Opus 69
Produktinformation
Product Information
Informations de produit
Dynamisches Mikrofon Dynamic Microphone Microphone dynamique

Anwendungen

Das Opus 69 eignet sich speziell zur Nahabnahme von Gesang,
Musikinstrumenten und Lautsprecherboxen bei Live-Auftritten.

Inbetriebnahme

Zur Vermeidung von Poppgeräuschen sollten Sie das Mikrofon
schräg unterhalb vom Mund halten. Durch den Nahbesprechungs­effekt ändern sich Klang und Lautstärke mit der Entfernung zum Mund. Wenn ein warmer, voller Klang gewünscht ist, sollte der Abstand zum Mund nicht mehr als 3 cm betragen.
Aufgrund der Supernierencharakteristik ist das Opus 69 sehr rück­kopplungsarm. Um maximale Rückkopplungssicherheit zu erreichen, sollte die Monitorbox in einem Winkel von ca. 140° zur Mikrofon­längsachse stehen.

Anschluss

Zum Anschluss ist das Opus 69 mit einem 3-pol. XLR-Stecker
ausgestattet. Sie können es an jeden Mikrofoneingang anschließen. Zur besseren Signalübertragung sollten Sie symmetrische Kabel verwenden.

Version

Bez. Beschreibung . . . . . . . . . . . . . . . . . . . Best.-Nr.
Opus 69 Dynamisches Mikrofon, Superniere
inkl. Mikrofonklammer MKV 108 . . . . 455.350
Opus 69 S dito, jedoch
mit Ein- und Ausschalter. . . . . . . . . . . . 457.205

Zubehör - optional

Stative
GST 400 Mikrofonstativ 3/8", Höhe 0,90-1,65 m,
mit Schwenkarm G 400. . . . . . . . . . . . . 421.294
GST 500 Mikrofonstativ 3/8", Höhe 0,85-1,60 m,
mit ausziehbarem Schwenkarm G 500
. 406.252
Poppschutz
PS 20/40 Poppschutz, Farbe: anthrazit . . . . . . . . 437.972
Kabel
BMC 05 FM BLK Mikrofonkabel XLR-XLR, 5 m lang . . . . 434.787
BMC 10 FM BLK Mikrofonkabel XLR-XLR, 10 m lang . . . 434.795

Technische Daten

Wandlerprinzip . . . . . . . . . . . . . . Dynamisch
Arbeitsprinzip . . . . . . . . . . . . . . . Druckgradient
Übertragungsbereich:
Nahfeld . . . . . . . . . . . . . . . . . . . . 35 - 16.000 Hz
Fernfeld . . . . . . . . . . . . . . . . . . . . 95 - 14.000 Hz (Entfernung 1 m)
Richtcharakteristik . . . . . . . . . . . . Superniere
Rückwärtsdämpfung
bei 1 kHz . . . . . . . . . . . . . . . . . . . > 22 dB bei 140 Grad
Feldleerlaufübertragungs­faktor bei 1 kHz
(0 dB = 1 V/Pa) . . . . . . . . . . . . . . . 2,5 mV/Pa ± 1,5 dB = -52 dBV
Magnetfeldunterdrückung . . . . . > 20 dB bei 50 Hz
Nennimpedanz. . . . . . . . . . . . . . . 290
Nennabschlussimpedanz . . . . . . . 1000
Membrane . . . . . . . . . . . . . . . . . . Hostaphan
®
Anschlussstecker. . . . . . . . . . . . . . 3-pol. XLR
Abmessungen. . . . . . . . . . . . . . . . Länge: 180 mm
Schaftdurchmesser: 25/31 mm Kopfdurchmesser: 45 mm
Gewicht ohne Kabel. . . . . . . . . . . 320 g
Thank you for selecting the Opus 69 dynamic microphone. Please take some time to read carefully through this product information before setting up the equipment.

Applications

The Opus 69 has been designed for live performances for close
miking of vocals, instruments and loudspeakers.

Setting up

To avoid “pop” sounds hold the microphone below from the
mouth slightly diagonally to sing or speak across the top edge of the microphone. Due to the close miking effect, sound and volume change according to the distance to the mouth. If you want a more intimate sound, choose a short distance (1").
Due to the supercardioid polar pattern the Opus 69 has a high gain­before-feedback. To achieve maximum gain-before-feedback, the wedge monitor should be positioned at an angle of approximately 140° to the longitudinal axis of the microphone.

Connection

The Opus 69 is equipped with a 3-pin XLR-plug. You can
connect the microphone to any microphone input. For best results we recommend the use of balanced microphone cables.

Version

Model Description . . . . . . . . . . . . . . . . . . . . . Order #
Opus 69 Dynamic microphone, supercardioid,
incl. MKV 108 mic clamp . . . . . . . . . . . 455.350
Opus 69 S same as above,
but with ON/OFF-switch . . . . . . . . . . . 457.205

Optional Accessories

Stands
GST 400 Microphone stand 3/8",
height 0.90-1.65 m
with G 400 boom. . . . . . . . . . . . . . . . . . . . . 421.294
GST 500 Microphone stand 3/8",
height 0.85-1.60 m
with extensible G 500 boom. . . . . . . . . . . 406.252
Pop screen
PS 20/40 Pop screen , charcoal-grey . . . . . . . . . . 437.972
Cables
BMC 05 FM BLK XLR-XLR mic cable, length 5 m. . . . . . . 434.787
BMC 10 FM BLK XLR-XLR mic cable, length 10 m. . . . . . 434.795

Technical Specifications

Transducer type . . . . . . . . . . . . . . Dynamic
Operating principle . . . . . . . . . . . Pressure gradient
Frequency response:
Close miking. . . . . . . . . . . . . . . . . 35 - 16,000 Hz
Distant miking . . . . . . . . . . . . . . . 95 - 14,000 Hz (measured at 1 m)
Polar pattern . . . . . . . . . . . . . . . . Supercardioid
Rear attenuation at 1 kHz . . . . . . > 22 dB at 140°
Open circuit voltage at 1 kHz
(0 dB = 1 V/Pa) . . . . . . . . . . . . . . . 2.5 mV/Pa ± 1.5 dB = -52 dBV
Magnetic field suppression . . . . . > 20 dB at 50 Hz
Nominal impedance . . . . . . . . . . . 290
Load impedance. . . . . . . . . . . . . . ≥ 1000 Ω
Diaphragm . . . . . . . . . . . . . . . . . . Hostaphan
®
Connection. . . . . . . . . . . . . . . . . . 3-pin XLR male
Dimensions. . . . . . . . . . . . . . . . . . Length: 180 mm
Shaft diameter: 25/31 mm Head diameter: 45 mm
Weight without cable . . . . . . . . . 320 g
Nous vous félicitons pour l’achat du microphone dynamique Opus 69 de beyerdynamic et vous remercions de votre confiance. Veuillez lire attentivement ces informations produit avant de la mise en marche du microphone.

Applications

L’Opus 69 se prête particulièrement à la prise de son à prox-
imité de voix, instruments et enceintes lors des représentations en direct.

Mise en marche

Pour éviter des bruits pop il faudrait tenir le microphone diag-
onalement au-dessous de la bouche. Dû au effet de proximité, le son et volume du micro changent en fonction de la distance entre le micro et la bouche. Pour obtenir un son chaud et plein, la distance entre la bouche et le micro doit être de 3 cm au maximum.
Grâce à sa directivité super-cardioïde, l’Opus 69 est très peu sensible au Larsen (accrochage arrière). Pour réduire l’effet Larsen au min­imum, veuillez positionnez les haut-parleurs moniteurs de façon à ce qu’un angle de 140° soit maintenu par rapport à l’axe longitudinal du micro.

Branchement

L’Opus 69 est muni d’une fiche XLR à 3 broches qui permet de
brancher le micro sur n’importe quelle entrée de microphone. Veuillez utiliser des câbles symétriques pour optimiser la transmission des signaux.

Modèles

Désignation Description . . . . . . . . . . . . . . . . . . . . . . . . Art. N°
Opus 69 Microphone dynamique, super-cardioïde,
avec pince de microphone MKV 108. . . . 455.350
Opus 69 S idem, mais avec
commutateur ON/OFF. . . . . . . . . . . . . . 457.205

Accessoires en option

Pieds de sol
GST 400 Pied de sol, 3/8", hauteur: 0,90-1,65 m,
avec perche G 400 . . . . . . . . . . . . . . . . . . . . 421.294
GST 500 Pied de sol, 3/8", hauteur: 0,85-1,60 m,
avec perche télescopique G 500. . . . . . . . 406.252
Dispositif anti-pop
PS 20/40 Dispositif anti-pop, anthracite. . . . . . . . . 437.972
Câbles
BMC 05 FM BLK Câble de microphone, XLR-XLR, 5 m. . . . 434.787
BMC 10 FM BLK Câble de microphone XLR-XLR, 10 m . . . 434.795

Spécifications techniques

Type de transducteuer . . . . . . . . . Dynamique
Principe de fonctionnement . . . . Gradient de pression
Bande passante:
En proximité. . . . . . . . . . . . . . . . . 35 à 16.000 Hz
A 1 mètre de distance . . . . . . . . . 95 à 14.000 Hz
Directivité. . . . . . . . . . . . . . . . . . . Supercardioïde
Atténuation à 140° (1 kHz . . . . . . > 22 dB
Efficacité en champ libre à 1 kHz
(0 dB = 1 V/Pa) . . . . . . . . . . . . . . . 2,5 mV/Pa ± 1,5 dB = -52 dBV
Atténuation des champs
pertubateurs . . . . . . . . . . . . . . . . > 20 dB à 50 Hz
Impédance de sortie nominale . . 290
Impédance de charge. . . . . . . . . . ≥ 1000 Ω
Membrane . . . . . . . . . . . . . . . . . . Hostaphan
®
Connecteur. . . . . . . . . . . . . . . . . . XLR 3 broches
Dimensions
Longueur . . . . . . . . . . . . . . . . . . . 180 mm
Diamètre corps du micro . . . . . . . 25/31mm
Diamètre tête du micro . . . . . . . . 45 mm
Poids sans câble . . . . . . . . . . . . . . 320 g
Frequenzkurve / Frequency Response Curve / Courbe de fréquence
Schaltbild / Wiring Diagram / Diagramme de câblage
Richtdiagramm / Polar Pattern / Diagramme de directivité
