product sheet
47511909
47511909
SCHUKO socket outlet with hinged cover Berker S.1/B.3/B.7, polar white matt
Technical features
Architecture
Design according to DIN 49440
Main electrical features
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- when opening hinged cover, it can be arrested in end position
- Central cover plate
Materials
RAL colour RAL 9010 - Pure white
Colour of design line polar white
Colour white
Colour polarwhite
Material thermoplastic
Surface appearance matt
Installation, mounting
- mounting orientation of insert selectable in 45? steps
- with spreader claws
Connection
Connection terminals according to IEC 60884-1
Connection terminals according to VDE 0620-1
- with plug-in terminals
Safety
Protection index IP IP20
IK protection code against mecanical impacts 05
- without enhanced contact protection
Identification
Main design line Berker S.1/B.3/B.7
Secondary design line(s) Berker B.7, Berker S.1, Berker B.3
Instructions
- Specially suited for combining several socket outlets if right angle plugs are used.
