Page 1
product sheet
47893525
SCHUKO socket outlet 2gang horizontal with hinged cover surface-mounted with labelling field, Locks differing lockings, enhanced contact protection, Berker W.1
Technical features
Architecture
Technical version 4 cable entries
Main electrical features
47893525
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- with hinged cover that falls back, manual clip-in
- Complete housing
Materials
RAL colour RAL 7011 - Iron grey
Colour of design line grey/light grey
Colour dark grey
Colour iron grey
Material thermoplastic
Surface appearance matt
Dimensions
Height 76 mm
Width 147 mm
Labelling field (W x H) 50 x 16 mm
Installation, mounting
- for horizontal mounting
- for screw fastening
Connection
Connection terminals according to IEC 60884-1
- with two clip-in places for Wago 2-wire connection terminals in the housing floor
- with Wago clip-in 2-wire connection terminal for wiring
- with plug-in terminals
Cable
- 2 additional side cable entries
- with one entry for 2 cables and one entry for cable and tube
Equipment
- with full-face sealing on the rear side of housing for cable entry and surface adjustment on the backside
Use
- with labelling field
- Locks - differing lockings
- enhanced contact protection
Technical subject to change
Page 2
product sheet
47893525
Safety
Protection index IP IP55
- Enhanced contact protection
- with 4 identical keys
Use conditions
Operating temperature -40 … 30 °C
Storage/transport temperature -50 … 50 °C
Identification
Application, usage Surface-mounted wet-room installation
Main design line Berker W.1
Instructions
- Hinged cover springs made of stainless steel, pins of quick-release lock made of ZAMAK
- Spare keys and other closures (max. 24) on request.
- As a result of the side cable entries specially suited for installation over workbenches.
- Housing screws, hinged cover springs made of stainless steel.
- Labelling field height arranged for P-touch strips 12 mm.
- The upper and lower entry for cables are laterally offset and therefore particularly suitable for mounting
beside door frame or the like
- The locks of an article do have identical lockings.
When ordering several articles those do usually have differing lockings.
