Page 1
BB005
Dal 1901
COD. 9942045.06 REV.00
Page 2
Dal 1901
2
BEZZERA BB005
cod. 9942045.06 rev.00
POS CODE DESCRIPTION
1 5097809.01LL FILTER HOLDER BRACKET
2 5340008LL NOZZLE
3 7633333 SWITCH
4 7613007 FAIRLEAD M17V 3121145 RUBBER
5 5070651LW COFFEE TRAY WITH LOGO
6 7633906 MICROSWITCH 250V
7 7816002 SCREW TCEI M4X12
8 7819901 SCREW TTEI M4X12
9 7819908 SCREW TTEI M4X8
10 7818002 TAPPING SCREW TPS D2.9X9.5
11 5071731LL COVER
12 7552001 CABLE WITH AUSTRALIAN PLUG
12 7551001 CABLE WITH USA PLUG 125V 15A
12 7551003 CABLE WITH USA PLUG 250V 20A
12 7555001 CABLE WITH SCHUKO PLUG
12 7555003 CABLE WITH SWITZERLAND PLUG
TABLE 1 (up to 31.12.09) - BB005NR
12 7554001 CABLE WITH ENGLISH PLUG
13 5071730LW BODY STAINLESS STEEL SATINED
14 5340007LL MOTOR SUPPORT
15 5963095R HOPPER WITH SPACER
18 0BDF1 COVER FOR HOPPER 0,25 KG
19 1R9009950 FEET
20 1R9001804 PLUG
21 7999904 ADHESIVE RUBBER TOP
22 7819911 SCREW TTEI M4X25
23 7822603 NUT M4
24 7814001 WASHER Ø 4
25 0BEB04CG SAFE-FINGER CAP GREY WITH MAGNET AND SCREW
26 5373001 COFFEE-PRESS
27 7990608 CLEANING BRUSH
28 7370502 CLAMP HOUSING
29 5522502 LABEL “BEZZERA”
Page 3
Dal 1901
3
BEZZERABB005
cod. 9942045.06 rev.00
Pressacaffè
5373001
1
26
Custodia morsetto
7370502
1
28
Targa "BEZZERA"
5522065
1
29
Pennello pulizia
7990608
145
18
25
15
11
2
7
13
20
4
12
6
23
24
14
22
19
8
5
21
1
3
27
26
28
29
10
TAV. 03
TABLE 1 (up to 31.12.09) - BB005NR
Page 4
Dal 1901
4
BEZZERA BB005
cod. 9942045.06 rev.00
POS CODE DESCRIPTION
1 5097809.01LL FILTER HOLDER BRACKET
2 5340008.01 NOZZLE
3 7633333 SWITCH
4 7613007 FAIRLEAD M17V 3121145 RUBBER
5 5070651LW COFFEE TRAY WITH LOGO
6 7633906 MICROSWITCH 250V
7 7816002 SCREW TCEI M4X12
8 7819908 SCREW TTEI M4X8
10 5071731.01LL COVER
11 7555001LL CABLE WITH SHUKO PLUG
11 7551001LL CABLE WITH USA PLUG 125V 15A
11 7551003LL CABLE WITH USA PLUG 250V 20A
11 7552001LL CABLE WITH AUSTRALIAN PLUG
11 7555003LL CABLE WITH SWITZERLAND PLUG
11 7554001LL CABLE WITH ENGLISH PLUG
12 5071730LW BODY STAINLESS STEEL SATINED
TABLE 1 (up to 16.09.10) - BB005NR
14 5340009.01LL MOTOR SUPPORT
17 0BDF1 COVER FOR HOPPER 0,25 KG
18 7822603 NUT M4
19 0BEB04CG SAFE-FINGER CAP GREY WITH MAGNET AND SCREW
20 5373001 COFFEE-PRESS
21 7990608 CLEANING BRUSH
22 5522502 LABEL “BEZZERA”
24 7818002 TAPPING SCREW TPS D2.9X9.5
27 7474212 ADHESIVE FEET
30 5224021 STUD
31 5471505 SPRING
32 7822603 NUT M4
33 7819901 SCREW TCI M4x12
34 7614005 CABLE-PRESS
35 5999911LL ADJUSTMENT HANDLE
36 5963095R HOPPER WITH SPACER
Page 5
Dal 1901
5
BEZZERABB005
cod. 9942045.06 rev.00
Serigrafia
macinatura
1
79
Pennello pulizia
7990608
1
80
31
30
7
14
8
5
1
3
27
12
22
11
34
32
33
4
24
10
2
19
17
20
21
6
35
18
36
33
TAV. 03
TABLE 1 (up to 16.09.10) - BB005NR
Page 6
Dal 1901
6
BEZZERA BB005
cod. 9942045.06 rev.00
POS CODE DESCRIPTION
1 5097809.01LL FILTER HOLDER BRACKET
2 5340008.03LL NOZZLE
3 7633333 SWITCH
4 7613007 FAIRLEAD M17V 3121145 RUBBER
5 5070651LW COFFEE TRAY WITH LOGO
6 7633906 MICROSWITCH 250V
7 7816002 SCREW TCEI M4X12
8 7819908 SCREW TTEI M4X8
9 5071731.02LL COVER
10 7555001LL CABLE WITH SHUKO PLUG
10 7551001LL CABLE WITH USA PLUG 125V 15A
10 7551003LL CABLE WITH USA PLUG 250V 20A
10 7552001LL CABLE WITH AUSTRALIAN PLUG
10 7555003LL CABLE WITH SWITZERLAND PLUG
10 7554001LL CABLE WITH ENGLISH PLUG
10 7551006LL CABLE WITH TAIWAN PLUG
TABLE 1 (from 17.09.10) - BB005NR
11 5071729.01LW BODY STAINLESS STEEL SATINED
12 5340009.02LL MOTOR SUPPORT
13 5963095R HOPPER WITH SPACER
15 0BDF1 COVER FOR HOPPER 0,25 KG
16 7305504 PLUG
18 0BEB04CG SAFE-FINGER CAP GREY WITH MAGNET AND SCREW
19 5373001 COFFEE-PRESS
20 7990608 CLEANING BRUSH
21 5522502 LABEL “BEZZERA”
22 7818002 TAPPING SCREW TPS D2.9X9.5
23 7474212 ADHESIVE FEET
24 5224021 STUD
25 5999911LL ADJUSTMENT HANDLE
26 5471505 SPRING
27 7614005 CABLE-PRESS
28 7822603 NUT M4
29 7819901 SCREW TCI M4x12
Page 7
Dal 1901
7
BEZZERABB005
cod. 9942045.06 rev.00
Bloccacavo
7614005
1
27
Dado esagonale M4
7822603
1
28
Vite con testa a bottone ed esagono incassato M4x12
7819901229
Pennello pulizia
7990608
1
20
15
18
13
19
22
26
9
8
20
24
25
11
21
27
28
4
29
10
6 16
23
12
5
3
1
7
2
29
TAV. 03
TABLE 1 (from 17.09.10) - BB005NR
Page 8
Dal 1901
8
BEZZERA BB005
cod. 9942045.06 rev.00
POS CODE DESCRIPTION
1 5097809.01LL FILTER HOLDER BRACKET
2 5340008LL NOZZLE
3 7667015 TIMER 110V
3 7667014 TIMER 230/240V
4 7633333 SWITCH
5 7613007 FAIRLEAD M17V 3121145 RUBBER
6 5070651LW COFFEE TRAY WITH LOGO
7 7633906 MICROSWITCH 250V
8 7816002 SCREW TCEI M4X12
9 7819901 SCREW TTEI M4X12
10 7819908 SCREW TTEI M4X8
11 7818002 TAPPING SCREW TPS D2.9X9.5
12 7809809 SCREW M3x5
13 5999910LL KNOB
14 5071731LL COVER
15 7555001 CABLE WITH SCHUKO PLUG
TABLE 2 (up to 31.12.09) - BB005TM
15 7551001 CABLE WITH USA PLUG 125V 15A
15 7551003 CABLE WITH USA PLUG 250V 20A
15 7552001 CABLE WITH AUSTRALIAN PLUG
15 7555003 CABLE WITH SWITZERLAND PLUG
15 7554001 CABLE WITH ENGLISH PLUG
16 5071729LW BODY STAINLESS STEEL SATINED X TIMER
17 5222204 SPACER M3 ES.6 H11 OT
18 5340009LL MOTOR SUPPORT
19 5963095R HOPPER WITH SPACER
22 0BDF1 COVER FOR HOPPER 0,25 KG
23 1R9009950 FEET
24 1R9001804 PLUG
25 7999904 ADHESIVE RUBBER TOP
26 7819911 SCREW TTEI M4X25
27 7822603 NUT M4
28 7814001 WASHER Ø 4
29 7817803 SCREW TPS M3X10 UNI 7688 DIN 965 A2
30 0BEB04CG SAFE-FINGER CAP GREY WITH MAGNET AND SCREW
31 5373001 COFFEE-PRESS
32 7990608 CLEANING BRUSH
33 7370502 CLAMP HOUSING
34 5522502 LABEL “BEZZERA”
Page 9
Dal 1901
G.BEZZERA
MACCHINE PER CAFFE’ ESPRESSO
Via Luigi Bezzera,1
20088 Rosate - Milano - Italy
Tel. ++39 02 90848102 r.a. - Telefax ++39 02 90870287
Web: www.g.bezzera.it
e-mail: [email protected]
Cod.9942045.06 ed.07/14 rev.00
