Page 1
Please retain this owners manual for future reference. rev.6
ANALOG MODELS
Contact Information:
866-665-7327
www.bertucciwatches.com
© 2012 MH BERTUCCI, INC.
ALL RIGHTS RESERVED
PRINTED IN THE U.S.A.
8
contains post
consumer material
Page 2
Thank you for your purchase of a Bertucci™Performance Field
Watch.
™
You’ve made an excellent choice. You’ll be pleased
with your Bertucci
™
watch for years to come.
Thank You!
Send responses to: askenzo@mhbertucci.com
In The Field With Bertucci
™
We would like to hear from you,
so please let us know your stories,
testimonials, or experiences you’ve
had using your Bertucci™field watch.
Please let us know of any questions
or comments you may have.
Congratulations!
You are now the owner of a Bertucci™Performance Field
Watch.
™
Every Bertucci™watch has been carefully
designed and manufactured from the best materials with
a n
on-compro
mised set of premium features. This is the
basis for our Promise Of Performance
™
to you. Please
carefully read this manual to familiarize yourself with your
Bertucci field watch.
Table of Contents:
Our Story – Your Watch
Durability by Design
®
Setting models without date
Setting models with date
Water resistance
Care for your Bertucci
™
watch
Genuine Bertucci
™
DX3®watch bands
Warranty information
Refurbishment program
Battery information
Thank you, In The Field With Bertucci
™
Contact Us
2
3
4 – 5
6 – 7
8
9 – 11
12 – 15
16 – 17
18 – 19
20
Inside backcover
Backcover
Page 3
32
Durability by Design®:
High Performance
U.S. Patented*
DX3® Case Design
Rugged, Solid Titanium or
Stainless Steel Case
100 M/ 328 Ft.
Water Resistance
Unbreakable Integrated
Band Lugs/Bars
Scratch-Resistant
Mineral Glass Crystal
Screw Down/ In
Case Back
Ergonomically Offset,
Durable Screw Down Crown
(Setting Knob)
Long Lasting and
Comfortable Band
Reliable, Precision
All Metal Quartz Movement
*Manufactured using one of more of the following U.S. Pat. No: 488388, 488075, 488724, 582296, 609586, 645766,
7832605 and other patents pending.
When we create a watch, we study the ways in which it will be
worn and used. As a result, every Bertucci
™
watch is carefully
designed, engineered and manufactured with a noncompromised selection of materials and features.
Our story is a simple one. It’s about building a better watch.
It’s a Promise Of Performance
™
that is derived from a belief that
innovative design and attention to detail matter. It is this focus
and integrity that drive us, an honest, true and authentic way.
We believe if a watch is done right, it connects with you…
creating an emotional touch point that says something about you,
a personal expression well suited to your active lifestyle.
Bertucci
™
Performance Field Watches™balance form and
function, with an enduring style and rugged quality that are ready
to survive the day to day challenges that come your way…
whatever they may be.
Our Story–Your Watch:
Page 4
54
Setting instructions: Models without date
If packaging clip is on the crown (setting knob), please remove.
Note: Crown may already be in the out position or unscrewed.
Step 1: Turn crown counter clock-wise to unscrew crown (fig. 1).
The crown is completely unscrewed when it turns freely.
Step 2: Gently and carefully pull crown out to stop second hand
(fig. 2).
Step 3: Turn crown clock-wise or counter clock-wise, moving hour
and minute hands to set the desired time (fig. 3).
Step 4: Push crown in to re-start second hand (fig. 4).
Step 5: Push in and turn crown clock-wise to engage threads.
Continue to turn crown clock-wise to firmly screw/rethread
down. Do not overtighten (fig. 5).
Note: Please screw/rethread down crown (setting knob) to ensure
water resistance and maintain warranty. Do not overtighten.
1
23
45
Page 5
76
Setting instructions: Models with date
If packaging clip is on the crown (setting knob), please remove.
Note: Crown may already be in the out position or unscrewed.
Step 1: Turn crown counter clock-wise to unscrew crown (fig. 1).
The crown is completely unscrewed when it turns freely.
Step 2: Gently and carefully pull crown halfway out, you will feel a “click”, there
will be a bit of feel here (fig. 2).
Step 3: Turn crown either clock-wise or counter clock-wise (depending on the
model) to advance the date, continue to advance the date to
yesterday’s date (fig. 3).
Step 4: Carefully pull the crown out a bit further for a second “click”. Turn the
crown clock-wise to cycle the time past midnight, you will see the date
advance to today’s date. Continue to advance to set the desired time,
this will ensure the AM/PM is correct (fig. 4).
Step 5: Push crown in to re-start second hand (fig. 5).
Step 6: Push in and turn crown clock-wise to engage threads. Continue to turn
clockwise to firmly screw/rethread down crown. Do not overtighten
(fig. 5).
Note: Please screw/rethread down crown (setting knob) to ensure
water resistance and maintain warranty. Do not overtighten.
Date will need to be reset for months not ending with 31 days.
1
23
465
Page 6
98
Care for your Bertucci™watch:Water resistance:
1 Never wear the watch unless the crown (setting knob) is completely screwed/
rethreaded down. Do not overtighten crown.
2 We recommend rinsing your watch and band with fresh water after exposure to salt
water, chlorinated water, chemicals or soil loads.
3 Never adjust crown (setting knob) when watch is wet or submerged in water.
4 Keep watch clean and free of debris, especially around the crown area.
Use dish detergent & warm water with a soft brush to clean, keep crown (setting knob)
screwed down when cleaning.
5 If leather band is submerged in water for an extended time period, allow it to air dry.
6 Replace band if excessively worn (see page 12).
7 If watch has stopped bring it to a local jeweler or a professional watch service shop
for battery replacement/ check (see page 20).
8 Do not expose your watch to intense magnetic fields such as loudspeakers and
other electromagnetic devices.
9 When setting your watch, handle the crown (setting knob) gently as this is a
precision device.
10 Do not subject your watch to severe impact, avoid dropping.
Your Bertucci™watch has been carefully designed and tested to be used in water.
The case material, screw down crown, and case back are premium features to
improve water resistance performance. Bertucci
™
watches are engineered to
withstand water pressure to 160 P.S.I.A (equals immersion to 100 meters or 328
feet below sea level) if crown (setting knob) is screwed down.
1 Never adjust crown (setting knob) when watch is wet or submerged in water.
2 Never wear the watch unless the crown (setting knob) is completely screwed
down. Don’t forget to tighten crown (setting knob) down after setting time as
water will leak and damage movement.
3 The watch is water resistant only as long as crystal, crown and case
are intact and undamaged.
4 Your Bertucci
™
watch has been designed to be worn during activities in which
the watch will be exposed to water and submersion in water. However, the watch
is not a professional diver watch and should not be used for diving.
5 Do not operate push buttons (if equipped with) when watch submerged
in water.
Page 7
1110
Care for your Bertucci™watch (cont.):
Most important: Keep crown (setting knob) screwed or rethreaded down.
Your watch is equipped with a screw down crown (setting knob). This
premium feature is the best design in order to maximize water-resistance
and durability to ensure protection of the watch movement.
Please note: After setting the time and/or date, it is critical that the crown is
tightened down by pushing in and gently turning clock-wise (to the
right) simultaneously in order rethread crown down.
Failure to do so will cause the watch's internals to be flooded with water
and voiding warranty.
Following this simple practice will extend the watch life dramatically.
screw down crown not screwed down crown
correct incorrect
Page 8
1312
Genuine Bertucci™DX3
®
watch bands: Bertucci
™
DX3
®
watch bands sizing:
The performance band for Bertucci™Performance Field Watches.™Our U.S.
patented DX3®bands are a unique design made for only Bertucci™watches.
Three hig h p erformance materials to ch oos e f rom:
Top Grain Leather – Manufactured from high performance top quality water
resistant leather with durable box stitch construction and stainless steel hardware.
Tridura
™
Ultra Duty – U.S. patented polyurethane coating over webbing, welded
construction, and metal hardware provide extreme durability. Band may be cut to
length for smaller wrists and will not fray.
Heavy Dut y 2 -Pl y Nylon – U.S. patented one piece design features military
specification nylon, rugged box stitch construction, all metal hardware.The U.S.
patented nylon band features a design that allows the excess band material to be
folded & “tucked-under” the keeper (see illustration). Short and long nylon bands
available.
Band Size: Case Type:
5/8" band M-1S
3/4" band A-1S, C-1T
7/8" band A-2T, A-2S, A-3T, B-1T, D-1T, G-1T
1" band A-4T
See case back engraving for case type.
Bands require no tools to change, simply slide the old band out and
the new band in.
Note: Use only genuine Bertucci™replacement bands.
Available in a variety of materials, colors, and sizes for your watch.
Page 9
1514
To order: Email us at [email protected] to use Paypal or
call 866-665-7327.
To see a full listing of all bands available for your watch go to
www.bertucciwatches.com or your authorized dealer.
Some of our most popular band styles:
Replacement Bertucci™DX3
®
watch bands:
TRIDURA™:
#31 - 7/8" Black
#32 - 7/8" Foliage Green
#55 - 7/8" Coyote Brown
LEATHER:
#43 - 3/4" Black Latigo
#9 - 7/8" Olive Brown Duration
#10 - 7/8" Black Duration
#46 - 7/8" Chestnut Latigo
#76 - 7/8" British Tan Vintage Latigo
#80 - 7/8" Military Black Vintage Latigo
#79 - 1" Bavarian Brown w/ post screws
NYLON:
#29 - 5/8" Black
#56 - 5/8" Dark Khaki
#1 - 3/4" Black
#2 - 3/4" Olive
#40 - 3/4" Dark Khaki
NYLON:
#4 - 7/8" Black
#5 - 7/8" Olive
#27 - 7/8" Khaki
#28 - 7/8" Drab
#36 - 7/8" Dark Khaki
#73 - 1" Black
#75 - 1" Dark Khaki
Page 10
1716
Warranty information:
Every Bertucci™watch is carefully designed, manufactured and inspected to
ensure it meets our Promise Of Performance
™
to you. This is backed up by a 3
year warranty on the watch head and 1 year on the band.
In the event of a malfunction, please follow these steps (for band only, go to
directly to Step 4.
Step 1 Determine whether the watch is in warranty. If the watch is in warranty,
please follow the remaining steps. If it is NOT in warranty, please refer to
the Refurbishment Section (pg. 18).
Step 2 Determine whether the watch has been abused. If not abused, please
follow the remaining steps. If the watch IS abused (for example, crown is
not screwed down and watch is water damaged, or there is visual
evidence of high impact to case or crystal), please refer to the
Refurbishment Section (pg. 18).
Step 3 Please have the battery checked by a local jeweler or professional watch
service shop. Most malfunctions are simply battery related. If the battery
is good, and watch is still not functioning correctly, please follow next
Step 4. If battery is bad, please refer to Battery Replacement Section
(pg. 20).
Step 4 Please return the defective watch (just the watch head, remove the band)
or defective band to the dealer or send to us for exchange. Please send a
note explaining the malfunction or use the Warranty Coupon (available on
our web site: www.bertucciwatches.com)
Please contact us with any questions at 866-665-7327
or email us at [email protected].
Return note with defective watch to include: name and address, phone number,
description of watch (ex. A-2T nylon) and description of malfunction.
Send the malfunctioning watch to:
Bertucci Consumer Service – BCS
P.O. Box 7920
Gurnee, IL 60031 USA
Page 11
1918
Out of Warranty Refurbishment Program:
Should the watch be out of warranty (more than 3 years old), damaged, deemed
abused, or water damaged as a result of not screwing the crown down, we offer
our refurbishment program. The way it works is as follows:
1 Send us the out of warranty or damaged watch head to the below address.
Just the watch head, keep your band.
2 Include a note or use the Refurbishment form (available at our web site:
www.bertucciwatches.com) advising nature of the problem (if known).
3 The note should also include your name, return address and phone
number (see refurbishment form).
4 Check or money order made out to Bertucci Watches in the amount based on
the refurbishment pricing, on page 19.
5 We will send out a fully refurbished watch to your shipping address.
6 The refurbished watch includes:
• refurbished, recertified, and cleaned watch head.
• new band • new battery • 1 year warranty
7 The refurbished watch sent back may include some minor or cosmetic
scratches to the case only. You may not get back your exact watch.
Send your watch to:
Bertucci Consumer Service – BCS
P.O. Box 7920
Gurnee, IL 60031 USA
A-1S – $48
A-2S, M-1S – $54
A-2T – $60
A-2T, B-1T (w/EL light) – $82
A-2T Vintage, High Polish, Procolor – $85
A-3T Vintage, D-1T Vintage – $85
B-1T, C-1T – $85
A-2T (w/10 year Li Battery) – $90
A-3T Vintage (w/sub second) – $90
A-4T Vintage – $90
G-1T Durato – $115
Tritium light styles – $190
Refurbishment Pricing: (add $9 for shipping)
Contact us with any questions you may have about the refurbishment program.
Page 12
Thank you for your purchase of a Bertucci™Performance Field
Watch.
™
You’ve made an excellent choice. You’ll be pleased
with your Bertucci
™
watch for years to come.
Thank You!
Send responses to: [email protected]
In The Field With Bertucci
™
We would like to hear from you,
so please let us know your stories,
testimonials, or experiences you’ve
had using your Bertucci™field watch.
Please let us know of any questions
or comments you may have.
Congratulations!
You are now the owner of a Bertucci™Performance Field
Watch.
™
Every Bertucci™watch has been carefully
designed and manufactured from the best materials with
a n
on-compro
mised set of premium features. This is the
basis for our Promise Of Performance
™
to you. Please
carefully read this manual to familiarize yourself with your
Bertucci field watch.
20
Battery information:
Bertucci™watches use common batteries that are readily available. The case
back is engraved with the model/case and battery type. Batteries should be
replaced by a local jeweler or professional watch service for a moderate price.
Do not attempt to remove the case back as it requires a special tool and skills.
Proper replacement of batteries is critical to ensure the long life of your
Bertucci™field watch. Actual battery life may vary based on environmental
factors and usage pattern. Replacement battery brands may have different
battery numbers, check battery equivalency reference.
Estimated Battery Life:
3 year A-1S, A-2S, M-1S, A-2T
2 year A-2T, B-1T (w/EL light)
5 year A-2T Vintage, High Polish, Procolor
5 year A-3T Vintage, A-4T Vintage, B-1T, C-1T, D-1T Vintage
2
year A-3T Vintage (w/sub second)
5 year G-1T Durato
10 year A-2T Lithium battery equipped styles
Loading...
