Page 1
Professional all-terrain garden tractors
nr.
31
09/2024
GB
Product information
GARDENTRACTORS
MULCHER
Sturdy and reliable, professional all-terrain garden tractors are suitable for large areas up to
9,000 m². They are designed for clearing and tidying overgrown areas with thick vegetation
and on uneven and sloping ground where pick-up is not required.
These garden tractors are equipped with various devices to facilitate the work of the operator,
such as hydrostatic transmission with lever or pedal operation for control of travel direction
and speed, the self-locking dierential and the cutter drive electromagnetic clutch. Cruise
Control is standard on all models, operated using a lever, and enables the garden tractor to
maintain a constant travel speed while working.
92 PRO 4x4 - 4x2
< 9000 m
2
Page 2
Performance and engineering solutions
—
1
2
The standard twin-cylinder engines guarantee
reliability and high performance in terms of torque
and power delivery in all working conditions, even
the most demanding.
—
The pedal-operated differential lock system
and 4-wheel drive (4x4 version) can overcome any
difficulty on any type of terrain.
—
3
4
The hydrostatic transmission provides
by means of a simple lever action and easily adapts the
speed to any type of application and terrain, even on
steep slopes (up to 22°).
—
Electromagnetic clutch, activated by means of
the switch located on the side of the steering wheel,
enables the blade to be operated independently of the
tractor’s ground speed, but only if the driver is seated (a
microswitch located under the seat detects the driver’s
presence).
—
Underbody blade with floating tips, extremely
resistant to wear, slices through even the most
stubborn vegetation (reeds, shrubs…) and has a
cutting diameter of 92 cm.
propulsion
2 — Product information —
Page 3
Comfort and ease of use
—
1
2
Centralised cutting height adjustment (6
positions from 5–12 cm) by means of control lever
located to the left of the operator (a).
—
Anatomical and adjustable seat, proximity to
the steering wheel can be adjusted by means of the
dedicated lever (b).
—
LCD display shows all service info and alerts
the operator whenever scheduled maintenance is
required, so that the machine is always running at
peak efficiency.
a b
—
3
4
Tank cap with level indicator tells the operator at
a glance how much fuel is left in the tank.
—
The front and rear bumpers and the folding roll
bar assure excellent protection and safety.
—
Access to the engine compartment is greatly
simplified by the hinged bonnet (a), as well as by
the front hatch of the battery compartment, which
can be removed by loosening the knob (b).
a b
3 — Product information —
Page 4
MODEL MULCHER 92 PRO 4x2 MULCHER 92 PRO 4x4
DISPLACEMENT 627 cm³ - 708 cm³ 708 cm³ - 726 cm³
ENGINE B&S Vanguard V-Twin - Emak K 2400 AVD V-Twin Emak K 2400 AVD V-Twin - Kawasaki FS 651
CUTTING WIDTH/NO. OF BLADES 92 cm/1 (with 2 oating blades)
TRANSMISSION (REAR/FRONT) Hydro Tu Torq K62 M Hydro Tu Torq K664 - Kanzaki KXH 10N
SPEED from 0 to 9.0 km/h in forward drive- from 0 to 6.0 km/h in reverse
TURNING RADIUS 115 cm 76 cm
MAXIMUM CLIMBING ABILITY 22°
FUEL TANK CAPACITY 19 L
LIGHTS LED + Daytime running lights
MULCHING KIT Optional
TOWING HITCH Optional
CRUISE CONTROL Yes (by means of lever)
CUTTING HEIGHT 50-100 mm, 5 positions + transfer position 120mm
DIMENSIONS 219x103x145 cm
WEIGHT 322 kg 349 kg
It’s an Emak S.p.A. trademark
42011 Bagnolo in Piano (RE) Italy
mybertolini.com
