product sheet
6768803512
Socket outlet insert with earthing pin and hinged cover surface-mounted/flush-mounted with enhanced
touch protection, Berker W.1, polar white matt
Technical features
Architecture
- 2pole + earth
Main electrical features
6768803512
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- with hinged cover that falls back, manual clip-in
- Complete housing
Materials
RAL colour RAL 9010 - Pure white
Colour of design line polar white
Colour white
Colour polarwhite
Material thermoplastic
Surface appearance matt
Installation, mounting
- for screw fastening
Connection
- with plug-in terminals
Use
- with enhanced touch protection
Safety
IK protection code against mecanical impacts 05
Enhanced contact protection (child protection) according to IEC 60884-1
Enhanced contact protection (child protection) according to VDE 0620-1
- Enhanced contact protection
Use conditions
Operating temperature -40 … 30 °C
Storage/transport temperature -50 … 50 °C
Identification
Main design line Berker W.1
Technical subject to change
product sheet
6768803512
Instructions
- Hinged cover springs made of stainless steel, pins of quick-release lock made of ZAMAK
- Inserts will only reach the degree of protection IP55 if mounted with a housing surface mounted or
frame for flush-mounted installation.
