product sheet
47436039
47436039
SCHUKO socket outlet with "SV" imprint in green Berker Q.1/Q.3/Q.7/Q.9, polar white velvety
Technical features
Architecture
Design according to DIN 49440
Technical version Imprint "SV" in green
Main electrical features
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- Central cover plate
Materials
RAL colour RAL 9010 - Pure white
Colour of design line polar white
Colour white
Colour polarwhite
Material duroplastic
Surface appearance velvety
Installation, mounting
- with spreader claws
Connection
Connection terminals according to IEC 60884-1
Connection terminals according to VDE 0620-1
- with plug-in terminals
Safety
Protection index IP IP20
IK protection code against mecanical impacts 02
- without enhanced contact protection
Identification
Powered by TCPDF (www.tcpdf.org)
Main design line Berker Q.1/Q.3/Q.7/Q.9
Secondary design line(s) Berker Q.1, Berker Q.3
Instructions
- Insert colour-coded.
Technical subject to change
