product sheet
47272045
47272045
SCHUKO socket outlet 45° Berker R.1/R.3/R.8, black glossy
Technical features
Architecture
Design according to DIN 49440
Main electrical features
Nominal voltage 250 V
Rated current 16 A
Rated voltage 250 V AC
Cover, door
- Central cover plate
Materials
RAL colour RAL 9005 - Jet black
Colour of design line black
Colour of labelling 217,217,217
Colour deep black
Colour black
Material thermoplastic
Material for printing PC-PMA black
Surface appearance glossy
Dimensions
Insertion depth 32 mm
Installation, mounting
- for diagonal insertion
- with spreader claws
Connection
Connection terminals according to IEC 60884-1
Connection terminals according to VDE 0620-1
- with plug-in terminals
Settings
Shading parameter R1_czarny
Laser parameter R1_schwarz
Equipment
Type of configuration Laserdruck
Safety
Protection index IP IP20
IK protection code against mecanical impacts 05
- without enhanced contact protection
Technical subject to change
Page 2
product sheet
47272045
Identification
Main design line Berker R.1/R.3/R.8
Secondary design line(s) Berker R.1, Berker R.3
Instructions
- Specially suited for combining several socket outlets if right angle plugs are used.
