8
ø10
3.3
Technical Data
Plastic bodied limit switch
Series I88
Description I88-SU1Z RIWKT NORM SW Article number 6186167273
Operating symbol
18.5
10
21
16
30.5
Operating diagram
4.3
20
22
31
62
M20x1.5
Tolerance:
Operating point ± 0,25 mm;
ON OFF
Electrical Data
Rated insulation voltage U
Conv. thermal current I
Rated operational voltage U
Utilization category AC-15, U
Direct opening action
Operating force ± 10 %
�
250 V AC
i
10 A
the
240 V
e
240 V / 3 A
e/Ie
acc. to IEC/EN 60947-5-1, annex K
Short-circuit protective device Fuse 2 A gG
Protection class II, totally insulated
BERNSTEIN AG . Hans-Bernstein-Straße 1 . 32457 Porta Westfalica . www.bernstein.eu
Technical modifications and errors excepted.
The technical datasheet corresponds to the technical state as of 2016-05-12 and will not be removed in case of changes.
Page 1 of 2
6186167273 / 2270-16
