Beyond LED Technology BJON1077 Specifications

LED Linear High Bays

SM Series

1

I N D OOR : L E D HIG H BAY FIXTURES

SM Series

Our SM Series Linear High Bay is the most feature rich product in this category. Durable,
aluminum housing with integrated junction box allows for easy installation. SM Linear High
Bay comes with a white polyester powder-coat finish and is fully ready to integrate with
most smart control systems.

• Ultra thin Sleek Design

• 1-10V Dimmable

• Up to 140 Lumens per watt

• Seoul 2835 Made in Korea Chip

• Plug and Play Motion Sensor

• Several mounting options
( Chain, Surface Mount and Pendant Mount)

• Optional Emergency backup

• Universal 120-277Vac / 480Vac optional

• DLC Premium listed

2’ Models - 105W/165W 4’ Models - 225W/300W

Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087

Due to continuous product improvement, information in this document is subject to change.

LED Linear High Bays

LED LINEAR HIGHBAY

Shenzhen XSY Lighting Co.,Ltd

SM Series

SM Series

SKU # Model # Watts Lumens CCT Size Input Voltage Certifications

151231 BLT-SMHB2P105-XXK-YZ-EF 105W 14700Lm 5000K 2ft 120-277Vac UL & DLC Premium

151357 BLT-SMHB2P165-XXK-YZ-EF 165W 23100Lm 5000K 2ft 120-277Vac UL & DLC Premium

151347 BLT-SMHB4P300-XXK-YZ-EF 300W 42000Lm 5000K 4ft 120-277Vac UL & DLC Premium

INDOOR : L E D HIG H BAY FIX T U RES

Specifications

• 140Lm/W Efficacy

• 120° beam angle

• >80 CRI

Motion Sensor

• Seoul 2835SMD LED

• Integrated enclosure design

• UL/CUL/DLC

Optional Accessories

Emergency Driver

CORRELATED COLOR

TEMPERATURE (CCT)

[phone] • www.BeyondLEDTechnology.com

Due to continuous product improvement, information in this document is subject to change.

2

Type A Type B Type C Type D

LED Linear High Bays

Dimensions

SM Series

2ft

23.03”

15.75”

1.18”

1.84”

INDOOR: LED HIGH BAY FIXTURES

4ft

46.06”

15.75”

1.18”

1.84”

3

Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087

Due to continuous product improvement, information in this document is subject to change.

Features

P/N: AST-PHB05-300WBFP3C2-abde

Note:

AST= Company name

PHB05 = Product series, LED Linear High Bay Light

300W = Rating Power

B= LED manufacturer, Lumileds 2835

F = Cover type, Frosted Lens

P3= Sosen Class P Driver

C2 = Version number

a = Housing colors, WH=White

b= Sensor, MS or PS or Blank(Motion Sensor or PIR

Sensor)

Structure

Only 1.7’’ thickness,
super thin design

LED Linear High Bays

SM Series

LED Driver

Class 2, Class P driver
AC120-277V, AC120-347V,
AC277-480V oponal

INDOOR: LED HIGH BAY FIXTURES

Paint

Highly Reflecve
Metal Paint, achieve
opmal apperance design

Housing

Integrated enclosure
design

Emergency backup

UL listed, 90min , suitable
for different size EM bac kup

Optional Motion Sensor

DC12Vsensor

[phone] • www.BeyondLEDTechnology.com

Due to continuous product improvement, information in this document is subject to change.

4

LED Linear High Bays

Photometric

0

30

60

90

120

150

-/+180

-150

-120

-90

-60

-30

UNIT:c d

C0/180,100. 6

UNIT:c d

C30/210,101. 5

UNIT:c d

C60/240,104. 6

UNIT:c d

C90/270,104. 9

AVERAGE BEAM ANGLE(50%):102.9 DEG

0

1200

2400

3600

4800

60 00

105W 2� 5000K 165W 2� 5000K

0

30

60

90

120

150

-/+180

-150

-120

-90

-60

-30

UNIT:c d

C0/180,99. 8

UNIT:c d

C30/210,100. 9

UNIT:c d

C60/240,104. 6

UNIT:c d

C90/270,105. 0

AVERAGE BEAM ANGLE(50%):102.6 DEG

0

3000

6000

9000

12000

15 00 0

225W 2� 5000K 165W 4� 5000K

225W 4� 5000K 300W 4� 5000K

24 0.8 6cm

48 1.7 3cm

72 2.5 9cm.

96 3.4 6cm

12 04. 32cm

14 45. 18cm

16 86. 05cm

19 26. 91cm

21 67. 78cm

24 08. 64cm

Di ame ter

o :

Photometric

105W 2� 5000K 165W 2� 5000K

(LED LINEAR HIGH BAY)

LED HIGH BAY SERIES

BEYOND SIGNS INC DBA BEYOND

LED TECHNOLOGY

Distribution Diagram

-/+180

1200

2400

3600

4800

60 00

150

120

0

0

30

90

60

UNIT:c d

UNIT:c d

UNIT:c d

UNIT:c d
C0/180,100. 6
C30/210,101. 5
C60/240,104. 6
C90/270,104. 9

-150

-120

-90

-60

-30

AVERAGE BEAM ANGLE(50%):102.9 DEG

SM Series

o :

24 0.8 6cm

48 1.7 3cm

72 2.5 9cm.

96 3.4 6cm

12 04. 32cm

14 45. 18cm

16 86. 05cm

19 26. 91cm

21 67. 78cm

24 08. 64cm

Di ame ter

INDOOR: LED HIGH BAY FIXTURES

5

Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087

Due to continuous product improvement, information in this document is subject to change.

LED Linear High Bays

SM Series

Mounting Accessories (Optional)

INDOOR : L E D HIG H BAY FIX T U RES

PendantSurfaceChain/Suspension

[phone] • www.BeyondLEDTechnology.com

Due to continuous product improvement, information in this document is subject to change.

6

LED Linear High Bays

Photometric

0

30

60

90

120

150

-/+180

-150

-120

-90

-60

-30

UNIT:c d

C0/180,100. 6

UNIT:c d

C30/210,101. 5

UNIT:c d

C60/240,104. 6

UNIT:c d

C90/270,104. 9

AVERAGE BEAM ANGLE(50%):102.9 DEG

0

1200

2400

3600

4800

60 00

105W 2� 5000K 165W 2� 5000K

0

30

60

90

120

150

-/+180

-150

-120

-90

-60

-30

UNIT:c d

C0/180,99. 8

UNIT:c d

C30/210,100. 9

UNIT:c d

C60/240,104. 6

UNIT:c d

C90/270,105. 0

AVERAGE BEAM ANGLE(50%):102.6 DEG

0

3000

6000

9000

12000

15 00 0

225W 2� 5000K 165W 4� 5000K

225W 4� 5000K 300W 4� 5000K

Installaon

ALWAYS TURN OFF THE POWER SUPPLY FROM MAIN CIRCUIT BREAKER FIRST!

24 0.8 6cm

48 1.7 3cm

72 2.5 9cm.

96 3.4 6cm

12 04. 32cm

14 45. 18cm

16 86. 05cm

19 26. 91cm

21 67. 78cm

24 08. 64cm

Di ame ter

o :

SM Series

Installation

Chain/Suspension

1. Chain installaon

1. Hook the cha in

2. Insert the hook into th e sloed
holes as shown

INDOOR: LED HIGH BAY FIXTURES

4. Turn off power, then make wiring
Connecon s with termina l cap

5. Insert the ter minal cap and wi re
into the driver box

3.Hook up the c hain on the ceiling
anchor

6. Insert the wire terminal joi nt
to the wire entry

7

Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087

Due to continuous product improvement, information in this document is subject to change.

Installation

LED Linear High Bays

SM Series

INDOOR : L E D HIG H BAY FIX T U RES

Surface

Diag ra m 2

80mm(3.15inch)

90mm(3.54inch)

27mm(1.06inch)

6. Wirin g L, N, E into the terminal block. Fast en

the two en d cap s on the ceiling bracket and

lock theM4 screw 1pcs.

[phone] • www.BeyondLEDTechnology.com

Due to continuous product improvement, information in this document is subject to change.

8

Installation

2. Surface Mounng installaon

6. Wirin g L, N, E into the terminal block. Fasten

the two en d cap s on the cei ling bracket and

lock theM4 screw 1p cs.

3. Us e th e to ol to op en 4 holes at the

top, and then fix th e ceilin g brac ket

4. Re move the iron p ie ce for easy

wir in g.

5. Li� the lamp into the bracket, align the

sid e holes , an d lo ck t he M 5 sc rews.

1. Dr il l th e ho le a cc ording to the size of

the b ra cke t an d in se rt t he p lasc

exp an si on t ub e.

Diag ra m 2

27mm(1.06inch)

80mm(3.15inch)

90mm(3.54inch)

2. Us e a ha mm er t o dr ive the nyl on

ex pan sio n t ube in to t he d ril led

hole on t he wall .

4. Turn off powe r, then make wiring
Connecon s with te rminal cap

5. Insert the terminal cap and wire
into the driver box

6. Insert the w ire termi nal joint
to the wire entry

LED Linear High Bays

SM Series

3. Pendant Mount installaon

Pendant

1. Th read th e 3/ 4 in ch conduit into

the hol eof upper box , an d sc rew

the nut a t en d.

INDOOR: LED HIGH BAY FIXTURES

9

3. Di sa ss em bl e th e te rm in al b lo ck , insert the

2. Li ft t he s cr ew h oles of the fixture to al ig n th e

4. Cov er the tw o sid es o f the c ov er an d lock

the M4 s crew 1p cs.

bra cke t sc rews, a nd t he n ti gh ten with the

M5 * 6s cr ews.

5. Che ck if the a sse mb ly is i nstal led a nd t hen

powe r on.

wi res L , N, E in t he h ollo w tu be i nto t he

ter mi na l bl oc k, a nd s ee t he s ig ns L , N, E .

Install the terminal block locki ng s cr ews.

Rei nstall the co ver plate s at b ot h en ds .

Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087

Due to continuous product improvement, information in this document is subject to change.

Model

2FT 105W

2FT 165W

2FT 225W

4FT 165W

4FT 225W

4FT 300W

Carton Dimension

Package Info.

Safety Precauon

To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts, cuts/abrasions, and other

25.39’’*6.77’’*17.91’’

48.43’’*6.77’’*17.91’’

Qty / Carton

2PCS

2PCS

N.W

17.2lbs

15.52lbs

19.4lbs

30.86lbs

31.75lbs

33.95lbs

G.W

21.16Ibs

23.15lbs

24.25lbs

37.04lbs

37.92lbs

40.12lbs

20GP

960PCS

500PCS

40HQ

2640PCS

1374PCS

4. Cov er th e tw o sid es o f the c over an d loc k

the M4 s cre w 1p cs.

5. Che ck if t he a sse mb ly is i nst al led a nd then

powe r on.

Model

2FT 105W

2FT 165W

2FT 225W

4FT 165W

4FT 225W

4FT 300W

Carton Dimension

Package Info.

25.39’’*6.77’’*17.91’’

48.43’’*6.77’’*17.91’’

Qty / Carton

2PCS

2PCS

N.W

17.2lbs

15.52lbs

19.4lbs

30.86lbs

31.75lbs

33.95lbs

G.W

21.16Ibs

23.15lbs

24.25lbs

37.04lbs

37.92lbs

40.12lbs

20GP

960PCS

500PCS

40HQ

2640PCS

1374PCS

4. Cov er th e tw o sid es of t he c ove r and l oc k

the M4 s cre w 1p cs.

5. Che ck if t he a sse mbl y is i nst all ed a nd th en

powe r on.

Package Info.

4. Cover the two sides of the cover and lock

the M4 screw 1pcs.

5. Check if the assembly is installed an d the n

power on.

Packing

400.00

46.00

400.00

46.00

1170.00

LED Linear High Bays

SM Series

INDOOR: LED HIGH BAY FIXTURES

Model

2FT 105W

2FT 165W

2FT 225W

4FT 165W

4FT 225W

4FT 300W

Carton Dimension

25.39’’*6.77’’*17.91’’

48.43’’*6.77’’*17.91’’

Qty / Carton

2PCS

2PCS

N.W

17.2lbs

15.52lbs

19.4lbs

30.86lbs

31.75lbs

33.95lbs

G.W

21.16Ibs

23.15lbs

24.25lbs

37.04lbs

37.92lbs

40.12lbs

20GP

960PCS

500PCS

Safety Precautions

hazards read all warnings and instrucons included with and on the fixture box and all fixture labels.
Before installing, servicing, or performing roune maintenance upon this equipment, follow these general precauons.
Commercial installaon, service and maintenance of luminaires should be performed by a qualified licensed electrician.
For The installaon: If you are unsure about the installaon or maintenance of the luminaires, consult a qualified licensed electrician
and check your local electrical code.
To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects.
Do not make or alter any open holes in an enclosure of wiring or electrical components during kit installaon.

WARNING: RISK OF FIRE OR ELECTRICAL SHOCK

Turn off electrical power at fuse or circuit breaker box before wiring fixture to the power supply.
Turn off the power when you perform any maintenance.
Verify that supply voltage is correct by comparing it with the luminaire label informaon.
Make all electrical and grounded connecons in accordance with the Naonal Electrical Code and any applicable local code
requirements.
All wiring connecons should be capped with UL approved wire connectors.

CAUTION: RISK OF INJURY

Avoid direct eye exposure to the light source while it is on.
Account for small parts and destroy packing material, as these may be hazardous to children.
SUITABLE FOR DRY OR DAMP LOCATION

40HQ

2640PCS

1374PCS

[phone] • www.BeyondLEDTechnology.com

Due to continuous product improvement, information in this document is subject to change.

10
