B-FORM Comfort, Silent, Deluxe User Manual

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

2

INDEX

• ................................................................................................................. Pag. 3

• ......................................................................................... Pag. 5

• ....................................................................................................... Pag. 7

• ...................................................................................................... Pag. 11

• ...................................................................................................................... Pag. 12

• ............................................................................................................... Pag. 13

• .................................................................................................................. Pag. 15

• ...................................................................................................................... Pag. 16

• .............................................................................................. Pag. 17

• ............................................................................................... Pag. 18

• ........................................................................ Pag. 21

• ................................................................... Pag. 26

• ..................................................................... Pag. 31

• ............................................................................. Pag. 44

• ....................................................................................................................... Pag. 46

• ....................................................................................................................... Pag. 47

• ............................................................................................................................. Pag. 48

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

3

ank you for purchasing our thermoforming machines and we are pleased to welcome
you into our large family of customers.
Our B-FORM thermoforming machines are of the most recent generation, having a
modern style and a sleek design. ey have been designed to satisfy every need that a
dentist and a dental technician might have in a fast and simple way.
Built with top-quality materials, the B-FORM thermoforming machines have a 3-year
warranty against defects in materials and workmanship.
All the components that make up the outer structure of the B-FORM thermoforming
machines were manufactured using glass-lled nylon and ABS, making it very light and
compact.
e seals were manufactured using silicone and are very resistant to heat and sticky ma­terials.
ey are equipped with a last generation vacuum pump that is powerful and quiet, and
allows one to perform the thermoforming process in less time and with the utmost pre­cision.
e equipped well beads make it possible to perform the thermoforming process and
always achieve great professional results even with very high gypsum models, undercuts,

INTRODUCTION

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

4

sharp edges, and palate or buccal beds (see “ ”).
e locking plate, in which the thermoplastic sheets are inserted, is raised and lowered
by an electric motor in the B-FORM Comfort and Deluxe version, and manually in the
B-FORM Silent version. In addition, the particular design of the plate allows you to use
each type of thermoplastic sheets:
square 13 x 13 cm, round Ø 12 cm, round Ø 12.5 cm.
e heating plate contains quartz modular infrared resistance. e main characteristic of
this resistance is the rapidity of response, and therefore there is no need for preheating.
e heat is emitted by radiation mainly downwards in the direction of the thermoplastic
sheet to be heated, thus it greatly reduces the power consumption during the heating of
the thermoplastic sheet and yields substantial energy savings. Furthermore, the heating
plate containing the resistance does not heat up excessively.
ey have an elegant control keyboard on which the control keys for the functionality of
the thermoforming machine are located.
ey are equipped with an energy saving and security device (automatic standby feature
if the thermoforming machine is not used for approximately 10 minutes).
e B-FORM thermoforming machines have the certication and are provided with a
multilingual user manual and a DVD-R for the use of the thermo-molder.

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

5

THERMOFORMING TECHNIQUE

To obtain the best results with the thermoforming technique, a good plaster model needs
to be prepared. To do so we recommend that you to keep in mind the following:

• e plaster model can be made with any type of plaster. However, we recommend that
you use a hard plaster because if you use a so plaster, a model completely covered with
powder is obtained, and the powder is transferred to the thermoforming device as well.

• e plaster model must not be very high and therefore it must be thinned as
much as possible. e base of the model must have a smooth, at surface. Remo­ ve the parts of the model (vestibule, buccal oor) that can prevent the molding. Ca­ refully remove the undercut areas and round the sharp edges of the plaster ( ).
You can overcome all of this if you use the well of thermoforming machine, aer
having lled it with beads ( ).

• If you use air-impermeable or lacquered resin models, you run the risk of having an
incomplete mold because the air is unable to escape completely between the model and
the thermoplastic sheet.

• If you remove the hard thermoformed materials from the model, this oen breaks. e
problem is not solved using extra-hard plasters: we recommend the molding with a
duplicate.

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

6

• During the thermoforming there is always a thinning of the material with respect to
the original thickness. In general, our long experience has taught us that for every cen­ timeter of height of the plaster model, there is a loss of thickness of approximately 20%.
For this reason, it is necessary to lower the plaster model height as much as possible
or insert the plaster model into the well of the thermoforming machine and cover it with
beads, leaving only the area that you want to mold uncovered.

• With the B-FORM thermoforming machines there is a molding in an axial direction, in
which the suitably heated sheet descends vertically on the model, surrounding it
completely. is creates a uniform thickness over the entire surface of the plaster mo­ del.

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

7

Please read and take the following precautions before using the equipment.

Positioning

1. e thermoforming machine must always be placed on a at and open surface:

Under no circumstances must the thermoforming machine be operated when it is
located inside a cabinet.

2. During operation, do not put the thermoforming machine too close to the walls, cabi­ nets or any other equipment due to the heat emitted from the resistance located in
heating plate.

3. Do not place the thermoforming machine near ammable liquids, such as alcohol
or solvents.

In case the internal electrical components come into contact with ammable liquids,
re or electric shocks might occur. Should one of these liquids penetrate in the appa­ ratus, disconnect the power supply cable immediately and contact your local dealer.

4. Do not put the equipment in the following places (re or electric shocks may occur).

- Areas with high humidity.

- Areas subject to direct sunlight.

SAFETY PRECAUTIONS

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

8

- Areas with high temperatures.

- Areas near ame sources.

5. Do not place the thermoforming machine on uneven supports, unstable surfaces or
surfaces that are subject to frequent vibrations. If the equipment falls, it can cause
injury.

6. Do not put heavy objects on the device. e objects may fall and cause injury.

Power supply

1. Do not damage, cut or modify the power supply cable. Do not put heavy objects on
the power supply cable, and do not pull and bend it excessively. Damaged wires may
cause a re or electric shocks.

2. Do not insert or remove the plug of the power supply cable with wet hands. Electric
shocks may occur.

3. Do not connect an excessive number of plugs to a single electrical socket. Fire or
electric shocks may occur.

4. Always make sure that the power supply cable is inserted properly into the wall socket.
If it is not fully inserted, it can cause a re or electric shocks.

5. Do not use power supply cables other than the one supplied. Fire or electric shocks
may occur. If you use a power supply cable that was not supplied by the dealer, make

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

9

sure it conforms to the standards in force in your country. If the power supply cable
is defective, please contact the manufacturer or your authorized supplier for a repla­ cement.

6. As a rule, please do not use extension cords. Fire or electric shocks may occur. In the
event that the use of an extension cord is inevitable, do not use one that is longer than
5 meters. Make sure that the cord is not twisted and that the power supply cable is
connected properly to the extension. Do not use multiple extension cords.

7. Do not use extension cord in corridors or in other areas that are used frequently whe­ re they can be stepped on or tripped over. is may damage the cables and it can cau­ se a re or electric shocks.

8. Do not connect the device into a power socket with an electrical voltage that is die­ rent than the one specied. is may cause re or electric shocks.

9. When removing the power supply cable from the wall socket, always pull it out from
the body of the plug. If the pull it using the power supply cable, the metal wires may
be damaged and cause a re or electric shock.

General precautions for use

1. Do not disassemble or modify the device. is may cause a re or electric shocks from
the improper use of its components.

2. In case you hear unusual sounds, see smoke, experience any excessive heat, or smell

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

10

an unusual smell disconnect power supply cable and contact your local dealer. Pro­ longed use may cause a re or electric shocks.

3. If you do not use the device for long periods, such as for example over the weekend,
be sure to disconnect the power supply cable as a precaution.

4. Be very careful when transporting the equipment. If you let it fall down, it may cause
an injury.

5. Wait until the device has cooled down before you put a cover over it. Otherwise, a re
may occur.

6. When you switch on the resistance for the rst time, you may notice some smoke co­ ming out of it. Do not worry because this is due to dust that was deposited on the re­ sistance.

7. When you’re nished working with the thermo-molder, remember to turn o the vol­ tage switch located on the rear of the device. ( ).

8. 8. Do not throw away the cardboard box and the packaging materials. ey are ideal
for transporting the equipment.

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

11

ank you for purchasing the B-FORM thermoforming machine. Verify that the
package contains all of the following items. If part of the material is missing or damaged,
please contact your local dealer. ( ).

• ermoforming machine.

• Schuko power supply cable.

• Perforated plate.

• Stainless steel balls per well.

• Interactive user manual on DVD-R.

MATERIALS PROVIDED

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

12

Do not use ammable sprays near the device. In addition, do not pour water, liquids, or
ammable liquids on the device. If these liquids get in this device and come in contact
with the electrical parts, this may cause a re or electric shocks. If something gets into the
device, disconnect the power supply cable immediately and contact your local dealer.

Always remove the power supply cable from the wall socket when cleaning the device.
Otherwise, a re or electric shocks may occur.

When you clean the equipment, use a well-wrung cloth dampened with water. Do not
use ammable liquids, such as alcohol, benzene or solvents. In case in a ammable liquid
penetrates in the electrical parts inside, it can cause a re or electric shocks.

CLEANING

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

13

1. e stopper with a hole in it, located at the bottom of the well, must always be free of
any debris that may form during the operation of the thermoforming machine. e
refore, you must periodically remove the beads from the well and thoroughly inspect
this area and check the lter located inside it ( ).

2. Check periodically to see if the power supply cable is worn and check to make sure
that the connection plugs are inserted correctly.

3. Replacing the fuse : In the electrical outlet, located in the rear part of the ther­ moforming machine, there are two incorporated fuses to protect the various electri­ cal components of the device. Should the fuse malfunction for some reason, you must
replace it. For the replacement of the fuse proceed as follows:

• First unplug the power supply cable both from the wall socket and also from the socket
of the device.

• Open the ap of the fuse container gently with a screwdriver ( ) and repla­ ce the old fuse with a new one. It is very important have spare fuses of the same type
(delayed 3.15 AT for 220 volts version and delayed AT 6.30 for the 115 volts version)
to be able to replace them should the need arise. Dierent types of fuses may cause
damage to the device and thus void the warranty.

MAINTENANCE

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

14

4. In the construction of the thermoforming machine, high quality materials were used.
However, aer some years of use the resistance, the seals and some other part may
wear down and you may need to replace them.

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

15

e thermoforming machine is supplied ready for use. A few simple steps are required
for the installation and operation.

1.  Take the thermoforming machine out of the packaging and place it on a at surface.

2. Connect the female part of the power supply cable to the power socket of the thermo­ forming machine, located at the rear, and the male part of the power supply cable to
the mains power supply outlet. Never put the power supply cable near any heat sour­ ce. Turn on the switch located on the rear, and the thermoforming machine is ready
for operation ( ). A light will turn on the control panel that will illuminate the
logo “B-FORM” to conrm that electric voltage is arriving in the machine.

ATTENTION: Before operating your thermoforming machine, check the voltage of

the main electricity supply.

INSTALLATION

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

16

e B-FORM thermoforming machine is guaranteed for 3 years from the date of purcha­se, for defects recognized in material or manufacture.
If during the warranty period a defect is observed, the thermoforming machine will be
repaired or replaced for free only if:

1. e thermoforming machine has not been used for purposes other than normal use.

2. No unauthorized modications or repair have been made.

NOTE: e following are excluded from the warranty: the seals, the fuses, the stain-

less steels balls, the ower supply cable.

e conditions of warranty may vary according to the country of purchase of the ther­moforming machine.

WARRANTY

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

17

For any type of repair, please send the B-FORM thermoforming machine to your dealer
or directly to our service center.
For repairs, we recommend that you follow the following instructions:

1. Always send the thermo-molder with a transport document. It should also be accom­ panied by a precise and detailed description of the problem.

2. e thermoforming machine must be shipped to our address always as carriage paid
and undamaged. Otherwise, the item will not be accepted.

3. e return of the item, from our head oce to your home, will be executed as carriage
paid and undamaged with charges for the cost of shipping on the invoice.

4. All of our repairs will be sent to you in the following manner: cash on delivery or pre­ payment.

5. When you send the thermo-molder, please make sure to pack it with great care using
the original packaging. In any case, you should never use polystyrene as packing ma­ terial because it may deposit within the resistance and may cause res.

ATTENTION: Never include the stainless steel balls in the package.

INSTRUCTIONS FOR REPAIRS

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

18

Check the following before requesting technical assistance:

• Insucient details - is is oen caused by an incorrect heating or vacuum time of
the plastic sheet. If your overlay does not have sucient details, you must prolong the
heating and/or vacuum time of the plastic sheet.

• Creased or torn material - is is due to an excessive heating of the plastic sheet.
Simply reducing the heating time solves this problem.

• Material glued to the model - e problem is solved by spraying the plaster model
with a silicone lubricant prior to the implementation of the overlay.

• Material glued to the seals - Replace the seals.

• Material glued in the holes in the vacuum plate - is happens when the plastic
sheet is heated excessively and is sucked inside the plate holes. Let the plastic material
cool down completely and then try to pull it out gently from the holes in the plate.

• e resistance does not work / e vacuum pump does not work / e clamping
plate does not move up and cannot be lowered - Check to see if the power supply
cable is properly inserted both in the thermo-molding socket of the thermo-molding
and the wall outlet. Check the fuse. Remove and replace it if it is blown.

TROUBLESHOOTING GUIDE

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

19

ATTENTION: If the problems persist please consult maintenance personnel. Do not

try to carry out the maintenance alone since opening the structure of the device may
expose the user to the danger of electrical shocks or other hazards. Please contact
qualied technical personnel.

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

20

Cover

Heating plate Knob

Heating plate

Sliding sleeve

Manopola piastra di serraggio

Locking plate

Wel l beads

Control Keyboard

Base

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

21

To correctly use the B-FORM Silent thermoforming machine, please keep in mind of the
following:

1. Activate the general switch located on the back of the thermoforming ma­ chine in the position “I” ( ), on the control keyboard, the B-FORM logo lights
up to conrm that the electrical voltage is arriving in the device and that it is ready
for use.

2. Turn the heating plate slowly sideways to the le ( ).

INSTRUCTIONS FOR USE B-FORM SILENT

Switch o button
of the vacuum pump

Power LED

Power on button
of the vacuum pump

Resistance power

on button

Resistance LED

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

22

3. Open the locking plate with the appropriate knob (by pushing and rotating it 180°)

and insert the desired thermoplastic sheet. en close the clamping plate always using
the knob ( ).

4. Grab both knobs of the locking plate and li it until the plate reaches the end point

( ).

5. Place the plaster model on the perforated plate ( ) or in the well, aer ha-

ving lled it with beads ( ). Turn the heating plate until it is exactly in the di­ rection of the locking plate ( ).

ATTENTION: If you want to use the well, position the plaster model in the basket

with the beads before starting the cycle.

6.  Press the resistance button (HEAT) , on the control keyboard. A red LED

lights up to conrm the resistance is ready for use. e thermoplastic sheet is heated
rapidly (it takes about 1- 4 minutes depending on the thickness).

7. When the thermoplastic sheet begins to bend signicantly to about 1.5 cm ( ),

grab both knobs and completely lower the clamping plate on the pla­ ster model until the plastic sheet surrounds the model itself ( ). Press the
button (VACUUM) of the vacuum pump: (for the thermoforming of the sheet

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

23

15 - 20 seconds are sucient), resistance turns o automatically. e vacuum pump
stays on for about 1 min and then it and then it switches o automatically. If you want
to turn it o before pressing the button (VACUUM) .

8. Turn the heating plate toward le ( ) and then cool the byte. e cooling takes a

few minutes.

ATTENTION: Always move the heating plate only by using the appropriate knob be-

cause the plate gets very hot during use.

9.  Aer the sheet has cooled, open the locking plate with the knob and remove the sheet

together with the plaster model.

10. To remove the plaster model from the mold, you must cut all the excess pla-

stic material with scissors, knife or specic disk: to facilitate the removal, the plastic

material should be cut as close as possible to the edge of the plaster model (

- ).

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

24

B-FORM SILENT 230 Volt

Item. 9617500

B-FORM SILENT 115 Volt

Item. 9617501

Height 33 cm Height 33 cm
Width 24 cm Width 24 cm
Depth 28 cm Depth 28 cm
Weight 5,1 kg Weight 5,1 kg
Environmental conditions 10 - 40 °C Environmental conditions 10 - 40 °C

Electrical resistance Electrical resistance

Power supply 230 Volt AC / 325 Watt Power supply 115 Volt AC / 325 Watt
Absorption 1,4 Amper Absorption 2,8 Amper
Power 325 Watt Power 325 Watt

Vacuum Pump Vacuum Pump

Frequency 50 Hz Frequency 60 Hz
Nominal ow 12 l/min Nominal ow 14 l/min
Final pressure (ASS) 250 mbar Final pressure (ASS) 210 mbar
Noise with silencer 56 dB/(A) Noise with silencer 58 dB/(A)
Engine power 80 Watt Engine power 80 Watt
Absorption 0,90 Amper Absorption 1,63 Amper

TECHNICAL DATA

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

25

Cover

Heating plate Knob

Heating plate

Sliding sleeve

Manopola piastra di serraggio

Locking plate

Wel l beads

Control Keyboard

Base

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

26

For the correct use of the B-FORM Comfort thermoforming machine, please keep in
mind the following:

1. Activate the general switch located on the back of the thermoforming ma­ chine in the position “I” ( ), on the control keyboard, the B-FORM logo lights
up to conrm that the electrical voltage is arriving in the device and that it is ready
for use.

2. Turn the heating plate slowly sideways to the le ( ).

INSTRUCTIONS FOR USE B-FORM COMFORT

Power LED

Power on button
of the vacuum pump

Switch o button
of the vacuum pump

Resistance power

on button

Resistance LED

Button to raise

the p late

Button to lower

the plate

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

27

3. Open the locking plate with the appropriate knob (by pushing and rotating it 180°)

and insert the desired thermoplastic sheet. en close the locking plate always using
the knob ( ).

4. Raise the locking plate by pressing the button (PLATE): the locking plate

rises and stops automatically.

5. Place the plaster model on the perforated plate ( ) or in the well, aer ha-

ving lled it with beads ( ). Turn the heating plate until it is exactly in the di­ rection of the locking plate ( ).

ATTENTION: If you want to use the well, position the plaster model in the basket

with the beads before starting the cycle.

6.  Press the resistance button (HEAT) , on the control keyboard. A red LED

lights up to conrm the resistance is ready for use. e thermoplastic sheet is heated
rapidly (it takes about 1- 4 minutes depending on the thickness).

7. When the thermoplastic sheet begins to bend signicantly to about 1.5 cm ( ),

press the down button (PLATE): the resistance turns o and the clamping plate
lowers and, aer the thermoplastic sheet will have surrounded the plaster model,
it automatically stops and then it activates the vacuum pump.

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

28

e vacuum pumpstays on for about 1 min and then it and then it switches o
automatically. If you want to turn it o before pressing the button (VACUUM) .
At the end of the process, the locking plate raises itself a few centimeters from the
base (this operation is very useful to preserve longer the O-ring of the locking
plate ).

8. Turn the heating plate toward le ( ) and then cool the byte. e cooling takes a

few minutes.

ATTENTION: Always move the heating plate only by using the appropriate knob be-

cause the plate gets very hot during use.

9.  Aer the sheet has cooled, open the locking plate with the knob and remove the sheet

together with the plaster model.

10. To remove the plaster model from the mold, you must cut all the excess pla-

stic material with scissors, knife or specic disk: to facilitate the removal, the plastic

material should be cut as close as possible to the edge of the plaster model (

- ).

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

29

B-FORM COMFORT 230 Volt

Item. 9617502

B-FORM COMFORT 115 Volt

Item. 9617503

Height 33 cm Height 33 cm
Width 24 cm Width 24 cm
Depth 28 cm Depth 28 cm
Weight 5,1 kg Weight 5,1 kg
Environmental conditions 10 - 40 °C Environmental conditions 10 - 40 °C

Electrical resistance Electrical resistance

Power supply 230 Volt AC / 325 Watt Power supply 115 Volt AC / 325 Watt
Absorption 1,4 Amper Absorption 2,8 Amper
Power 325 Watt Power 325 Watt

Vacuum Pump Vacuum Pump

Frequency 50 Hz Frequency 60 Hz
Nominal ow 12 l/min Nominal ow 14 l/min
Final pressure (ASS) 250 mbar Final pressure (ASS) 210 mbar
Noise with silencer 56 dB/(A) Noise with silencer 58 dB/(A)
Motor power 80 Watt Motor power 80 Watt
Absorption 0,90 Amper Absorption 1,63 Amper

Gearmotor Gearmotor

Power supply 24 Volt Power supply 24 Volt
Absorption 0,6 Amper Absorption 0,6 Amper
Power 12 Watt Power 12 Watt

TECHNICAL DATA

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

30

Cover

Heating plate Knob

Heating plate

Sliding sleeve

Manopola piastra di serraggio

Locking plate

Wel l beads

Control Keyboard

Base

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

31

For the correct use of the B-FORM Deluxe thermoforming machine, please keep in mind
the following:

1. Cleaning of the IR temperature sensor
Clean the IR temperature sensor with a so and dry cloth ( ).

2. Turning on the thermoformer machine
Activate the general switch located on the back of the thermoforming ma­ chine in the position “I” ( ), on the LCD Dispaly appears for 5 sec. B-FORM

INSTRUCTIONS FOR USE B-FORM DELUXE

Conrmation buttonSelection Button

Next buttonBack button

LCD Display

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

32

Deluxe logo ( ).
Immediately aer appears the screen “LANGUAGE SELECTION” ( ).

3. Language selection
By pressing direction buttons you can select the desired language and con­ rm with the conrm button . e selected language is kept in memory at next
boot. To return to “LENGUAGE SELECTION” menu select the button .

4. Sheets menu selection
On the LCD Dispaly appears the screen “SHEETS MENU” ( ).

• By pressing the forward button or the back button you can turn the pages
of the sheets menu to select the type of sheet to format and conrm with the conrm
button .

• Turn the heating plate slowly sideways to the le ( ).

• Open the locking plate with the appropriate knob (by pushing and rotating it 180°)
and insert the desired thermoplastic sheet. ( ).

• Close the locking plate always using the knob.

• Turn the heating plate slowly sideways to the right ( ).

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

33

ATTENTION: Always move the heating plate only by using the appropriate knob be-

cause the plate gets very hot during use.

5. ickness of the sheet selection

By pressing direction buttons you can select the desired thickness and con-

rm with the conrm button ( ).

6. ermoforming process

e thermoforming machine B-FORM Deluxe allows full automation of the thermo­ forming process of square and round sheets.
Aer having selected the thickness of the sheet to be formatted, on the LCD display
appears the following screen ( ).
To start the thermoforming process select “STA RT ” by pressing direction buttons
and conrm with the conrm button .
On the LCD display ashes for a few seconds the symbol “hot surfaces” ( ).
Place the plaster model on the perforated plate ( ) or in the well, aer ha­ ving lled it with beads ( ).
During the heating process appears the following screen ( ).

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

34

Aer the heating of the sheet, the locking plate lowers automatically and on the LCD
display ashes for a few seconds the symbol “Danger of crushing” ( ).

ATTENTION: to use the well the placement of the plaster model must be done before

starting the process.

Aer the thermoforming process, on the LCD display appears the following screen
( ). e locking plate lis itself a few centimeters from the base.
To make a new thermoforming process with the same type of sheet, select “REPEAT

THE PROCESS

” with the conrm button or select the select button to return to

the “SHEETS MENU”.

7. Temperature customizing

If you are not satised of the factory set temperature and you prefer that the sheet is
more or less warmed up, the B-FORM Deluxe thermoforming machine gives you the
possibility to customize the temperature of each individual sheet.
Proceed as follows:

• Aer having selected the thickness of the sheet to be formatted, on the LCD display
appears the following screen ( ). Select “CUSTOMIZE” by pressing direction but-

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

35

ton and conrm with the conrm button .
On the LCD display appears the following screen ( ).

• On the le side of the screen is indicated the temperature in the memory (°C / °F).
On the right side is indicated the new temperature to customize (°C / °F).

• Upon reaching the desired temperature, save with the conrm button and the
thermoforming process will nish automatically.

• If you are not satised with just customized new temperature, you can customize
another temperature until you do not nd the temperature that satises you.

8. Factory temperature reset

If you are not satised with the personalized temperature, the B-FORM Deluxe
thermoforming machine gives you the possibility to restore the factory temperature.
Proceed as follows:

• Aer having selected the thickness of the sheet to be formatted, on the LCD display
appears the following screen ( ).

• Select “RESET” by pressing direction button and conrm with the conrm but­ ton . A “beep” signals the reset.

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

36

9. Storing of the temperature of a new type of sheet

If you want to thermoform a sheet that It is not stored in the soware, the B-FORM

Deluxe thermoforming machine gives you the possibility to store p to 10 new sheets.
Proceed as follows:

• On the LCD Dispaly appears the screen “SHEETS MENU” ( ).

• Select one of the 10 memories for example “MEMORY 1” by pressing direc-
tion button and conrm with the conrm button . ( )

On the LCD Dispaly appears the following screen ( ).

• On the screen is shown the real time temperature to be stored (°C / °F).

• Upon reaching the desired temperature, save with the conrm button and the
thermoforming process will nish automatically.

• If you are not satised with just customized new temperature, you can customize
another temperature until you do not nd the temperature that satises you.
In this way it is possible to overwrite innite number of times the temperature on the
same memory. Remember to associate the name of the disk just formatted to the me­ mor y.

ATTENTION: Always move the heating plate only by using the appropriate knob be-

cause the plate gets very hot during use.

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

37

10.Extraction of the formatted sheet

• At the end of the process, the locking plate raises itself a few centimeters from the
base (this operation is very useful to preserve longer the O-ring of the locking
plate ).

• Turn the heating plate toward le ( ) and then cool the byte. e cooling takes a
few minutes.

ATTENTION: Always move the heating plate only by using the appropriate knob be-

cause the plate gets very hot during use.

• Aer the sheet has cooled, open the locking plate with the knob and remove the sheet
together with the plaster model.

• To remove the plaster model from the mold, you must cut all the excess pla­ stic material with scissors, knife or specic disk: to facilitate the removal, the plastic

material should be cut as close as possible to the edge of the plaster model (

- ).

ATTENTION: If you want to interrupt the started process, just turn o the main swi-

tch on the back of thermoforming machine ( ).

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

38

11.ermoforming process of Dual Laminate sheet

For thermoforming technique of B-FORM Dual Laminate sheet, at some point in the
thermoforming process will be necessary your intervention.
is type of sheet needs a double heating: must be heated rst on one side and then
the other side.
Proceed as follows:

• Turn the heating plate toward le ( ).

• Open the locking plate with the appropriate knob (by pushing and rotating it 180°)
and insert the Dual Laminate sheet with the so side facing upwards.

• Close the locking plate always using the knob.

• Turn the heating plate slowly sideways to the right ( ).

• On the LCD Dispaly appears the screen “SHEETS MENU” ( ).

• Select the Dual Laminate sheet by pressing direction button and conrm with
the conrm button .

• Aer having selected the thickness of the sheet to be formatted, on the LCD display
appears the following screen ( ).

• To start the thermoforming process select “STA RT” by pressing direction buttons
and conrm with the conrm button .

On the LCD display ashes for a few seconds the symbol “hot surfaces” ( ).

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

39

• Place the plaster model on the perforated plate ( ) or in the well, aer ha­ ving lled it with beads ( ).

During the heating process appears the following screen ( ).

ATTENTION: to use the well the placement of the plaster model must be done before

starting the process.

• When the so side of Dual Laminate sheet reaches its heating temperature, on the
LCD display appears the following screen ( ).

• Turn the heating plate toward le ( ).

• Open the locking plate with the appropriate knob (by pushing and rotating it 180°)
and with a pair of tweezers to grab the disc and rotate it so that the hard side, not yet
heated, is facing upward.

• Close the locking plate always using the knob.

• Turn the heating plate slowly sideways to the right ( ).

• Press the conrm button to restart the cycle. On the LCD display appears the
following screen ( ).

• Aer the heating of the sheet, the locking plate lowers automatically and on the LCD
display ashes for a few seconds the symbol “Danger of crushing” ( ).

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

40

ATTENTION: to use the well the placement of the plaster model must be done before

starting the process.

• Aer the thermoforming process, on the LCD display appears the following screen
( ). e locking plate lis itself a few centimeters from the base.

• To make a new thermoforming process with the same type of sheet, select “REPEAT

THE PROCESS

” with the conrm button or select the select button to return to

the “SHEETS MENU”.

• Turn the heating plate toward le ( ) and then cool the byte. e cooling takes a
few minutes.

ATTENTION: Always move the heating plate only by using the appropriate knob be-

cause the plate gets very hot during use.

• Aer the sheet has cooled, open the locking plate with the knob and remove the sheet
together with the plaster model.

• To remove the plaster model from the mold, you must cut all the excess pla­ stic material with scissors, knife or specic disk: to facilitate the removal, the plastic
material should be cut as close as possible to the edge of the plaster model (

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

41

- ).

ATTENTION: If you want to interrupt the started process, just turn o the main swi-

tch on the back of thermoforming machine ( ).

12. Temperature customizing of Dual Laminate sheet

If you are not satised of the factory set temperature and you prefer that the sheet is

more or less warmed up, the B-FORM Deluxe thermoforming machine gives you the
possibility to customize the temperature only the temperature of the so side.
Proceed as follows:

• Aer having selected the thickness of the sheet to be formatted, on the LCD display
appears the following screen ( ). Select “CUSTOMIZE” by pressing direction but­ ton and conrm with the conrm button .

On the LCD display appears the following screen ( ).

• On the le side of the screen is indicated the temperature in the memory (°C / °F).
On the right side is indicated the new temperature to customize (°C / °F).

• Upon reaching the desired temperature, save with the conrm button and the
thermoforming process will nish automatically.

• If you are not satised with just customized new temperature, you can customize

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

42

another temperature until you do not nd the temperature that satises you.

ATTENTION: you can only customize the temperature of the so side of the Dual La-

minate sheet.

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

43

B-FORM DELUXE 230 Volt

Item. 9617504

B-FORM DELUXE 115 Volt

Item. 9617505

Height 33 cm Height 33 cm
Width 24 cm Width 24 cm
Depth 28 cm Depth 28 cm
Weight 5,1 kg Weight 5,1 kg
Environmental conditions 10 - 40 °C Environmental conditions 10 - 40 °C

Electrical resistance Electrical resistance

Power supply 230 Volt AC / 325 Watt Power supply 115 Volt AC / 325 Watt
Absorption 1,4 Amper Absorption 2,8 Amper
Power 325 Watt Power 325 Watt

Vacuum Pump Vacuum Pump

Frequency 50 Hz Frequency 60 Hz
Nominal ow 12 l/min Nominal ow 14 l/min
Final pressure (ASS) 250 mbar Final pressure (ASS) 210 mbar
Noise with silencer 56 dB/(A) Noise with silencer 58 dB/(A)
Motor power 80 Watt Motor power 80 Watt
Absorption 0,90 Amper Absorption 1,63 Amper

Gearmotor Gearmotor

Power supply 24 Volt Power supply 24 Volt
Absorption 0,6 Amper Absorption 0,6 Amper
Power 12 Watt Power 12 Watt

TECHNICAL DATA

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

44

INSTRUCTIONS FOR USE FOR THE “WELL”

e presence of the well makes the B-FORM thermoformer machines very ecient and
complete ( ).
In the beads of the well, you have the possibility to immerse, to the depth you want, indi­vidual teeth, teeth sections or an entire model.
e use of the Well is recommended for those plaster models that have a pronounced un­dercut, i.e. because it is not possible to prepare a plaster model as described in the chap­ter “ ”. e use of the well becomes necessary, therefore, if you
have a very high plaster model, with undercuts, sharp edges and with palate or buccal
oor. Failure to use the well may lead to the breakage of the heated sheet during the de­scent of the blocking plate with the consequent hindrance of the thermoforming process
Before the well can be used, the following operations must be performed:

1. Place a portion of the beads in the well and level them.

2. Put the plaster model or the individual teeth or teeth sections that you would like to
reproduce inside the well and verify that the area of the model to be molded comes
out completely from the edge of the well. If the area that you want to mold does
not come out completely from the edge of the well, remove the plaster model from
the well and add other beads and level them. Repeat this process until the area that

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

45

you want to mold comes out completely from the edge of the well. Finally, cover the
entire plaster model with beads and level them, leaving uncovered only the area that
you want to mold.

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

46

is guide uses the following symbols to indicate important information. Always follow
the instructions indicated by these symbols.

ATTENZIONE: is symbol indicates instructions whose non-compliance involves

the risk of serious damage to persons or property caused by the incorrect use of the
device. ese instructions must be observed for safe use.

NOTA : is symbol indicates additional operational procedures and other useful in-

formation.

SYMBOLS

Fuse

Danger of crushing

Hot surfaces

Electric voltage

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

47

For the disposal of the B-FORM thermoformer machines, please refer to the laws of each
country.

DISPOSAL

ITALIA

Via Bassa 36

48123 Mezzano (RA)

Tel. / Fax: [phone]

[e-mail]

www.bartmedical.com

48

VIDEOS
