product sheet
6768761606
6768761606
Socket outlet with earthing pin with enhanced touch protection, Berker S.1/B.3/B.7, anthracite, matt
Technical features
Architecture
- 2pole + earth
Main electrical features
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- Central cover plate
Materials
RAL colour RAL 7021 - Black grey
Colour of design line anthracite
Colour anthracite charcoal grey
Colour anthracite
Material thermoplastic
Surface appearance matt
Dimensions
Insertion depth 32 mm
Mirror depth 14,5 mm
Installation, mounting
- with spreader claws
Connection
Connection terminals according to IEC 60884-1
- with plug-in terminals
Use
- with enhanced touch protection
Safety
IK protection code against mecanical impacts 05
Enhanced contact protection (child protection) according to IEC 60884-1
- Enhanced contact protection
Identification
Powered by TCPDF (www.tcpdf.org)
Main design line Berker S.1/B.3/B.7
Secondary design line(s) Berker B.7
Technical subject to change
