product sheet
47292045
47292045
Double SCHUKO socket outlet with cover plate enhanced contact protection, Berker R.1, black glossy
Technical features
Architecture
Design according to DIN 49440
Main electrical features
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- Full cover plate
Materials
RAL colour RAL 9005 - Jet black
Colour of design line black
Colour deep black
Colour black
Material thermoplastic
Surface appearance glossy
Dimensions
Assembling height 22 mm
Installation, mounting
For installation in 1gang wall boxes according to DIN 49073-1
- with spreader claws
Connection
Connection terminals according to IEC 60884-1
Connection terminals according to VDE 0620-1
- with plug-in terminals
Use
- enhanced contact protection
Safety
Protection index IP IP20
IK protection code against mecanical impacts 05
Enhanced contact protection (child protection) according to IEC 60884-1
Enhanced contact protection (child protection) according to VDE 0620-1
- Enhanced contact protection
Powered by TCPDF (www.tcpdf.org)
Identification
Main design line Berker R.1
Technical subject to change
