product sheet
6765096084
Socket outlet with earth contact pin and monitoring LED with enhanced touch protection, Screw-in lift
terminals, Berker Q.1/Q.3/Q.7/Q.9
Technical features
Architecture
- 2pole + earth
Main electrical features
6765096084
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- Central cover plate
Materials
RAL colour RAL 9006 - White aluminium
Colour of design line aluminium
Colour aluminium optics
Colour aluminium
Material / workmanship lacquered
Material thermoplastic
Surface appearance velvety
Dimensions
Insertion depth 32 mm
Installation, mounting
- with spreader claws
Connection
Connection terminals according to IEC 60884-1
- with screw-in lift terminals
Use
- with enhanced touch protection
- Screw-in lift terminals
Safety
IK protection code against mecanical impacts 02
Enhanced contact protection (child protection) according to IEC 60884-1
- Enhanced contact protection
Identification
Main design line Berker Q.1/Q.3/Q.7/Q.9
Secondary design line(s) Berker Q.1, Berker Q.3
