SAFETY INFORMATION
3
UNIT MEASUREMENTS
4
PARTS LIST
7
PRODUCT OVERVIEW
8
BEFORE INSTALLATION
9
INSTALLATION
10
REMOTE CONTROL
16
OPERATION
18
CLEANING AND MAINTENANCE
23
REPLACING THE FILTER
24
DRAINING THE WATER TANK
25
TROUBLESHOOTING
26
SUPPORT
27
TECHNICAL SPECIFICATIONS
28
Filter
Toilet
Electrical Cable Coupler
Stop Valve
Waste Pipe and Seal Wall Fixing Rods Wall Fixing Nuts
Wall Fixing Washers Side Fixing Bolt Sleeve Wall Cushion
G3/8” – ½”
Flexi Hose
Remote
Remote Control
Holder
Flush Pipe and Seal
Tape Measure Pencil Phillips Screwdriver Flat Head Screwdriver
Knife File Adjustable Wrench Wire Strippers
12mm Drill bit Hacksaw Drill
PRODUCT OVERVIEW
Toilet Lid
Dryer
Recommended
Flush pipe from Wall Frame
Waste pipe from Wall Frame
an adequate seal and tighten using a spanner.
Rear Wash
Dry/ Stop
Decrease Flow
Retract Nozzle/
Decrease
Front Wash
Indicator Lights
Increase Flow/
Extend Nozzle
Increase
NOTE: Batteries are not
MASSAGE
adjusted using the remote control.
WATER FLOW
To adjust the water flow, press the
You can also adjust the water
WATER TEMPERATURE ADJUSTMENT
The water temperature can be adjusted.
Use the temperature adjustment
Keep pressing the dial on the side
STOP
Stops all functions immediately no matter where they are in their cycle.
on the remote control.
ADJUST NOZZLE
mode.
AIR TEMPERATURE ADJUSTMENT
STOP
are in their cycle.
NIGHT LIGHT
The night light defaults to always
Alternatively, the night light can be
AUDIO
The toilet will bleep when settings are
activated.
Or Open the cover and seat, keep pressing the control dial then
when turned anti-clockwise
STANDBY
INDICATOR LIGHT
Or Open the cover and sit, without washing or drying, keep pressing
for 6 seconds, the light will turn on.
MULTIPLE INSTALLATION REMOTE SETTING
Daily
Remove water drops with a soft lint free
cloth to avoid limescale build-up.
Weekly
Clean all surfaces and corners. Clean
Nozzle cleaning)
Monthly
Clean the ceramic with low acidic
cleaning agents.
Every 6 months
Replace the filter if required. (see
replacing the filter)
Problem
Potential cause
Suggested action
The power supply may not be
connected
Ensure the power switch is in the on position and the
RCD has been reset.
The water supply may be
disconnected
Ensure the inlet water valve is in the open position, and
ensure there is adequate water flow to the unit.
Please replace a new filter. It has a service life of approx.
6 months.
Seat detector not activated
Ensure the seat is occupied to activate the function.
Toilet lid is closed
Lift the toilet seat.
The self-cleaning function will activate, which takes
ll the buttons are
deactivated until the function has completed.
The washing cycle is 3mins. The
3mins, and then retract.
Water supply interrupted
Please check if there is a water outage
The seat detector has sensed
the user left the seat
The toilet lid is not fully open
Ensure the lid remains upright during the function.
The water flow rate may be set
at low grades
Please increase the flow rate as per "adjusting water flow
rate" of operating instructions
The water supply pressure may
be too low
Please check and ensure the water supply pressure is
0.07Mpa
The filter may be blocked
Replace the filter. It has a service life of approx. half a
year
The nozzle may be blocked
Please replace the nozzle
The water temperature may be
set at low grades
Please set the water temperature at high grade as per
"adjusting temperature “of
the
operating instructions
The temperature of water supply
Please set the water temperature at high grade as per
"adjusting water flow rate".
Upon starting the washing
coming out.
The water flows out
but the nozzle does
not come out
The toilet is not used for more
This is normal. If not used for more than 72 hours, when
minutes
The power supply may not be
opened
Not correctly seated
Please sit on the seat and adjust sitting position
The cover is closed
Please open the cover and sit on the seat
The air temperature may be set
Please set the air temperature at high grade as per
operating instructions
The air heater is not working
normally
To much light in the
When the night light is set at smart mode, the night light
environment.
The night light function may be
closed.
Please open the night light function and adjust the night
light mode as per "Light Setting".
Night light is always
on
Something may be covering the
control dial.
When the night light is set at smart mode, the night light
will be always on when in a dark environment
The night light is set at always
on mode
The nozzle goes back after
washing 5 minutes.
Please adjust the night light mode as per "Light Setting"
of operating instructions
The nozzle goes back
automatically when
manual cleaning
Press the "stop" button
This is normal
Manual cleaning will be stopped if you press the control
the remote control.
The remote control is
not functioning
There are no batteries in the
remote control
Maybe the battery power is too
low
Maybe the code of the bidet
the same
Please set the code of the remote control to the correct
Setting"
There is a short BEEP when
commands.
There are BEEP
sounds when the
bidet is working
Please shut off the power and turn on after one minute. If
the bidet still cannot work, please contact local distributor
The bidet cannot
work normally
The water supply temperature
may be too high
Check the temperature settings on the remote. If
nothing changes, contact the retailer.
The light around the
BEEP
MODEL
BeBa_24911/Beba_26880
Rear Wash
●
Front Wash
●
Oscillating Spray ●
Pulsating Spray
●
Oscillating and Pulsating Spray
●
Adjustable Water Temperature
5 Steps (Default 3rd)
Adjustable Flow Rate
5 Steps (Default 3rd)
Adjustable Spray Position
5 Steps (Default 3rd)
Air Drying
●
Adjustable Dryer Temperature
5 Steps (Default 3rd)
Nozzle Self Cleaning ●
Nozzle Manually Cleaning
●
Night Light
●
Breathing Lamp
●
Soft Closing Seat and Cover
●
Body Control dial ●
Remote Control
●
Rimless Toilet ●
Installation of the toilet
Wall Mounted
Water Supply Connector
G 3/8” ½”
Rated Voltage
AC220–240V, 50/60HZ
Power
950W
Length of Power Cord
1.8m
Water Supply Pressure
0.07~0.75MPa (0.7~7.5Bar)
Water Supply Temperature
4~35⁰C
Ambient Temperature
4~40⁰C
Protection Degree
IPX4
wash
Device
Flow Rate
350~650mL/min
Water Temperature
31~39⁰C
Wash Cycle Time
3 Minutes
Heating Mode
Tank
Maximum Heater Power
1200W
Switch\Thermostat
Backflow Prevention
Air
Gap
Dry
Maximum Speed Of Air
5m/S
Maximum Dryer Power
280W
Dry Cycle Time
3 Minutes
Warm Air Temperature
35~50⁰C
Thermal Cutoff/ fuse›\Thermostat
Remote
Control
Frequency Range
2460MHz
Maximum RF Output Power
–10dBm
Type of batteries 3V CR2032
Number of
batteries Two pieces
Net Weight
32 Kg
Dimensions
593 x 370 x 380mm
料号
236E400-E71-01A
版本 1.0
材质
日期 页数 28
2020.08.05
尺寸
表单编号
版本 1.0
175X260mm100克双胶
CONTENTS
SAFETY INFORMATION
This manual must be read and fully understood before installing or using the
appliance.
This product must not be operated without a connected water supply.
Installation must be in accordance with all relevant local regulations
applicable at the time of installation.
It must be installed by a qualified professional to in accordance with BS
7671.
If electrical work is carried out within the bathroom which involves addition or
alteration of existing circuits, it may be notifiable to your local building control
department (Part P). If unsure, professional advice should be sought.
The toilet must be fitted in accordance with the Water Supply (Water
Fittings) Regulations and Water Supply (Water Fittings) (Scotland) Byelaws.
If the power cable or RCD are damaged in any way, the power must be
disconnected until the part is replaced. Contact the retailer or manufacturer.
The toilet must be fitted in a well-ventilated bathroom.
The toilet must not be sprayed with liquid, or placed in a position it is likely to
be sprayed.
The toilet must not be installed in a location where it may be subject to high
temperatures.
The toilet must be stored in an upright position before installation.
Do not over bend or kink the water supply hose as this could cause leaks
Only use this product for its intended use. Only use attachments
recommended by the manufacturer.
Do not use this product in an outdoor environment.
Children and people with limited physical, sensory or capabilities must be
supervised when using this device or have been told the proper procedure
for use beforehand.
Do not climb or stand on the toilet.
If the product is not working properly, disconnect from the mains and close
the water supply valve immediately before contacting the supplier or a
qualified professional.
This is a Class I electrical appliance and must be correctly earthed. Make
sure the earth cable is connected first during the electrical connection.
In case of any damage to the supply cable, you must arrange for a certified
and qualified electrician to replace the cable for you.
This appliance is designed for fixed connection to the power supply.
Connecting this appliance to the power supply must be performed by a
qualified and authorised electrician.
Incorrect repairs are dangerous. Repairs must only be carried out by trained
and qualified engineers.
The Supplier and Manufacturer are not responsible for any injury and/or
damage caused by incorrect installation, maintenance or operation of the
product.
Do not force the soft close toilet seat down as this may damage the
mechanism.
A defective appliance may cause electric shock. Never switch on a defective
appliance. The power must be disconnected before seeking assistance.
This product is IPX4 rated, and so no part of the installation is allowed to be
within bathroom Zones 0 or 1. Installation is permitted within Zone 2 and
outside of the bathroom zones as long as it is not in a position where it is
likely to be sprayed with water.
Zone 0: The interior of the bathtub or shower basin.
Zone 1:
Zone 2:
The area around the bathtub or shower basin up to
a height of 2.25m above the floor
The area stretching to 0.6m outside the bath or
shower and above the bath or
shower if over 2.25m
INSTALLATION DIAGRAMS - BeBa_24911
INSTALLATION DIAGRAMS - BeBa_26880
PARTS LIST
(Batteries Not Included)
TOOLS REQUIRED
2
BEFORE INSTALLATION
installation area.
IMPORTANT!
Before commencing installation, the water and electrical supplies should be turned
OFF.
Please note with your floor mounted back to wall toilet, a Flush Pipe and Waste Pipe are
supplied, these may not be required as it will be dependant on the cistern to which the toilet
is being connected and the position of the soil stack.
Before attempting installation, ensure that you are in possession of all the required tools and
fittings to ensure successful installation.
Prepare the wall with the wall frame fitted, tiled/finished with access holes prepared for the
flush pipe and waste pipe.
Prepare the water supply pipe with a 1/2" female connector and electrical 3 core cable
(which should be connected to a 13-amp fuse spur or isolation switch outside the bathroom)
as per below, allowing for 200mm of water supply pipe and 400mm of electrical cable to
extend beyond the surface against which the toilet will sit, to allow connection to the toilet
unit.
3
INSTALLATION INSTRUCTIONS
Connect the stop valve to the pipe end, ensuring to fit
Once connected and fully tightened, place a bucket
under the stop valve, open the stop valve and flush the
pipe for at least 10 seconds to remove any debris in the
system.
Once flushed through, turn the stop valve to the closed
position.
Connect the 1/2" female threaded end of the Filter to
the Stop Valve, ensuring to fit the seal provided and
tighten.
Connect the 3/8"" - 1/2" Flexi Pipe to the Filter, ensuring
to fit the seal provided and tighten using a spanner, do
not over tighten as this could crack the plastic body of
the Filter.
Push the flush pipe
and waste pipe
supplied into the wall
frame, ensuring
these are level and
aligned.
Using a ruler draw a
line on the flush and
waste pipe, where it
meets the wall
surface.
4
Remove the pipes from the wall and push them
fully onto and into the back of the toilet pan,
using a ruler mark a line level with the back of
the pan.
Remove the flush pipe and measure and
measure the distance between the two marks,
this will be dimension L1.
From the end of the flush pipe measure
dimension L1 and then add 6mm, cut at this
point, as shown below.
Carry out the same process for the waste
pipe, but only add 3mm and cut at this point
as shown below.
Once cut, using a file, smooth off the pies internally
and create a chamfer on the external edge as
shown below.
After cutting and filing, insert the pipes into the
back of the toilet and ensure these are fully
attached.
Remove the screws on the seat, using a cross head
screwdriver, ensuring not to lose the screws once
removed.
Two people may be required for the next part of the
installation.
Pull the seat from the toilet pan (do not turn this
upside down).
The threaded bolts should be attached to the frame and
screwed inwards until 48mm of thread is left exposed, as
shown below.
Place the toilet cushion against the wall over the
threaded bolts and pipe holes
5
Push the toilet base into position against
the wall, ensuring that the waste and flush
pipes to the rear engage to create a full
seal and the holes in the back of the pan sit
over the threaded bolts on the frame.
Pull through the flexi pipe and cable, to
allow connection to be made with the seat
unit.
Push the threaded bolt sleeves over the
threaded bolts and into the hole in the pan to
prevent the metal of the bolt damaged the
ceramic, during use.
Place the washer onto the threaded bolt, then
fit the nut and tighten until the pan is secure.
6
Slide out the support box from underneath the toilet
pan, only when the pan is secured.
Strip the end of the household cable to
expose the wires for connection to the
coupler.
When stripped, tidy the ends and connect
to the coupler as shown, ensuring the
screws are tightened and the wire ends are
fully secured.
7
Trim the cushion which is exposed around the
edge of the toilet pan, using a sharp knife.
Carry out the same process for the cable attached to
the toilet, then connect the coupler sections together.
8
Connect the end of the water supply flexi to the tank inlet
on the underside of the toilet lid, this will require a firm
push to connect the flexi to the inlet.
Once fully inserted and secure, tighten the nut.
Before replacing the seat, turn on the water supply, the
stop valve and the electrical supply.
After turning on the water and electrical supplies you MUST carry
out the RCD test, instructions for this are printed on the rear of the
RCD, also carry out a leak check on all water connections.
When checks are completed and no leaks are
found and RCD test is passed, the lid assembly
can be re-fitted to the pan, feed the flexi pipe and
cables carefully under the pan, so as not to trap the
pipe or cable or cause any kinks, which will reduce
water flow.
Locate the seat onto the pan and push down at the rear
(not in the middle), as this could crack the seat.
When the seat is located, re-fit the seat screws and
tighten until secure, then fit the cover caps.
9
INSTALLATION OF THE REMOTE HOLDER
Clean the wall surface in the area in which the remotecontrol holder will be located
Dry fully before attempting the installation
From the rear of the holder, peel off the adhesive strip cover.
Place the holder with the adhesive side to the wall, ensuring this
is level, press to the wall firmly and hold for a couple of seconds.
Once located and secure, place the remote control against the
holder. The magnet within the holder will retain the remote in
position.
10
REMOTE CONTROL
Massage
Night Light
Temperature/ shift
Temperature/ Shift
FITTING / REPLACING BATTERIES
Different types of batteries or new and used batteries should not be
mixed
Batteries should be inserted using the correct polarity
Exhausted batteries should be removed and disposed of safely
If the appliance is not to be used for a long period, batteries should be
removed
included.
The remote requires
2 x 3v CR2032 batteries.
When the light flashes continuously, the batteries need to be replaced
11
OPERATION
REAR WASH/ FRONT WASH
While seated, press the rear wash or front wash button
on the remote and the toilet will begin wash mode.
Alternatively, the dial on the side of the toilet can be
turned clockwise to activate front wash or
anticlockwise to activate rear wash.
The washing function will run for 3 minutes.
NOTE: When the wash mode is activated, after a 10 second delay the
nozzle will move for 18 seconds before staying in the set position for the
rest of the wash.
While in wash mode, you can adjust the following settings:
Change between “OSCILLATING”, “PULSATING” AND “OSCILLATING
AND PULSATING” functions.
To access massage mode, keep pressing the + or – temperature
buttons. Then, press the + water flow button to change between the
different massage functions.
The Indicator lights on the remote will show the
massage mode selected.
1 Light – Oscillating Mode
2 Lights – Pulsating Mode
3 Lights – Oscillating and Pulsating Mode
Please Note: The massage mode can only be
12
Change between LOW, MEDIUM or HIGH
+ or – water flow buttons on the
remote. The indicator will show the
rate that the water is flowing
between LOW, MEDIUM and
HIGH.
flow using the dial located on the
side of the toilet. Turn the dial
clockwise to increase the flow or
anticlockwise to decrease.
buttons on the remote. Press the +
or – to increase or decrease the
temperature.
of the toilet. The temperature can
then be increased by turning
clockwise or decreased by turning
it anticlockwise.
To stop any of the functions at any time, press the stop button
The nozle position controls where the water is sprayed during washing
Change the nozzle position by using the +
and – nozzle buttons on the remote to
retract or extend the nozzle.
Please Note: The nozzle position can only be adjusted using the
remote control.
13
AIR DRY MODE
When seated, press the Dry button on the remote and air-dry mode will
operate for 3 minutes.
While the air-dry mode is operating, you can change the following
settings:
Adjust the temperature of the air
flow by using the + and - adjust
temperature buttons on the
remote.
Turn the dial on the side of the seat
clockwise to increase the air
temperature or anticlockwise to
reduce it.
The stop button stops all functions immediately no matter where they
To stop any of the functions at any time, press the stop
button.
14
OTHER FEATURES
The intelligent toilet comes with other features that improve its ease of
use. These can be adjusted when no other function is in operation.
on. Keep pressing the + or –
temperature buttons on the
remote at the same time before
pressing the – nozzle button.
adjusted by lifting the toilet lid and
seat. Then turn the control dial on
the side of the seat anti clockwise
to change the mode.
Keep pressing the – nozzle button
to change between OFF, ON and
SMART modes. (Light will operate
in dark conditions).
changed. To turn this alert off press
and hold the “+” or “-“temperature
button. Then release and press the
Front Wash Button. The sound/beeps
will turn off. Press the Front Wash
button again and the sound will be
rotate, the sound will activate when turned clockwise and deactivate
Without sitting press and hold the control dial on the
side of the seat for 6 seconds, the seat will go into
“Standby Mode” Press and hold the button again for
6 seconds to restart the seat.
15
The indicator light on the control dial is on by
default. To turn it off press and hold the “+”
or “-“temperature button. Then press the
“Rear Wash” button. The Indicator light will
illuminate when the “Rear Wash” button is
pressed again.
the control dial for 6 seconds, the lamp will turn off, if pressed again
If you are installing multiple units in one area
and want to avoid controller interference
between units. You can set each controller to be
connected to an individual unit. Open both the
cover and seat, do not sit on the seat and set the "Night Light" to the
"Close" mode (Refer to Night Light Setting) Press the STOP button
and the "+" or "-" temperature button together. The first indicator will
flash. Release the STOP button, but continue to press the temperature
button Press the "+" or "-" flow rate button then releases the
temperature button the fifth indicator will flash. Press "+" or "-" flow
rate buttons to switch to a different remote/product ID code and the
corresponding indicator lights will illuminate. The first code is the
default code and the light "-" lights up.
16
CLEANING AND MAINTENANCE
the spray nozzle is necessary (see
NOTE: Do not use strong abrasive cleaning agents or materials, as this can damage
the product and will invalidate your guarantee.
TANK SELF-CLEAN
If the product is not used for more than 72 hours, the next time it is used, and the
wash function is activated, the unit will carry out a self-clean for approximately 3
minutes. All functions will be de-activated during this time.
CLEANING THE NOZZLE
It is recommended that regular cleaning of the nozzle takes place to prevent
blockages.
To manually clean the nozzle, follow the below:
Open the seat cover and seat, then rotate the control dial clockwise. The nozzle will
extend, rub clean with a brush to clean the nozzle holes and then wipe clean.
The nozzle will return after a 5-minute period or you can press the Stop button.
17
REPLACING THE FILTER
The filter supplied has a life of 6 months and should be replaced to
prevent reduced flow. This can be affected by the water type i.e. Hard
Water areas.
To replace the filter, you will
need to turn off the power supply
and the water supply and the
seat will need to be removed.
Once the power has been cut to
the unit, unscrew the seat from
the toilet, do not turn the seat
upside down. Once removed,
access the filter and the stop valve.
Turn the stop valve to the closed position.
Disconnect the filter and
replace with the new part,
ensuring to re-fit the seals.
Feed the pipes back into the toilet base, turn the power
back on and re-set the RCD Re-open the stop valve.
Re-fit the seat and secure into position.
18
DRAINING THE WATER TANK
The water and power must be cut to the unit before work is started Do
not invert the seat.
Ensure a water holding container is in place prior to draining
Using pliers hold the plug on the tank turn the plug to OPEN and pull out
Water will start to drain.
After draining is completed, insert the plug and turn to CLOSE.
TROUBLESHOOTING
The washing function
not operating
Washing function
suddenly stops and
nozzle retracts.
Low water flow rate
Low water
temperature
The nozzle comes
out slowly
The dryer cannot
work
Low air temperature
Night light is always
off
The filter may be blocked
Function not used for more than
72 hours
nozzle will stop spraying after
is too low
function, the nozzle will be in
self-cleaning mode before
than 72 hours
at low grades
surrounding environment.
19
20
21
TECHNICAL SPECIFICATIONS
around 3 minutes. During self-cleaning a
This is normal and please press the "wash" button to
start another wash cycle.
Please adjust sitting position
control dial flash
twice with constantly
The seat detector senses that
the seat is closing
and remote control is not
you are sitting down, and a
long BEEP when you leave.
Also, there is a short BEEP
when the bidet has received
Maybe there is something
abnormal
There may be something wrong
with the product
dial or press the "stop" button on
Change the batteries
Please install the correct batteries in the remote control
one. See "One-On-One
This is normal. You can turn off the sound. See "Sound
Setting"
Please shut off the power and water supply, stop using
the product, and then contact
local distributor.
Wash
Warm
Air
Hygiene
Recycling facilities are now available for all customers at which you can deposit your
old electrical products. Customers will be able to take any old electrical equipment to
"adjusting temperature “of
operating instructions, or decrease the flow rate as per
This is normal
the unit starts it will begin the self-cleaning for about 3
Please turn on the power
At the time of printing the product contains no substances listed within Annex XIV of the Reach
Regulations (EC) 1907/2006. In accordance with Article 59 of the same regulation the following
substances are contained within the product at permitted levels: Lead & Cadmium.
As a responsible manufacturer the regulations are monitored to ensure continued compliance. Further
information can be provided upon request.
participating sites run by their local councils. Please remember that this equipment will
be further handled during the recycling process, so please be considerate when
depositing your equipment. Please contact the local council for details of your local
household waste recycling centers.
Safety Device
Thermal Cutoff/ Fuses\Liquid Level
"adjusting temperature “of
Please contact local distributor
will not work when in the bright
Device
Safety Device
22
.
Remove the obstructions around the control dial
23
24
25
26
27
28
Loading...
