product sheet
47403521
SCHUKO socket outlet with red hinged cover surface-mounted with labelling field, with screw-in lift
terminals, Berker W.1, grey/light grey matt
Technical features
Architecture
Design according to DIN 49440
Main electrical features
47403521
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- with hinged cover that falls back, manual clip-in
- Complete housing
Materials
RAL colour RAL 7011 - Iron grey
Colour of design line grey/light grey
Colour dark grey
Colour light grey
Material thermoplastic
Surface appearance matt
Installation, mounting
- for screw fastening
Connection
Connection terminals according to IEC 60884-1
Connection terminals according to VDE 0620-1
- with Wago clip-in 2-wire connection terminal for wiring
- with two clip-in places for Wago 2-wire connection terminals in the housing floor
- with plug-in terminals
Cable
- with one entry for 2 cables and one entry for cable and tube
Equipment
- with full-face sealing on the rear side of housing for cable entry and surface adjustment on the backside
Use
- with labelling field
- with screw-in lift terminals
Safety
Protection index IP IP55
IK protection code against mecanical impacts 05
- without enhanced contact protection
Technical subject to change
product sheet
47403521
Use conditions
Operating temperature -40 … 30 °C
Storage/transport temperature -50 … 50 °C
Identification
Application, usage Surface-mounted wet-room installation
Main design line Berker W.1
Instructions
- Hinged cover springs made of stainless steel, pins of quick-release lock made of ZAMAK
