Beyond LED Technology BJON1067 Specifications

LED Landscaping Light

Boise Series

Boise Series

Beyond LED’s Boise Series Landscaping lights are the best solutions to replace HID lamps.
Superior performance and robust design make this product suitable for any general purpose

LED LANDSCAPING LIGHTS

1

landscape lighting application such as garden, signage, and accent lighting in heavy
commercial and residential applications. Its great for lighting flags, monuments, steeples, and
bridges.

• High Lumens per watt

• Easy to install and operate

• Ground Stake or Lawn Base options

• Wide rotation angle, flexible and
convenient

• Durable, anti-aging, and resists damage

• Aluminum Alloy housing

• Good heat dissipation and anti-corrosion

• Optical-grade PC lampshade

Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087

Due to continuous product improvement, information in this document is subject to change.

• Transparent polycarbonate optical lens

• No UV or IR in the beam

• Strict waterproof and dustproof treatment for
dry or wet locations

• Energy saving, long lifespan

• Light is soft and uniform, safe to eyes

• Instant start, NO flickering, NO humming

• Green and eco-friendly without mercury

• Universal 100-277Vac

LED Landscaping Light

Warning: Risk of electrical shock
Turn o electrical power at fuse or circuit breaker box before wiring xture to
the power supply；Verify that supply voltage is within right and reasonable
limits. Connect the xture with 100-277V 50/60Hz power supply;Make all
electrical and grounded connections in accordance with the National
Electrical Code and applicable local code requirements；

SPECIFICATION

Warning: Risk of electrical shock

Turn o electrical power at fuse or circuit breaker box before wiring xture to

the power supply；Verify that supply voltage is within right and reasonable

limits. Connect the xture with 100-277V 50/60Hz power supply;Make all

electrical and grounded connections in accordance with the National

Electrical Code and applicable local code requirements；

All wiring connections should be capped with UL approved wire connec-

tions.

Warning: Risk of burn

Wear gloves and safety glasses at all times when moving luminaire from

carton, installing, servicing or performing maintenance;Avoid direct eye

SPECIFICATION

Warning: Risk of electrical shock

Turn o electrical power at fuse or circuit breaker box before wiring xture to

the power supply；Verify that supply voltage is within right and reasonable

limits. Connect the xture with 100-277V 50/60Hz power supply;Make all

electrical and grounded connections in accordance with the National

Electrical Code and applicable local code requirements；

All wiring connections should be capped with UL approved wire connec-

tions.

Warning: Risk of burn

Wear gloves and safety glasses at all times when moving luminaire from

carton, installing, servicing or performing maintenance;Avoid direct eye

exposure to the light source while it is on. LED lights are very bright. Do not

stare LED light beam in any case. Or this may cause irreparable damage to

the eyes.; Allow xture to cool before handling.

Do not touch enclosure or light source;Do not exceed maximum wattage

marked on luminaire label.

Warning: beware of re

Keep combustible and other materials that can burn away from lamp/lens.。

SPECIFICATION

Warning: Risk of electrical shock

Turn o electrical power at fuse or circuit breaker box before wiring xture to

the power supply；Verify that supply voltage is within right and reasonable

limits. Connect the xture with 100-277V 50/60Hz power supply;Make all

electrical and grounded connections in accordance with the National

Electrical Code and applicable local code requirements；

All wiring connections should be capped with UL approved wire connec-

tions.

Warning: Risk of burn

Wear gloves and safety glasses at all times when moving luminaire from

SPECIFICATION

LED LAWN LIGHT

INSTALLATION METHOD

04

1.Connect the power

cable to junction box, then

fixed junction box.

2.Installed the lamp

on the base.

Warning: Risk of electrical shock

Turn o electrical power at fuse or circuit breaker box before wiring xture to

the power supply；Verify that supply voltage is within right and reasonable

limits. Connect the xture with 100-277V 50/60Hz power supply;Make all

electrical and grounded connections in accordance with the National

LED LAWN LIGHT

INSTALLATION METHOD

LED LAWN LIGHT

Boise Series

Boise Series

SKU # Model # Watts Lumens CCT Housing Color Input Voltage Mount

151734 BLT-CL-G70-DC-10W 10W 800Lm 3000K Brown 12VAC/DC Ground Stake

151735 BLT-CL-G70-AC-10W 10W 1000Lm 3000K Brown 100-277Vac Lawn Base

Wide rotation angle,

flexible and convenient

Specifications

LED LANDSCAPING LIGHTS

Model:

Color:

Driver:

Power:

Voltage:

BLT-CL-G70-DC-10W | BLT-CL-G70-AC-10W

Brown

Non-dimmable driver

10W

12VAC/DC | 100-277VAC 50/60Hz

CORRELATED COLOR

TEMPERATURE (CCT)

Product Size:

CRI:

CCT:

Source:

Beam Angle:

Led Q’ty:

Applicable Environment:

Cover Type:

Lumens:

Light Efficacy:

Package:

Package Q’ty:

Due to continuous product improvement, information in this document is subject to change.

[phone] • www.BeyondLEDTechnology.com

4.1339” X 2.7559” X 6.5748” | 4.5276” X 2.7559” X 8.8583”

Ra≥80

3000K

COB

100°

1 pcs

Dry/wet location

Transparent PC

800LM | 1000LM

up to 80Lm/W | up to 100Lm/W ETL

4” X 3” X 8” | 5” X 4” X 10”

40pcs | 12pcs

2

38 0 50 0 60 0 70 0 80 0

Wa vel en gt h( nm)

0. 0

0. 2

0. 4

0. 6

0. 8

1. 0

1. 2

Spec trum

4. 2 SDCM

01

. Led source use high bright LED chip, energy saving and pro-environment, lighting stableand long lifespan.
. Optical-grade PC lampshade, the light is good, anti-aging, difficult to damage；
. High heat conduction aluminum alloy shell, good heat dissipation, vacuum dust-free spray,anti-corrosion, no stripping；
. Strict waterproof treatment technology, meet international waterproof and dustproof standards；
. Can three-dimensional rotate, wide rotation angle, flexible and convenient adjustment；
. Radiate light protection design, won’t affect the lighting effects because of weather。

Product Name：
Model:
Driver:
Power:
Voltage:
Cri:
C C T:
Source :
Beam Angle:
Led Q'ty:
Applicable Environment:
Cover Type
Color:
Lumen:
Light Efficiency:
Product size:
Package:
Qty:
N.W.:
G.W.:

LED Landscape Light
CL-G70-DC-10W
Non-dimmable driver
10W
100-277V 50/60Hz
Ra≥80
3000K、4000K、5000K、6000K
COB
100°
1 pcs
Dry/wet location
Transparent PC
White/brown
750LM
75LM/W
80*75*180mm
85*75*190mm
40pcs
350g
450g

SPECIFICATION

LED LAdNscape LIGHT PARAMETER

02

FEATURES

03

LIGHT SOURCE TEST REPORT

ETL CLASSIFIED

5002143

Spectrum

80*75*180mm
85*75*190mm
40pcs
350g
450g

Wa vel e ng t h(n m)

85*75*190mm
40pcs
350g
450g

LED Landscaping Light

Boise Series

Distribution Diagram

1.2

1.0

0.8

0.6

0.4

0.2

LED LANDSCAPING LIGHTS

0.0
380 500 600 700 800

Wavel e n g t h (nm)

Color Parameters:
Chromaticity Coordinate:x=0.4316(dx=-0.0027) y=0.3975(dy=-0.0057)
Chromaticity Coordinate:u'=0.2500 v'=0.5180(duv=-1.90e-03)
Tc=3038K Dominant WL:Ld=583.4nm Purity=48.8% Centroid WL:588.0nm
Ratio:R=24.5% G=72.8% B=2.7% Peak WL:Lp=600.0nm HWL:122.8nm
Render Index:Ra=81.8

R1 =81 R2 =93 R3 =94 R4 =78 R5 =81 R6 =91 R7 =80
R8 =57 R9 =5 R10=83 R11=76 R12=70 R13=84 R14=97 R15=74

Photo Parameters:
Flux: 792.34 lm Fe: 2.4202 W Efficacy:82.26 lm/W

4.2 SDCM

3

Electrical Parameters:
Luminaire: U=110.2V I=0.08883A P=9.632W PF=0.9835

Instrument Status:
Scan Range:380.0nm-800.0nm Interval:5.0nm[0] Ip=33037(G=5,D=58)
REF=27248(R=3)%=-0.224% PMT: 30.4 centigrade [150.0]

Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087

Due to continuous product improvement, information in this document is subject to change.

x=0.440 y=0.403 F3000

Installation

INSTALLATION METHOD

04

Warning: Risk of electrical shock
Turn o electrical power at fuse or circuit breaker box before wiring xture to
the power supply；Verify that supply voltage is within right and reasonable
limits. Connect the xture with 100-277V 50/60Hz power supply;Make all
electrical and grounded connections in accordance with the National
Electrical Code and applicable local code requirements；
All wiring connections should be capped with UL approved wire connec-
tions.
Warning: Risk of burn
Wear gloves and safety glasses at all times when moving luminaire from
carton, installing, servicing or performing maintenance;Avoid direct eye
exposure to the light source while it is on. LED lights are very bright. Do not
stare LED light beam in any case. Or this may cause irreparable damage to
the eyes.; Allow xture to cool before handling.
Do not touch enclosure or light source;Do not exceed maximum wattage
marked on luminaire label.
Warning: beware of re
Keep combustible and other materials that can burn away from lamp/lens.。

SPECIFICATION

SPECIFICATION

LED Landscaping Light

Boise Series

1.Connect the power
cable to junction box, then
fixed junction box.

2.Installed the lamp
on the base.

LED LANDSCAPING LIGHTS

White

Black

GND

L

N

3.Connect the
power cord.

Warning: Risk of electrical shock
Turn o electrical power at fuse or circuit breaker box before wiring xture to
the power supply；Verify that supply voltage is within right and reasonable
limits. Connect the xture with 100-277V 50/60Hz power supply;Make all
electrical and grounded connections in accordance with the National
Electrical Code and applicable local code requirements；
All wiring connections should be capped with UL approved wire connec­tions.
Warning: Risk of burn
Wear gloves and safety glasses at all times when moving luminaire from
carton, installing, servicing or performing maintenance;Avoid direct eye
exposure to the light source while it is on. LED lights are very bright. Do not
stare LED light beam in any case. Or this may cause irreparable damage to
the eyes.; Allow xture to cool before handling.
Do not touch enclosure or light source;Do not exceed maximum wattage
marked on luminaire label.
Warning: beware of re
Keep combustible and other materials that can burn away from lamp/lens.。

4.fixed light fixture.

[phone] • www.BeyondLEDTechnology.com

Due to continuous product improvement, information in this document is subject to change.

5.Adjust the angle
of light fixture.

4

LED Landscaping Light

Boise Series

Dimensions

Lawn Base

Mount

SKU: 151735

2.7559”

4.5276”

8.8583”

2.7559”

Ground Stake

SKU: 151734

4.1339”

6.5748”

Mount

LED LANDSCAPING LIGHTS

5

Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087

Due to continuous product improvement, information in this document is subject to change.

LED Landscaping Light

Boise Series

Packaging

SKU # Mount Pcs/Box Dimensions Weight Pallet Quantity Pallet Weight Pallet Dimensions

151734 Ground Stake 4

151735 Lawn Base 4

- - Lb

- - Lb

LED LANDSCAPING LIGHTS

[phone] • www.BeyondLEDTechnology.com

Due to continuous product improvement, information in this document is subject to change.

6

Application

LED Landscaping Light

Boise Series

User Notice

LED LANDSCAPING LIGHTS

• Please turn off the power before installing or changing assembly parts.

• The input voltage and lamps should be matching. Before connecting the power line, please
make sure the wiring section is insulated.

• Only professionals should install and disassemble the lamps.

Trouble Shooting

• Flickering light - Turn off the power and turn on again in 3 minutes. If the same phenomena

occurs, then call Support.

• Not working - Please check all power connections.

7

Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087

Due to continuous product improvement, information in this document is subject to change.
