Beverage Air WTF27 Operators Manual

BEVERAGE-AIR

SP/DP/UC/WT

SPD/WTRD/UCRD

PARTS

MANUAL

115V/60HZ & 220V/50HZ

PM 09 4/4/2000

ILLUSTRATIONS 29' BASE REFRIGERATORS

CABINET COMPONENTS

SP48

TOP ASSEMBLES

29'' BASE REFRIGERATORS

ITEM MODEL DESCRIPTION PART NUMBER

1 SP27/SP27-16 TOP ASSY. COMPLETE 01B35-254C-01

SP27C TOP ASSY. COMPLETE 01B35-255C-01

SP27-12M TOP ASSY. COMPLETE 01B35-246C-01

SP48-08 TOP ASSY. COMPLETE 01B35-256D-01

SP48-08C TOP ASSY. COMPLETE 01B35-259D-01

SP48-10 TOP ASSY. COMPLETE 01B35-257D-01

SP48-10C TOP ASSY. COMPLETE 01B35-260D-01

SP48-12 TOP ASSY. COMPLETE 01B35-258D-01 SP48-12C TOP ASSY. COMPLETE 01B35-261D-01 SP48-12M TOP ASSY. COMPLETE 01B35-262D-01 SP48-18M TOP ASSY. COMPLETE 01B35-247D-01

SP60-08 TOP ASSY. COMPLETE 01B35-263D-01

SP60-12 TOP ASSY. COMPLETE 01B35-265D-01 SP60-12M TOP ASSY. COMPLETE 01B35-271D-01

SP60-16 TOP ASSY. COMPLETE 01B35-266D-01 SP60-18M TOP ASSY. COMPLETE 01B35-272D-01 SP60-24M TOP ASSY. COMPLETE 01B35-248D-01

SP72-08 TOP ASSY. COMPLETE 01B35-273D-01 SP72-08C TOP ASSY. COMPLETE 01B35-277D-01

SP72-10 TOP ASSY. COMPLETE 01B35-274D-01 SP72-10C TOP ASSY. COMPLETE 01B35-278D-01

SP72-12 TOP ASSY. COMPLETE 01B35-275D-01 SP72-12C TOP ASSY. COMPLETE 01B35-279D-01 SP72-12M TOP ASSY. COMPLETE 01B35-281D-01

SP72-18 TOP ASSY. COMPLETE 01B35-276D-01 SP72-18M TOP ASSY. COMPLETE 01B35-282D-01 SP72-18C TOP ASSY. COMPLETE 01B35-280D-01 SP72-24M TOP ASSY. COMPLETE 01B35-283D-01 SP72-30M TOP ASSY. COMPLETE 01B35-249D-01

UCR27A TOP ASSY. COMPLETE 01B35-250C-04

UCR48A TOP ASSY. COMPLETE 01B35-251C-04

UCR60A TOP ASSY. COMPLETE 01B35-252D-04

UCR72A TOP ASSY. COMPLETE 01B35-253D-04

WTR27A TOP ASSY. COMPLETE 01B35-284C-04 WTR48A TOP ASSY. COMPLETE 01B35-285D-04 WTR60A TOP ASSY. COMPLETE 01B35-286D-04 WTR72A TOP ASSY. COMPLETE 01B35-287D-04

*2 WTR27-A SPLASH BOARD 01B36-010B

WTR48A SPLASH BOARD 01B36-011B

3 SP27/-16/16C/SPD27 TOP COVER ASSY. 01B36-082A-01

SP27-12M TOP COVER ASSY. 01B36-069C-01

SP48-08/08C TOP COVER ASSY. 01B36-084A-03 SP48-10/10C TOP COVER ASSY. 01B36-084A-02 SP48-12/12C TOP COVER ASSY. 01B36-084A-01

SP48-12M TOP COVER ASSY. 01B36-074A-02 SP48-18M TOP COVER ASSY. 01B36-074A-01

SP60-08 TOP COVER ASSY. 01B36-084A-03

SP60-12 TOP COVER ASSY. 01B36-085A-02 SP60-12M TOP COVER ASSY. 01B36-073A-01

SP60-16 TOP COVER ASSY. 01B36-085A-01

SP60-16 (AFTER #5006876)

SP60-18M TOP COVER ASSY. 01B36-074A-01 SP60-24M TOP COVER ASSY. 01B36-075A-01

SP72-08/08C TOP COVER ASSY. 01B36-085A-04

(SINGLE) TOP COVER ASSY. 01B36-113A-01

* Indicates part not illustrated

1/28/2000

ILLUSTRATIONS 34'' BASE REFRIGERATORS

CABINET COMPONENTS

DP46

TOP ASSEMBLES

34'' BASE REFRIGERATORS

ITEM MODEL DESCRIPTION PART NUMBER

1 DP41 TOP ASSY. COMPLETE 03B01-170D-01

WTR41 TOP ASSY. COMPLETE 03B01-106D

UCR41 TOP ASSY. COMPLETE 01B35-184C

DP46 TOP ASSY. COMPLETE 03B01-179D-01 WTR46A TOP ASSY. COMPLETE 03B01-181D-02 UCR46A TOP ASSY. COMPLETE 01B35-290C-06 UCR48A TOP ASSY. COMPLETE 01B35-251C-04 WTR48A TOP ASSY. COMPLETE 04B02-176C-02

DP67 TOP ASSY. COMPLETE 03B01-172D-01 WTR67A TOP ASSY. COMPLETE 04B02-171C-01 UCR67A TOP ASSY. COMPLETE 01B35-190C

DP93 TOP ASSY. COMPLETE 03B01-174D-01 WTR93A TOP ASSY. COMPLETE 03B01-108D UCR93A TOP ASSY. COMPLETE 01B35-196C

DP119 TOP ASSY. COMPLETE 03B01-176D-01

WTR119A TOP ASSY. COMPLETE 03B01-109D

UCR119A TOP ASSY. COMPLETE 01B35-202C

2 DP41 LID ASSY. (1 NEEDED) 03B04-018D-01

DP46 LID ASSY.(1 NEEDED) 03B04-024D-01

DP67 LID ASSY. (SHORT) 03B04-024D-02

LID ASSY.(LONG) 03B04-024D-03

DP93 LID ASSY. (LONG) (2 NEEDED) 03B04-024D-03

DP119 LID ASSY. (LONG) (2 NEEDED) 03B04-024D-03

LID ASSY.(SHORT) (1 NEEDED) 03B04-024D-04

3 ALL LID HANDLE 401-201A

*ALL LID HANDLE SCREW 603-340A 4 ALL DP HINGE BRACKET PLATE( RH) 03B03-019B 5 ALL DP HINGE BRACKET PLATE( LH) 03B03-020B 6 ALL DP HINGE PIN 604-196A

*7 ALL DP INSERT #10-32 LOW HEAD 604-161A

8 ALL DP TOP COVER HINGE (L.H.) 03A07-022C-04 9 ALL DP TOP COVER HINGE (R.H.) 03A07-021C-04

10 DP67/93/119 TOP COVER HINGE (CENTER) 03A07-023C-04

DOOR ASSEMBLES

34'' BASE REFRIGERATORS

ITEM MODEL DESCRIPTION PART NUMBER

11 ALL DP/UC/WT-A D00R ASSEMBLY COMPLETE 02B01-257C 12 ALL DP/UC/WT-A DOOR GASKET (23-1/8X25-1/8) 703-963D-05 13 ALL DP/UC/WT-A DOOR HANDLE 401-506C

*14 ALL DP/UC/WT-A DOOR HANDLE SCREWS 603-338A

15 ALL DP/UC/WT-A DOOR HINGE (TOP/BOTTOM/LH&RH) 401-657B 16 ALL DP/UC/WT-A HINGE COVER 401-244B

*17 ALL DP/UC/WT-A HINGE PIVOT CAM (NYLON) 401-242B

* Indicates part not illustrated 2/28/2000

ILLUSTRATIONS FOR UNDER COUNTER & WORK TOP FREEZERS

17. Defrost timer

is located in the

rear

of unit.

CABINET COMPONENTS

WTF27A

19 20

CABINET COMPONENTS

UNDER COUNTER & WORK TOP FREEZERS

ITEM MODEL DESCRIPTION PART NUMBER

1 UCF/WTF27A

UCF/WTF48A

UCF/WTF67

TOP ASSY. COMPLETE TOP ASSY. COMPLETE TOP ASSY. COMPLETE

01B35-284C-04 01B35-285D-04

03B01-107

2 UCF/WTF27A SPLASH BOARD ASSY. 01B36-010B

UCF/WTF48A SPLASH BOARD ASSY. 01B36-011B

DOOR ASSEMBLES

UNDER COUNTER & WORK TOP FREEZERS

ITEM MODEL DESCRIPTION PART NUMBER

7 8

*9 *10 *11

UCF/WTF27A D00R ASSEMBLY COMPLETE 02B01-249C UCF/WTF48A D00R ASSEMBLY COMPLETE 02B01-253C

UCF/WTF67 D00R ASSEMBLY COMPLETE 02B01-257C

UCF/WTF27A DOOR GASKET (23-18X24-1/2) 703-963D-02 UCF/WTF48A DOOR GASKET (21-1/16X23-1/8) 703-963D-03

UCF/WTF67 DOOR GASKET (23-1/8X25-1/8) 703-963D-05 UCF/WTF27/48A DOOR HANDLE 401-506C UCF/WTF27/48A DOOR HANDLE SCREWS 603-338A UCF/WTF27/48A DOOR HINGE (TOP/BOTTOM/LH&RH) 401-657B UCF/WTF27/48A HINGE COVER 401-244B UCF/WTF27/48A HINGE PIVOT CAM (NYLON) 401-242B UCF/WTF27/48A THERMOMETER 402-233B UCF/WTF27A&67 FACE HEATER 504-247B

UCF/WTF48A FACE HEATER 504-248B

EVAPORATOR HOUSINGS

UNDER COUNTER & WORK TOP FREEZERS

ITEM MODEL DESCRIPTION PART NUMBER

12 UCF/WTF27/48A EVAP. HOUSING ASSY. 04B01-076D-0

UCF/WTF27/48A EVAP HSG. ONLY 04A02-356D-09

*13 UCF/WTF67 EVAP.FAN MOUNT ASSY. 04B04-036C

14 UCF/WTF67 EVAP.FRT.COVER ASSY. 04B04-043C

UCF/WTF27/48A EVAP.FRT.COVER ASSY. 04B02-175D-0

15 ALL UCF/WTF EVAP. TOP COVER 28D47-040D-10

Note: UCF/WTF/27/48A units have the evaporator pans incorporated into the cabinet and are not replaceable. After

serial number 5100521

*16 UCF/WTF67 PAN ASSY - EVAP 04B02-171C-01

17 UCF/WTF27/48A DEFROST TIMER 502-171A

UCF/WTF67 DEFROST TIMER 502-233

18 UCF/WTF27/48A TEMP. CONTROL 502-111A

UCF/WTF67 TEMP. CONTROL 502-150 19 ALL UCF/WTF EVAPORATOR MOTOR 501-105B 20 ALL UCF/WTF EVAPORATOR MOTOR BLADE 405-063A

*Indicates parts not illustrated 3/01/2000

ILLUSTRATIONS SPD/UCRD/WTRD/UCR UNITS

CABINET COMPONENTS

12,13,14,15

10,11

SPD27
