbers shall be represented by preceding the
number with "0x". For example: the hexadecimal equivalent of the decimal number 255 is
0xFF.
Individual ASCII characters, except control characters, will be enclosed in single quotes.
For example: the ASCII character 'A' has the hexadecimal value 0x41. The ASCII
"carriage return" control character shall be represented as ↵. An ASCII code chart is
included with this document for your convenience.
When an 8-bit binary data value is being transmitted over a serial data communications
link, it is a common practice to transmit the byte as two "ASCII-hex" characters - one
character represents the most significant nibble of the data value and the other character
represents the least significant nibble (a nibble is 4-bits; half of a byte). Each ASCII-hex
character is in the range of '0' thru '9' or 'A' thru 'F' (from the ASCII code chart, 0x30 thru
0x39 or 0x41 thru 0x46). For example, the hexadecimal equivalent of the decimal number
61 is 0x3D. To transmit this in an ASCII-hex format, first transmit the ASCII character '3'
(whose hex value is 0x33), followed by the ASCII character 'D' (whose hex value is 0x44).
This is the standard way to transmit an ASCII-hex value. In some cases, the lower case
characters 'a' thru 'f' (0x61 thru 0x66) are accepted in addition to the upper case letters 'A'
thru 'F'.
The Advantage DRI does not utilize standard ASCII-hex format. The DRI computer
commands implement what I call "pseudo-hex" notation (also sometimes referred to as a
"poor man's" ASCII-hex notation). Instead of representing the hexadecimal value using
the ASCII characters '0' thru '9' and 'A', 'B', 'C', 'D', 'E', and 'F', the pseudo-hex format uses
the ASCII characters '0' thru '9' and the characters ':', ';', '<', '=', '>', and '?'. As you can see
by studying the ASCII code chart, a binary nibble may be converted to its equivalent
pseudo-hex character by simply adding 0x30.
A binary/decimal/hexadecimal/pseudo-hex conversion chart is included at the end of this
manual for your convenience.
21-Jul-97
Computer Control of the Advantage DRI page 1
Data Communications Parameters
The Advantage DRI has a rear-panel dip-switch which allows you to set its baud rate to
either 2400, 9600, or 19200 bits per second. The factory default setting is 9600. The
Advantage DRI communicates with 8 data bits, no parity, and 1 stop bit. The Advantage
DRI utilizes a subset of the standard 7-bit ASCII character set.
The Advantage DRI utilizes interrupt-driven communications firmware with a 32character receive buffer. When the Advantage DRI receives a command, it may become
“busy” for as long as 200 milliseconds while it is executing the command. During this
time, the Advantage DRI can successfully receive up to 32 additional characters. If more
than 32 characters are sent to the Advantage DRI while it is busy executing a command,
its input buffer will be overrun and some characters will be “lost”.
To avoid overrunning the Advantage DRI’s input buffer, it is recommended that some
form of flow control be implemented. Neither hardware (DTR or RTS) nor XON/XOFF
(also known as DC1/DC3 or control-S/control-Q) handshaking is supported by the
Advantage DRI. However, each character which the Advantage DRI receives through its
serial port will be "echoed" back to the computer. A simple form of flow control may be
implemented by simply waiting for each character's echo from the Advantage DRI before
transmitting the next character, since the Advantage DRI doesn't retrieve and echo an
incoming character until it has finished processing the previous character.
Computer Control
The Advantage DRI has an RS-232-compatible serial port which allows it to be controlled
by a computer or by a system controller such as those provided by AMX or Crestron. The
Advantage DRI offers the following two methods of computer control:
• Control Button Emulation. This method of computer control allows the computer to
emulate Biamp's standard infrared remote control transmitter or wall-mount remote
control panel. Using this method, the computer outputs ASCII characters which are
equivalent to the characters which would be generated by a remote control connected
to the Advantage DRI. These ASCII characters are transmitted from the computer to
the Advantage DRI’s serial port. Control Button Emulation is simple to perform,
however, it only provides "one-way" control of the Advantage DRI - it allows the
computer to send simple commands to the Advantage DRI, but it does not provide any
mechanism for requesting status information from the Advantage DRI.
• Advanced Computer Control. This method of computer control provides advanced
commands which allow "two-way" control of the Advantage DRI. Using Advanced
Computer Control commands, the computer may request status information from the
device as well as send commands to the device. The computer communicates with the
Advantage DRI using the Advantage DRI’s serial port.
page 2 Computer Control of the Advantage DRI
21-Jul-97
Control Button Emulation
Control Button Emulation is the simplest form of computer control of the Advantage DRI.
This method of operation allows the computer to emulate the operation of a standard
Biamp remote control transmitter.
For each button on a standard Biamp remote control, there is a corresponding ASCII
character. In order to emulate a remote control button, the computer simply transmits the
corresponding ASCII character to the Advantage DRI’s serial port. Each character
received by the Advantage DRI will be echoed back to the computer.
The standard Biamp remote control devices never exceed a transmission rate of 9
characters per second. If the computer wishes to perform Control Button Emulation at a
rate of greater than 20 characters per second (50 msec per character), flow control should
be implemented by waiting for the echo of each character before transmitting the next
character. At slower speeds, flow control should not be necessary.
The following table summarizes the ASCII character codes for Control Button Emulation
corresponding to each of the 40 remote control buttons supported by the Advantage DRI.
These button codes are also summarized on the ASCII code chart provided at the end of
this manual. The remote control buttons on the standard Biamp transmitter are numbered
from left to right going from bottom to top with the lower left-hand button being button
number 1.
Control Button Emulation ASCII Codes (with factory default button definitions shown)
button 1 'B' (0x42) Vol Down ch.5
button 2 'C' (0x43) Vol Down ch.6
button 3 'D' (0x44) Vol Down ch.7
button 4 'E' (0x45) Vol Down Main output
button 5 'F' (0x46) Vol Up ch.5
button 6 'G' (0x47) Vol Up ch.6
button 7 'H' (0x48) Vol Up ch.7
button 8 'I' (0x49) Vol Up Main output
button 9 'J' (0x4A) Toggle Mute ch.5
button 10 'K' (0x4B) Toggle Mute ch.6
button 11 'L' (0x4C) Toggle Mute ch.7
button 12 'M' (0x4D) Toggle Mute Main output
button 13 'N' (0x4E) Vol Down ch.1
button 14 'O' (0x4F) Vol Down ch.2
button 15 'P' (0x50) Vol Down ch.3
button 16 'Q' (0x51) Vol Down ch.4
button 17 'R' (0x52) Vol Up ch.1
button 18 'S' (0x53) Vol Up ch.2
button 19 'T' (0x54) Vol Up ch.3
button 20 'U' (0x55) Vol Up ch.4
button 21 'V' (0x56) Toggle Mute ch.1
button 22 'W' (0x57) Toggle Mute ch.2
button 23 'X' (0x58) Toggle Mute ch.3
button 24 'Y' (0x59) Toggle Mute ch.4
button 25 'Z' (0x5A) Recall Preset 1
button 26 '[' (0x5B) Recall Preset 2
button 27 '\' (0x5C) Recall Preset 3
button 28 ']' (0x5D) Recall Preset 4
button 29 '^' (0x5E) Recall Preset 5
button 30 '_' (0x5F) Recall Preset 6
button 31 '`' (0x60) Recall Preset 7
button 32 'b' (0x62) Recall Preset 8
button 33 'c' (0x63) Vol Down ch.8
button 34 'd' (0x64) Vol Up ch.8
button 35 'e' (0x65) Toggle Mute ch.8
button 36 'f' (0x66) Vol Down Aux1 out ch.11
button 37 'g' (0x67) Vol Up Aux1 out ch.11
button 38 'h' (0x68) Toggle Mute Aux1 ch.11
button 39 'i' (0x69) Vol Down Aux In ch.9
button 40 'j' (0x6A) Vol Up Aux In ch.9
21-Jul-97
Computer Control of the Advantage DRI page 3
Device Select Prefix Characters
When using Advanced Computer Control, up to sixty-four Advantage DRIs may be linked
together and individually controlled by the computer (a rear-panel dip-switch is used to set
a unique device number to each unit). When using Control Button Emulation, a limited
subset of device addressing may be performed, which allows individual control of up to
four Advantage DRIs (with device numbers 1 thru 4). This is accomplished by
transmitting a device select prefix code immediately prior to each control button ASCII
character code. The device select prefix code is inspected by each device to determine
whether or not the device should react to the button code which immediately follows. If a
button code is not immediately preceded by a device select prefix character, then all
Advantage DRIs in the system will react to that button code. The following table
summarizes the ASCII characters to use for selecting various devices. This information is
also summarized in the ASCII code chart provided at the end of this manual.
Device Select Prefix Codes
select device 1 'l' (0x6C)
select device 2 'm' (0x6D)
select devices 1 & 2 'n' (0x6E)
select device 3 'o' (0x6F)
select devices 1 & 3 'p' (0x70)
select devices 2 & 3 'q' (0X71)
select devices 1 & 2 & 3 'r' (0x72)
select device 4 's' (0x73)
select devices 1 & 4 't' (0x74)
select devices 2 & 4 'u' (0x75)
select devices 1 & 2 & 4 'v' (0x76)
select devices 3 & 4 'w' (0x77)
select devices 1 & 3 & 4 'x' (0x78)
select devices 2 & 3 & 4 'y' (0x79)
select devices 1 & 2 & 3 & 4 'z' (0x7A)
page 4 Computer Control of the Advantage DRI
21-Jul-97
Advanced Computer Control
The Advanced Computer Control command set includes commands which allow the
Advantage DRI to return information about the system to the computer, unlike Control
Button Emulation which is basically a one-way control mechanism. The following list
summarizes the commands available using Advanced Computer Control, including the
ASCII command character associated with each command:
#
do-volume-action perform the specified volume action (up, down, mute, etc).
$
define-preset-mix define a preset mix and store it in non-volatile memory.
%
get-preset-mix retrieve the preset mix settings for the specified preset.
&
get/set-volume get or set the volume for the specified channel.
(
do-logic-action perform the specified logic output action (on, off, toggle).
)
do-preset-action perform the specified preset action (recall, store).
/
get-version retrieve the model information and firmware version date.
Each Advanced Computer Control command requires at least two parameter bytes (four
pseudo-hex characters) to be sent prior to the command character. Each command will be
explained in detail on the following pages.
Some of the commands cause the Advantage DRI to return information to the computer.
For each string of information returned to the computer, the Advantage DRI terminates
the string by transmitting the ASCII carriage return character (0x0D - represented in this
document as ↵ ).
As mentioned earlier, the Advantage DRI will echo all characters it receives, regardless of
whether or not the characters are valid commands or parameters. Characters greater than
0x7F are reserved and should not be transmitted by the computer. The Advantage DRI
utilizes a subset of the standard ASCII character set. The following characters have
meaning to the Advantage DRI:
21-Jul-97
Computer Control of the Advantage DRI page 5
character hexadecimal operation
ASCII control characters (0x00 - 0x1F) no operation
SPACE
ASCII
!
thru
0
thru
@
A
B
thru
a
b
thru
k
thru
{
thru
0x80 thru 0xFF (0x80 - 0xFF) RESERVED
character
/
?
`
j
z
DEL
(0x20) no operation
(0x21 - 0x2F) Advanced Computer Control
commands
(0x30 - 0x3F) pseudo-hex parameters for Advanced
Computer Control commands
(0x40) Control Button Emulation Repeat Code
(0x41) no operation
(0x42 - 0x60) Control Button Emulation commands
(buttons 01 - 31)
(0x61) no operation
(0x62 - 0x6A) Control Button Emulation commands
(buttons 32 - 40)
(0x6B - 0x7A) Control Button Emulation Device
Select Prefix commands
(0x7B - 0x7F) no operation
An ASCII code chart showing all Advantage DRI commands and codes is provided later
in this document for your convenience. Please note that all ASCII control characters
(including space, tab, carriage return, and line feed) will be echoed by the Advantage DRI
and then ignored - they have no special significance to the Advantage DRI.
Device Type Bitmask and Device Number Parameters
In a system which has more than one Advantage product connected to the computer, the
Device Type Bitmask and Device Number parameters provide a mechanism for the
computer to address a command to a particular device (or a combination of devices).
Every command in the Advanced Computer Control command set requires that a Device
Type Bitmask and a Device Number be transmitted as the last two parameter bytes before
the computer transmits the command character itself. These two parameter bytes provide
a device addressing capability to specify which of the devices in the system should execute
the command. All devices which are not specifically addressed by these two command
parameters will ignore the command.
The Device Type Bitmask parameter byte for the Advantage DRI is always 0x80. This
Device Type Bitmask is also shared with other Biamp devices, including the Advantage
EQ281/8, Advantage EQ282/8, and Advantage SMS200. It is anticipated that all new
devices developed by Biamp will utilize 0x80 as their Device Type Bitmask. Other Device
Type Bitmasks currently in use are:
0x01 Biamp Advantage DRC 4+4 digital remote control
0x02 Biamp Advantage EQ28X digitally-controlled graphic equalizer
0x04 Biamp Advantage SPM522D stereo preamp/mixer
0x08 Biamp Advantage PMX84 programmable matrix switch
page 6 Computer Control of the Advantage DRI
21-Jul-97
The Device Number parameter byte provides support for up to sixty-four devices,
numbered 0 thru 63 (‘00’ thru ‘3?’ in pseudo-hex). The Advanced Computer Control
command structure also supports a “broadcast” command, which allows you to send a
command to all devices which match the Device Type Bitmask. To send a “broadcast”
command, specify 255 (‘??’ in pseudo-hex) as the Device Number parameter.
Each Advantage DRI’s device number is assigned using rear-panel dip-switches. Except
for broadcast commands, any particular Advantage DRI will respond to an Advanced
Computer Control command only if bit 7 of the Device Type Bitmask is a ‘1’ and the
Device Number parameter matches its dip-switch settings.
21-Jul-97
Computer Control of the Advantage DRI page 7
Advanced Computer Control Data Structures
Preset Mix Status Data Structure
The data structure used for preset mixes consists of an array of 13 bytes (which are
transmitted as 26 pseudo-hex characters). Mix[0] through mix[11] represent the volume
level and mute status of channels 1 through 12. Mix[12] represents the status of the logic
outputs, and also has other special meanings for the "current" mix.
Advantage DRI Preset Mix Data Structure
13 -byte array with elements numbered mix[0] thru mix[12]
mix[12]
(transmitted first)
mix[11]
mix[10]
mix[9]
mix[8]
mix[7]
mix[6]
mix[5]
mix[4]
(msb) (lsb)
Logic2Logic
1
AUX1 OUTPUT/CH.11 VOLUME (0-100)Mute
MAIN OUTPUT/CH.10 VOLUME (0-100)Mute
Mix
Mod
CHANNEL 12 VOLUME (0-100)Mute
AUX INPUT/CH.9 VOLUME (0-100)Mute
CHANNEL 8 VOLUME (0-100)Mute
CHANNEL 7 VOLUME (0-100)Mute
CHANNEL 6 VOLUME (0-100)Mute
CHANNEL 5 VOLUME (0-100)Mute
Last Recalled
Preset
01234567
Note: Bits 0-5 of this byte
are only significant for the
"current" mix (0x80).
mix[3]
mix[2]]
mix[1]
mix[0]
(transmitted last)
CHANNEL 4 VOLUME (0-100)Mute
CHANNEL 3 VOLUME (0-100)Mute
CHANNEL 2 VOLUME (0-100)Mute
CHANNEL 1 VOLUME (0-100)Mute
page 8 Computer Control of the Advantage DRI
21-Jul-97
The volumes specified in mix[0] thru mix[11] have a range of 0 (minimum volume) thru
100 (maximum volume, ‘64’ in pseudo-hex). The Advantage DRI only recognizes evennumbered volume steps - if an odd number is specified for a volume, the Advantage DRI
will round it down to the next lower even number. For example, volume level 75 and
volume level 74 are exactly the same as far as the Advantage DRI is concerned.
Seven data bits are required to specify a number in the range of 0 to 100. The eighth data
bit (bit 7) is used to indicate the mute status for each channel. If bit 7 is a ‘1’, the channel
is muted (set to minimum volume) and the volume level specified in bits 0 thru 6 specify
what volume level the channel will return to if it receives an un-mute command.
Bit 6 of mix[12] indicates the status of logic output number 1 - a '1' in this bit means the
logic output is on, and a '0' in this bit means the logic output is off. When the Advantage
DRI is used to control and Advantage DLA93, logic output 1 connects to the DLA93’s
master/slave logic input. Turning off logic output 1 puts the DLA93 into master mode
and turning on logic output 1 puts the DLA93 into slave mode.
Bit 7 of mix[12] indicates the status of logic output number 2 - a '1' in this bit means the
logic output is on, and a '0' in this bit means the logic output is off. When the Advantage
DRI is used to control and Advantage DLA93, logic output 2 connects to the DLA93’s
automix/manual logic input. Turning off logic output 2 puts the DLA93 into automix
(gated) mode and turning on logic output 2 puts the DLA93 into manual (non-gated)
mode.
When the preset mix being specified is the "current" mix (mix number 0x80), bits 0 thru 3
of mix[12] indicate which preset mix was the last mix recalled and bit 4 of mix[12]
indicates whether or not the current mix has been modified since the last time a preset mix
has been recalled.
Advanced Computer Control Command Notation
For the following descriptions of the Advanced Computer Control command set, the
following conventions will be used. Each ASCII character which represents a pseudo-hex
nibble will be shown in italics, with the following letters representing certain types of
parameters:
a a pseudo-hex nibble specifying an action code.
d one of the pseudo-hex nibbles in the device number which indicates which device the
command is addressed to.
m one of the pseudo-hex nibbles occurring in the preset mix data structure.
n a pseudo hex nibble specifying a channel number, logic output number, or preset mix
number.
v one of the pseudo-hex nibbles specifying a volume level.
21-Jul-97
Computer Control of the Advantage DRI page 9
# do-volume-action
Description:
The do-volume-action command causes the Advantage DRI to perform the specified
volume action (volume up, volume down, toggle mute, mute, or un-mute) for the specified
channel.
Syntax of Command:
an80dd#
where:
a = Volume Action:
0 = NOP, 1 = vol down, 2 = vol up,
3 = toggle mute, 4 = mute, 5 = un-mute.
n = Channel Number (pseudo-hex):
1 - 8 = channel 1 - 8. 9 = Aux Input.
: = Main Output. ; = Aux1 Output. < = ch 12.
80 = Device Type Bitmask (pseudo-hex)
dd = Device Number (pseudo-hex)
# = do-volume-action command character (0x23)
Syntax of Response:
(no response)
Example:
2:8001#
This example causes Advantage DRI number 1 to increase the main output volume by one
step.
Comments:
The Advantage DRI supports 51 discrete volume levels or steps: 0 (minimum volume)
thru 100 (maximum volume) in increments of 2. On a 0 - 100 scale, each volume up or
volume down command increments or decrements the volume by 2 (one step).
The typical execution time for the do-volume-action command is 5 milliseconds (not
including the time required to transmit the command string).
page 10 Computer Control of the Advantage DRI
21-Jul-97
$ define-preset-mix
Description:
The define-preset-mix command provides a new definition for the specified preset mix.
The new preset mix is stored in the Advantage DRI’s non-volatile memory. This
command does not change the “current mix” (it does not immediately change any of the
volumes or logic outputs).
Syntax of Command:
mmmmmmmmmmmmmmmmmmmmmmmmmmnn80dd$
where:
mmmm...mmmm = Preset Mix Data Structure (26 pseudo-hex chars)
(see page 8)
nn = Preset Mix Number (pseudo-hex):
01 thru 08 for presets 1 thru 8.
80 = Device Type Bitmask (pseudo-hex)
dd = Device Number (pseudo-hex)
$ = define-preset-mix command character (0x24)
Syntax of Response:
(no response)
Example:
40000064000000326464000064048001$
This example causes Advantage DRI number 1 to redefine its preset mix number 4 to have
logic output 1 on, logic output 2 off, channels 1, 4, 5, and main output at maximum
volume, channel 6 at 50%, and all other volumes at minimum.
Comments:
The typical execution time for the define-preset-mix command is 150 milliseconds (not
including the time required to transmit the command string).
21-Jul-97
Computer Control of the Advantage DRI page 11
% get-preset-mix-settings
Description:
The get-preset-mix-settings command causes the Advantage DRI to return the settings of
the specified preset mix. The preset mix settings will be returned in the Preset Mix Data
Structure format. To retrieve the “current mix” settings, specify 0x80 as the preset mix
number.
Syntax of Command:
nn80dd%
where:
nn = Preset Mix Number (pseudo-hex)
01 thru 08 for presets 1 thru 8.
80 for the “current mix”.
80 = Device Type Bitmask (pseudo-hex)
dd = Device Number (pseudo-hex)
% = get-preset-mix-settings command character (0x25)
Syntax of Response:
mmmmmmmmmmmmmmmmmmmmmmmmmm↵
where:
mmmm...mmmm = Preset Mix Data Structure (26 pseudo-hex chars)
(see page 8)
Example:
command:
028001%
response:
40000064000000326464000064↵
This example causes Advantage DRI number 1 to retrieve its settings for preset mix
number 2. In this example, preset mix number 2’s definition was: logic output 1 on, logic
output 2 off, channels 1, 4, 5, and main output at maximum volume, channel 6 at 50%,
and all other volumes at minimum.
Comments:
page 12 Computer Control of the Advantage DRI
21-Jul-97
& set-volume
Description:
The set-volume command causes the Advantage DRI to set the specified channel to a new
volume level. The volume level is a 7-bit value which ranges from 0 (minimum volume) to
100 (maximum volume, 0x64). The eighth data bit (bit 7) of the volume byte indicates
whether or not that particular channel should be muted. When bit 7 indicates that the
channel should be muted (bit 7 = '1'), the 7 least significant bits (bits 0 - 6) indicate the
volume level which will be restored by the Advantage DRI if that channel subsequently
becomes un-muted.
Syntax of Command:
vvnn80dd&
where:
vv = Volume level (pseudo-hex)
nn = Channel Number (pseudo-hex)
1 - 8 = channel 1 - 8. 9 = Aux Input.
: = Main Output. ; = Aux1 Output. < = ch 12.
80 = Device Type Bitmask (pseudo-hex)
dd = Device Number Bitmask (pseudo-hex)
& = set-volume command character (0x26)
Syntax of Response:
(no response)
Example:
4<0:8001&
This example causes Advantage DRI number 1 to set its main output volume (channel 10,
‘0:’ in pseudo-hex) to 76% of full travel (volume step 76, ‘4<’ in pseudo-hex).
Comments:
The Advantage DRI supports 51 discrete volume levels or steps: 0 (minimum volume)
thru 100 (maximum volume) in increments of 2. Any odd-numbered volume setting will
be truncated to the next lowest even number. For example, as far as the Advantage DRI is
concerned, specifying a volume of 75 is no different from specifying a volume of 74.
The typical execution time for the set-volume command is 200 microseconds (not
including the time required to transmit the command string).
21-Jul-97
Computer Control of the Advantage DRI page 13
& get-volume
Description:
The get-volume command causes the Advantage DRI to return the current volume setting
for the specified channel. The volume level is a 7-bit value which ranges from 0 (minimum
volume) to 100 (0x64 - maximum volume). The eighth bit (bit 7) of the volume byte
indicates whether or not that particular channel is muted. When bit 7 indicates that the
channel is muted (bit 7 = '1'), the 7 least significant bits (bits 0 - 6) indicate the volume
level which will be restored by the Advantage DRI if that channel subsequently becomes
un-muted.
Syntax of Command:
??nn80dd&
where:
?? = 0xff in pseudo-hex (command specifier)
nn = Channel Number (pseudo-hex)
1 - 8 = channel 1 - 8. 9 = Aux Input.
: = Main Output. ; = Aux1 Output. < = ch 12.
80 = Device Type Bitmask (pseudo-hex)
dd = Device Number Bitmask (pseudo-hex)
& = get-volume command character (0x26)
Syntax of Response:
vv↵
where:
vv = Volume (in pseudo-hex) of the specified channel.
Example:
command:
??028001&
response:
64↵
This example causes Advantage DRI number 1 to return the volume setting for channel 2.
In this example, the volume is set at 100% (64 in pseudo-hex).
Comments:
page 14 Computer Control of the Advantage DRI
21-Jul-97
( do-logic-action
Description:
The do-logic-action command causes the Advantage DRI to perform the specified logic
output action (turn on, turn off, toggle).
Syntax of Command:
an80dd(
where:
a = Logic Output Action:
0 = NOP (no operation), 1 = turn off,
2 = turn on, 3 = toggle.
n = Logic Output Number (1 or 2)
80 = Device Type Bitmask (pseudo-hex)
dd = Device Number Bitmask (pseudo-hex)
( = do-logic-action command character (0x28)
Syntax of Response:
(no response)
Example:
218001(
This example causes Advantage DRI number 1 to turn on logic output number 1.
Comments:
When the Advantage DRI is connected to an Advantage DLA93, logic output number 1
corresponds to the master/slave function of the DLA93 (off = master, on = slave) and
logic output number 2 corresponds to the automix/manual function of the DLA93 (off =
automix, on = manual mix).
The typical execution time for the do-logic-action command is 300 microseconds (not
including the time required to transmit the command string).
21-Jul-97
Computer Control of the Advantage DRI page 15
) do-preset-action
Description:
The do-preset-action command causes the Advantage DRI to perform the specified preset
action (recall a preset mix or store the current mix as a preset). The Advantage DRI
supports eight normal preset mixes (1 thru 8) plus a “temporary” preset mix (preset
number 0). Action code 3 allows you to store the current settings as preset 0 (the
temporary mix) and recall one of the eight normal presets. You can then, sometime later,
restore the settings to the way they were by recalling preset 0.
Syntax of Command:
an80dd)
where:
a = Preset Action: 0 = NOP (no operation), 1 = recall,
2 = store, 3 = store temporary mix then recall.
n = Preset Number (0 through 8)
80 = Device Type Bitmask (pseudo-hex)
dd = Device Number Bitmask (pseudo-hex)
) = do-preset-action command character (0x29)
Syntax of Response:
(no response)
Example:
178001)
This example causes Advantage DRI number 1 to recall preset mix number 7.
Comments:
The typical execution time for the do-preset-action command is 30 milliseconds for
recalling a preset, 175 milliseconds for storing a preset, and 200 milliseconds for storing
the temporary preset then recalling (not including the time required to transmit the
command string).
page 16 Computer Control of the Advantage DRI
21-Jul-97
/ get-version
Description:
The get-version command causes the Advantage DRI to return its model identifier code
and firmware version to the computer. The model identifier string is always ‘10’ for the
Advantage DRI. The firmware version number is simply the release date of the firmware,
in the format of mmddyy. These date values are decimal digits, not pseudo-hex notation.
For example, December 31, 1997 would be represented as 123197.
Syntax of Command:
0080dd/
where:
00 = ‘00’ (command specifier)
80 = Device Type Bitmask (pseudo-hex)
dd = Device Number Bitmask (pseudo-hex)
/ = get-version command character (0x2F)
Syntax of Response:
10mmddyy↵
where:
10 = Advantage DRI model identifier
mm = 2-digit decimal month number
dd = 2-digit decimal day of the month
yy = 2-digit decimal year number
Example:
command:
008001/
response:
10070297↵
This example causes device number 1 to return its model I.D. and firmware version. In
this example, device number 1 is an Advantage DRI and its firmware version date is July
2, 1997.
21-Jul-97
Computer Control of the Advantage DRI page 17
Advanced Computer Command Summary
an80dd# do-volume-action
mmmmmmmmmmmmmmmmmmmmmmmmmmnn80dd$ define-preset-mix
nn80dd% get-preset-mix-settings
vvnn80dd& set-volume
??nn80dd& get-volume
an80dd( do-logic-action
an80dd) do-preset-action
0080dd/ get-version
a a pseudo-hex nibble specifying an action code.
d one of the pseudo-hex nibbles in the device number which indicates which device the
command is addressed to.
m one of the pseudo-hex nibbles occurring in the preset mix data structure.
n a pseudo hex nibble specifying a channel number, logic output number, or preset mix
number.
v one of the pseudo-hex nibbles specifying a volume level.
page 18 Computer Control of the Advantage DRI
21-Jul-97
.
ASCII Code Chart
with Decimal & Hexadecimal Equivalents and Advantage DRI Commands
000.
001.
002.
003.
004.
005.
006.
007.
008.
009.
010.
011.
012.
013.
014.
015.
NUL
SOH
STX
ETX
EOT
ENQ
ACK
BEL
BS
HT
LF
VT
FF
CR
SO
SI
0x00
0x01
0x02
0x03
0x04
0x05
0x06
0x07
0x08
0x09
0x0A
0x0B
0x0C
0x0D
0x0E
0x0F
016.
017.
018.
019.
020.
021.
022.
023.
024.
025.
026.
027.
028.
029.
030.
031.
DLE
DC1
DC2
DC3
DC4
NAK
SYN
ETB
CAN
EM
SUB
ESC
FS
GS
RS
US
0x10
032.
(space)
0x11
033.
vol limits
034.
0x12
do-button
035.
0x13
do-volume
036.
0x14
define-preset
037.
0x15
get-preset
038.
0x16
get/set-volume
039.
0x17
040.
0x18
do-logic
041.
0x19
do-preset
042.
0x1A
get-status
043.
0x1B
sleep 10 sec.
044.
0x1C
read memory
045.
0x1D
write memory
046.
0x1E
set defaults
047.
0x1F
get version
!
"
#
$
%
&
'
(
)
*
+
,
-
.
/
0x20
0x21
0x22
0x23
0x24
0x25
0x26
0x27
0x28
0x29
0x2A
0x2B
0x2C
0x2D
0x2E
0x2F
048.
0
nibble 0x0
049.
1
nibble 0x1
050.
2
nibble 0x2
051.
3
nibble 0x3
052.
4
nibble 0x4
053.
5
nibble 0x5
054.
6
nibble 0x6
055.
7
nibble 0x7
056.
8
nibble 0x8
057.
9
nibble 0x9
058.
:
nibble 0xA
059.
;
nibble 0xB
060.
<
nibble 0xC
061.
=
nibble 0xD
062.
>
nibble 0xE
063.
?
nibble 0xF
0x30
0x31
0x32
0x33
0x34
0x35
0x36
0x37
0x38
0x39
0x3A
0x3B
0x3C
0x3D
0x3E
0x3F
064.
@
repeat code
065.
A
066.
B
button 01
067.
C
button 02
068.
D
button 03
069.
E
button 04
070.
F
button 05
071.
G
button 06
072.
H
button 07
073.
I
button 08
074.
J
button 09
075.
K
button 10
076.
L
button 11
077.
M
button 12
078.
N
button 13
079.
O
button 14
0x40
0x41
0x42
0x43
0x44
0x45
0x46
0x47
0x48
0x49
0x4A
0x4B
0x4C
0x4D
0x4E
0x4F
080.
P
button 15
081.
Q
button 16
082.
R
button 17
083.
S
button 18
084.
T
button 19
085.
U
button 20
086.
V
button 21
087.
W
button 22
088.
X
button 23
089.
Y
button 24
090.
Z
button 25
091.
[
button 26
092.
\
button 27
093.
]
button 28
094.
^
button 29
095.
_
button 30
0x50
0x51
0x52
0x53
0x54
0x55
0x56
0x57
0x58
0x59
0x5A
0x5B
0x5C
0x5D
0x5E
0x5F
096.
`
button 31
097.
a
098.
b
button 32
099.
c
button 33
100.
d
button 34
101.
e
button 35
102.
f
button 36
103.
g
button 37
104.
h
button 38
105.
i
button 39
106.
j
button 40
107.
k
select none
108.
l
select 1
109.
m
select 2
110.
n
select 1,2
111.
o
select 3
0x60
0x61
0x62
0x63
0x64
0x65
0x66
0x67
0x68
0x69
0x6A
0x6B
0x6C
0x6D
0x6E
0x6F
112.
0x70
p
select 1,3
113.
0x71
q
select 2,3
114.
0x72
r
select 1,2,3
115.
0x73
s
select 4
116.
0x74
t
select 1,4
117.
0x75
u
select 2,4
118.
0x76
v
select 1,2,4
119.
0x77
w
select 3,4
120.
0x78
x
select 1,3,4
121.
0x79
y
select 2,3,4
122.
0x7A
z
select 1,2,3,4
123.
0x7B
{
124.
125.
0x7C
0x7D
}
126.
0x7E
~
127.
0x7F
DEL
21-Jul-97
Computer Control of the Advantage DRI page 19
binary decimal hex pseudo
0000 0000 0. 0x00 00
0000 0001 1. 0x01 01
0000 0010 2. 0x02 02
0000 0011 3. 0x03 03
0000 0100 4. 0x04 04
0000 0101 5. 0x05 05
0000 0110 6. 0x06 06
0000 0111 7. 0x07 07
0000 1000 8. 0x08 08
0000 1001 9. 0x09 09
0000 1010 10. 0x0a 0:
0000 1011 11. 0x0b 0;
0000 1100 12. 0x0c 0<
0000 1101 13. 0x0d 0=
0000 1110 14. 0x0e 0>
0000 1111 15. 0x0f 0?
0001 0000 16. 0x10 10
0001 0001 17. 0x11 11
0001 0010 18. 0x12 12
0001 0011 19. 0x13 13
0001 0100 20. 0x14 14
0001 0101 21. 0x15 15
0001 0110 22. 0x16 16
0001 0111 23. 0x17 17
0001 1000 24. 0x18 18
0001 1001 25. 0x19 19
0001 1010 26. 0x1a 1:
0001 1011 27. 0x1b 1;
0001 1100 28. 0x1c 1<
0001 1101 29. 0x1d 1=
0001 1110 30. 0x1e 1>
0001 1111 31. 0x1f 1?
0010 0000 32. 0x20 20
0010 0001 33. 0x21 21
0010 0010 34. 0x22 22
0010 0011 35. 0x23 23
0010 0100 36. 0x24 24
0010 0101 37. 0x25 25
0010 0110 38. 0x26 26
0010 0111 39. 0x27 27
0010 1000 40. 0x28 28
0010 1001 41. 0x29 29
0010 1010 42. 0x2a 2:
0010 1011 43. 0x2b 2;
0010 1100 44. 0x2c 2<
0010 1101 45. 0x2d 2=
0010 1110 46. 0x2e 2>
0010 1111 47. 0x2f 2?
0011 0000 48. 0x30 30
0011 0001 49. 0x31 31
0011 0010 50. 0x32 32
0011 0011 51. 0x33 33
0011 0100 52. 0x34 34
0011 0101 53. 0x35 35
0011 0110 54. 0x36 36
0011 0111 55. 0x37 37
0011 1000 56. 0x38 38
0011 1001 57. 0x39 39
0011 1010 58. 0x3a 3:
0011 1011 59. 0x3b 3;
0011 1100 60. 0x3c 3<
0011 1101 61. 0x3d 3=
0011 1110 62. 0x3e 3>
0011 1111 63. 0x3f 3?
binary decimal
0100 0000 64. 0x40 40
0100 0001 65. 0x41 41
0100 0010 66. 0x42 42
0100 0011 67. 0x43 43
0100 0100 68. 0x44 44
0100 0101 69. 0x45 45
0100 0110 70. 0x46 46
0100 0111 71. 0x47 47
0100 1000 72. 0x48 48
0100 1001 73. 0x49 49
0100 1010 74. 0x4a 4:
0100 1011 75. 0x4b 4;
0100 1100 76. 0x4c 4<
0100 1101 77. 0x4d 4=
0100 1110 78. 0x4e 4>
0100 1111 79. 0x4f 4?
0101 0000 80. 0x50 50
0101 0001 81. 0x51 51
0101 0010 82. 0x52 52
0101 0011 83. 0x53 53
0101 0100 84. 0x54 54
0101 0101 85. 0x55 55
0101 0110 86. 0x56 56
0101 0111 87. 0x57 57
0101 1000 88. 0x58 58
0101 1001 89. 0x59 59
0101 1010 90. 0x5a 5:
0101 1011 91. 0x5b 5;
0101 1100 92. 0x5c 5<
0101 1101 93. 0x5d 5=
0101 1110 94. 0x5e 5>
0101 1111 95. 0x5f 5?
0110 0000 96. 0x60 60
0110 0001 97. 0x61 61
0110 0010 98. 0x62 62
0110 0011 99. 0x63 63
0110 0100 100. 0x64 64
0110 0101 101. 0x65 65
0110 0110 102. 0x66 66
0110 0111 103. 0x67 67
0110 1000 104. 0x68 68
0110 1001 105. 0x69 69
0110 1010 106. 0x6a 6:
0110 1011 107. 0x6b 6;
0110 1100 108. 0x6c 6<
0110 1101 109. 0x6d 6=
0110 1110 110. 0x6e 6>
0110 1111 111. 0x6f 6?
0111 0000 112. 0x70 70
0111 0001 113. 0x71 71
0111 0010 114. 0x72 72
0111 0011 115. 0x73 73
0111 0100 116. 0x74 74
0111 0101 117. 0x75 75
0111 0110 118. 0x76 76
0111 0111 119. 0x77 77
0111 1000 120. 0x78 78
0111 1001 121. 0x79 79
0111 1010 122. 0x7a 7:
0111 1011 123. 0x7b 7;
0111 1100 124. 0x7c 7<
0111 1101 125. 0x7d 7=
0111 1110 126. 0x7e 7>
0111 1111 127. 0x7f 7?
hex pseudo
binary decimal
1000 0000 128. 0x80 80
1000 0001 129. 0x81 81
1000 0010 130. 0x82 82
1000 0011 131. 0x83 83
1000 0100 132. 0x84 84
1000 0101 133. 0x85 85
1000 0110 134. 0x86 86
1000 0111 135. 0x87 87
1000 1000 136. 0x88 88
1000 1001 137. 0x89 89
1000 1010 138. 0x8a 8:
1000 1011 139. 0x8b 8;
1000 1100 140. 0x8c 8<
1000 1101 141. 0x8d 8=
1000 1110 142. 0x8e 8>
1000 1111 143. 0x8f 8?
1001 0000 144. 0x90 90
1001 0001 145. 0x91 91
1001 0010 146. 0x92 92
1001 0011 147. 0x93 93
1001 0100 148. 0x94 94
1001 0101 149. 0x95 95
1001 0110 150. 0x96 96
1001 0111 151. 0x97 97
1001 1000 152. 0x98 98
1001 1001 153. 0x99 99
1001 1010 154. 0x9a 9:
1001 1011 155. 0x9b 9;
1001 1100 156. 0x9c 9<
1001 1101 157. 0x9d 9=
1001 1110 158. 0x9e 9>
1001 1111 159. 0x9f 9?
1010 0000 160. 0xa0 :0
1010 0001 161. 0xa1 :1
1010 0010 162. 0xa2 :2
1010 0011 163. 0xa3 :3
1010 0100 164. 0xa4 :4
1010 0101 165. 0xa5 :5
1010 0110 166. 0xa6 :6
1010 0111 167. 0xa7 :7
1010 1000 168. 0xa8 :8
1010 1001 169. 0xa9 :9
1010 1010 170. 0xaa ::
1010 1011 171. 0xab :;
1010 1100 172. 0xac :<
1010 1101 173. 0xad :=
1010 1110 174. 0xae :>
1010 1111 175. 0xaf :?
1011 0000 176. 0xb0 ;0
1011 0001 177. 0xb1 ;1
1011 0010 178. 0xb2 ;2
1011 0011 179. 0xb3 ;3
1011 0100 180. 0xb4 ;4
1011 0101 181. 0xb5 ;5
1011 0110 182. 0xb6 ;6
1011 0111 183. 0xb7 ;7
1011 1000 184. 0xb8 ;8
1011 1001 185. 0xb9 ;9
1011 1010 186. 0xba ;:
1011 1011 187. 0xbb ;;
1011 1100 188. 0xbc ;<
1011 1101 189. 0xbd ;=
1011 1110 190. 0xbe ;>
1011 1111 191. 0xbf ;?
page 20 Computer Control of the Advantage DRI 21-Jul-97
hex pseudo
binary decimal
1100 0000 192. 0xc0 <0
1100 0001 193. 0xc1 <1
1100 0010 194. 0xc2 <2
1100 0011 195. 0xc3 <3
1100 0100 196. 0xc4 <4
1100 0101 197. 0xc5 <5
1100 0110 198. 0xc6 <6
1100 0111 199. 0xc7 <7
1100 1000 200. 0xc8 <8
1100 1001 201. 0xc9 <9
1100 1010 202. 0xca <:
1100 1011 203. 0xcb <;
1100 1100 204. 0xcc <<
1100 1101 205. 0xcd <=
1100 1110 206. 0xce <>
1100 1111 207. 0xcf <?
1101 0000 208. 0xd0 =0
1101 0001 209. 0xd1 =1
1101 0010 210. 0xd2 =2
1101 0011 211. 0xd3 =3
1101 0100 212. 0xd4 =4
1101 0101 213. 0xd5 =5
1101 0110 214. 0xd6 =6
1101 0111 215. 0xd7 =7
1101 1000 216. 0xd8 =8
1101 1001 217. 0xd9 =9
1101 1010 218. 0xda =:
1101 1011 219. 0xdb =;
1101 1100 220. 0xdc =<
1101 1101 221. 0xdd ==
1101 1110 222. 0xde =>
1101 1111 223. 0xdf =?
1110 0000 224. 0xe0 >0
1110 0001 225. 0xe1 >1
1110 0010 226. 0xe2 >2
1110 0011 227. 0xe3 >3
1110 0100 228. 0xe4 >4
1110 0101 229. 0xe5 >5
1110 0110 230. 0xe6 >6
1110 0111 231. 0xe7 >7
1110 1000 232. 0xe8 >8
1110 1001 233. 0xe9 >9
1110 1010 234. 0xea >:
1110 1011 235. 0xeb >;
1110 1100 236. 0xec ><
1110 1101 237. 0xed >=
1110 1110 238. 0xee >>
1110 1111 239. 0xef >?
1111 0000 240. 0xf0 ?0
1111 0001 241. 0xf1 ?1
1111 0010 242. 0xf2 ?2
1111 0011 243. 0xf3 ?3
1111 0100 244. 0xf4 ?4
1111 0101 245. 0xf5 ?5
1111 0110 246. 0xf6 ?6
1111 0111 247. 0xf7 ?7
1111 1000 248. 0xf8 ?8
1111 1001 249. 0xf9 ?9
1111 1010 250. 0xfa ?:
1111 1011 251. 0xfb ?;
1111 1100 252. 0xfc ?<
1111 1101 253. 0xfd ?=
1111 1110 254. 0xfe ?>
1111 1111 255. 0xff ??
hex pseudo
Loading...
