LED Round High Bay
UFO Junior
UFO Junior
Beyond LED Technology’s New Junior UFO High Bay is the newest and most feature rich
LED HIGH BAY FIXTURES
1
product of 2021. This Junior fixture offers High Lumens per Watt and it’s CCT Adjustable.
The UFO Junior is built to last with standard 4kv surge protection, 113°F ambient
temperature rating, and IP65 rating for elimination of dust, moisture, and airborne
contaminants. The unique easy connect driver to optical assembly interface allows for quick
and easy maintenance for applications including warehousing, gymnasiums, manufacturing,
and outdoor canopies. Our Junior High Bay is fully ready to integrate with most smart control
systems.
• Up to155 Lumens per watt
• CCT Adjustable 3000K, 4000K, & 5000K
• Ultra thin Sleek Design
• 0-10V Dimming capability
• Plug and Play Motion Sensor
• Several mounting options
• IP65 water, dust, corrosion, and pressure
proof
• Optional Emergency backup
• Universal 100-277Vac / 480Vac optional
• DLC listed
• Various installation methods
Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087
Due to continuous product improvement, information in this document is subject to change.
Pendent Surface-mounted
P/N: BLT-HB05B-240/XXXWS1XYD1-abcde
Note:
AST= Company name
HB05B = Product series, LED High Bay Light
240 = Rating Power
“XXX”can be any digits less or equal to input wattage;
“S1” stand for Driver manufacturer, sosen CNL series;
“X”stand for LED manufactory, could be any alphabet;
“Y”stand for cover type,could be PC lens;
“a” can be any two letters to represent lamp colors;
BH=Black, WH=White, or Customized;
“b” can be “S” or blank for Surge-protective
Device provided or not;
“c” can be “M” or blank for Motion Sensor provided
or not;
“d” can be “W” or blank for dimming module provided
or not
“e” can be any digits to represent CC T.
30/40/50K=3000/4000/5000K,
ADVANTAGE
¾ UL cUL certificate.
¾ LumiledsChip, high CRI.
¾ Input voltage 100-277VAC.
¾ Output constant current lever can be
adjusted through output cable with 0-10V.
¾ No UV or IR in the beam.
¾ Wattage Tunable
¾ Easy to install and operate.
¾ Energy saving, long lifespan.
P/N: BLT-HB05B-240/XXXWS1XYD1-abcde
Note:
AST= Company name
HB05B = Product series, LED High Bay Light
240 = Rating Power
“XXX”can be any digits less or equal to input wattage;
“S1” stand for Driver manufacturer, sosen CNL series;
“X”stand for LED manufactory, could be any alphabet;
“Y”stand for cover type,could be PC lens;
“a” can be any two letters to represent lamp colors;
BH=Black, WH=White, or Customized;
“b” can be “S” or blank for Surge-protective
Device provided or not;
“c” can be “M” or blank for Motion Sensor provided
or not;
“d” can be “W” or blank for dimming module provided
or not
“e” can be any digits to represent CC T.
30/40/50K=3000/4000/5000K,
ADVANTAGE
¾ UL cUL certificate.
¾ LumiledsChip, high CRI.
¾ Input voltage 100-277VAC.
¾ Output constant current lever can be
adjusted through output cable with 0-10V.
¾ No UV or IR in the beam.
¾ Wattage Tunable
¾ Easy to install and operate.
¾ Energy saving, long lifespan.
Pendent Surface-mounted
Note:
AST= Company name
HB05B = Product series, LED High Bay Light
240 = Rating Power
“XXX”can be any digits less or equal to input wattage;
“S1” stand for Driver manufacturer, sosen CNL series;
“X”stand for LED manufactory, could be any alphabet;
“Y”stand for cover type,could be PC lens;
“a” can be any two letters to represent lamp colors;
BH=Black, WH=White, or Customized;
“b” can be “S” or blank for Surge-protective
Device provided or not;
“c” can be “M” or blank for Motion Sensor provided
or not;
“d” can be “W” or blank for dimming module provided
or not
“e” can be any digits to represent CC T.
30/40/50K=3000/4000/5000K,
ADVANTAGE
¾ UL cUL certificate.
¾ LumiledsChip, high CRI.
¾ Input voltage 100-277VAC.
¾ Output constant current lever can be
adjusted through output cable with 0-10V.
¾ No UV or IR in the beam.
¾ Wattage Tunable
¾ Easy to install and operate.
¾ Energy saving, long lifespan.
¾ Light is soft and uniform, safe to eyes.
¾ Instant start, NO flickering, NO humming.
¾
Green and eco-friendly without mercury.
APPLICATION
Note:
AST= Company name
HB05B = Product series, LED High Bay Light
240 = Rating Power
“XXX”can be any digits less or equal to input wattage;
“S1” stand for Driver manufacturer, sosen CNL series;
“X”stand for LED manufactory, could be any alphabet;
“Y”stand for cover type,could be PC lens;
“a” can be any two letters to represent lamp colors;
BH=Black, WH=White, or Customized;
“b” can be “S” or blank for Surge-protective
Device provided or not;
“c” can be “M” or blank for Motion Sensor provided
or not;
“d” can be “W” or blank for dimming module provided
or not
“e” can be any digits to represent CC T.
30/40/50K=3000/4000/5000K,
ADVANTAGE
¾ UL cUL certificate.
¾ LumiledsChip, high CRI.
¾ Input voltage 100-277VAC.
¾ Output constant current lever can be
adjusted through output cable with 0-10V.
¾ No UV or IR in the beam.
¾ Wattage Tunable
¾ Easy to install and operate.
¾ Energy saving, long lifespan.
¾ Light is soft and uniform, safe to eyes.
¾ Instant start, NO flickering, NO humming.
¾
Green and eco-friendly without mercury.
APPLICATION
LED Round High Bay
UFO Junior
UFO Junior Series - HD High Bay Light
SKU # Model # Watts Lumens CCT Housing Color Input Voltage Certifications
151778 BLT-HB05B-240WS1XYD1-abcde 240W 33600Lm
CCT Adjustable
3000
3500K/4000K/5000K
Standard
Hook Mount
Dimensions
White 100-277Vac UL
Optional
200W / 240W U-Bracket
SKU: 151886
Optional Motion Sensor
SKU: 152598
Optional Motion Sensor
Remote SKU: 152613
LED HIGH BAY FIXTURES
Hook Mounted
Surface Mounted
7.59843”
ø 14.5669”
ø 14.5669”
Hook Mounted with Motion
Sensor
Surface Mounted with
Motion Sensor
8.07087”
ø 14.5669”
ø 14.5669”
(866) 786-1117 • www.BeyondLEDTechnology.com
Due to continuous product improvement, information in this document is subject to change.
9.13386”
9.6063”
CORRELATED COLOR
TEMPERATURE (CCT)
2
LED Round High Bay
LED UFO High Bay Junior Series 240W Page 2 of 3
SPECIFICATIONS
UFO Junior
Specifications
Input Power (Tolerance : ±10%) 240W
Color Temperature 3000K 4000K 5000K
OPTICAL
ELECTRICAL
LED HIGH BAY FIXTURES
MATERIALS
OTHERS
Lumen (Tolerance : -10%) 32650LM 37200LM 34550LM
Efficacy (Tolerance : -3%) 136LM/W 155LM/W 144LM/W
CRI >80
Color Consistency ˘6 Steps (or ˘6 SDCM)
UGR ˘28 (X=4H, Y=8H; S/H=1; Reflectances: 70%/50%/20%)
Diffuser Type PC Lens
Beam Angle (50%) (Tolerance : ±15%) 90 Degree
Input Voltage and Frequency 100-277VAC, 50/60Hz
PF (Tolerance : -3%)
THD (Tolerance : +5%)
Flicker Percent ˘5%
Driver Brand SOSEN
Driver Model SS-240CNL-260BH
Driver Surge protection L/N-PE: 4k V, L -N: 4kV
Dimming 0-10V dimming standard
Optional Accessory
LED Brand Lumileds
LED Type SMD2835
LED QTY 800PCS
Housing Die-cast aluminum
Housing Color White
Waterproof Rating WET˄IP65˅
Operating Temperature
Storage Temperature -40°F to 176°F
Operating Humidity 20ˁ - 90ˁ RH
Storage Humidity 10ˁ - 95ˁ RH
Warranty 5 years warranty with 24/7 operating hours Luminaire lifetime at 77°F.
Motion Sensor, Surge-protective Device
-40°F to 122°F
3
Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087
Due to continuous product improvement, information in this document is subject to change.
LED Round High Bay
LED UFO High Bay Junior Series 240W Page 2 of 3
SPECIFICATIONS
OPTICAL
Input Power (Tolerance : ±10%) 240W
Color Temperature 3000K 4000K 5000K
Lumen (Tolerance : -10%) 32650LM 37200LM 34550LM
Efficacy (Tolerance : -3%) 136LM/W 155LM/W 144LM/W
CRI >80
Color Consistency ˘6 Steps (or ˘6 SDCM)
UGR ˘28 (X=4H, Y=8H; S/H=1; Reflectances: 70%/50%/20%)
Diffuser Type PC Lens
Beam Angle (50%) (Tolerance : ±15%) 90 Degree
ELECTRICAL
Input Voltage and Frequency 100-277VAC, 50/60Hz
PF (Tolerance : -3%)
THD (Tolerance : +5%)
Flicker Percent ˘5%
Driver Brand SOSEN
Driver Model SS-240CNL-260BH
Driver Surge protection L/N-PE: 4k V, L -N: 4kV
Dimming 0-10V dimming standard
Optional Accessory
Motion Sensor, Surge-protective Device
MATERIALS
LED Brand Lumileds
LED Type SMD2835
LED QTY 800PCS
Housing Die-cast aluminum
Housing Color White
Waterproof Rating WET˄IP65˅
OTHERS
Operating Temperature
-40°F to 122°F
Storage Temperature -40°F to 176°F
Operating Humidity 20ˁ - 90ˁ RH
Storage Humidity 10ˁ - 95ˁ RH
Warranty 5 years warranty with 24/7 operating hours Luminaire lifetime at 77°F.
PACKAGE
Lamp Type Carton Size Qty / Carton Net Weight / Carton Gross Weight / Carton
Pendent
18” x 18” x 9”
1 PC 10 Lbs 13 Lbs
Surface-mounted
18” x 18” x 9”
1
PC 12 Lbs 14 Lbs
Tolerance of Carton Size: ±0.59 IN, Tolerance of Weight: ±10%.
1 PC 10 Lbs 13 Lbs
1
PC 12 Lbs 14 Lbs
UFO Junior
Packing
Model Type Pcs/Box Dimensions Weight Pallet Quantity Pallet Weight Pallet Dimensions
240W Hook Mount UFO 1
240W Surface Mount UFO 1
18” X 18” X 9” 10 Lb
18” X 18” X 9” 12 Lb
LED HIGH BAY FIXTURES
(866) 786-1117 • www.BeyondLEDTechnology.com
Due to continuous product improvement, information in this document is subject to change.
4
Installation
LED Round High Bay
UFO Junior
LED HIGH BAY FIXTURES
5
Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087
Due to continuous product improvement, information in this document is subject to change.
Installation
LED Round High Bay
UFO Junior
LED HIGH BAY FIXTURES
(866) 786-1117 • www.BeyondLEDTechnology.com
Due to continuous product improvement, information in this document is subject to change.
6
LED Round High Bay
UFO Junior
Motion Sensor Specifications - SKU 152598
LED HIGH BAY FIXTURES
7
Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087
Due to continuous product improvement, information in this document is subject to change.
LED Round High Bay
UFO Junior
Motion Sensor Specifications - SKU 152598
LED HIGH BAY FIXTURES
(866) 786-1117 • www.BeyondLEDTechnology.com
Due to continuous product improvement, information in this document is subject to change.
8
LED Round High Bay
UFO Junior
Motion Sensor Remote Control Specifications - SKU 152613
LED HIGH BAY FIXTURES
9
Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087
Due to continuous product improvement, information in this document is subject to change.
ASMART LIGHT CO., LIMITED
E-mail: sales@asmart-light.com
www.asmart-light.com
P/N: AST-HB05B-240WRBCGD1-abcd
Note:
AST= Company name
HB05B = Product series, LED High Bay Light
240W = Rating Power
R= Driver manufacturer, DAERMAY
B= LED manufactory, could be Lumileds 2835.
CG=cover type, flat clear glass.
D1 = Version number
a=Stand for lamp colorˈCan be any two letters
b=Surge-Protective DeviceˈCan be S or blank
c= M
otion Sensor,can be M or blank,
LED HIGH BAY LIGHT Page 1 of 3
LED HIGH BAY LIGHT Page 1 of 3
ASMART LIGHT CO., LIMITED
E-mail: sales@asmart-light.com
www.asmart-light.com
P/N: AST-HB05B-240WRBCGD1-abcd
Note:
AST= Company name
HB05B = Product series, LED High Bay Light
240W = Rating Power
R= Driver manufacturer, DAERMAY
LED HIGH BAY LIGHT Page 1 of 3
LED Round High Bay
UFO Junior
User Notice
• Please turn off the power before installing or changing assembly parts.
• The input voltage and lamps should be matching. Before connecting the power line, please
make sure the wiring section is insulated.
• Only professionals should install and disassemble the lamps.
Trouble Shooting
LED HIGH BAY FIXTURES
• Flickering light - Turn off the power and turn on again in 3 minutes. If the same phenomena
occurs, then call Support.
• Not working - Please check all power connections.
Application
(866) 786-1117 • www.BeyondLEDTechnology.com
Due to continuous product improvement, information in this document is subject to change.
10
Application
LED Round High Bay
UFO Junior
LED HIGH BAY FIXTURES
11
Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087
Due to continuous product improvement, information in this document is subject to change.
Loading...
