Bestop 29261 User Manual

Standard Seat Cover

Installation Instructions

For: Suzuki Samurai Part Number: 29261

Parts List

Seat Cover- Right, Qty - 1

Seat Cover - Left, Qty - 1

Seat Covers are not waterproof.

Warning:

the seats from the vehicle
to install this product.

DO NOT remove

Remove
Headrest

Pull Cover over
back of seat

Warning:

This product is designed to enhance the appearance of the vehicle and
to shield the occupants from ordinary weather conditions. Do not rely in
any way on the components of this product to contain occupants within
the vehicle, or to protect against injury or death in the event of an acci­dent. This product will not protect the occupants from falling objects.
Never operate vehicle in excess of manufacturer's specifications.

Wear seat belts at all times.

Read and follow, precisely, all installation instructions provided when
installing this product. Failure to do so may result in a poor fit and could
place occupants of the vehicle in a potentially dangerous situation.

Step One

Refer to your Owner's Manual for instructions to remove the
headrest.

Orient the Seat Cover with the quilting toward the front of the
seat. Slip the opening in the cover over the seat back and
pull the cover down to the seat bottom. Make sure that the
security cord on the bottom of the cover goes around and
under the outside of the plastic cover of the seat recliner
mechanism and tuck the fabric under the mechanism cover.

Step Two

Locate the flap sewn to the inside of
the cover at the corner between the
seat back and the seat bottom. Tuck
the flap between the seat back and
the seat bottom.

Tuck Flap between
Seat Back and Bottom

Rev. B 0204

29261 1

Step Three

Slide the cover over the seat bottom with the opening in the
side of the cover over the seat back release lever. Release the
seat back and tilt the seat forward. Unhook the security cord
and thread it through the end of the flap. Hook the ends of
the cord together. If necessary for a smooth fit, tighten the
cord by tying a knot and tuck in any loose fabric.

Unhook Security Cord and
Thread through Flap - Reattach

Tuck Fabric behind
Mechanism Cover

Slip opening
over lever

Hook ends
together

Cord length may be adjusted
by tying additional knots to
pull fabric up tighter

To Fasten Hooks

Slip the two hooks together at right
angles to each other.

Turn one hook until they hook
to each other.

To secure the hooks , pull them
against each other until they click
into position.

Reinstall Headrest

To Release Hooks: Turn one hook until it is at right
angles to the other and pull apart.

Step Four

Locate the hook and loop strips sewn to the cover on
side of the seat toward the center of the vehicle. Fasten
the strips to each other.

Reinstall the headrest.

Fasten Hook and Loop
Strips

Security Cord around and
under Mechanism Cover

We warrant our product to be free from defects in material and workmanship, for the terms specified below, provided there has been normal use and proper mainte-

LIMITED WARRANTY

nance. This warranty applies to the original purchaser only. All remedies under this warranty are limited to the repair or replacement of any item or items found by the
factory to be defective within the time period specified.

If you have a warranty claim, first you must call our factory at the number below for instructions. You must retain proof of purchase and submit a copy with any items
returned for warranty work. Upon completion of warranty work, if any, we will return the repaired or replaced item or items to you freight prepaid. Damage to our
products caused by accidents, fire, vandalism, negligence, misinstallation, misuse, Acts of God, or by defective parts not manufactured by us, is not covered under this
warranty.

THE WARRANTY TIME PERIOD IS AS FOLLOWS: ALL “SOFT GOODS” MANUFACTURED BY OUR COMPANY (USING PRIMARILY VINYLS, PLASTICS, AND/OR FOAM):
ONE YEAR FROM DATE OF PURCHASE.

ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR PURPOSE CREATED HEREBY ARE LIMITED IN DURATION TO THE SAME
DURATION AND SCOPE AS THE EXPRESS WRITTEN WARRANTY. OUR COMPANY SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGE.

Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
For further information or request for warranty work, please contact: Bestop Inc.

*All or a portion of this product may be made in China.

Customer Service
[phone]
[phone]

Rev. B 0204

29261 2
