Page 1
S2-III
Professional Active Performance System
User Manual
UM-Meline S 2 - I I I -20160122 ver A
Page 2
SAFETY INSTRUCTIONS
PLEASE READ THIS MANUAL FIRST
Thank you for a buyin product. Read this manual first as it will help you operate the system properly. Please keep this manual
for future reference.
WARNING:
The exclamation point within an equilateral triangle is intended to alert you to the presence of important
operating and servicing instructions.
ATTENTION: Don't refit the system or spare parts without being authorized as this will .void the warranty
WARNING: Don't (such as candles) the equipment.place naked flames close to
Read the instruction first before using this product.
1.
Please keep this manual for future reference
2.
Pay attention to all warnings.
3.
Obey all operating instructions.
4.
Do not expose this product to rain or moisture.
5.
Clean this equipment with a dry cloth.
6.
Do not block any ventilation openings. Install according to instructions .
7.
Do not install this product near any heat source, such as , heater, burner, or any other equipment with heat radiation .
8.
Only use spare parts by manufacturer.
9.
Pay attention to the safety symbol on the of the cover.
10.
g
This product must be installed by professionals. When using hanging brackets or rigging other than those supplied with
the product, please ensure they comply with the local safety codes.
manual
manufacturer's
a
supplied the
outside
1
Page 3
S2-III
CONTENT
CONTENT
INTRODUCTION
Features
Description
Applications
AMPLIFIER MODULE
Amplifier Module
INSTALLATION
Mounting Accessories
Installation Reference
TECHNICAL SPECIFICATION
Technical Sheet
Frequency Response and THD CurveCurve
2D Dimension
3
3
3
3
4
4
5
5
5
6
6
6
7
Product information is subject to change without
prior notification. Please visit www.elderaudio.com
for the latest updates.
2
Page 4
INTRODUCTION
S2-III
Professional Active Performance System
Features
Compact,portable and eye catching design.
System is 1.8M high to deliver full,natural sound.
12 2.75"full range and 2 25mm × × Silk dome tweeter
vertical column speakers to ensure smooth sound coverage.
Bi-amp module including DSP.
Exclusive CLIK together connections,no cables required.
Handle on back of subwoofer.
Carry bags for system,ease of transportation.
S2-III
Description
β3 Meline S2-III is a performance sound reinforcement system
designed for musicians, meeting room presentation, DJ's etc for an
audience up to 300. The three piece system is designed for quick
and easy setup with new click together interconnecting
speakers. The amplifier module is housed within the
subwoofer. This bi-amp module includes DSP to enable superior
performance.
The active 3-way column speaker system Meline S2-III can be used
for various PA applications. The individual components of the
Meline S2-III (1 subwoofer module, 2 column modules) can be
connected so that the Meline S2-III is also ideally suited for mobile
applications. Two class D amplifiers, each with a power of 400W
RMS, are available for the low-frequency and the mid-high
frequency ranges.
Two audio units and two microphones can be connected to the 4-
channel mixer unit. For sound adjustment and frequency
splitting, the audio signals pass a digital signal processor (DSP) that
also includes a signal limiter.
.
.
.
Applications
Church
Auditorium
Conference room
Small performance
Multifunctional hall
3
Page 5
S2-III
Amplifier Module
AMPLIFIER MODULE
11
12
13
14
15
S2-III
PROFESSI ONAL
ACTIVE
PERFORMA NCE
SYSTEM
2
1
3 4
6 7 8 9 10
S2-III
Professional Active Performance System
S/N:
Elder Audio Manufacture Co.,Ltd.
AC INPU T
230V~ 50Hz,T5AL
5
2. Volume control for the input MIC IN(11)
3. Volume control for the input COMBI IN(15)
4. Volume control for the input AUX IN(16)
5. Control to adjust the strength of the low frequencies radiated by
the subwoofer
6. Control CONTOUR to define the level of the aurally compensated
sound correction for the input LINE IN(12)
7. Equalizer control for the signal of the input MIC IN(11),
continuously adjustable between vocals(SING), neutral
(FLAT)and speech
8. Equalizer control for the signal of the input COMBI IN(15),
continuously adjustable between neutral(FLAT),music and speech
9. Control CONTOUR to define the level of the aurally compensated
sound correction for the input AUX IN(16)
10. LED indicators
1. Volume control for the input LINE IN(12)
16
ON = Power indicator
SIGNAL = Signal indicator
LIMIT = Limiter indicator:Lights up when the signal level is too
high;the limiter will reduce the signal level to protect
the speaker.
17
11. MP3 music player module
12. Input MIC IN(combined 6.3mm jack/XLR,bal.)to connect a
microphone
18
13. Stereo input LINE IN(combined 6.3mm jacks/XLR,bal.)to connect
a signal source with line output level(e.g.mixer,CD/MP3 player)
14. Output LINE OUT(XLR,unbal.)
19
At this output,the signal of the input LINE IN(12)is available;
either as a mono signal or only the signal of the right channel,
can be selected by means of the selection switch(14).
15. Switch to select the operating mode
MONO = The speaker column reproduces the signal of the input
LINE IN(12)monophonically;the monophonic input
signal is available at the output LINE OUT(13).
RIGHT = The speaker column reproduces the left channel of the
input LINE IN;the input signal of the right channel is
available at the output LINE OUT.
16. Mono input COMBI IN(combined 6.35mm jack/XLR,bal.)to
connect a microphone
17. Stereo input AUX IN(RCA jacks and 3.5mm jack,unbal.)to
connect a signal source with line output level
18. Output MIX OUT(XLR,unbal.)to send the mixed mono signal to
an additional amplifier,for example
19. Output REC OUT(RCA)to connect a recorder
20
21
At this output,the mixed stereo signal is available.
20. Support for the mains fuse
Always replace a blown fuse by one of the same type.
21. Mains jack for connection to a socket(230V~50Hz)by
22
means of the mains cable provided
22. Power switch
4
Page 6
INSTALLATION
S2-III
Installation Accessories(Optional)
1.Meline S2-II BAG
Installation Reference
1. Place the subwoofer module on an even,horizontal
surface(floor).
2. Start with the column module where a 6.35mm jack is
located on the upper side.Place the column module turned by approx.20°to the left-onto the connector
of the subwoofer module and then turn it to the right
stop so that it is firmly engaged.
3. Proceed in the same way to connect the second
column module to the first one.
4. If the tweeters located in the centre of the connected
columns do not have the optimal height(ear's height),
use the adapter piece Meline S2-II EXT(available as an
option)to increase the height of the column modules.
Reference A Reference B
2.Meline S2-II EXT
Meline
S2-II EXT
5
Page 7
S2-III
Specification
TECHNICAL SPECIFICATION
Frequency response(-3dB):
Max.SPL:
Dispersion(H×V):
Transducer:
Power:
Rated impedance:
Connector:
Input:
Input impedance(line):
Input level:
Input overloading level:
Wire connection:
Heat radiation:
Power cable:
Safety voltage range:
Amplifier power output:
Cabinet:
Handle:
Painting:
Cabinet dimension(W D H): × ×
Packing dimension : (W×D×H)
Net weight:
Gross weight:
45Hz-20kHz
113dB/119dB(PEAK)
0
0
90 ×40
2 8" Woofer,12 2.75" Midrange Unit× ×
2 25mm × Silk dome tweeter
LF:200W,M HF:30W F:180W,
4 Ohms
XLR for input, XLR for output
T channel (MIC/COMBI/LINE) balanced input(XLR and 6.35mm jack)hree
One channel (AUX) unbalanced input(RCA and 3.5mm jack)
20kohm balanced input, 10kohm unbalanced input
LINE IN 775mVrms, AUX IN 200mVrms
: :
MIC IN: 20mVrms, COMBI IN: 40mVrms
: 3.5 :
LINE IN Vrms, AUX IN 2Vrms
MIC IN: 200mVrms,COMBI IN: 400mVrms
pin 1: ground; pin2: signal +; pin3: signal Forced air-cooled drives
PowerCon, three pins
AC 220V-230V~50Hz/60Hz
800W
Plywood,column loudspeaker
1× Wooden handles
Cabinet coated by Polyurethane paint; grille is powder coated
250 400 1726mm(9.8 15.7 68.0in)× × × ×
615 355 705mm(24.2 14.0 27.8in)× × × ×
23.5kg(51.7 lbs)
25.5kg(56.1 lbs)
Frequency response curve & THD curve
100
90
80
70
Sensitivity (dB)
60
Frequency Response
2nd Distortion
50
6
3rd Distortion
180
108
36
-36
-108
-180
200001000010001005020
Frequency (Hz)
Page 8
TECHNICAL SPECIFICATION
2D Dimension
Front view Side view Back view
S2-III
(67.95in)
1726mm
586mm
(23.07in)
250mm
(9.84in)
Meline S2-II EXT:
Top view
Bottom view
108.6mm
(4.28in)
86.5mm
(3.41in)
Front view
400mm
(15.75in)
570mm
(22.44in)
Side view
Back view
7
