product sheet
47501902
47501902
SCHUKO socket outlet with labelling field, Berker S.1/B.3/B.7, red matt
Technical features
Architecture
Design according to DIN 49440
Main electrical features
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- Central cover plate
Materials
RAL colour RAL 3003 - Ruby red
Design lines special colours red
Colour red
Colour red
Material thermoplastic
Surface appearance matt
Dimensions
Insertion depth 32 mm
Installation, mounting
- with spreader claws
Connection
Connection terminals according to IEC 60884-1
Connection terminals according to VDE 0620-1
- with plug-in terminals
Use
- with labelling field
Safety
Protection index IP IP20
IK protection code against mecanical impacts 05
- without enhanced contact protection
Identification
Main design line Berker S.1/B.3/B.7
Secondary design line(s) Berker B.3, Berker S.1, Berker B.7
Technical subject to change
product sheet
47501902
Instructions
- Insert colour-coded. 1140.
Labelling field height designed for 6 mm P-touch strips.
