PENDENZA
BESTRANGEHOODS.COM, IN U.S.A. 800-558-1711, IN CANADA 866-737-7770
WC26
CHIMNEY
Two 20-watt halogen lamps
provide ample lighting for the
work surface.
Four-speed electronic pushbutton control with blue LED
display.
Blue LED light provides beautiful
accent color to the glass canopy.
Ambient light sensor
automatically turns on/off LED
accent light.
Quick release, dishwasher-safe,
stainless steel, mesh grease
filters ensure a clean, fresh
kitchen.
Ten-minute time-delay shut-off
feature and reminder light for
filter maintenance.
Model Numbers:
WC26E36CB
WC26E36SB
WC26E42CB
WC26E42SB
WC26E48CB
WC26E48SB
Hood Sizes
Widths 36", 42", 48"
Depth 21"
Finish
Stocked Brushed Stainless Steel
with Clear Glass
Special Order Brushed Copper with Clear Glass
Features
Lighting Type Halogen, G4-20W
Number of Lamps 2
Lighting Levels 2
Lighting Lamps Included Yes
Control Type 4-speed Electronic Pushbutton
with LED Display
Control Features Heat Sentry
Filter Timer, Light Sensor
™
, Delay Off,
Remote Control Not Available
Filter Type Stainless Steel with Mesh
Grease Filter
Non-ducted Capability Yes
Hood Blower Included (WC26I)
Internal
Blower CFM High/Low 480/130
Sones Low/High 9.5/1.0
Hood Blower Options (WC26E blowers sold separately)
External In-line ILB3 ILB6 ILB9 ILB11
Vertical or straight through CFM 280 600 800 1100
Horizontal or right angle CFM 260 600 700 1000
Sone levels are typically half of comparable CFM internal blowers.
External Exterior EB6 EB9 EB12 EB15
Blower CFM 600 900 1200 1500
Sone levels are typically half of comparable CFM internal blowers.
Accessories
10' Flue Extension (Ducted) AEWC26SB—Stainless Steel
AEWC26CB—Copper
10' Flue Extension (Non-ducted) AEWC26SBN—Stainless Steel
AEWC26CBN—Copper
Non-ducted Recirculating Kit ANKWC26
CFM Reducer Kit ARP6
Universal MUA Damper MD6TU, MD8TU, MD10TU
Installation Requirements
Amps @ 120V 3.13
Amps @ 120V: External Blower 7.0 Max
Electrical Plug In
Duct Size: Internal Blower 6"
Duct Size: External Blower 8" at hood (Transition to 10"
typical, see pages 64–65)
Duct Direction Vertical
Backdraft Damper Included
Heat Sentry
heat and adjusts speed to high
automatically.
Works with optional Universal
Make-Up Air Dampers.
CFM Reducer Kit for internal
blower reduces max CFM to
250–300.
WC26I36CB
WC26I36SB
Installation height above the cooking
surface:
Telescopic flue for 8'–9' ceiling is
standard. Optional flue extensions
for 10' ceiling
Reversible telescopic flue allows
non-ducted recirculation. (see page 68)
For more details see the product
specifications sheet found at
www.BESTRangeHoods.com
WC26I42CB
WC26I42SB
8' ceiling: 22"–25"
9' ceiling: 22"–28"
10' ceiling: 22"–28"
™
detects excessive
WC26I48CB
WC26I48SB
41
