Beverage-Air RID18HGS Specifications

Item No.
Quantity

3779 Champion Blvd., Winston-Salem, NC 27105
1-888-845-9800 Fax# [phone]
http://www.Beverage-Air.com

Commercial Refrigeration Equipment
General Specification

3 Year Parts/Labor Warranty

Additional 2 Year Compressor Warranty

CABINET CONSTRUCTION

Heavy-duty construction includes stainless front (doors and
grilles). Exterior sides are stainless steel. Exterior top, back
and bottom are stainless steel. Cabinet includes interior
thermometer and interior fluorescent light.

Two shelves per door section standard.
Foamed-in-place CFC and HCFC-free polyurethane insula-

tion enhances the structural strength of the cabinet and
helps increase energy efficiency.

RI18-HGS model features (1) “half-size glass door” and (1)
“half-size solid door.” RI18-HS-26 model features (2) “half­size doors”. RID18 Pass-Thru models feature (1) “half-size
glass door” and (1) “half-size solid door” per side. Doors
attach to cabinet on cam-lift hinges. Hinges permit doors to
stay open at 120° and gravity self-close. A plug-in type,
vinyl magnetic gasket is attached to each door. Three-inch
heavy-duty casters included, two with brakes standard.

REFRIGERATION

Balanced refrigeration system is located at bottom of cabi­net. System uses R134a refrigerant, which is CFC and
HCFC-free for compliance with environmental safety con-

BOTTOM MOUNTED
REACH-IN & PASS-THRU
REFRIGERATORS

RI18 SERIES

MODELS:
RI18-HGS
RI18-HS-26
RID18-HGS

SPECIAL FEATURES

 RI18-HGS model features (1) “half-size glass door” and

(1) “half-size solid door.”

 RI18-HS-26 model features (2) “half-size doors.”
 RID18 Pass-Thru models feature (1) “half-size glass

door” and (1) “half-size solid door” per side.

 3” casters included, two with brakes standard.

*Note: Not all markings may apply to all model variations.

RI18-HGS

Available From:

Model Specified
Location

Store#
Quantity

Bottom Mount, RI18 Series Refrigerators

Models: RI18-HGS, RID18-HGS

MODEL RI18-HGS RID18-HGS

RI18-HS-26

PLAN VIEWS

EXTERNAL DIMENSIONAL DATA

Length Overall (inches)
Length Overall (mm)

Depth Overall—(inches) less handle
Depth Overall—(mm) less handle

Height Overall— (inches) less casters
Height Overall— (mm) less casters

Number of doors 2 4
INTERNAL DIMENSIONAL DATA
NET Capacity (cubic ft.)

NET Capacity (Liters)
Internal Length Overall (inches)

Internal Length Overall (mm)

Internal Depth Overall (inches)
Internal Depth Overall (mm)

Internal Height Overall (inches)
Internal Height Overall (mm)

Number of shelves 4 4
ELECTRICAL DATA
Full Load Amperes 115/60/ 1 5.9 5.9
REFRIGERATION DATA
Horsepower 1/4 1/4
WEIGHT DATA
Gross Weight (Crated lbs) 339 339
Gross Weight (Crated kg) 154 154

27 1/4”

692

27 1/2”

699

69 1/4”

1759

18

510
24”

610

24”
610

46 1/2”

1181

27 1/4”

692

27 1/2”

699

69 1/4”

1759

2

18

510
24”

610

24”
610

46 1/2”

1181

4

5.9

1/4

339

154

27 1/4”

692

29 1/2”

749

69 1/4”

1759

18

510
24”

610

24”
610

46 1/2”

1181

RI18-HGS

RI18-HS-26

RID18-HGS

*Note: Not all markings may apply to all model variations.

ELECTRICAL
CONNECTION

Units pre-wired at
factory and
include 8’ long
cord and plug set.

3779 Champion Blvd. • Winston-Salem, NC 27105 USA • [phone] • Fax [phone] • [phone] • www.beverage-air.com

RI18-HGS/RID18-HGS

BEVERAGE-AIR® CORPORATION

Specifications are subject to change without prior notice. 06/13

RI18-HS-26
