1SW Canto 5
mini SconceS wall
SPECIFICATIONS:
DESCRIPTION
Wall-mounted sconce featuring one handcrafted glass.
LAMPING
Standard: 40W Low-pressure G9 Halogen 120V lamp, included.
Suitable for use in an open fixture. Dimmable with standard incandescent
dimmer.
LED: 5W LED Replaceable source 120V, dimmable, included.
DIFFUSER
Shade shall be handcrafted glass of various decors.
Diameter of 4.0” and height of 4.125”
CONSTRUCTION
Fixture utilizes metal arm assembly with stamped steel
canopy and faceplate (5” Circle or Square), with plated finish.
METAL FINISH
Fixture shall be finished in Bronze, Chrome or Satin Nickel.
MOUNTING
Installs directly to a 4” octagonal outlet box. Wall-mount only.
Designed for uplighting, but may also be oriented downward.
LABELS
UL or ETL Listed. Suitable for Damp Locations (interior use only).
CHOICE
COLLECTION
location:
DAMP
5.5” 4”
8”
5”
5.5” 4”
8”
5”
ORDERING:
FIXTURE
1SW Sconce 513107 Opal Matte (blank) 40W G9 Hal BR Bronze SQ Square
Ex. 1SW-513131-SN
Canto 5 Mini Sconce w/ Red Matte Glass,
Satin Nickel Finish
Project Information:
GLASS OPTIONS
513131 Red Matte LED 5W LED 120V, CR Chrome Canopy
513180 Amber Matte dimmable SN Satin Nickel
5131GY Bicolor Green/Yellow
5131OP Bicolor Orange/Pina
5131SL Solare
METAL FINISHMETAL FINISHOPTIONS
Canto 5 shown in amber matte (513180) &
red matte (513131) with square Canopy in Chrome finish
513107
opal matte
5131sl
solare
LED SCONCES:
• Total power of only 5 watts
• Dimmable with a standard dimmer
• Rated life: 25,000 hours
• 450 lumens
• CCT: 3000° Kelvin
• CRI: 80+
5131op
biColor orange/pina
5131gy
biColor green/yellow
All dimensions provided are nominal.
Allowance must be made for dimensional tolerance in handcrafted glasses.
Besa Lighting Co., Inc. • 6695 Taylor Rd. • Blacklick, OH 43004 • tel 614-475-7046 • fax 614-475-7048 • www.besalighting.com
REV 10/14
