Page 1
product sheet
50413515
Push-button insert, NO contact with rocker surface-mounted/flush-mounted with labelling field illuminated, Berker W.1, grey matt
Technical features
Architecture
Type of control unit rocker
Main electrical features
50413515
Nominal voltage 250 V
Rated voltage 250 V AC
Electric current
Momentary-contact current 10 A
Materials
RAL colour RAL 7011 - Iron grey
Colour of design line grey
Colour dark grey
Colour iron grey
Material thermoplastic
Surface appearance matt
Dimensions
Depth 42 mm
Height 71 mm
Width 71 mm
Labelling field (W x H) 50 x 16 mm
Installation, mounting
- for screw fastening
Connection
- Wago clip-in 3-wire connection terminal for wiring
- with N-terminal
- with plug-in terminals
Cable
- with cable entry at top and bottom
Equipment
- with {\b blue} 230 V LED unit
Use
- with labelling field - illuminated
Safety
Protection index IP IP55
Technical subject to change
Page 2
product sheet
50413515
Use conditions
Operating temperature -40 … 30 °C
Storage/transport temperature -50 … 50 °C
Identification
Application, usage Surface-mounted wet-room installation
Main design line Berker W.1
Instructions
- Pins of quick-release lock made of ZAMAK
- For labelling with name, information notice, etc.
- Labelling field height arranged for P-touch strips 12 mm.
- Inserts will only reach the degree of protection IP55 if mounted with a housing surface mounted or
frame for flush-mounted installation.
