Bertazzoni KG30X Specifications

KG30X

30" WALL MOUNT - GLASS FRONT HOOD

Complete your Bertazzoni kitchen with this modern and powerful range hood.

Choose among 3 extraction airflow speed with booster function, reaching a maximum flow performance of 600 CFM (cubic feet per minute).

Reduce airflow down to 300 CFMs with the digital flowthrough restrictor.

Easily control all the hood functions with ease using the touch-through-glass user interface.

Enjoy powerful illumination of the cooking surface with the long lasting and bright LED lights which also don’t create additional heat and are energy efficient.

Filter out odors and grease with the stainless steel mesh filters which can be easily cleaned periodically in the dishwasher or by hand.

This hood includes a telescopic duct cover reaching up to 9' high ceilings. Use the optional extension 901562 for taller ceilings.

The hood comes standard for venting outside the kitchen but, can be easily modified for recirculation by installing the optional charcoal filter kit.

PRODUCT FEATURES

Size

30''





Hood type

Wall mount





Hood finish

Black glass + stainless steel frame





Motor

1





Speed

3 + Booster





Hood control

Touch





Lights

2 LED





Filters type

Stainless steel mesh





Extraction power

600 CFM





Sound Level (min)

42 db(A)





Recirculation

Yes





Duct cover

Included





Duct size

6'' diameter



TECHNICAL SPECIFICATIONS





Electrical supply

120 V 60 HZ - 422.2 W

3.5 Amp







Power connection

Hardwired





Certification

UL





Warranty

2 years parts & labor







W 38 1/2''

Packaging dimensions and

H 23 1/32''

weight

D 22 1/16''



52.91 lbs





OPTIONAL ACCESSORIES







901486

Charcoal filters





901562

Duct Cover Installation up to 10'





901271

Recirculation Kit





Designed with pride by Bertazzoni in Italy.

Industry leading 2 years parts and labor warranty.

version: 4

bertazzoni.com
