BJON1005
Specifications
9 pgs1.75 Mb0

Beyond LED Technology BJON1005 Specifications

Download
i10
LED Area Light
LED AREA LIGHTS
1
i10 LED Area Light
Beyond LED Technology’s i10 Area light is the most economical and newest 2021 model. Our i10 Area light offers high lumen's per watt for maximum power savings and rebates from power companies. Our i10 Area light is a perfect solution for lighting parking areas, loading docks and other general lighting applications.
• High Efficacy LumiLEDs
• Ultra thin sleek design
• Several bracket options
• Heat resistant polycarbonate optical lens
• Die Cast Aluminum in Bronze
• Universal 100-277Vac
• UL & DLC Listed
• 5 Year Warranty
Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087
Due to continuous product improvement, information in this document is subject to change.
Product Spec
ifications
Technical Characteristic
LED Area Light Z
OHO Series 4
th
Gen
Model
BLT-S-GB-200WXYZA3-abcdefg
Mounting
Brackets
Slip-Fitter Straight Arm Yoke Universal U-Bracket
Dimension (In)
30*14*4 31*14*7 28
*14*3 32*14*7 24*14*3
Color temperature 5000K
CRI >70
Lumen 34000LM
Lumen Efficacy 170 LM/W
Input Power 200W
Standard Viewing Angle
150*85 Degree (Typ e III)
Input Voltage
100-277Vac 50/60Hz
Driver model
Beyond Brand Driver
PF
>0.9
Waterproof Rating IP65
Bridgelux
3030
456 Pcs
Aluminum
Photocell / Surge protector / Motion sensor
Black, Brown
Product Spec
ifications
Technical Characteristic
O
thers
LED A
rea Light Z
OHO Series 4
th
Gen
Model
BLT-S-GB-200WXYZA3-abcdefg
Mounting
Brackets
Slip-Fitter Straight Arm Yoke Universal U-Bracket
Dimension (In)
30*14*4 31*14*7 28
*14*3 32*14*7 24*14*3
Color temperature 5000K
CRI >70
Lumen 34000LM
Lumen Efficacy 170 LM/W
Input Power 200W
Standard Viewing Angle
150*85 Degree (Typ e III)
Input Voltage
100-277Vac 50/60Hz
Driver model
Beyond Brand Driver
PF
>0.9
Waterproof Rating IP65
ED Brand
Bridgelux
LED Type 3030
LED
QTY 456 Pcs
Housing Aluminum
Optional Accessory Photocell / Surge protector / Motion sensor
Housing color Black, Brown
-40°F to 122°F
20% - 90% RH
-40°F to 176°F
10% - 95%
Outdoor / Indoor
UL、cUL
5 Years
OHO Series 4
th
Gen
*14*3 32*14*7 24*14*3
150*85 Degree (Typ e III)
100-277Vac 50/60Hz
Beyond Brand Driver
>0.9
OHO Series 4
th
Gen
*14*3 32*14*7 24*14*3
150*85 Degree (Typ e III)
100-277Vac 50/60Hz
Beyond Brand Driver
>0.9
Bridgelux
Product Spec
ifications
Technical Characteristic
LED Area Light Z
OHO Series 4
th
Gen
Model
BLT-S-GB-200WXYZA3-abcdefg
Mounting
Brackets
Slip-Fitter Straight Arm Yoke Universal U-Bracket
Dimension (In)
30*14*4 31*14*7 28
*14*3 32*14*7 24*14*3
5000K
>70
34000LM
170 LM/W
200W
150*85 Degree (Typ e III)
100-277Vac 50/60Hz
OHO Series 4
th
Gen
*14*3 32*14*7 24*14*3
Product Spec
ifications
Technical Characteristic
LED Area Light Z
OHO Series 4
th
Gen
Model
BLT-S-GB-200WXYZA3-abcdefg
Mounting
Brackets
Slip-Fitter Straight Arm Yoke Universal U-Bracket
Dimension (In)
30*14*4 31*14*7 28
*14*3 32*14*7 24*14*3
Color temperature 5000K
CRI >70
Lumen 34000LM
Lumen Efficacy 170 LM/W
Input Power 200W
Standard Viewing Angle
150*85 Degree (Typ e III)
Input Voltage
100-277Vac 50/60Hz
Beyond Brand Driver
>0.9
IP65
OHO Series 4
th
Gen
*14*3 32*14*7 24*14*3
150*85 Degree (Typ e III)
100-277Vac 50/60Hz
ifications
LED Area Light Z
OHO Series 4
th
Gen
Model
BLT-S-GB-200WXYZA3-abcdefg
Slip-Fitter Straight Arm Yoke Universal U-Bracket
30*14*4 31*14*7 28
*14*3 32*14*7 24*14*3
Color temperature 5000K
CRI >70
Lumen 34000LM
Lumen Efficacy 170 LM/W
Input Power 200W
150*85 Degree (Typ e III)
Input Voltage
100-277Vac 50/60Hz
Driver model
Beyond Brand Driver
PF
>0.9
Waterproof Rating IP65
ED Brand
Bridgelux
ype 3030
i10
LED Area Light
450W
37.20’’
13.34’’
6.29’’
SKU # Model # Housing Watts Lumens CCT IP
151695
BLT-S-G07-450WCT3B2­BH3RPDM50
Due to continuous product improvement, information in this document is subject to change.
Bronze 450W 54000Lm 5000K 100-277V IP65
(866) 786-1117 • www.BeyondLEDTechnology.com
Input
Voltage
32.55’’
13.34’’
3.74’’
Tier 1
1-24
$309.99 $299.99 $289.99
Tier 2 24-49
Tier 3
50+
LED AREA LIGHTS
2
LED Flood Light Page 3 of 3
LED Flood Light Page 3 of 3
LED Area Light
150W Distribution Diagram
i10
LED AREA LIGHTS
3
Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087
Due to continuous product improvement, information in this document is subject to change.
(866) 786-1117 • www.BeyondLEDTechnology.com
Due to continuous product improvement, information in this document is subject to change.
LED Flood Light Page 3 of 4
LIGHT DISTRIBUTION TESTING PARAMETERS
LED Flood Light Page 3 of 4
i10
LED Area Light
240W Distribution Diagram
LED AREA LIGHTS
4
LED Flood Light Page 3 of 4
LED Flood Light Page 3 of 4
LIGHT DISTRIBUTION TESTING PARAMETERS
LED Flood Light Page 3 of 4
LED Area Light
300W Distribution Diagram
i10
LED AREA LIGHTS
5
Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087
Due to continuous product improvement, information in this document is subject to change.
(866) 786-1117 • www.BeyondLEDTechnology.com
Due to continuous product improvement, information in this document is subject to change.
TECHNICAL DATA SHEET
TECHNICAL DATA SHEET
Light Dis
tribution Testing Parameters
TECHNICAL DATA SHEET
tribution Testing Parameters
TECHNICAL DATA SHEET
LED Area Light
450W Distribution Diagram
i10
LED AREA LIGHTS
6
AM DM YM A&
D FM
NAME：LED ShoeBox Light
P/N：AST-S-GB-150WXYZA3-abcdefg
Note：
The letter “X” can be any alphabet to represent manufacturer of LED, A means LUMILEDS ,C means Seoul ;
The letter “Y” can be“50” or “30” to represent LED size.
The letter"Z" can be "T1" to "T9" and suffix blank or "A" to "Z" to represent different Diffuser light angle type employed,
eg. it can be T4 or T4L or T4M;
The letter "a" can be can be 2 letters represent lamp colors;
The letter “b” can be “3RP”, “3NP”, “5RP”, “5NP”, “7RP” or “7NP” for Photocontrol type provided or blank for no
Photocontrol provided;
The letter “c” can be “10SP” or “20SP” for Surge-Protective Device type provided or blank for no Surge-Protective
Device provided;
The letter“d” can be “PS” or “MS” for Motion Sensor type provided or blank for no Motion Sensor provided;
The letter“e” can be “AM”, “DM”, “YM”, “A&D” or “FM” to represent mounting bracket types;
The letter “f” can be “S” or blank for Socket provided or not;
The letter "g"can be any two-digit number to represent CCT.
Advantage：：
Bridgelux Chip, high CRI
IP65 driver, Input voltage 100-277Vac
AM DM YM A&
D FM
NAME：LED ShoeBox Light
P/N：AST-S-GB-150WXYZA3-abcdefg
Note：
The letter “X” can be any alphabet to represent manufacturer of LED, A means LUMILEDS ,C means Seoul ;
The letter “Y” can be“50” or “30” to represent LED size.
The letter"Z" can be "T1" to "T9" and suffix blank or "A" to "Z" to represent different Diffuser light angle type employed,
eg. it can be T4 or T4L or T4M;
The letter "a" can be can be 2 letters represent lamp colors;
The letter “b” can be “3RP”, “3NP”, “5RP”, “5NP”, “7RP” or “7NP” for Photocontrol type provided or blank for no
Photocontrol provided;
The letter “c” can be “10SP” or “20SP” for Surge-Protective Device type provided or blank for no Surge-Protective
Device provided;
The letter“d” can be “PS” or “MS” for Motion Sensor type provided or blank for no Motion Sensor provided;
The letter“e” can be “AM”, “DM”, “YM”, “A&D” or “FM” to represent mounting bracket types;
The letter “f” can be “S” or blank for Socket provided or not;
The letter "g"can be any two-digit number to represent CCT.
Advantage：：
Bridgelux Chip, high CRI
IP65 driver, Input voltage 100-277Vac
Optional Photocell and A&D
surge protection function
No UV or IR in the beam
Easy to install and operate
AM DM Y
M A&D FM
NAME：LED ShoeBox Light
P/N：
BLT-S-GB-200WXYZA3-abcdefg
Note：
The letter “X” can be any alphabet to represent manufacturer of LED, A means LUMILEDS, C means Seoul ;
The letter “Y” can be“50” or “30” to represent LED size.
The letter"Z" can be "T1" to "T9" and suffix blank or "A" to "Z" to represent different Diffuser light angle type employed,
eg. it can be T4 or T4L or T4M;
The letter "a" can be can be 2 letters represent lamp colors;
The letter “b” can be “3RP”, “3NP”, “5RP”, “5NP”, “7RP” or “7NP” for Photocontrol type provided or blank for no
Photocontrol provided;
The letter “c” can be “10SP” or “20SP” for Surge-Protective Device type provided or blank for no Surge-Protective
Device provided;
The letter“d” can be “PS” or “MS” for Motion Sensor type provided or blank for no Motion Sensor provided;
The letter“e” can be “AM”, “DM”, “YM”, “A&D” or “FM” to represent mounting bracket types;
The letter “f” can be “S” or blank for Socket provided or not;
The letter "g"can be any two-digit number to represent CCT.
Advantages:
Bridgelux Chip, high CRI
IP65 driver, Input voltage 100-277Vac
Optional Photocell and
A&D
AM DM Y
M A&D FM
NAME：LED ShoeBox Light
P/N：
BLT-S-GB-200WXYZA3-abcdefg
Note：
The letter “X” can be any alphabet to represent manufacturer of LED, A means LUMILEDS, C means Seoul ;
The letter “Y” can be“50” or “30” to represent LED size.
The letter"Z" can be "T1" to "T9" and suffix blank or "A" to "Z" to represent different Diffuser light angle type employed,
eg. it can be T4 or T4L or T4M;
The letter "a" can be can be 2 letters represent lamp colors;
The letter “b” can be “3RP”, “3NP”, “5RP”, “5NP”, “7RP” or “7NP” for Photocontrol type provided or blank for no
Photocontrol provided;
The letter “c” can be “10SP” or “20SP” for Surge-Protective Device type provided or blank for no Surge-Protective
Device provided;
The letter“d” can be “PS” or “MS” for Motion Sensor type provided or blank for no Motion Sensor provided;
The letter“e” can be “AM”, “DM”, “YM”, “A&D” or “FM” to represent mounting bracket types;
The letter “f” can be “S” or blank for Socket provided or not;
The letter "g"can be any two-digit number to represent CCT.
Advantages:
Bridgelux Chip, high CRI
IP65 driver, Input voltage 100-277Vac
Optional Photocell and
surge protection function
No UV or IR in the beam
Easy to install and operate
Energy saving, Long lifespan
AM DM YM A&D
FM
NAME：LED ShoeBox Light
P/N：
BLT-S-G07-450WXYA1-abcdef
The letter "X" in P/N stands for LED manufactory, A means LUMILEDS 3030,C means Seoul 3030;
The letter "Y" can be "T1" to "T9" and suffix blank or "A" to "Z" to represent different Diffuser light angle type
employed, eg. it can be T4 or T4L or T4M;
The letter "a" can be can be 2 letters represent lamp colors;
The letter "b" can be "P" or blank to represent Photocell or None Photocell;
The letter "c" can be "S" or blank to represent Surge protector or None Surge protector;
The letter "d"can be "M" or None,represnet Motionsensor or None Motionsensor.
The letter "e" can be "AM","DM","YM","FM","A&D"represent bracket type.
The letter "f"can be any two-digit number to represent CCT.
Advantage：：
UL cUL certificate
Bridgelux Chip, high CRI
IP65 driver, input voltage
100-277VAC.
Optional Photocell and AM DM
surge protection function
No UV or IR in the beam
Easy to install and operate
Energy saving, Long lifespan
Light is soft and uniform, Safe to eyes
Instant start, NO flickering, NO humming
Green and eco-friendly without mercury.
AM DM YM A&D
FM
NAME：LED ShoeBox Light
P/N：
BLT-S-G07-450WXYA1-abcdef
The letter "X" in P/N stands for LED manufactory, A means LUMILEDS 3030,C means Seoul 3030;
The letter "Y" can be "T1" to "T9" and suffix blank or "A" to "Z" to represent different Diffuser light angle type
employed, eg. it can be T4 or T4L or T4M;
The letter "a" can be can be 2 letters represent lamp colors;
The letter "b" can be "P" or blank to represent Photocell or None Photocell;
The letter "c" can be "S" or blank to represent Surge protector or None Surge protector;
The letter "d"can be "M" or None,represnet Motionsensor or None Motionsensor.
The letter "e" can be "AM","DM","YM","FM","A&D"represent bracket type.
The letter "f"can be any two-digit number to represent CCT.
Advantage：：
UL cUL certificate
Bridgelux Chip, high CRI
IP65 driver, input voltage
100-277VAC.
Optional Photocell and AM DM
surge protection function
No UV or IR in the beam
Easy to install and operate
Energy saving, Long lifespan
Light is soft and uniform, Safe to eyes
Instant start, NO flickering, NO humming
Green and eco-friendly without mercury.
i10
LED Area Light
Dimensions
Universal Mount
150W
13.1102”
6.29921”
24.1732”
LED AREA LIGHTS
240W/300W
13.1102”
21.9291”
6.29921”
Yoke Mount
450W
31.8898”
6.29921”
13.3465”
37.2047”
7
2.75591”
150W
13.1102”
240W/300W
13.1102”
27.126”
19.4094”
2.75591”
Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087
Due to continuous product improvement, information in this document is subject to change.
450W
32.5591”
3.74016”
13.3465”
(866) 786-1117 • www.BeyondLEDTechnology.com
Due to continuous product improvement, information in this document is subject to change.
Packaging
LED Shoebox Light Page 3 of 3
PACKAGE
Mount Type
Carton Size
Qty / Carton
Net Weight / Carton
Gross Weight / Carton
Slip Fitter (AM)
32.28 x 15.35 x 6.49in
1 PC
19.1802 lbs
21.3848 lbs
U Bracket (FM)
23.81 x 15.55 x 6.88in
1 PC
18.2984 lbs
20.503 lbs
Tolerance of Carton Size: ±0.590551 in, Tolerance of Weight: ±10%.
Model Pcs/Box Dimensions Weight Pallet Quantity Pallet Weight Pallet Dimensions
i10
LED Area Light
150W 1
240W 1
300W 1
450W 1
Yoke Mount 1
Universal Mount 1
20” X 16” X 7” 14 Lb
28” X 16” X 7” 21 Lb
28” X 16” X 7” 21 Lb
LED AREA LIGHTS
10” X 5” X 5” 4 Lb
10” X 5” X 5” 6 Lb
User Notice
• Please turn off the power before installing or changing assembly parts.
• The input voltage and lamps should be matching. Before connecting the power line, please make sure the wiring section is insulated.
• Only professionals should install and disassemble the lamps.
Trouble Shooting
• Flickering light
• Not working - Please check all power connections.
- Turn off the power and turn on again in 3 minutes. If the same phenomena occurs, then call Support.
8
Application
i10
LED Area Light
LED AREA LIGHTS
9
Beyond LED Technology | 1939 Parker Ct, Stone Mountain, GA, 30087
Due to continuous product improvement, information in this document is subject to change.
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
