Beyerdynamic OPUS 53 User manual

Opus 53
Produktinformation
Product Information
Informations de produit
Kondensatormikrofon Condenser Microphone Microphone condensateur

Anwendung

Das Opus 53 eignet sich zur Abnahme der verschiedensten
Instrumente. Es empfiehlt sich vor allem für die Schlagzeugabnahme wie Overhead, Snare oder Hi-Hat, für Blech- und Holzblasinstru­mente sowie für Gitarre und andere Saiteninstrumente.

Anschluss

Das Opus 53 hat einen 3-pol. XLR-Stecker und kann an jeden
Mikrofoneingang mit Phantomspeisung (12 - 48 V) angeschlossen werden. Wir empfehlen zum Betrieb eine Phantomspannung von 48 V.

Aufstellung

Für besten Klang und höchste Lautstärke positionieren Sie das
Mikrofon am besten direkt vor der Schallquelle.
Aufgrund der frequenzunabhängigen Nierencharakteristik tritt
auch bei seitlichen Bewegungen des Instruments keine Klangver­färbung auf.
Um maximale Rückkopplungssicherheit zu erreichen, sollten Sie
das Mikrofon so positionieren, dass die Monitorbox genau von hinten auf das Mikrofon strahlt.
Zur Befestigung auf Stativen mit 3/8"-Gewinde ist im Lieferum-
fang die Mikrofonklammer MKV 9 enthalten. Für Stative mit 5/8"-Gewinde können Sie den Gewindeeinsatz herausschrauben. Zur Befestigung mit der MKV 9 drücken Sie das Mikrofon Opus 53 einfach zwischen die beiden elastischen, ovalen Backen der Mikrofonklammer.

Pflege

Bei Bedarf reinigen Sie das Opus 53 mit einem weichen feuch-
ten Tuch. Wenn notwendig, können Sie ein mildes Reinigungsmittel (z.B. Geschirrspülmittel) verwenden, auf keinen Fall lösemittel­haltige Reiniger. Achten Sie darauf, dass in den Mikrofonwandler kein Wasser läuft.

Service

personal. Öffnen Sie das Mikrofon auf keinen Fall selbst, Sie könnten sonst alle Garantieansprüche verlieren.

Version

Bez. Beschreibung . . . . . . . . . . . . . . . . . . Best.-Nr.
Opus 53 Kondensatormikrofon
(Back-Elektret), Niere,
mit Mikrofonklammer MKV 9 . . . . . . . . 460.303

Zubehör - optional

BMC 05 FM BLK Mikrofonkabel XLR-XLR, 5 m lang. . . . . 434.787
BMC 10 FM BLK Mikrofonkabel XLR-XLR, 10 m lang. . . . 434.795
MAV 800 Mikrofon-Abhängevorrichtung . . . . . . . 448.133
MAV 802 Variable Stereo-Halterung. . . . . . . . . . . 453.323

Technische Daten

(gemessen bei 48 V Phantomspeisung)
Wandlerprinzip. . . . . . . . . . . . . . . . . . . . . . Kondensator (Back-Elektret)
Arbeitsprinzip . . . . . . . . . . . . . . . . . . . . . . . Druckgradientenempfänger
Übertragungsbereich . . . . . . . . . . . . . . . . .
30 - 20.000 Hz
Richtcharakteristik . . . . . . . . . . . . . . . . . . . Niere
Feldleerlaufübertragungsfaktor . . . . . . . . . 5 mV/Pa = -46 dBV
Nennimpedanz . . . . . . . . . . . . . . . . . . . . . . 200
Nennabschlussimpedanz. . . . . . . . . . . . . . . > 1 k
Max. Grenzschalldruckpegel
bei f = 1 kHz . . . . . . . . . . . . . . . . . . . . . . . . 136 dB (bei 48 V Phantomspeisung)
126 dB (bei 12 V Phantomspeisung)
Geräuschspannungsabstand bei 1 Pa . . . . . 64 dB
A-bewerteter
Äquivalentschalldruckpegel . . . . . . . . . . . . 22 dB
Spannungsversorgung . . . . . . . . . . . . . . . . 12 - 48 V Phantom
(empfohlene Phantomspeisung: 48 V)
Stromaufnahme . . . . . . . . . . . . . . . . . . . . . < 6 mA
Anschluss. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-pol. XLR
Gewicht (ohne Klammer) . . . . . . . . . . . . . . 36 g
Thank you for selecting the Opus 53 condenser microphone. Please take some time to read carefully through this product information before setting up the equipment.

Application

The Opus 53 has been designed for miking various instruments.
It is ideal for miking drums such as overhead, snare or hi-hat, for brass and woodwind instruments as well as for guitars and other string instruments.

Connection

The Opus 53 is equipped with a 3-pin XLR-plug and can be
connected to any microphone input supplying phantom power (12 ­48 V). We recommend a phantom power of 48 V.

Setting up and use

To achieve the best results place the microphone directly in front
of the sound source.
Due to the cardioid polar pattern independent of frequency there
is no coloration even when the instrument is moved off-axis.
To achieve the maximum gain before feedback, place the monitor
on an 180° axis from the front of the microphones.
Supply of the Opus 53 includes the MKV 9 microphone clamp for
mounting onto stands with 3/8" thread. For stands with 5/8" thread unscrew the 3/8" thread insertion piece. For mounting with the MKV 9 clamp the microphone shaft is pressed between the two flexible jaws of the clamp.

Maintenance

Use a soft, damp cloth for cleaning the Opus 53 microphone.
If necessary, you can use a gentle cleansing agent (such as washing­up liquid). Make sure not to allow any water to enter the transducer element and never use any solvent cleansers.

Service

Servicing must be carried out by qualified service personnel
only. Dismantling the microphone yourself will render the guarantee null and void.

Version

Model Description . . . . . . . . . . . . . . . . . . . . . Order #
Opus 53 Condenser microphone
(back electret), cardioid,
with MKV 9 microphone clamp. . . . . . . 460.303

Optional Accessories

BMC 05 FM BLK Mic cable XLR-XLR, 5 m long . . . . . . . . . 434.787
BMC 10 FM BLK Mic cable XLR-XLR, 10 m long . . . . . . . . 434.795
MAV 800 Clip for hanging mounting of
microphones . . . . . . . . . . . . . . . . . . . . . 448.133
MAV 802 Multi-purpose mounting for two
microphones . . . . . . . . . . . . . . . . . . . . . 453.323

Technical Specifications

(measured with 48 V phantom power)
Transducer type . . . . . . . . . . . . . . . . . . . . . Condenser (back-electret)
Operating principle. . . . . . . . . . . . . . . . . . . Pressure gradient
Frequency response . . . . . . . . . . . . . . . . . . 30 - 20,000 Hz
Polar pattern. . . . . . . . . . . . . . . . . . . . . . . . Cardioid
Open circuit voltage . . . . . . . . . . . . . . . . . . 5 mV/Pa = -46 dBV
Nominal impedance . . . . . . . . . . . . . . . . . . 200
Load impedance . . . . . . . . . . . . . . . . . . . . . > 1 k
Max. SPL at f = 1 kHz . . . . . . . . . . . . . . . . . 136 dB (at 48 V phantom power)
126 dB (at 12 V phantom power)
S/N ratio rel. to 1 Pa . . . . . . . . . . . . . . . . . . 64 dB
A-weighted equivalent SPL. . . . . . . . . . . . . 22 dB
Supply voltage . . . . . . . . . . . . . . . . . . . . . . 12 - 48 V phantom
(recommended 48 V)
Current consumption . . . . . . . . . . . . . . . . . < 6 mA
Connection . . . . . . . . . . . . . . . . . . . . . . . . . 3-pin XLR
Weight (without mic clamp). . . . . . . . . . . . 36 g
Nous vous félicitons pour l’achat du microphone condensa­teur Opus 53 de beyerdynamic et vous remercions de votre confian­ce. Veuillez lire attentivement ces informations produit avant de la mise en marche du microphone.

Application

L’Opus 53 est un microphone conçu spécialement pour la prise
de son d’instruments comme la batterie, la prise d’ambiance «Overhead» des batteries, les cuivres, des instruments à vent en bois, la guitare et des instruments à cordes.

Branchement

L’Opus 53 est muni d’une embase XLR à 3 broches. Il se bran-
che directement sur toute entrée micro pouvant fournir un courant fantôme entre 12 et 48 V. Nous recommandons un courant fantôme de 48 V.

Fixation et positionnement

Pour obtenir les meilleurs résultats, il faut placer le microphone
directement devant la source sonore.
Grâce à la directivité cardioïde sur toute la bande passante du
Opus 53 il n’y a pas de risque de coloration du son, même lors­que l’instrument se déplace hors axe du microphone.
L’Opus 53 disposant d’une sensibilité élevée, il faut veiller, lors
d’une utilisation sur une scène, que les moniteurs de retour soient placés dans un angle d’environ 180° par rapport à l’axe longitudinal du microphone.
L’Opus 53 est fourni avec une pince de micro MKV 9 muni d’un
filetage 3/8". Si vous utilisez un pied de sol avec un filetage 5/8" il vous suffit de dévisser l’insert 3/8". La matière souple de la MKV 9 permet une fixation aisée par simple écartement des sup­ports.

Entretien

Si nécessaire, veuillez nettoyer l’Opus 53 avec un tissu doux
humidifié. Vous pouvez ajouter un produit vaiselle; n’utilisez jamais des détergents; éviter toute pénétration de l’eau dans le transduc­teur du microphone.

Service après-vente

En cas de dommage, veuillez vous adresser au service après-
vente de beyerdynamic. N’ouvriez pas le microphone, vous risqueriez sinon de perdre vos droits de garantie.

Version

Modèle Description . . . . . . . . . . . . . . . . . . . . . Art. N°
Opus 53 Microphone condensateur
(back électret), cardioïde, avec
pince de microphone MKV 9 . . . . . . . . . 460.303

Accessories en option

BMC 05 FM BLK Câble de microphone XLR-XLR, 5 m . . . 434.787 BMC 10 FM BLK Câble de microphone XLR-XLR, 10 m . . 434.795
MAV 800 Suspension microphone. . . . . . . . . . . . . 448.133
MAV 802 Fixation stéréo variable . . . . . . . . . . . . . 453.323

Spécifications techniques

(avec alimentation fantôme de 48 V)
Type de transducteur . . . . . . . . . . . . . . . . . Condensateur (back-électret)
Fonctionnement acoustique . . . . . . . . . . . . Gradient de pression
Bande passante. . . . . . . . . . . . . . . . . . . . . . 30 - 20.000 Hz
Directivité . . . . . . . . . . . . . . . . . . . . . . . . . . Cardioïde
Sensibilité . . . . . . . . . . . . . . . . . . . . . . . . . . 5 mV/Pa = -46 dBV
Impédance nominale . . . . . . . . . . . . . . . . . 200
Impédance de charge nom. . . . . . . . . . . . . > 1 k
Niveau de pression sonore max.
f = 1 kHz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136 dB (alimentation fantôme 48 V)
126 dB (alimentation fantôme 12 V)
Rapport signal/bruit, 1 Pa . . . . . . . . . . . . . . 64 dB
Pression sonore pondérée A . . . . . . . . . . . . 22 dB
Alimentation. . . . . . . . . . . . . . . . . . . . . . . . 12 - 48 V fantôme
(recommandé: 48 V)
Consommation . . . . . . . . . . . . . . . . . . . . . . < 6 mA
Connecteur . . . . . . . . . . . . . . . . . . . . . . . . . XLR 3 broches
Poids (sans pince de fixation) . . . . . . . . . . . 36 g
Frequenzkurve / Frequency response curve / Courbe de fréquence
Schaltbild /
Wiring diagram /
Diagramme de câblage
Richtdiagramm / Polar pattern / Directivité
± 2,5 dB 0 dB 5 mV/Pa Opus 53
=
^
DEF3/PI Opus 53 (01.06)/554.847/Hoh. • Änderungen, Irrtümer und Druckfehler vorbehalten • Subject to change without notice • Sous réserve de modifications • Printed in Germany
beyerdynamic GmbH & Co. KG Theresienstr. 8 D-74072 Heilbronn Tel. +49 (0) 71 31 / 617-0 Fax +49 (0) 71 31 / 617-224 info@beyerdynamic.de www.beyerdynamic.de
beyerdynamic Inc. USA 56 Central Ave. Farmingdale, NY 11735 Tel. +1 (631) 293-3200 Fax +1 (631) 293-3288 salesUSA@beyerdynamic.com www.beyerdynamic.com
beyerdynamic U.K. Ltd. 17 Albert Drive Burgess Hill RH15 9TN Tel. +44 (0)1444 / 258258 Fax +44 (0)1444 / 258444 sales@beyerdynamic.co.uk www.beyerdynamic.co.uk
