1.1SYSTEM DESCRIPTION: M11S-S Hydraulic Control System is a compact, modular
system designed for use with Bettis spring return actuators. The system incorporates a
piston type hand pump and a make-up oil reservoir necessitated by the differential volume
of the hydraulic cylinder (the differential volume is due to the inboard piston rod
displacement).
1.2DEFINITIONS:
WARNING:If not observed, user incurs a high risk of severe damage to actuator
CAUTION:If not observed, user may incur damage to actuator and/or injury to
NOTE:Advisory and information comments provided to assist maintenance
1.3SAFETY STATEMENT: Products supplied by Bettis, in its "as shipped" condition, are
intrinsically safe if the instructions contained within this Service Instruction are strictly
adhered to and executed by a well trained, equipped, prepared and competent technician.
Bettis P/N 121960
Revision "A"
Page 1 of 4
and/or fatal injury to personnel.
personnel.
personnel to carry out maintenance procedures.
WARNING:For the protection of personnel working on Bettis actuators, this
procedure should be reviewed and implemented for safe operation.
Close attention should be noted to the WARNINGS, CAUTIONS and
NOTES contained in this procedure.
WARNING:This procedure should not supersede or replace any customers plant
safety or work procedures. If a conflict arises between this
procedure and the customers procedures the differences should be
resolved in writing between an authorized customers representative
and a authorized Bettis representative.
2.0GENERAL INFORMATION
CAUTION:The M11S-S package must be mounted with the pump and reservoir upright
and vertical. The reservoir fill plug must be removed and replaced, with the
breather supplied, before operation.
2.1Numbers in parentheses ( ), indicate the bubble number (reference number) used on the
Bettis Assembly Drawing.
2.2Bettis M11S-S System Assembly Drawing part number 121107.
2.3M11S-S Hydraulic Control System Fluid Requirements: Hydraulic fluids, other than those
listed in steps 2.3.1 and 2.3.2, should not be used without prior written approval of Bettis
Product Engineering.
2.3.1Standard and high temperature service (-35°F to +350°F) use Dexron II Automatic
Transmission Fluid.
2.3.2Low temperature service (-65°F to +180°F) Use Exxon Univis J13 Hydraulic Fluid.
CAUTION:Apply thread sealant per the manufacture's instructions.
2.4Do not use Teflon tape on threads, use a non-hardening thread sealant on all pipe threads.
3.0ACTUATOR POWER OPERATION
3.1Fully open the M11S-S by-pass control valve (30). NOTE: The valve is located on the right
hand side of the M11S-S control module.
CAUTION:Do not exceed the maximum operating pressure rating of the actuator.
3.2Apply a operating media, of the correct pressure, through a control valve to the actuator's
power cylinder.
4.0ACTUATOR M11S-S MANUAL OPERATION
4.1Shut off and exhaust the operating media from the actuators power cylinder.
4.2Fully close the M11S-S by-pass control valve (30).
Bettis P/N 121960
Revision "A"
Page 2 of 4
4.3Operate the M11S-S hand pump (280) until the actuator strokes to the desired degree.
NOTE: When the actuator is fully stroked against the travel stops, an increased resistance in
pumping effort will be noted. Continued operation of the pump simply circulates fluid
through a high pressure relief.
4.4Fully open the M11S-S by-pass control valve (30) to reverse the actuator rotation or to
return to normal power operation.
5.0SYSTEM REFILLING
5.1Use either Refilling Method Number 1 (steps 5.2) or Refilling Method Number 2 (steps 5.3).
Method number 1 is the best, most efficient and the recommended method.
5.2REFILLING METHOD NUMBER 1. - Refilling of the M11S-S module and actuator hydraulic
cylinder is best accomplished using a pressure pump.
5.2.1Shut off and exhaust the operating media from the actuators power cylinder.
5.2.2Allow the actuator to fully stroke to its fail position by opening the M11S-S by-pass
control (30) valve.
5.2.3Remove the breather (150) from the reservoir end cap (25).
5.2.4Attach the pump discharge line to the reservoir end cap (25) breather port.
5.2.5Remove the two top o-ring plugs located in the top of the hydraulic cylinder(s) inner
and outer end caps..
5.2.6Slowly pump hydraulic fluid into the reservoir. Approximately 3 to 5 psi will be
required. As the fluid passes through the M11S-S module and into the hydraulic
cylinder, air will be displaced. Install each top o-ring plug when the air has been
displaced and hydraulic fluid appears.
Bettis P/N 121960
Revision "A"
Page 3 of 4
5.3REFILLING METHOD NUMBER 2. - Refilling the M11S-S control system during field
service often must be done without the use of a pressure pump. Proceed as follows:
5.3.1Shut off and exhaust the operating media from the actuator's power cylinder.
5.3.2On the M11S-S block (10) fully close the by-pass control valve (30).
5.3.3Fill hydraulic cylinder(s) with fluid by removing the top o-ring plugs located in the
top of the hydraulic cylinder(s) inner and outer end caps.
5.3.4Fill the M11S-S reservoir. Maintain at lease 1 through 1-1/2 inches of fluid from the
top of the reservoir at all times.
5.3.5On the M11S-S block (10), close by-pass control valve (30).
5.3.6Operate M11S-S hand pump (280) slowly. Keep handle up for about 4 to 5
seconds before each pressure stroke. This allows time for the pump cylinder to fill
in order that full displacement of the pump is utilized.
NOTE: If the pump fails to deliver fluid, open the by-pass valve, rapidly operate the pump
15 to 20 times, close the by-pass valve and continue filling sequence.
5.3.7Replace the hydraulic cylinder outboard top o-ring plugs valve when fluid appears.
5.3.8Operate the M11S-S hand pump (280) to fully stroke the actuator. Refill the
M11S-S reservoir as required.
5.3.9Open the M11S-S block (10) by-pass control valve (30).
5.3.10 As the actuator strokes, fluid will be displaced from the greater volume of the
outboard cylinder into the lesser volume of the inboard cylinder. Fluid will begin
flowing from the hydraulic cylinder inboard top o-ring plug port hole.
5.3.11 Replace the hydraulic cylinder inboard top o-ring plug when fluid appears and
proceed to step 5.3.16.
NOTE: If the actuator completes its stroke and fluid does not appear at the hydraulic
cylinder inboard top o-ring plug port hole, omit step 5.3.10 and proceed as follows:
5.3.12 Close the M11S-S block (10) by-pass control valve (30).
5.3.13 Operate the M11S-S hand pump as described in section 4.0 to cycle actuator.
5.3.14 Replace the hydraulic cylinder inboard top o-ring plug when fluid appears. Stop
operation of pump.
NOTE: If fluid does not appear, repeat steps 5.3.8 through 5.3.11.
5.3.15 Open the M11S-S by-pass control valve (30).
5.3.16 Add fluid to reservoir so that level is within approximately 1 inch through 1-1/2
inches of fluid from the top of the reservoir.
5.3.17 Install breather (150) back into reservoir end cap (25) port.
5.3.18 Connect power supply lines back to the actuator control system or power cylinder
6.0MAINTENANCE
Bettis does not recommend periodic field maintenance for the M11S-S module and pump. The only
time the M11S-S module or pump should be disassembled is when either the pump or the M11S-S
module fails to perform its override function. If maintenance is required and when possible the
M11S-S package should be returned to the factory for maintenance.
Bettis P/N 121960
Revision "A"
Page 4 of 4
and cycle the actuator using available power media.
ECN DATE REVBY *DATE
ReleasedSeptember, 1997ACOMPILEDBill Cornelius24 September 1997
CHECKEDBill Cornelius24 September 1997
APPROVEDRobert McEver24 September 1997
* Signatures on file Bettis Actuator & Controls, Waller, Texas
