product sheet
47506003
47506003
SCHUKO socket outlet with labelling field, Berker Q.1/Q.3/Q.7/Q.9, green velvety
Technical features
Architecture
Design according to DIN 49440
Main electrical features
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- Central cover plate
Materials
RAL colour RAL 6029 - Mint green
Design lines special colours green
Colour green
Colour green
Material duroplastic
Surface appearance velvety
Dimensions
Insertion depth 32 mm
Installation, mounting
- with spreader claws
Connection
Connection terminals according to IEC 60884-1
Connection terminals according to VDE 0620-1
- with plug-in terminals
Use
- with labelling field
Safety
Protection index IP IP20
IK protection code against mecanical impacts 02
- without enhanced contact protection
Identification
Main design line Berker Q.1/Q.3/Q.7/Q.9
Secondary design line(s) Berker Q.3, Berker Q.1
Technical subject to change
product sheet
47506003
Instructions
- Insert colour-coded. 1140.
Labelling field height designed for 6 mm P-touch strips.
