Page 1
ring 13 / 15 / 19
flush mount ceiling
SPECIFICATIONS:
DESCRIPTION
Flush-mounted round ceiling luminaires, featuring handcrafted glass.
Three sizes available.
LAMPING
Standard: 60W A19 120V incandescent, suitable for dimming,
not included.
CFL: Standard 4-Pin CFL with non-dimming electronic ballast. 120V,
lamp not included.
GU24 CFL: Self-ballasted GU24 lampholders. 13W max, 120V,
lamp not included.
LED: 10W GU24 LED Lamp 120V, dimmable, included.
DIFFUSER
Handcrafted white glass diffuser with an attached glass ring
of various decors, including distressed metallic foil applique.
Ring 13 #9772XX: 12.625” Dia. x 3.875” H
Ring 15 #9771XX: 15.5” Dia. x 4.25” H
Ring 19 #9770XX: 19” Dia. x 5.25” H
MOUNTING
Installs directly to a 4” octagonal outlet box, centered on fixture.
90°C supply wire required for incandescent lamping.
LABELS
UL or ETL Listed. Suitable for Damp Locations (interior use only).
location:
DAMP
RING CEILING SHOWN IN WHITE/FROST
Twist and lock bayonet glass
WHITE/CLEAR
WHITE/GOLD FOIL
For ordering information, see next page
All dimensions provided are nominal.
Allowance must be made for dimensional tolerance in handcrafted glasses.
Besa Lighting Co., Inc. • 6695 Taylor Rd. • Blacklick, OH 43004 • tel 614-475-7046 • fax 614-475-7048 • www.besalighting.com
WHITE/GOLDWHITE/SMOKE
WHITE/SILVER FOILWHITE/COPPER FOIL
REV 10/14
Page 2
ORDERING:
Ring 13: #9772
12.625”
ring 13 / 15 / 19
flush mount ceiling
3.875”
FIXTURE /DECOR
977200C White/Clear Ring (blank) 1x 60W A19 Incan LW Low Wattage
977202C White/Smoke Ring D1 1x 13W Quad 120V labeling
977203C White/Gold Ring GU24 1x 13W GU24 120V
977225C White/Frost Ring LED 1x 10W LED 120V,
9772CFC White/Copper Ring dimmable
9772GFC White/Gold Ring
9772SFC White/Silver Ring
LAMP OPTIONS OPTIONS
Ring 15: #9771
15.5”
4.25”
FIXTURE /DECOR
977100C White/Clear Ring (blank) 2x 60W A19 Incan LW Low Wattage
977102C White/Smoke Ring D2 2x 13W Quad 120V labeling
977103C White/Gold Ring GU24 2x 13W GU24 120V
977125C White/Frost Ring LED 2x 10W LED 120V,
9771CFC White/Copper Ring dimmable
9771GFC White/Gold Ring
9771SFC White/Silver Ring
LAMP OPTIONS OPTIONS
Ring 19: #9770
19”
5.25”
FIXTURE /DECOR
977000C White/Clear Ring (blank) 3x 60W A19 Incan LW Low Wattage
977002C White/Smoke Ring H2 2x 26W Quad 120V labeling
977003C White/Gold Ring GU24 3x 13W GU24 120V
977025C White/Frost Ring LED 3x 10W LED 120V,
9770CFC White/Copper Ring dimmable
9770GFC White/Gold Ring
9770SFC White/Silver Ring
LAMP OPTIONS OPTIONS
Ex. 977100C
Ring 15 Ceiling w/ White/Clear Ring Glass
Project Information:
Besa Lighting Co., Inc. • 6695 Taylor Rd. • Blacklick, OH 43004 • tel 614-475-7046 • fax 614-475-7048 • www.besalighting.com
LED 120V PENDANTS:
• Internal driver integrated in the lamp, GU24 base
• Total power of only 10 watts
• Dimmable with a standard dimmer
• Rated life: 30,000 hours
• Frosted acrylic diffuser
• 800 lumens
• CCT: 2800° Kelvin
• CRI: 80+
