Page 1
#58381
220-240V~50Hz, 16W
IPX7 Hmin 0.19m
TO THE STORE
QUESTIONS? PROBLEMS?
MISSING PARTS?
For FAQ, Manuals Or
Spare Parts, Please Visit
www.bestwaycorp.com
FLOWCLEAR
TM
FILTER PUMP
OWNER’S MANUAL
www.bestwaycorp.com
Visit Bestway YouTube channel
P-S-004771
Page 2
WARNING
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
WARNING-RISK OF ELECTRIC SHOCK-The pump is to be supplied
by an isolating transformer or supplied through a residual current device
(RCD) having a rated residual operating current not exceeding 30 mA.
The appliance must be supplied by earthed power source.
Extension cords can’t be used.
WARNING- RISK OF ELECTRIC SHOCK- The pump cannot be using
while people are inside the pool.
DO NOT BURY CORD. Locate cord to minimize abuse from lawn
mowers, hedge trimmers, and other equipment.
WARNING- The supply cord cannot be replaced. If the cord is
damaged the appliance should be scrapped.
CAUTION- This pump is for use with storable pools only. Do not use
with permanently-installed pools. A storable pool is constructed so that it
is capable of being readily disassembled for storage and reassembled
to its original integrity. A permanently-installed pool is constructed in or
on the ground or in a building such that it cannot be readily
disassembled for storage.
IMPORTANT - Using the pump with an unmatched electrical supply is
dangerous and will result in catastrophic failure of pump.
RISK OF ELECTRICAL SHOCK- When working with electricity, turn the
electrical power off at the circuit breaker and lock breaker door. Failure
to do so will result in increased risk of shock, injury and possibly death.
DO NOT REMOVE THE GROUNDING PRONG OR MODIFY THE
PLUG IN ANY WAY. DO NOT USE ADAPTOR PLUGS. Consult a
qualified electrician for any questions related to the validity of your plugs
grounding.
Handle the pump with care. Do not pull or carry the pump by the power
cord. Never pull a plug from the outlet by yanking the power cord. Keep
cord free from abrasions. Sharp objects, oil, moving parts, and heat
should never be exposed to the filter pump.
WARNING- This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure that they do not
play with this product.
2
P-S-004771
Page 3
CAUTION: Read the instruction before using the appliance and
installation/reassemble each time.
Cleaning and user maintenance must be performed by an adult
above 18 years old who is familiar with the risk of electric shock.
NOTE:
Please examine equipment before use. Notify Bestway at the customer
service address listed on this manual for any manufacturing defect or
missing parts at the time of purchase. Verify that the equipment
components represent the filter pump model that you had intended to
purchase.
NOTE:
Place pump on a solid and level ground. Pay attention to position of
pool and pump so adequate ventilation, drainage, and access for
cleaning is available. Never place pump in an area that may accumulate
water, or in an area where foot traffic will flow around the pool.
It is necessary to have the plug accessible after installation of the pool.
NOTE:
Atmospheric conditions may affect the performance and life span of
your filter pump. Unnecessary wear and tear may occur during periods
of cold, heat and exposure to sun. Whenever possible shelter pump
from these conditions.
It is important to ensure the factory equipped stopper plugs for the inlet
and outlet ports replace the screens before removal or maintenance on
the pump is attempted.
NOTE:
Do not add chemicals in the filter pump.
Don’t plug or unplug the appliance if hand is wet.
Always unplug the appliance:
• On raining days
• Before cleaning or other maintenance
• Leave it unattended on holidays
When the appliance will be not used for long time, such as in the
winter, the pool set should be disassembled and stored indoor.
Safekeeping the instruction. For reconstruction the pool set every time,
please always refer to the instructions.
-If instruction is missed, please contact with Bestway or search it in
website: www.bestwaycorp.com
NOTE: This product is not intended for commercial use.
SAVE THESE INSTRUCTIONS.
3
P-S-004771
Page 4
P6112
P6113
P6114
P6(H1)114
P6116
P6118
P6124
58093
B
P6005
A
P6719AU
P6019
A B C
P6112
P6113
P6114/P6(H1)114
P6116
P6118
58093
P6719AU
P6019
P6132
P6124
P6005
P6362
P6680
P61318
1
1
1
1
1
1
1
1
2
2
8
5
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
0
5
2
5
2
1
0
0
0
0
0
A
B
C
1 2
A
P6132
P6019
B
B
P6132
P6362
P6132
ABA
P6362
P6680
P61318
X3
X3
X2 X1 X1
A
A
B
B
B
B
3
A
P61318 P6680
B
B
X2
4
P6124
4
P-S-004771
Page 5
PEDESTAL FIXING
IEC60335-2-41 TEST standard requires the filter pump to be
vertically fixed on ground or a certain pedestal made of wood or
concrete before use. There should be two holes 9mm in
diameter on the pedestal, the space between which should be
127mm. Put filter pump on the pedestal and fix them together by
fasten the bolts and nuts. All the pedestal parts should weigh
over 18kgs at least to prevent the pump from accidentally falling.
250
127
390
2-M8 nut
2-M8 bolt
390
127
NOTE: It is imperative to check that the hydraulic connectors are
not closed.
Operation
1) Open/unscrew the Air Purge Valve (P6112) on the top of the Filter Pump; air is released as water fills the Filter Pump.
2) When water comes out of the Air Purge Valve (P6112) screw it closed and wipe away any water.
3) To start the Filter Pump, insert the plug into a residual current device (RCD).
IMPORTANT: DO NOT DRY RUN THE FILTER PUMP - Make
sure both the pool’s Inlet and Outlet valves are fully covered by
water before operating the Filter Pump.
Maintenance
CAUTION: YOU MUST ENSURE THE FILTER PUMP IS
UNPLUGGED BEFORE ANY MAINTENANCE OR STORAGE
BEGINS OR SEVERE RISK OF INJURY OR DEATH EXISTS.
1) Unplug the Filter Pump.
2) Loosen the Hose Clamps on the pool’s Inlet and Outlet Hoses by unscrewing the fly nut counter-clockwise.
3) Remove Debris Screens from inside of pool.
4) Replace the Debris Screens with the Stopper Plugs in the pool’s Inlet and Outlet Valves.
5) Unscrew the Filter Cap Retainer and remove the Filter Cap.
6) Clean the Filter Cartridge with a garden hose, if filter cartridge remains soiled or discolored, it is necessary to replace it with a new
one.
7) Insert the cleaned (or new) Filter Cartridge; ensure it is centered in the Filter Pump.
8) Check that the Filter Cap Seal is in place.
9) Replace the Filter Cap and screw the Filter Cap Retainer into position.
10) Replace the Stopper Plugs with the Debris Screens in the pool’s Inlet and Outlet Valves. Tighten the Hose Clamps. Water will now
flow to the pump.
11) Follow PUMP INSTALLATION DIRECTIONS section to prepare the system for use.
IMPORTANT: For sanitary reasons we suggest replacing the Filter
Cartridge with a new one every two weeks.
STORAGE
1) Unplug the Filter Pump.
2) Follow the instructions as previously outline to stop water flowing to the Filter Pump and to remove the Filter Cartridge.
3) Discard the Filter Cartridge.
4) Detach all Hoses.
5) Dry all components thoroughly.
6) Store the filter pump in a dry location out of child’s reach. Storage temperature: 4-40°C (39.2-104°F)
Pump Warranty
For information concerning pump warranty please visit our website at: www.bestwaycorp.com
5
P-S-004771
Page 6
Limited BESTWAY® Manufacturer’s Warranty
The product you have purchased comes with a limited warranty. Bestway
your product will be free from manufacturer’s defects.
To enact a warranty claim, this form must be completed and submitted with a copy of your purchase receipt to your local Bestway After Sales Center. Please
contact your local Bestway After Sales Center before sending any documents. They will provide full instructions of what is needed for your claim. Bestway® will
not replace any products deemed to damaged due to negligence or having been used outside of the owner’s manual guidelines.
Bestway’s warranty covers manufacturing defects discovered while unpacking the product or during use as recommended within the user manual. This
warranty applies only to products which have not been modified by any 3rd parties. The product must be stored and handled in accordance with the technical
recommendations.
The warranty does not cover damages caused by misuse, abuse, neglect, including, but not limited to collision, fire, use of incorrect voltage, excessive heat
exposure, improper installation, improper wiring or testing, or improper storage.
Replacements and repairs don’t extend the duration of the warranty. The warranty start date is the date of sale shown on the original receipt/purchase invoice.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
®
stands behind our quality guarantee and assures, through a replacement warranty,
Please copy the Batch Number found on the body of the filter pump.
Batch Number
Batch Number:
®
TO: Bestway
FAX/E-MAIL/TEL: Please refer to your country according to the information found on the back cover or on our website: www.bestwaycorp.com
Please provide your address details in full. Note: Incomplete address details will result in delayed shipments.
Bestway reserves the right to charge for redelivery of undelivered packages where the recipient is at fault.
Service Department
Batch Number
Date of purchase:
Date:
Customer Code Number:
Batch Number
REQUIRED INFORMATION - PLEASE WRITE THE DELIVERY ADDRESS
Name: Address:
Zip Code:
Country: City:
Mobile: Telephone:
Fax: E-mail:
Please Clearly Write Your Item Code:
Retailer:
POOL FILTER PUMP
MODEL
#XXXXX
Item Code
All drawings for illustration purpose only. Not to scale.
Problem description
Water leakage Stopped working
Missing part - Please use the code for the missing part. This can be found in the owner's manual.
Other (Please describe)
IMPORTANT: ONLY THE DAMAGED PART WILL BE REPLACED, NOT THE COMPLETE SET.
Bestway reserves the right to request photographic evidence of defective parts, or to require sending the item for additional testing.
In order to best assist you, we request all information you provide to be complete.
FOR FAQ, MANUALS, VIDEOS OR SPARE PARTS, PLEASE VISIT OUR WEBSITE: www.bestwaycorp.com
VIDEOS ARE ALSO AVAILABLE ON OUR BESTWAY CHANNEL ON YOU TUBE:
www.youtube.com/user/BestwayService
