product sheet
6768766074
6768766074
Socket outlet with earthing pin with enhanced touch protection, Berker Q.1/Q.3/Q.7/Q.9
Technical features
Architecture
- 2pole + earth
Main electrical features
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- Central cover plate
Materials
RAL colour RAL 9006 - White aluminium
Colour aluminium optics
Colour aluminium
Material duroplastic
Surface appearance velvety
Dimensions
Mirror depth 14,5 mm
Installation, mounting
- for screw fastening
Connection
Connection terminals according to IEC 60884-1
Use
- with enhanced touch protection
Safety
IK protection code against mecanical impacts 05
- without enhanced contact protection
Identification
Main design line Berker Q.1/Q.3/Q.7/Q.9
Secondary design line(s) Berker Q.3, Berker Q.1
Powered by TCPDF (www.tcpdf.org)
Technical subject to change
