Page 1
ANALOG MODELS
& FIELD COMBO
Page 2
Table of Contents:
Our Story – Your Watch
Durability by Design
®
Bertucci™DX3®watch bands
Models without date
Models with date
Instructions for A-2TC Field Combo
Water resistance
Care for your Bertucci
™
field watch
Warranty infor mation
Refurbishment program
Battery information
Thank you, In The Field With Bertucci
Contact Us
2
3
4 - 5
6 - 7
8-9
10-13
14
15
16 - 17
18 - 19
20
Inside backcover
Backcover
Congratulations!
Distinctive Performance For The Real World
™
You are now the owner of a Bertucci™Performance Field
Watch.
™
Every Bertucci™watch has been carefully
designed and manufactured from the best materials with
a non-compromised set of premium features. This is the
basis for our Promise Of Performance
™
to you. Please
carefully read this manual to familiarize yourself with your
Bertucci field watch.
Page 3
32
Durability by Design®:
High Performance
U.S. Patented*
DX3®Case Design
Rugged,
Solid Titanium or
Stainless Steel Case
100 M/ 328 Ft.
Water Resistance
Heavy Duty Integrated
Band Lugs/Bars
Scratch-Resistant
Mineral Glass Crystal
Screw Down/ In
Case Back
Ergonomically Offset,
Durable Screw Down Crown
(Setting Knob)
Long Lasting and
Comfortable DX3
®
Band
Reliable, Precision
Quartz Movement
(provides +/– 15 seconds
accuracy per month)
*U.S. Pat. No: 488388, 488075, 488724 and other patents pending
When we create a watch, we study the ways in which it will be
worn and used in the real world. As a result, every Bertucci
™
watch is carefully designed, engineered and manufactured with
a non compromised selection of materials and features.
Our story is a simple one. It’s about building a better watch.
It’s a Promise Of Performance
™
that is derived from a belief that
innovative design and attention to detail matter. It is this focus
and integrity that drive us, an honest, true and authentic way.
We believe if a watch is done right, it connects with you…
creating an emotional touch point that says something about you,
a personal expression well suited to your active lifestyle.
Bertucci
™
Performance Field Watches™balance form and
function, with an enduring style and rugged quality that are ready
to survive the day to day challenges that come your way…
whatever they may be.
Our Story–Your Watch:
Page 4
54
Bertucci™DX3
®
watch bands: Bertucci
™
DX3
®
watch bands sizing:
The performance band for Bertucci™Performance Field Watches.™Our U.S. patent
pending DX3®bands are a unique design made for only Bertucci™watches.
Note: Other replacement bands are not compatible. Bertucci™DX3®bands are long
lasting, comfortable and highly durable. Bertucci™DX3®bands and are available in
a variety of materials, colors, and sizes for your watch.
Three high perfor mance mater ials to choose from:
1 Leather – Long lasting full grain leather bands with stainless steel hardware.
2 Tridura
™
– Highly durable, moisture, mildew and odor resistant U.S. patented
polyurethane coated webbing with powder coated steel buckle & keeper.
3 Nylon – Heavy duty 2–ply military spec. nylon strap with all-metal hardware.
The patent pending nylon band features a design that allows the excess band
material to be folded & “tucked-under” the keeper (see illustration). Short and
long nylon bands available.
To see a full listing of all bands available for your watch go to
www.bertucciwatches.com or your authorized dealer.
To order:
Email us at [email protected] to use paypal or
call 866-672-6442 or 866-524-7877.
Band Size: Model/Case:
5/8" band M-1S
3/4" band A-1S, C-1T
7/8" band A-2T, A-2S, A-3T, B-1T, D-1T, G-1T
1" band A-4T
See case back engraving for model/case type.
Page 5
76
Setting instructions: Models without date
See case back engraving for model/case type.
Models: A-1S, A-2S, A-2T, A-3T, A-4T, M-1SE
If packaging clip is on the crown (setting knob), please remove. Note:
Crown may already be in the out position or unscrewed when new.
Step 1: Turn crown counter clock-wise to unscrew crown (fig. 1).
The crown is completely unscrewed when it turns freely.
Step 2: Gently and carefully pull crown out to stop second hand
(fig. 2).
Step 3: Turn crown, moving hour and minute hands to set the
desired time (fig. 3).
Step 4: Push crown in to re-start second hand (fig. 4).
Step 5: Push in and turn crown clock-wise to engage threads.
Continue to turn clockwise to firmly screw down crown.
Do not overtighten (fig. 5).
Note: Please screw down crown (setting knob) to ensure water
resistance and maintain warranty. Do not overtighten.
1
23
45
Page 6
98
Models: A-2T(E), B-1T(E), C-1T, D-1T(E), M-1S
Setting instructions: Models with date
See case back engraving for model/case type.
If packaging clip is on the crown (setting knob), please remove.
Note: Crown may already be in the out position or unscrewed when new.
Step 1: Turn crown counter clock-wise to unscrew crown (fig. 1).
The crown is completely unscrewed when it turns freely.
Step 2: Gently and carefully pull crown halfway out, you will feel a “click”,
there will be a bit of feel here (fig. 2).
Step 3: Turn crown either clock-wise or counter clock-wise (depending on the
model) to advance the date, continue to advance the date to
yesterdays date (fig. 3).
Step 4: Carefully pull the crown out a bit further for a second “click”.Turn the
crown either clock-wise or counter clock-wise (depending on the
model) to cycle the time past midnight, you will see the date advance
to todays date. Continue to advance to set the desired time, this will
ensure the AM/PM is correct (fig. 4).
Step 5: Push crown in to re-start second hand (fig. 5).
Step 6: Push in and turn crown clock-wise to engage threads. Continue to
turn clockwise to firmly screw down crown. Do not overtighten (fig. 5).
Note: Please screw down crown (setting knob) to ensure water
resistance and maintain warranty. Do not overtighten. Date will
need to be reset for months not ending with 31 days.
1
23
465
Page 7
1110
Instructions for A-2TC Field Combo:
Start/ Stop:
(button C)
Mode:
(button A)
Set/Split:
(button B)
Functions:
• 12/24 hour time (analog dial)
• 2nd time zone (digital time,
12/24 hour display)
• Stopwatch/Chrono (STP.W)
(1 hour capacity, split time,
1/100 sec)
• Day, Date (DATE)
• Alarm (ALM)
• Hourly chime
Note: Mode indicators flash to
indicate the mode you are in.
Mode Indicators:
alarm
icon
hourly
chime icon
Crown
setting knob
(analog
setting)
day
month date
DATE mode ALM mode
alarm
armed
Setting date:
Setting alarm:
– push button A and select
DATE mode
– push & hold button B until
date flashes
– push button C to select date
– push button B for month
– push button C to select month
– push button B for day
– push button C to select day
– push button B to lock settings
– push button A and select
ALM mode
– push & hold button B until
hour flashes
– push button C to select hour
– push button B for minute
– push button C to select minute
– push button B to lock settings
– push button C to arm/disarm
alarm
Page 8
1312
A
B
C
Setting digital time:
– push button A and select 2nd time mode
– push & hold button B until seconds flash
– push button C to reset seconds
– push button B for minute
– push button C to select minute
– push button B for hour
– push button C to select hour cycle through for
A for am, P for pm
– push button B for 12 or 24 hour time
– push button C to select 12 or 24 hour time
– push button B to lock settings
– press & hold button C & press B to turn
hourly chime on or off
See page 6 to set analog (hands) time. Digital
time is not synchronized with analog time, as
the timing systems operate independently.
hourly chime
activated
AM/PM
Using stopwatch/chronograph:
A
B
C
– push button A and select STP.W mode.
– push button C to start timing
– push button C to stop timing
– push button B to reset stopwatch.
For splits:
– push button B during timing for splits
STP.W mode
split time indicator
minutes
seconds
1/100
sec.
Note: Stopwatch/chronograph has 1 hour capacity, it will cycle
over after 1 hour and keep running restarting from 00:00:00.
Page 9
1514
Care for your Bertucci™field watch:Water resistance:
1 Never wear the watch unless the crown (setting knob) is completely screwed down. Do
not overtighten crown.
2 We recommend rinsing your watch and band with fresh water after exposure to salt
water, chlorinated pools, hot tubs, whirlpools, chemicals or soil loads.
3 Never adjust crown (setting knob) when watch is wet or submerged in water.
4 Keep watch clean and free of debris, especially around the crown area.
Use mild soap and a soft brush to clean, keep crown (setting knob) screwed down
when cleaning.
5 If leather band is submerged in water for an extended time period, allow it to air dry.
6 Replace band if excessively worn (see page 5).
7 If watch has stopped bring it to a local jeweler or a professional watch service shop
for battery replacement (see page 20).
8 Do not expose your watch to intense magnetic fields such as loudspeakers and
other electromagnetic devices.
9 When setting your watch, handle the crown (setting knob) gently as this is a
precision device.
10 Do not subject your watch to severe impact.
Your Bertucci™watch has been carefully designed and tested to be used in water.
The case material, screw down crown, and case back are premium features to
improve water resistance performance. Bertucci watches are engineered to
withstand water pressure to 160 P.S.I.A (equals immersion to 100 meters or 328
feet below sea level) if crown (setting knob) is screwed down.
1 Never adjust crown (setting knob) when watch is wet or submerged in water.
2 Never wear the watch unless the crown (setting knob) is completely screwed
down. Don’t forget to tighten crown (setting knob) down after setting time as
water will leak and damage movement.
3 The watch is water resistant only as long as crystal, crown and case
are intact and undamaged.
4 Your Bertucci
™
watch has been designed to be worn during activities in which
the watch will be exposed to water and submersion in water. However, the watch
is not a professional diver watch and should not be used for diving.
5 Do not operate push buttons (if equipped with) when watch submerged
in water.
Page 10
1716
Warranty information:
Every Bertucci™watch is carefully designed, manufactured and inspected to
ensure it meets our Promise Of Performance
™
to you. This is backed up by a 3
year warranty on the watch head and 1 year on the band. If defective, please
return to the dealer or send to us for warranty replacement.
In the event of a malfunction, please follow these steps (for band only, go to
directly to Step 4 .
Step 1 Determine whether the watch is in warranty. If the watch is in warranty,
please follow the remaining steps. If it is NOT in warranty, please refer to
the Refurbishment Section (pg. 18).
Step 2 Determine whether the watch has been overly abused. If not overly
abused, please follow the remaining steps. If the watch IS overly abused
(for example, crown is not screwed down and watch is water damaged, or
there is visual evidence of high impact to case or crystal), please refer to
the Refurbishment Section (pg. 18).
Step 3 Please have the battery checked by a local jeweler or professional watch
service shop. Most malfunctions are simply battery related. If the battery
is good, and watch is still not functioning correctly, please follow next
Step 4. If battery is bad, please refer to Battery Replacement Section
(pg. 20).
Step 4 Please return the defective watch or band to the dealer or send to us for
exchange. Please send a note explaining the malfunction or use the
Warranty Coupon (available on our web site: www.bertucciwatches.com)
Please contact us with any questions at 866-672-6442 / 866-524-7877 or
email us at [email protected].
Return note with defective watch to include: name and address, phone number,
description of watch (ex. A-2T nylon) and description of malfunction.
Send the malfunctioning watch to:
MH Bertucci, Inc – Warranty Dept.
P.O. Box 377
Metropolis, IL 62960 USA
Page 11
1918
Out of Warranty Refurbishment Program:
Should the watch be out of warranty (more than 3 years old), damaged severely,
deemed overly abused, or water damaged as a result of not screwing the crown
down, we offer our refurbishment program. The way it works is as follows:
1 Send us the out of warranty or damaged watch head to the below address.
Just the watch head, keep your band.
2 Include a note or use the Refurbishment form (available at our web site:
www.bertucciwatches.com) advising nature of the problem (if known).
3 The note should also include your name, return address and phone
number (see refurbishment form).
4 Check or money order made out to MH Bertucci, Inc. in the amount based on
the refurbishment pricing, on page 19.
5 We will send out a fully refurbished watch to your shipping address.
6 The refurbished watch includes:
• refurbished, recertified, and cleaned watch head.
• new band • new battery • 1 year warranty
7 The refurbished watch sent back may include some minor or cosmetic
scratches to the case only.You may not get back your exact watch.
Send your watch to:
MH Bertucci, Inc – Refurbishment Dept.
P.O. Box 377
Metropolis, IL 62960 USA
A-1S – $48
A-2S, M-1S – $54
A-2T, M-1SE (w/EL light) – $60
A-2TE, B-1TE, D-1TE (w/EL light) – $82
A-2TC Field Combo – $82
A-2T Vintage, High Polish – $85
A-3T, B-1T, C-1T, D-1T – $85
A-2T (w/10 year Li Battery) – $90
A-3T (w/sub second) – $90
A-4T – $90
G-1T Durato – $115
Tritium light styles – $190
Refurbishment Pricing: (add $9 for shipping)
Page 12
20
Battery information:
Bertucci™watches use common batteries that are readily available. The case
back is engraved with the model/case and battery type. Batteries should be
replaced by a local jeweler or professional watch service for a moderate price.
Do not attempt to remove the case back as it requires a special tool and skills.
Proper replacement of batteries is critical to ensure the long life of your
Bertucci™field watch. Actual battery life may vary based on environmental
factors and usage pattern. Replacement battery brands may have different
battery numbers, check battery equivalency reference.
Estimated Battery Life:
A-1S, A-2S, M-1S, A-2T – 3 year
A-2TE, B-1TE, D-1TE, M-1SE (w/EL light), – 2 year
A-2TC Field Combo – 2 year
A-2T Vintage, A-2T High Polish, – 5 year
A-3T, A-4T, B-1T, C-1T, D-1T – 5 year
A-3T Vintage (w/sub second) – 2 year
G-1T Durato – 5 year
Lithium battery equipped styles – 10 year
Thank you for your purchase of a Bertucci™Performance Field
Watch.
™
You’ve made an excellent choice. You’ll be pleased
with your Bertucci
™
watch for years to come.
Thank You!
Send responses to: [email protected]
In The Field With Bertucci
™
We would like to hear from you,
so please let us know your stories,
testimonials, or experiences you’ve
had using your Bertucci™field watch.
Please let us know of any questions
or comments you may have.
Page 13
Please retain this owners manual for future reference. rev.5
Contact Information:
866-672-6442 • 866-524-7877
www.bertucciwatches.com
© 2010 MH BERTUCCI, INC.
ALL RIGHTS RESERVED
PRINTED IN THE U.S.A.
8
contains post
consumer material
Loading...
