Bestway 61064E, 61068E, 61110E User guide

61064E,61068E,61110E

www.bestwaycorp.com

2

Construction of the boat

Inflatable Seat Cushion

(Only for 61068E,61110E)

Heavy Duty Handle

Inflatable Floor

1

Valve

3

Oar Clasp

2

Pressure-scale

Oarlock

13. Prohibit the product misuse, such as, but not limited to: (a) riding seat back, gunwale, or other unsafe position, (b)
failure to use hanhold, (c) overloading or improper loading, (d) excessive speed for the operating conditions, (e)
using a boat in weather or sea conditions beyond the skill or experience of the operator, (f) continued operation
with operator’s visibility blocked or impaired (g) operating under the influence of drugs or alcohol, and/or (h)
modifications.

14. Boat operation where the boat operator or occupants are not under the influence of drugs and/or alcohol.

15. Knowledge of federal, state, and/or local regulations concerning operation requirement, including: (a) discharge of
oil, (b) solid waste disposal (Marpol Treaty), (c) marine sanitation, (d) speed, (e) noise, and (f) wake

16. Knowledge of accident reporting requirements.

17. The owner of operator of a vessel is required by law to render assistance to any individual or vessel in distress,
as long as his vessel is not endangered in the process.

18. U.S.Coast Guard Infoline: [phone]. Web site: www.uscgboating.org

Inflation
NEVER USE HIGH PRESSURE AIR TO INFLATE INFLATABLES. THIS CAN DAMAGE YOUR PRODUCT
AND VOID YOUR WARRANTY

SAVE THESE INSTRUCTIONS

Grab Rope

- Recommended seating arrangement of the occupants.

" "

Rope Grommet

Oar

(Only for 61068E,61110E)

Foot Pump

(Only for 61068E,61110E)

For 61064E, 61068E, 61110E: Number 1 ; Number 2 ; Number 3

61064E is not equipped with the oar and pump.

Technical Specifications

Item

Inflated Size

Maximum Weight

Passenger Capacity

Inflation Pressure

Dry Weight

NOTE: Drawings for illustration purpose only. Not to scale. Inflatable seats are not included with
the following boat size: 7ft.5in. x 47.5in. (2.28m x 1.21m).

The boats are designed and manufactured in conformity with ABYC H-28.
Boat Design Category -“SHELTERED WATERS”: Designed for voyages on sheltered coastal
waters, small bays, small lakes, rivers and canals when conditions up to, and including, wind force
4 and significant wave heights up to, and including, 0.3m may be experienced, with occasional
waves of 0.5m maximum height, for example from passing vessels.

Follow all the Safety and Operating Instructions. If you don’t follow these instructions, it may cause the boat to
overturn or explode and result in drowning.

1. Do not exceed the maximum recommended number of persons. Regardless of the number of persons on board,
the total weight of persons and equipment must never exceed the maximum recommended load. Always use the
seats /seating spaces provided.

2. When loading the craft, never exceed the maximum recommended load: Always load the craft carefully and
distribute loads appropriately to maintain design trim (approximately level). Avoid placing heavy weights high up.

NOTE: The maximum recommended load includes the weight of all persons onboard, all provisions and personal

effects, any equipment not included in the light craft mass, cargo (if any) and all consumable liquids (water, fuel,
etc.).

3. When using the boat, life saving devices such as life jackets and buoys should be pre-inspected and used at all
times.

4. Before every use, carefully inspect all boat components including air-chambers, grab ropes, oars, and air valves,
to ensure everything is in good condition and tightly secured. If you find any damage, please stop to repair it.

5. Buckets, water scoops and air pumps should always be available in case of air leakage or if the boat takes on
water.

6. When the boat is in motion, all passengers must remain seated at all times to avoid falling overboard. Keep the
boat balanced. Uneven distribution of persons or load in the boat may cause the boat to overturn and result in
drowning.

7. Use the boat near the shore and beware of natural factors such as wind, tide waters and tidal waves.

BE AWARE OF OFFSHORE WINDS AND CURRENTS.

8. If one chamber is punctured when the boat is in the water, it may be necessary to fully inflate the other air
chamber to prevent the boat from sinking.

9. Be careful when landing on the shore. Sharp and rough objects such as rocks, cement, shells, glass, etc. may
puncture the boat. To avoid damage, do not drag the boat on rough surfaces.

10. Inflate according to the numbered air chamber and rated pressure of the boat, or it will cause over-inflation and
potential and boat explosion. Exceeding the data given on the capacity plate may cause the craft to be damaged,
overturn and lead to drowning.

11. Know how to operate a boat. Check in your local area for information and/or training as needed. Inform yourself
about local regulations and dangers related to boating and/or other water activities.

12. The operator of a vessel is responsible for the maintenance and safe conduct of the vessel and the safety of
passengers.

61064E

7 ft.6in. x 48in.

2.28m x 1.21m

8ft.4in. x 50in.

2.55m x 1.27m

374 pounds (170 kg)

2 adults

0.03 bar
(0.5 psi) (0.5 psi)(0.5 psi)

11.8 lbs.(5.34 kg) 21.0 lbs.(9.5 kg)18.8 lbs.(8.51 kg)

IMPORTANT SAFETY INSTRUCTIONS

Warning

61110E61068E

10ft.1in. x 50in.

3.07m x 1.26m

594 pounds (270 kg)495 pounds (225 kg)

3 adults 2 adults

0.03 bar 0.03 bar

Deflation

Assembling of the boat

• Spread the boat on a level and even ground.

• Inflate the air chambers with a fitting-boat-pump.

• Never use compressed air!

• Inflate only as far that after inflating one can see some folding at the welding-seams. After inflation compare the height
of the printed scale on the product with the attached scale to make sure reach the height shown in the right list. Inflate
bottom chamber and other accessories such as seat until it is stiff to the touch but NOT hard. DO NOT OVER
INFLATE.

• Take care that the boat has got the correct pressure. Pay attention to the both pressure scales on the type-plate and
on the inside of the boat. Check after inflating of the boat with the enclosed scale, if the both printed scales on the boat
are identically with the enclosed scale. As soon as both scales are identically, the boat is inflated in a correct way. If
they are not identically, regulate the air by inflating or deflating. After you have inflated all air-chambers, check the
pressure of all air chambers finally once again due to safety reason, because while inflating the other air chambers,
the pressure of the first could change again. Check the pressure from time to time, because in the sun the pressure
can grow and it must be balanced then to correct one. Use the enclosed rope and slip it through the available
grommets. Then make a strong knot (as shown on the enclosed drawing).

Note: Extended exposure to sun can shorten the lifespan of your boat. We suggest not leaving boats
in direct sunlight for more than 1 hour after use.

Item

Product Inflated Size

7ft.6in. x 48in. / 2.28m x 1.21m

61064E

8ft.4in. x 50in. / 2.55m x 1.27m61068E

10ft.1in. x 50in. / 3.07m x 1.26m

61110E

How to install safety rope:

Please put safety rope through rope grommets and all round holes on tow handle in turn, to
make safety rope surround each side of inflatable boat, then fasten safety rope.

Caution:

1. Safety rope must go through rope grommets and all round holes of tow handle in a

correct way.

2. Please carefully check whether safety rope is in perfect condition and fastened tightly

prior to each use.

Repairs

1. If there is a leak, spray water onto the boat surface and look for air bubbles. Soapy water works well.

2. Clean and dry the damaged area. Apply a repair patch and smooth out any air bubbles.

3. If there are bigger defects at the boat, give the boat to a special repair-shop. Changes in the technical progress are
reserved.

Storage

1. Remove the Oars from the oarlocks.

Note: Keep all accessories for future use.

2. Carefully clean the boat using a mild soap with clean water.

Note: Do not use acetone, acid, and/or alkaline solutions.

3. Use a cloth to gently dry all surfaces. Do not dry the product in direct sunlight.

Note: Also, never dry with equipment such as electric blowers. Doing so will cause damage and shorten the boat’s

life span.

4. Deflate the hull chambers. Deflate all the hull chambers at the same time so the air-pressure drops together. This will
prevent damage from occurring to the boat inner structures.

5. Next deflate the floor.

6. Fold the boat from front to back to remove additional air. You can also use a pump to drain any remaining air.

7. Store in a cool, dry place and out of children’s reach.

Registration

If you need to register your boat, please have the boat Hull Identification Number and model name ready
and then visit www.bestwaycorp.com/support to obtain your Certificate of Origin, or you can send e-mail to
[email protected] for the Certificate of Origin. The HIN is located on the starboard outboard side of the
hull and near the stern.

PLEASE KEEP THIS MANUAL IN A SECURE PLACE, AND HAND IT OVER TO THE NEW OWNER WHEN YOU
SELL THE CRAFT.

3

Only for 61068E,61110E

Deflated Size

5cm / 10cm

5cm / 10cm

Inflated Size

Chamber 1

5.4cm

5.4cm

Inflated Size

Chamber 2

5.4cm

5.4cm

Inflated Size

Chamber 3

11.1cm

11.1cm5cm / 10cm 5.4cm5.4cm

11.3cm
