product sheet
47903512
Combination series switch/SCHUKO socket outlet with hinged cover surface-mounted Berker W.1, polar
white matt
Technical features
Main electrical features
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
47903512
Electric current
Switching current 10 AX
Cover, door
- with hinged cover that falls back, manual clip-in
- Complete housing
Materials
RAL colour RAL 9010 - Pure white
Colour of design line polar white
Colour white
Colour polarwhite
Material thermoplastic
Surface appearance matt
Dimensions
Contact spacing > 3 mm
Installation, mounting
- for vertical mounting
- for screw fastening
Connection
Connection terminals according to VDE 0620-1
- with Wago clip-in 2-wire connection terminal for wiring
- with two clip-in places for Wago 2-wire connection terminals in the housing floor
- with plug-in terminals
Cable
- with one entry for 2 cables and one entry for cable and tube
Equipment
- with full-face sealing on the rear side of housing for cable entry and surface adjustment on the backside
- series switch and socket outlet connectable separately
Safety
Protection index IP IP55
- without enhanced contact protection
Technical subject to change
Page 2
product sheet
47903512
Use conditions
Operating temperature -40 … 30 °C
Identification
Application, usage Surface-mounted wet-room installation
Main design line Berker W.1
Instructions
- Hinged cover springs made of stainless steel, pins of quick-release lock made of ZAMAK
